Elkay WGA5 1C Series Installation manual

97059C (REV. A - 4/98)
WGA5, 10*1C
PAGE 1
Installation/Care/Use Manual
USES HFC-134A REFRIGERANT
FIG. 1
SEE FIG. 3
SEE FIG.4 7
12
28
13
26 & 27
21, 22,
23, & 24
25
31 & 32
20
14 & 15
29
16, 17,
18, & 19

97059C (REV. A - 4/98)
WGA5, 10*1C
PAGE 2
40" (1016mm) RECOMMENDED HEIGHT FOR ADULTS ALTURA RECOMENDADA PARALOS ADULTOS 40" (1016 mm) HAUTEUR RECOMMANDÉE POUR LES ADULTES 40" (1016mm)
33" (838mm) RECOMMENDED HEIGHT FOR CHILDREN ALTURA RECOMENDADA PARA LOS NIÑOS 33" (838 mm) HAUTEUR RECOMMANDÉE POUR LES ENFANTS 33" (838mm)
FIG. 2
FINISHED FLOOR PISO ACABADO PLANCHER FINI
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGURE UNA VENTILACIÓN ADECUADA MANTENIENDO UN ESPACIO E 4" (102mm) (MÍN.) DE HOLGURA ENTRE LA REJILLA DE VENTILACIÓN DEL MUEBLE Y LA PARED ASSUREZ-VOUS UNE BONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LES ÉVENTS DE LENCEINTE ET LE MUR.
F = POWER CORD 1-1/2' (457mm) LONG
CABLE ELÉCTRICO DE 1-1/2' (457mm) DE LARGO CORDON DALIMENTATION 1-1/2' (457mm)
G = ALT. ELECTRICAL OUTLET LOCATION
UBICACIÓN ALT. DE LA TOMA DE ELECTRICIDAD EMPLACEMENTALTERNATIF DE LA PRISE DE COURANT
H = 5/16" (8mm) SCREW HOLES IN MOUNTING PLATE
AGUJEROS DE TORNILLO 5/16" (8mm) EN LA PLACADE MONTAJE TROUS DE VIS 5/16" (8mm) DANS LA PLAQUE DE MONTAGE
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB OUT 1-1/2 IN. (38mm)
FROM WALL SHUT OFF BY OTHERS
SE RECOMIENDA UBICAR ELTUBO CORTO DE CONEXIÓN AL TUBO DE COBRE SIN CHAPAR DE 3/8" DE DIÁM. EXT. A 1-1/2"
(38 mm) FUERA DE LA LLAVE DE PASO EN LA PARED COLOCADA POR TERCEROS.
EMPLACEMENT RECOMMANDÉ D'ALIMENTATION EN EAU PAR TUBE EN CUIVRE NON PLAQUÉ DE 3/8 PO. (9,5 mm) D.E.
CONNECTANT UNE TUYAUTERIE DE 1-1/2 PO. (38 mm) DEPUIS LE ROBINET D'ARRÊT FOURNI PAR D'AUTRES.
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN
UBICACIÓN RECOMENDADA PARA EL DRENAJE DE SALIDA DE AGUA, DE 1¼ DE DIÁMETRO. EMPLACEMENT RECOMMANDÉ POUR LE DRAIN DE D.E. 1-1/4" DE SORTIE DEAU.
C = 1-1/4 TRAP NOT FURNISHED
PURGADOR DE 1¼ NO PROPORCIONADO SIPHON 1-1/4 NON FOURNI
D = ELECTRICAL OUTLET LOCATION
UBICACIÓN DE LA TOMA DE ELECTRICIDAD EMPLACEMENT DE LA PRISE DE COURANT

97059C (REV. A - 4/98)
WGA5, 10*1C
PAGE 3
FIG. 4
FIG. 3
Stream height is factory set at 35 PSI. If supply pressure varies
greatly from this, remove items 1 & 2 and adjust screw on item 4.
Clockwise adjustment will raise stream and counter-clockwise
adjustment will lower stream. For best adjustment, stream should
hit basin approximately 6-1/2" (165mm) from bubbler.
BASIN
ESTANQUE
BASSIN
1
2
3
4
5
6
9
10
33
10
11
8

97059C (REV. A - 4/98)
WGA5, 10*1C
PAGE 4
ELKAY MANUFACTURING COMPANY  2222 CAMDEN COURT  OAK BROOK, IL 60523  630.574.8484
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
PRINTED IN U.S.A.
PARTS LIST 115V
ITEM NO. PARTNO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21*
22
23
24
25
26
27
28
29
30
31
32
33
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY, REPLACE
WITH SAME COMPRESSOR USED IN ORIGINALASSEMBLY.
NOTE: All correspondence pertaining to any of the above water cool-
ers or orders for repair parts MUST include Model No. and Serial No. of
cooler, name and part number of replacement part.
RIGHT
PANEL
FRONT
PANEL
LEFT
PANEL
COLOR
TABLE
Gray Beige
Stainless Steel
Sandalwood
20646C
20648C
21466C
20647C
20649C
21467C
20684C
20681C
21456C
Cover
Button
Regulator Retaining Nut
Regulator
Hex Nut
Regulator Holder
Basin
Bubbler Assy
Orifice Assy
Bubbler Washer
Bubbler Nipple
Cold Control
Power Cord
Condenser (5 GPH)
Condenser (10 GPH)
Fan Shroud
Fan Motor
Fan Blade
Fan Bracket
Fan Blade Nut
Drier (5 GPH)
Drier (10 GPH)
Compressor Serv. Pak 5 GPH
Compressor Serv. Pak 10 GPH
Overload/Relay Assy (5 GPH)
Overload/Relay Assy (10 GPH)
Relay Cover
Electrical Shield
Strainer
Precooler
Tailpipe Helix
Heat Exchanger (5 GPH)
Heat Exchanger (10 GPH)
Evaporator
Receptor-Drain
Evaporator Retaining Clip
Evaporator Drain Plug
Washer
40089C
40048C
15005C
61313C
40169C
50986C
20776C
45314C
40322C
100322740560
10079C
31513C
31502C
61012C
61013C
21516C
31490C
30664C
20239C
70018C
66201C
66202C
35787C
35762C
31034C
31027C
35766C
194243901550
55996C
45678C
55909C
66255C
66229C
66427C
50368C
70767C
70772C
70046C
