EM2GO FW101 User manual

Model: FW101
USER MANUAL
Thank you for purchasing our EM2GO product . For optimum performance
and safety please read these instructions carefully before operating the
product. Please keep this manual for future reference.

1. General Information
2. Product Overview
2.1 Introduction
2.2 What you need to know
3. Product Description
3.1 Unfolding
3.2 Assembly
3.3 Folding
3.4 How to adjust height of extension pole
4. How to ride
5. SCOOTER SAFETY PRECAUTIONS
6. Weight and Speed Limitations
6.1 Weight Restrictions
6.2 Speed Limits
7. Operating Range
8. Battery Information and Specications
9. Charging your scooter
10. Inspection, Maintenance, and Storage
11. Scooter Specications
12. Thank you
13. Warranty
CATALOG

1. General Information
01
Front Wheel
Motor
Kickstand
Charging port
Deck
Rear Brake
Vibration Light
( Please Remove the protection foil)
Folding Latch
Lock buckle
Handle
Display
LED Light
Accelerator Electric Brake

2. Product Overview
3. Product Description
02
2.1 Introduction
2.2 What you need to know
The E-Scooter can be assembled within 2 minutes:
The enclosed Allen key is used to adjust the brake
and manual accelerator pedal.
To do this, turn it counterclockwise, set the desired
position and turn it clockwise.
Install the Handlebars and tighten the handles.
Before Installing the handles, please
make sure to differentiate the
left & right handles carefully.
Please mind the difference between
the left and right handle that you
can see in the images below.
L
L
R
R
3.2 Assembly
Pull up the spring loaded tube out of its socket
of the folding latch to unlock the front pole.
Now you can push it down until the tube locks
into the bottom latch into the folded position..
The E-Scooter can be folded within a matter
of seconds.
3.3 Folding
You can unfold the E-Scooter easily within a
matter of seconds.
Pull up the spring loaded tube out of its socket
of the folding latch to unlock the front pole.
Now you can push it up until the tube locks into
the top latch into the unfolded position.
3.1 Unfolding
Before you first experience your E-Scooter, please read the USER MANUAL thoroughly and learn the basics to ensure your safety and the safety of others.
The power will be shut down if nobody operate in five minutes, you need press power button before you ride.
The EM2GO E-Scooter is an intuitive, technologically advanced solution. Using the latest technology and production processes, each scooter undergoes strict
testing for quality and durability. With its lightweight, portable design, ease of use, range, and low carbon footprint.
Failure to follow the basic instructions and safety precautions listed in the USER MANUAL, can lead to damage to your scooter, other property damage,
serious bodily injury,and even death.
WARNING
Screw

03
3.4 How to adjust height of extension pole
1. Open the lock buckle of extension pole. 2. Press down height-limit button (the metal bead in hole of
extension pole), and pull extension pole to the length(3 levels
of height for option) to t the riders height. When the bead goes
into the hole, the height is xed.
3. Close the lock buckle.
lock buckle
Height-limit button
In order to tighten or loosen the folding tube or to increase the stability of the front pole,
gently adjust the screw as shown in the picture.
The extensive height is prohibited to exceed the first upper Limit hole.
Limit ball must be perfectly placed into the limit hole when the extensive height is finalized. Before riding you must fasten the lock buckle first.
Any operation violating the instructions above may result in accidents due to the loose front pole.
Screw

04
4.1 How to ride
4. How to ride
1. Turn on the E-Scooter by pressing the power button
for 2 seconds and check the battery power level.
Power key
3. Turn o the scooter by holding the power button when
you are done riding.
2. In order to let the electronic motor accelerate, push yourself of the ground a few times to
reach the minimum speed and hold down the accelerator paddle to accelerate.
You can control your speed by easing up on the accelerator. If you come to a complete halt
you have to push yourself o again.
Power key
Warning: If the E-Scooter has an electric brake and a rear physical break, the
electric brake is to be used first and the rear break only as auxiliary brake,
in case of the electric brake not working properly or is not sufficient.
Do not use the rear brake excessively, as it could damage the tire or fender.
Warning: Accidents could occur during practice. Make sure to wear an appropriate helmet and protectors during
riding. E-Scooter is not suitable for people under 14 Years!
The quoted regulations pertain to gerrman law. Please inquire about your countries/states legislations.

05
You can choose 3 lighting modes by pressing the button.
4.2 Display description
4.3 Light description
Speed level +
Power key
Switch display mode
Display mode: ODO, VOL, TIME, DIS, RPM
Speed level: 1--Max 5km/h
2--Max 15km/h
3--Max 23km/h
Speed level -
Km/h
TIME
Battery power
Selected speed level
Speed (Km/h)
Display mode (TIME)
Using time
Km/h
km
DIS
Battery power
Selected speed level
Speed (Km/h)
Display mode (DIS)
Single distance (km)
Km/h
RPM
Battery power
Selected speed level
Speed (Km/h)
Display mode (RPM)
Motor speed
Km/h
km
ODO
Battery power
Selected speed level
Speed (Km/h)
Display mode (ODO)
Total mileage (km)
Km/h
VOL
Battery power
Selected speed level
Speed (Km/h)
Display mode (VOL)
Battery voltage (V)
1. Press the button to switch on, the LED ashes with
short intervals.
2. Pressing again, the LED ashes with longer intervals.
3. Press the button again to activate the permanent
lighting.
4. Press the button the fourth time to turn o the light.

06
5. E-SCOOTER SAFETY PRECAUTIONS
Failure to follow any of the following safety precautions can and may lead to damage to your E-Scooter, void your manufacturer warranty, lead to property damage,
cause serious bodily injury, and can lead to death.
1. Please wear all appropriate safety and protective gear as previously mentioned in the User Manual before operating the E-Scooter.
2. Make sure to wear comfortable clothes and at closed toe shoes when operating your E-Scooter.
3. Please carefully read the User Manual, which will assist in explaining the basic working principles and provide tips on how to best enjoy your E-Scooter
experience.
4. Do not try to open or modify your E-Scooter, as doing so will void your manufacturer warranty, and may cause failure to your device leading to serious bodily
injury or death.
5. Do not use the E-Scooter to place yourself or anyone else and their property in danger.
6. Do not operate the E-Scooter while under the inuence of drugs and/or alcohol.
7. Do not operate the E-Scooter when you are restless or sleepy.
8. Use your best judgment to keep yourself out of dangerous situations with your E-Scooter.
9. Do not ride your E-Scooter o of curbs, ramps, or attempt to operate in a skate park, empty pool, or in any ways similar to a skateboard or E-Scooter.
THE E-SCOOTER IS NOT A SKATEBOARD.
10. Do not turn sharply, especially at high speeds.
11. Do not abuse your E-Scooter, doing so can damage your unit and cause failure to the operating system leading to injury.
12. Do not drive in or near puddles of water, mud, sand, stones, gravel, debris or near rough and rugged terrain.
13. The E-Scooter can be used on paved roads that are at and even. If you encounter uneven pavement, please lift your E-Scooter over and past the obstruction.
14. Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads or in extreme heat.
15. Do not ride in or near pools or other large bodies of water.
16. For Bumps and Uneven pavement-Bend your knees when riding on bumpy or uneven pavement to absorb the shock and vibration and help you keep your
balance. If you are unsure if you can safely ride on a specic terrain, step o and carry your scooter. ALWAYS ERR ON THE SIDE OF CAUTION.
17. Do not attempt to ride over bumps or objects greater then 1.5 cm even when prepared and bending your knees.
18. PAY ATTENTION - look at where you are riding and be cognoscente of the road conditions, people, places, property and objects around you.
19. Do not operate the E-Scooter in crowded areas. Please pay attention on riding of E-Scooter in Public road and it´s regulations.
20. Operate your E-Scooter with extreme caution when indoors, especially around people, property, and narrow spaces like doorways and other narrow spaces.
21. Operate your E-Scooter with extreme consideration for people and property at all times.
22. Do not operate the E-Scooter while talking, texting, or looking at your phone.
23. Do not ride your E-Scooter where it is not permitted.
24. Do not ride your E-Scooter near motor vehicles or on public roads.
25. Do not climb or travel down steep hills with your E-Scooter.

07
Maximum Weight: 90 kg.
6.1 Weight Restrictions
6.3 E-Scooters must be equipped with front and rear lights, bell
and reflectors.
Maximum Speed: 20 km/h
6.2 Speed Limits
PLEASE NOTICE
Speed and weight limits are set for your own safety. Please do not exceed the
limits listed in the User Manual.
6. Weight and Speed Limitations
7. Operating Range
26. The E-Scooteris intended for use by a single individual, DO NOT attempt to
operate the scooter with two or more people.
27. Do not carry anything while reding the E-Scooter.
28. Individuals with lack of balance should not attempt to operate the
E-Scooter.
29. Women who are pregnant or who may become pregnant should not
operate the E-Scooter.
30. Young children under 14 Years and the elderly should not operate the
scooter without proper instruction and supervision from a Certied
scooter trainer.
31. At higher speeds, always take into consideration longer stopping distances.
32. Do not step forward o your E-Scooter.
33. Do not attempt to jump on or o your E-Scooter.
34. Do not attempt any stunts or tricks with your E-Scooter.
35. Do not ride the E-Scooter in dark or poorly lit areas.
36. Do not ride the E-Scooter near or over potholes, cracks or uneven pavement.
37. Do not operate yout E-Scooter o-road.
38. Do not exceed the maximum or minimum weight limits.
39. Avoid driving the E-Scooter in unsafe places, including near areas with
ammable gas, steam, liquid, dust, ber, which could cause re and
explosion accidents.
40. Please Contact your insurance, if and under what conditions your E-Scooter
insures.
Please notice the E-Scooter can travel a distance of 8-10km on a fully charged
battery in ideal conditions. The following are some of the major factors that will
aect the operating range of your scooter.
Terrain: A smooth, at surface will increase your driving distance, while driving
uphill, as well as rough or uneven terrain will reduce your distance signicantly.
Weight: The weight of the user can aect driving distance, a lighter user will
have further range than a heavier user.
Ambient temperature: Please ride and store the E-Scooter under recommended
temperatures, which will increase driving distance; battery life, and overall
performance of your scooter.
Maintenance: Reasonable battery charging and maintenance will increase the
distance. Overcharging the battery can reduce range.
Speed and Driving Style: Maintaining a moderate speed will increase your
distance; while travelling at high speeds for extended periods, frequent starts,
stops, idling, along with frequent acceleration and deceleration will reduce
your overall distance.
8. Battery Information and Specifications
This section is intended to provide you basic information about your battery
and charger. Please read this section carefully to ensure you. For user safety
and to prolong the life of your battery, as well as improve battery
performance, please follow these instructions.
When the battery indicator shows lowbattery capacity, please charge your
battery 3 hours utilizing the charger that you received in your scooter package.
To fully recharge your battery please follow the instructions under
“Charging your E-Scooter”.

Battery Lithium Battery
6 months
-20 ℃- 25 ℃
5 % -95 %
0 ℃- 40 ℃
-15 ℃- 50 ℃
3 hours
25.2 V
Charging time
Voltage
Initial Capacity
Working Temperature
Charging Temperature
Storage Time
Storage Temperature
Storage Humidity
4400 mAh
08
8.1 Weight Restrictions
Battery Specifications
BATTERY WARING
9. Charging your E-Scooter
Failure to follow the Safety Precautions listed in the Battery Warning could
lead to serious bodily injury and death. Seek immediate medical attention if
you are exposed to any substance that is emitted from the battery.
• Do not attempt to modify, change, or replace your battery.
• Do not use your scooter if the battery begins to emit odor, overheats, or
begins to leak.
• Do not touch any leaking materials, or breathe fumes emitted.
• Do not allow children and animals to touch the battery.
• The battery contains dangerous substances, do not open the battery, or
insert anything into the battery.
• Please only use the charger provided by scooter.
• Do not attempt to charge the scooter if the battery has discharged or
emitted any substances. In that case, the battery should be abandoned for
safety.
• Please follow all local, state and federal laws in regards to recycling,
handling and disposing of Lithium Ion batteries. Batteries contain harmful
substances that have a negative impact on health and the environment.
• The E-Scooter should only be shipped in its original packaging.
• Do not throw away your box as you need you E-Scooter packaging for future use.
Step 1: Ensure that the charging port is clean and dry.
Step 2: Plug the charger into the cable socket, then connect the cable with the
power supply (100V～240V; 50,60Hz), make sure the light on the charger
is lit GREEN.
Step 3: Male DC connector plug into the charging port ofthe E-Scooter. The
indicator light on the charger should change to RED, indicating that your
E-Scooter is now, being charged. When the RED indicator light on your
charger turns to GREEN then your E-Scooter is fully charged. A full charge
typically occurs within 3 hours.
Step 4: Please unplug the charger from your E-Scooter and from the power outlet.
IMPORTANT NOTES ABOUT CHARGING
If the green light on your charger does not turn RED when you plug it tinto your
E-Scooter, it could mean you have to check the cables to ensure you have a
proper connection; or that your scooter is already fully chaged. Push and hold
your power button next to the charging port to check the status of your battery
in the display.
• Do not overcharge, as this will affect the life of the battery.
• Batteries should be charged at least once every 3 months.
• The best charging temperatures are between 0°~40°. Extreme cold and
extreme heat will prevent your battery from charging fully.
• Make sure to unplug your charger before standing on or operating your
E-Scooter, as this can be very dangerous.
• Use only the E-Scooter charger that you received in your box.
• If the scooter is powered on when you enter the plug, the Battery Indicator will
begin blinking, if the E-Scooter is powered off when you enter the plug,
the Battery Indicator will not blink.

09
10. Inspection, Maintenance, and Storage
11. Scooter Specifications
12. Thank you
Your E-Scooter requires routine inspection and maintenance. This chapter
describes maintenance steps and important operating tips. Before you perform
the following operations, ensure the power and charging cable is disconnected.
Inspecting and Cleaning your scooter
Disconnect the charger and turn o your E-Scooter.
Routinely check the body of the E-Scooter and tires for damage or excessive
wear. Avoid using water or other liquids and cleaners on the scooter for
cleaning. Wet a clean cloth with clean soapy water, rinse the cloth thoroughly,
and wipe the body of the E-Scooter making sure that water does not get into
the power button, charging port, the foot mats, or tires. Children are not
allowed to clean the E-Scooter without supervision.
Storing your E-Scooter
Fully charge your battery before storing.
If you are storing your scooter for an extended period of time, please fully
charge your E-Scooter at least once every three month.
If the ambient temperature of the storage location is below 0°, please do not
charge. You must bring the scooter into a warmer environment before
charging. Check under Battery Information and Specications for more details.
To prevent dust from getting into your E-Scooter, try wrapping it or sealing it
with its original packaging.
Store your E-Scooter indoors, in a dry and suitable temperature.
• Net Weight: 7.6 kg
• Load: 90 kg
• Max. Speed Limit: 20 km/h
• Range: 8-10 km
• Max. Climbing Limit: 20 degree
• Battery: Lithium-ion, 4.4 Ah, 25.2 V
• Power Requirement: AC 100-240V / 50-60Hz
• Size (fold): 81 x 42 x 29 cm
• Size (unfold): 90 x 42 x (92-102) cm
• Platform Height: 90mm
• Tire: solid tire
NOTE
NOTE
Only the indicator light on the charger will tell you the status of the battery
during charging.
Users who disassemble the scooter will forfeit their right of warranty.
Thank you for the purchase of your new E-Scooter, and thank for taking the
time to read the User Manual. We hope that the information that you obtained
from this manual will help you safely operate, maintain and enjoy your
E-Scooter for years to come. Thank you and welcome to the E-Scooter
movement! Enjoy your E-Scooter.
13. Warranty
Operation, care and maintenance instructions given in the user manual must
be adhered to. The guarantee is local and can only be claimed in the country of
invoicing. The manufacturer gives a guarantee of 24 months from the date of
sale to the end user. The warranty is valid only for defects that are due to
material or manufacturing appear. Wear parts and materials used for service are
excluded from the warranty.

D-Parts Mobilphon & Zubehör GmbH
Birkenweiher Str. 16
63505 Langenselbold
Germany
Tel. ; [phone]
E-Mail: [email protected]
Service: [e-mail]
