emaux NT-UV Series User manual

Nano Tech UV-C
DISINFECTION SYSTEM
A NON-CHEMICAL APPRORACH TO WATER SANITIZATION
For above-ground and residential pools water disinfection
EMUV21081846
USER MANUAL
EMAUX WATER TECHNOLOGY CO., LTD
ADDRESS FLAT A-D, 20/F., KAI BO 22, 22 WING KIN ROAD,
KWAI CHUNG, HONG KONG
PHONE [phone]
STRIVE FOR CLEAR WATER
www.emauxgroup.com
Model: NT-UV Series

TABLE OF
CONTENT
SAFETY WARNINGS
INTRODUCTION
2.1. HOW ULTRAVIOLET DISINFECTION WORK?
2.2. HOW OZONE DISINFECTION WORK?
4.1 WATER CHEMISTRY
5.1 PLUMBING INSTALLATION
5.2 TYPICAL INSTALLATION
5.3 INSTALLATION OPTIONS
5.4 NT-UV130F AND NT-UV130-TF WITH FLOW SWITCH INSTALLATION
5.5 NANO-TECH UV-C OZONE SYSTEM
4.2 DIMENSIONS
MAIN ADVANTAGES
INSTALLATION
TECHNICAL SPECIFICATIONS
START UP
OPERATION
7.1 DIGITAL TIMER*
7.2 UV LAMP LIFETIME METER
7.3 CLOCK SETTING
7.4 SCHEDULE TIMER SETTING
7.5 FLOW SWITCH*
MAINTENANCE
START UP
LAMP AND QUARTZ GLASS MAINTENANCE AND REPLACEMENT
ELECTRICAL UNIT REPLACEMENT
11.1 ELECTRICAL WIRING
11.2 CONTROLLER PCB
11.3 BALLAST CONNECTION
11.4 GROUNDING
11.5 LAMP SOCKET
TROUBLE SHOOTING
SPARE PART LIST
PAGE
....2.
....1.
....7.
....8.
....9.
....10.
２
３
....3.
....4.
....5.
４
５
６
....6.
１１
１１
....11.
....12.
....13.
１５
１９
２０
TERMS OF THE WARRANTY
....14.
２５
１３
１４
１５
P1 CONTENT
Nano Tech
NANO TECH UV-C

SAFETY WARNINGS P2
This installation and operation include important guide to installer and users. It must be installed and serviced
by qualified Pool and SPA technician in accordance with corresponding electrical and piping code. It is
recommend to have owner and operator to keep this manual for further reference.
IMPORTANT: The instruction manual you are holding includes essential information on the
safety measures to be implemented for installation and start-up of this appliance.
Therefore, the installer as well as the user must read the instructions before beginning
installation and start-up. Keep this manual for future reference.
This device is intended for swimming pool sand spas only; do not use it for potable water sanitation (drinking
water).
The system must be connected only to a supply circuit that is protected by a Ground Fault Circuit Interrupter
(GFCI), otherwise could result in electrical shock causing serious bodily injuries, including death.
The following safety instructions have to be taken into consideration when installing or using this ultraviolet
disinfection system:
1. Disconnect all power supplies during installation.
2. Do not operate the ultraviolet system if the power supply lead is damaged.
3. Replace damaged cords immediately.
4. To avoid possible electrical shock, special care should be taken keeping all connections dry and off the ground.
Do not touch the plug with wet hands.
5. For each of the following situations, do not attempt to repair the appliance on your own; return it to an auth
rized service facility for revision:
5.1 If the appliance falls into the water, DO NOT reach for it! First unplug it and then retrieve it. If electric
components of the appliance get wet, unplug the appliance immediately.
6. Do not operate this UV-C system if the cord or plug is damaged, if it is not operating properly after a fall or
other wise caused damage.
7. Never look at the UV lamp directly while it is operating, as it may cause eye injury, burns, or even blindness.
8. Lamps and quartz sleeves are extremely delicate. Care should be taken when handling or replacing these
components:
8.1 Wear cotton gloves when handling lamps or sleeves.
8.2 Hold bulbs by the ends only and never touch the glass with bare hands, since it would leave dirt which
would reduceit working life.
8.3 If any fingerprint is left, clean it with alcohol.
9. Allow the ultraviolet lamps to cool before handling.
10. Make sure that the nut, the washer and the O-Ring are correctly positioned, otherwise the quartz sleeves
could be expelled from their holder at speed and injure you.
11. Special safety warning must be taken into conside ration for the model Nano-Tech UV-C Ozone NT-UV87-TO:
11.1 The UV lamp generates ozone that emits a strong odour, even in very small quantities, and can be harmful
for eyes, nose and skin.
12. Check the system for any leakage. A proper installation and the correct position of the sealing rings are of
crucial importance.
1. SAFETY WARNINGS
WARNING:
P25 TERMS OFTHE WARRANTY
14. TERMS OFTHE WARRANTY
As originalpurchaser of this equipment have purchased fromEmaux Water Technology Co Ltd, through
Authorized International Distributor or Dealer, warrants its productsfree fromdefects in materials and
workmanship under normal use during warranty period. The warranty period begins on the day of purchase and
extendsonly to the originalpurchaser. It is not transferable to anyone who subsequently purchases the product
fromyou. It excludesall expendable parts.
During the warranty period, Emaux authorized reseller will repair or replace defective partswith new partsor,
at the option of Emaux, serviceable used partsthat are equivalent or superior to new parts in performance.
This Limited Warranty extendsonly to productspurchased fromEmaux authorized reseller. This Limited
Warranty doesnot extend to any product that hasbeen damaged or rendered defective (a) asa result of
accident, misuse or abuse;
(b) asa result of an act of God;
(c) by operation outside the usage parameters stated herein;
(d) by the use of partsnot manufactured or sold by Emaux;
(e) by modification of the product;
(f) asa result of war or terrorist attack; or
(g) asa result of service by anyone other than Emaux authorized reseller or authorized agent.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, EMAUX MAKES NO OTHER WARRANTIES EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES ORMERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. EMAUX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITEDTO THE TERMS OFTHIS EXPRESS LIMITED
WARRANTY.
Correct disposal of this product
This symbol on the product, or in its packaging, indicates that this product
may not be treated as household waste. Instead, it should be taken to the
appropriate waste collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by the inappropriate waste
handling of this product. For more detailed information about the recycling
of this product, please contact your local council, your household waste
disposal service, or the shop where you purchased the product.

P3 INTRODUCTION
2. INTRODUCTION
Ozone and UV-C are the two most efficient disinfection processes in water treatment. By mixing these two
concepts in one unique equipment you will keep your swimming pool water always fresh, crystal clear and to
tally disinfected, reducing the use of chlorine to a minimum.
2.1 HOW ULTRAVIOLET DISINFECTION WORK
Ultraviolet technology is a non-chemical approach to disinfection. In this method of disinfection, nothing is
added which makes this process simple, inexpensive and requires very low maintenance. UV-C light is becoming
increasingly favored by the pool industry as its ability to break down and remove chloramines, which will cause
eye, skin and nose irritation, and breathing difficulties.
UV-C light at a particular wavelength 253.7nm is a very powerful germicide. It deactivates the DNA of bacteria,
viruses and other pathogens and thus destroys their ability to multiply and cause disease.
UV dose of 30mJ/cmis sufficient for disinfection of the water and protection against 99.9% chlorine-resistant
micro organisms.
2.2 HOW OZONE DISINFECTION WORK
Emaux has developed a special model which combines the ozone and UV-C technology in one unique equipment
(see technical specifications for NT-UV87-TO).
Nano-Tech UV-C & Ozone (NT-UV87-TO model) contains a high intensity Ultraviolet lamp different from the
other UV models. This special lamp emits two separates wavelengths within the UV spectrum: 254nm and 185nm.
While the 254nm wave deactivates the DNA of bacteria, viruses and other pathogens, the 185 nm wave is
responsible for converting the oxygen contained in the quartz sleeve area into ozone.
Gamma
Rays
X-Rays
Irradiation
Energy (eV)
Wavelength (NM)
Wavelength (NM)
10
100 200 300 400 500 600 700 800
10101010
10
10
10
10
10
10
10
10
10
10
10
10
10
10󰂊
10󰂊
10󰂊
10󰂊
10󰂊
10󰂊
UV Visible Light
10󰂊10󰂊10󰂊
Infrared
Microwaves
Radiowaves
SPARE PART LISTP24
NT-UV130-F & NT-UV130-TF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
1
2
1
2
2
1
2
4
2
2
2
2
2
2
1
1
1
1
1
1
1
1
1
1
E130423
111040015
E130429
440420156
111030020
103025330
E190201
620125430
6200060156
111142482
430221017
111142482
1304565458
430170986
620145462
E130404
E130413
E130412
E130407
114145332
E130434
620135460
430170635
105021259
End cap for cable hole with epoxy
Lamp connector O'ring
130W UV lamp
31 Lamp adaptor

130W Quartz tube D31x 915mm
Pipe connection 2''
Adaptor
31 Cross
Connector O'ring
Transparent lid

Body connection
Union nut
Stainless steel body
Closed pipe clips
UV130-F ballast
UV130-TF ballast
Earth connection
Flow switch
Flow switch union kit
Cap
Union nut 1.5''
Plug lead
Key No. Part No. Description QTY
20
2
3
4
5
6
89 8 10 11
12
13
14
15
1
7
16
17
21
22
16
17
1
19
18
23
23

P23 SPARE PART LIST
NT-UV87-TO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
1
2
2
1
2
2
4
2
2
2
2
2
1
1
2
1
1
1
1
1
1
1
E130424
111040015
E130428
440422251
111030021
103025489
430221017
111142482
620125430
620061857
E190201
111202472
1304565458
430170986
105004779
620145462
E130404
E130402
E130407
620135467
430170635
108275466
105021259
E130403
End cap for double hole with epoxy
Lamp connector O'ring
87W UV lamp
25 Lamp adaptor
Quartz O'ring ( d24.8 x ф5.2 )
87W Quartz tube D25 x 910mm
Transparent lid
Connector O'ring
Adaptor
25 Cross
Pipe connection 2''
UV body O'ring ( D76 x ф6 )
Body connection
Union nut
Cable
Stainless steel body
Closed pipe clips
UV87-TO ballast
Earth connection
Air hole cap
Union nut 1.5''
Gas nozzle
Plug lead
Oxidation set
Key No. Part No. Description QTY
2
3
4
5
6
89 10 11
12
13
14
16
1
17
20
7
21
18
17
18
9
22
24
19
15
23
21
MAIN ADVANTAGES P4
The ozone produced is introduced into the water streamby Venturieffect.
Finally, the Ozone and the ultraviolet radiation will work together to destroy micro-organism such as moulds,
Legionella bacteria, parasites, algae or viruses, and also breaks down urine, transpiration, cosmetics and sun
creamparticles without leaving any by-products(Figure 1).
Figure 1
PUMP
OUT
Ozone UV-C lamp
Ozone
Water
Air + 20% oxygen
Air + Ozone (O₃)
Air + Ozone (O₃) with hydoxide
Ozone (O₃)
UV-C
3. MAIN ADVANTAGES
Ultraviolet advantages
1. Protectsyour poolagainst pathogenic organism and algae
2. Environmentally friendly
3. No risk of allergies
4. Non-irritating to skin
5. Corrosion and Odour-free
6. Reduceschlorine consumption up to 85%
7. UV-C low pressure lamp life of 9000 hours, Amalgam lamp life of 12000 hours
8. The device indicateswhen the lamp must be replaced (only models with timer)
9. Housing with mirror polished Stainless Steel AISI-316L that increases the UV-C radiation reflection, there by
increasing the efficiency up to 35%
10. Easy installation and maintenance

P5 TECHNICAL SPECIFICATIONS
Ozone advantages (only NT-UV87-TO)
1. Protects your pool against pathogenic organism and algae
2. Environmentally friendly
3. No risk of allergies
4. Non-irritating to skin
5. Corrosion and Odour-free
6. Reduce chlorine consumption up to 90%
7. Ozone lamp life of 10000 hours
8. The device indicates when the lamp must be replaced
9. Urine, sun cream, cosmetics and transpiration particles are broken down by Ozone
10. Low maintenance
11. Cost-saving
4. TECHNICAL SPECIFICATIONS
NT-UV16
NT-UV40
NT-UV40-T
NT-UV75
NT-UV75-T
NT-UV87-TO
NT-UV130-F
NT-UV130-TF
UV
UV
UV with timer
UV
UV with timer
UV and Ozone with timer
UV with flow switch
UV with timer and flow switch
TUV 16W 4P SE
TUV 36T5 HE 4P SE
TUV 36T5 HO 4P SE
GHO36T5VH
Amalgam UV-C lamp TUV
130W XPT SE
30
25
25
7
20
130
87
75
16
40
Main Feature
Model Max. flow
Rate(m³/h)
Input
Power (W) Type Of Uv Lamp
Power supply NT-UV40 220-240V,
50 / 60Hz
3 bar 3 bar 3 bar
10000 hours N/A N/A
IP 54 IP 54 IP 54
0.6 gram N/A N/A
N/A 9000 hours 9000 hours
N/A 12000 hours 12000 hours
1½’’/ 2’’ 1½’’/ 2’’ 1½’’/ 2’’
30 mJ/cm�30 mJ/cm�30 mJ/cm�
220-240V,
50 / 60Hz
90-270V,
50 / 60Hz
4.1 WATER CHEMISTRY
Maximum Ozone production
IP Protection
UV and Ozone lamp lifetime
Amalgam lamp lifetime
Low pressure lamp lifetime
Performance at recommended
flow rate
Connection size
Maximum working pressure
NT-UV87-TO NT-UV130F / -TF Other Models
SPARE PART LISTP22
NT-UV40T & NT-UV75T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
2
1
1
2
2
1
2
4
2
2
2
2
2
2
1
2
1
1
1
1
1
1
E130423
111040015
E130426
E130427
440422251
111030021
103025325
E190201
620125430
620061857
111142482
430221017
111202472
1304565458
430170986
620145462
E130404
E130410
E130411
E130407
620135460
430170635
105021259
End cap for cable hole with epoxy
Lamp connector O'ring
40W UV lamp
75W UV lamp
25 Lamp adaptor
Quartz O'ring ( d24.8 x ф5.2 )
40W / 75W Quartz tube D25 x 915mm
Pipe connection 2''
Adaptor
25 Cross
Connector O'ring
Transparent lid
UV body O'ring ( D76 x ф6 )
Body connection
Union nut
Stainless steel body
Closed pipe clips
UV40T ballast
UV75T ballast
Earth connection
Cap
Union nut 1.5''
Plug lead
Key No. Part No. Description QTY
2
3
4
5
6
89 8 1011
12
13
14
15
1
7
16
17
19
20
16
17
1
18
21
20

P21 SPARE PART LIST
NT-UV40 & NT-UV75
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
1
2
1
1
2
2
1
2
4
2
2
2
2
2
2
1
2
1
1
1
1
1
1
E130423
111040015
E130426
E130427
440422251
111030021
103025325
E190201
620125430
620061857
111142482
430221017
111202472
1304565458
430170986
620145462
E130404
E130408
E130409
E130407
620135460
430170635
105021259
End Cap for Cable Hole With Epoxy
Lamp connector O'ring
40W UV lamp
75W UV lamp
25 Lamp adaptor
Quartz O'ring ( d24.8 x ф5.2 )
40W/75W Quartz tube D25 x 915mm
Pipe connection 2＂
Adaptor
25Cross
Connector O'ring
Transparent lid
UV body O'ring ( D76 x ф6 )
Body connection
Union Nut
Stainless steel body
Closed pipe clips
UV40 ballast
UV75 ballast
Earth Connection
Cap
Union Nut 1.5＂
Plug lead
Key No. Part No. Description QTY
2
3
4
5
6
89 8 1011
12
13
14
15
1
7
16
17
19
20
16
17
1
18
21
20
INSTALLATION P6
4.2 DIMENSIONS
UV-16
353
353
122
580
UV40-T / UV75-T
UV40 / UV75
UV130-TF
UV130-F
UV87-TO
353
163
163
163
163
163
163 163
1012
1012 1012 1012
1012 1012
483
483 483 858
505
242
1040
483
Way 1 Way 2
Way 1 Way 2
5. INSTALLATION
Install the unit taking into consideration the access and space for servicing, and in a position where the lamp can
be taken out easily. It is important to choose your disinfection system according to the flow rate required for the
installation. If water passes through the unit too fast, the exposure time required for its maximum efficiency will
be not enough. For this reason, the ultraviolet equipment selected for your pool should correspond to the
maximum flow rate of your filtration system(pumps).
We also recommend to install the unit in a by-pass.
5.1 PLUMBING INSTALLATION
WARNING:
It is recommended to use the same power source for UV-C system and the filtration pump
such that they can be power ON / OFF simultaneously to prevent no water flow for UV-C
lamp cooling inside the stainless steelcylinder.
This UV-C disinfection system comes with all internal components assembled and it is ready
to be installed. Only pipesconnections should be made before starting up the equipment.

P7 INSTALLATION
To achieve the correct installation, please follow the recommendations listed below:
1. Never install the UV-C system in an area exposed to full sunlight. This equipment must be in stalled in a dry
and ventilated area.
2. The UV-C system must be fitted in a vertical position, and leaving a minimum space of 30cm und neathand
1.5meters at the top of the equipment for servicing and replacing the lamp.
3. The UV-C system will need to be plumbed into the swimming pool / spa / water feature circuit, always after
the filter and before pH regulator or salt electrolysis system (if any).
4. If the filtration pump exceeds the maximum flow rate allowed for the UV-C system, a by-pass circuit will be
required.
5. Fit the UV-C system with the supplied clamps in a fixed position and hand-tighten the 3 part couplings. Neve
use a wrench, tongs or other tools to tighten synthetic parts.
6. Make the UV-C connections 1½”or 2” to the circuit pipes.
7. Activate the pump and check that there is not any leakage in the circuit.
5.2 TYPICAL INSTALLATION
This water circulation system flow from water pump from swimming pool skimmer to sand filter and position the
Nano Tech UV-C lamp or ozone disinfection unit after filter and before chlorinator.
Water pH or ORP probe should be mount in front of the Ozone generator and chemical dosing, such as acid or
chlorine, after the ozone UV-C unit.
WARNING:
For UV-C and Chlorinator put together as disinfection system, the UV-C should be place
before Chlorinator.
Nano Tech, UVC products are not recommended to be used in seawater or seawater-like
environments with high salt content, as the stainless steel body will be corroded and
leaked in long term operation.
Water From Pool
SB Pump
Backwash Waste Water
MFS Sand Filter
Water To Pool
SSC-50E
Nano Tech UV-C Ozone
SPARE PART LIST P20
13.SPARE PART LIST
NT-UV16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
1
2
2
2
2
4
2
2
2
2
2
2
1
1
2
1
1
E130405
E130425
111040015
440422251
111030021
E190201
620125430
111142482
430221017
620061857
111202472
1304565458
430170986
103025322
107175310
E130404
620135460
430170635
UV16 Ballast and lamp connection
16W UV lamp
Lamp connector O' ring
25 Lamp adaptor
Quartz O' ring ( d24.8 x ф5.2 )
Pipe connection 2''
Adaptor
UV body O' ring
Transparent lid
25 Cross
Quartz O' ring ( D76 x ф6 )
Body connection
Union nut
16W Quartz tube D25 x 485mm
Stainless steel body
Closed pipe clips
Cap
Union nut 1.5''
Key No. Part No. Description QTY
1
3
4
5789
10
11
12
13
14
15
16
17
6
1
18
2
16
18

P19 TROUBLE SHOOTING
12. TROUBLE SHOOTING
Possible SolutionTrouble
Disconnect the power cord from the electrical outlet, disassemble the lamp and
verify if the lamp connector is fixed firmly in place.
Verify if the electric cable is connected into an electrified circuit. Test the electrical
circuit.
Verify that the electrical outlet where the UV-C System is plugged into has the
proper voltage and the cable is securely plugged into the outlet.
The lamp has burned out. Replace the UV lamp.
Check the chemical balance of the pool.
Check the UV-C system to make sure it is on.
Run the UV-C system and the circulation pump longer. If the UV system is operated
by a timer, increase a number of working hours.
Check all connections and sealing rings, especially those near to the UV lamp and
the quartz glass.
Check the screws on the installation, and pay attention to those vibration points
Check all connections and sealing rings, make sure that all connections are threaded
properly.
Check the quartz glass if it is broken or damaged.
Consider replacing the UV lamp. After 4500 hours of operation, the lamp efficiency
drops up to 80%. This is normal for all low- pressure type UV lamps.
Clean the air mesh for O-zone model to ensure air flow is enough.
The electrical unit has burned out. Contact your supplier for the replacement.
Check the timer setting. It can be at “OFF” schedule.
UV-C system failure, possible lamp
disconnection
The UV lamp no longer lit
Pool water is green
UV-C system makes noise when operating
Water is coming out; the UV-C system is
leaking
Make sure you have not connected the device into any power source other than
specified on the unit's label. If you have done so in error, the electrical unit might
have been damaged and should be replaced. Contact your supplier for the
replacement (Not warranted).
INSTALLATION P8
5.3 INSTALLATION OPTIONS
The dark blue transparent end cap and union set is inter changeable for all models, it can be place on either side.
It is necessary to place and tighter the O-ring properly to prevent water leakage when doing relocation. There
are two setsof 1.5” and 2” union which can be fit into imperial and metric pipe.
Transparent end cap with o-ring Union with O-ring set 1.5” and 2” union
For NT-UV16, NT-UV40, NT-UV40-T, NT-UV75 and NT-UV75-T model Lamp unit, stainless steel lamp body can be
installed in verticalor horizontalorientation.
WARNING:
For NT-UV130F, NT-UV130-TF (130W UV-C Lamp), and NT-UV87-TO (O-zone) only vertical
installation is allowed.
Mounting Options:
Instead on mounting on wall, there are two option of mounting on the ground.
1. Using the mounting base provided. 2. Using a wooden stand (not provided)

P9 INSTALLATION
5.4 NT-UV130F and NT-UV130-TF with Flow Switch installation
WARNING:
1. There is a flow direction arrow mark on the flow switch for following. Reverse the flow
direction will not switch on the UV-C lamp.
2. The flow switch connection union can adopt both imperial and metric pipe.
The flow switch version’s flow switch location is flexible to fit into the actual environment water flow direction.
It can be placed from left side or right side, and top to bottom or bottom to top flow direction.
5.5 NANO-TECH UV-C OZONE SYSTEM
1. Never install the UV-C system in an area exposed to direct sunlight.
This equipment must be installed in a dry and ventilated area.
2. The UV-C system must be fitted in a vertical position, and leaving a
minimum space of 30cm underneath and 1.5 meters at the top of
the equipment for maintenance operations and replacing the lamp.
3. The UV-C system needs to be installed always after the filter and
before pH regulator or any possible salt chlorinator or dosing
system.
4. If the filtration pump exceeds the maximum flow rate allowed for
the UV-C system, a by-pass circuit will be required.
WARNING:
To achieve the correct installation, please follow there commendations listed below:
Right Side Top Down Bottom Left Side Bottom To Top
Flow Switch
ELECTRICAL UNIT REPLACEMENT P18
11.4 GROUNDING
11.5 LAMP SOCKET
Yellow color output connect T5 lamp socket blue and brown wire with crimp
There is a ground crimp with three yellow / green wire, one is from the power cord (earth), one is to the ballast
ground terminaland one connect to the stainless steelhousing outside the ballast plastic housing.
Loss of any grounding will trigger the RCD or GFCI and stop the power when power on. It is use to protect
frompersonnelelectric socket.
Red color output connect T5 lamp socket black and yellow green wires with crimp
WARNING:
It is a T5 type lamp socket and be careful to plug the lamp in right orientation to prevent the
lamp’s connect pins broken. Don’t force the lamp pin into the lamp socket. Ensure the lamp
and socket is well connected to prevent the lamp loose and damage before insert to the
stainless steelbody.
For NT-UV87-OT O-zone model, the UV-C lamp is designed dedicate. Replacement of any
other band name model has to been consulted your dealer for confirmation. It will affect the
ballast and O-zone generation quantity.
UV-C Lamp Socket Assemble T5 Socket Cable Wiring Color Scheme 3 Pins UV-C Lamp
From Power Cord Ground
To Ballast Ground
Ground Terminal On Stainless Steel Housing

P17 ELECTRICAL UNIT REPLACEMENT
11.3 BALLAST CONNECTION
The Output L and N of the controller PCB connect to the power input of the ballast according to the pin defini-
tion Live, Neutral and Ground. The other side ballast output has four pins for UV-C lamp connection.
L,N from Control PCB Side
NT-UV40
NT-UV40-T
NT-UV75
NT-UV75-T
NT-UV130F
NT-UV130-TF
NT-UV87-TO
Ballast Wiring Type UV-C Lamp Side
NT-UV130F without Timer version, there is flow switch controller PCB
Connect Flow Switch
From Power Cord
To Ballast
Power Input
NT-UV130TF Timer version, remove the white color jumper and connect the flow switch red and black cable.
From Power Cord
To Ballast
Power Input
Connect Flow Switch
Flow Switch Red
And Black Cable
INSTALLATION P10
VENTURI INSTALLATION GUIDE
Follow the instructionsprocedure below for installing the Nano-Tech UV Ozone System:
1. Fit the manometer (A) onto the Venturicircuit using Teflon tape. Hand-tighten the manometer.
2. Insert (B) into the outlet (C), make sure that the threaded nut (D) is asthe following image displays :
3. Screw the female hose fitting (E) onto the male thread of the Venturi circuit. The other end of the hose must
be fitted into the elbow adapter, on the top of the system (F). There is a Non-Return valve (K) between (E) and
(F) which is a one direction valve to prevent air go backto the UV lamp Ozone generator.
4. Reverse the Non Return Valve will not inject Ozone to the Venturi systemand
5. Joint the 3parts(B), (D) and (L), so that the Venturicircuit and the UV systemare firmly assembled.
6. Afterwards, choose at suitable place to install the assembled system, if and when it follows the order
accoring to Section 3Typical Installation.
7. Fit the UV-C reactor with the supplied clips (H) and ensure that the 3-part couplings (B) (D) (L) are still
solilytighten. Never use a wrench, clamps or other tools whatsoever to fix the reactor.
8. The power supply wire (I) has to be connected in a way that the UV system works as the same time as the
filtrtion pump does. If not, all the UV systemcould get overheated.
Connect To Venturi (E)
Non Return Valve
Connect To Lamp Side
A
D
B
C
E
J
G
I
E
H
KL
F
9. Activate the pump, vent the whole systemand checkfor any leakage in the circuit.
10. The quality of the Ozone air in the system can be adjusted by using the manual valve (J). The closer it remains,
the more Ozone will enter the circuit. The desirable range on the manometer is 9~14 psi.
11. Keep in mind: the air filtering intake (G) on the upper part of the Ozone device is intended to absorb air for
Ozone generation. It has to remain cleared. The venturi system also can be installed in vertical orientation but
the UV-C Ozone lamp body cannot be installed in verticalorientation.

P11 START UP
Before starting up the UV-C system, perform the following actions:
1. Back wash the filter and make sure it is completely clean.
2. Make sure the pool does not contain copper, iron nor algae.
3. Check and adjust the chemical parameters of your pool or spa. The proper chemical balance is essential for
the correct UV-C system operation, and it also helps to reduce drastically the use of chemicals sanitizers.
3.1 pH: 7.2 – 7.6
3.2 Total alkalinity: 60 – 120ppm
3.3 Hardness: less than 120mg/L
3.4 Turbidity: less than 1NTU
3.5 TSS (Total suspended solids): less than 10mg/L
3.6 UV Transmittance: more than 75%.
4. Check the hydraulic connections and ensure there is no leakage.
5. Release the air from the circuit through the air relief valve in stalled on the filter (if equipped).
6. Power on the device and the UV-C lamp will light slowing and there is light come out from the transparent
cover for power on sight.
7. For Ozone model, adjust the venture tube valve to have manometer reading 9~14 psi. Use the finger to cover
air mesh to feel suction pressure is available.
6. START UP
*Available for the following models:
NT-UV40-T, NT-UV75-T, NT-UV130-TF, NT-UV87-TO.
The following three functions are available thanks to the digital timer (Figure 2):
1. UV lamp lifetime meter
2. Schedule timer
3. Clock
7. OPERATION
7.1 DIGITALTIMER*
figure 2
Bright For Lamp
On Sight Adjust The Valve
Pressure Gauge Reading Air Mesh Air
ELECTRICAL UNIT REPLACEMENT P16
RCD NEMA GFCI Receptacle
The power cord Live connect to L and Neutral to N of the PCB upper terminals. The power output of the PCB has
the same Live and Neutralcolor wire to the UV-C lamp ballast.
Don’t unwired the lower 2 position terminal white color wire. It is for with flow switch version connection to stop
the lamp when there is no water inside the piping to prevent UV-C lamp over heat without water cooling.
There is a CR2032 button size battery for timer setup memory.
11.2 CONTROLLER PCB
Australia Plug UK Plug European Plug
200-240Vac Single Phase
L
N
L
N
Ground Green / Yellow
or Green
NEMA Plug
115Vac Single Phase
NEMA 230Vac 3 phase
Wire Color Code
L1 = Black
L2 = Red
L3 = Blue
White
Green / Yellow
or Green
Green / Yellow
or Green
Black
White or
Silver
From Power Cord
To Ballast
Power Input

P15 STAINLESS STEEL HOUSING MAINTENANCE
If the electrical unit needs to be replaced, first of all the earth connection must be disconnected from the
electrical housing. The entire ballast box must be unscrewed and the earth wiring must be disconnected from
the device.
Unscrew the screw of the ballast box and carefully disconnect the lamp holder from the lamp.
All these parts must be carefully kept, as they are not supplied with the new housing or electrical unit.
WARNING: The unit has power cord with plug attached on the plug, plug
it to a power socket with a Residual Current Device (RCD) or Ground Fault
Circuit Interrupt (GFCI) having a rated residual operating current not
exceeding 30mA.
11. ELECTRICAL UNIT REPLACEMENT
11.1 ELECTRICAL WIRING
WARNING:
If the RCD / GFCI device trips, it means there is fault on the power line grounding. Do not
use this unit. Disconnect the power and have the problem corrected by a qualified service
representative before using. Press the reset button to reset the RDC / GFCI devices after
fixed. It will keeps the circuit shut off and will not reset if the power line problem is not
fixed. It is recommend to test the RCD / GFCI at least once a month.
10. STAINLESS STEEL HOUSING MAINTENANCE
The stainless steel interior can be cleaned with a soft brush. First of all, the UV-C and quartz lamps have to be
removed following the below steps:
1. Unthread the adaptor male - male 2 ½”– 2”. Remove the sight glass from the opposite side of the adaptor.
There are two more threaded adaptors inside the connections. These adaptors make the stainless steel
housing holes to be aligned with the connections and sight glass. These two adaptors are placed in the thread
of the connection and in the thread of the sight glass.
2. Unthread the main union nut from the stainless steel housing, and remove the pressuring connector from
inside the nut.
3. Remove the PVC tee connections from the stainless steel housing using a plastic hammer.
4. Remove the sealing ring from the stainless steel housing.
5. Clean stainless steel housing and then assemble the UV-C system again:
5.1 Introduce the sealing ring on the stainless steel housing.
5.2 Assemble the PVC tee connections taking into consideration that the connections must coincide with the
holes of the stainless steel housing.
5.3 Assemble again the pressuring connector and all the union nuts properly. Note that the adaptors that keep
the position of the connections aligned with the stainless steel housing have to be threaded in a specific
position so that the two holes can be used for an unscrew to help you to thread the adaptor.
OPERATION P12
As soon as the above mentioned model with Timer is switched on, the program will carry out a self-test. The
display will automatically show the following code: 8888 (display test); software version number; 50Hz or 60Hz
indication of the mains frequency.
Following this, the display will show the meter reading:
1. For the models NT-UV40-T and NT-UV75-T: When the UV-C lamp is switched on for the first time, or after the
'Reset' function has been used, the value '9000' will appear on the display. A dot next to the digit on the far
right of the display will blink every second: this indicatesthat the counter is running.
2. For the models NT-UV130-TF and NT-UV87-TO: When the UV-C lamp is switched on for the first time, or
after the 'Reset' function has been used, the value '9000' will appear on the display. A dot next to the digit on
the far right of the display will blink every second: this indicates that the counter is running. The real lifetime
of these lamps is of 12000 and 10000 hours respectively, but the display can only show 4 digits. You can adjust
the number of hours manually once 3000 hours (for NT-UV130-TF) or 1000 hours (for NT-UV87-TO) have
passed (please find the instructionsbelow).
3. If the UV-C system was used previously, once it is switched on again the display will indicate the last value
before it was switched off. If you increased or reduced the value of the meter manually, the display will indicate
the latest counter reading before it was switched off.
MANUAL ADJUSTMENT
1. Press the button ‘MENU’ and select the option ‘Hr’ by pressing ‘MENU’ again.
2. The flashing number shown on the screen will indicate the hours left for replacing the lamp.
3. Press the button ‘MENU’ to modify the hours.
3.1 Use the buttons ▲and ▼to increase or decrease the counter value in steps of 500 hours from the initial
value up to the maximum value of 9500 and the minimum of 500.
3.2 Once to the desired hour is reached, stand off for 10 seconds until it stops flashing and confirm the set
hour chosen.
7.2 UV LAMP LIFETIME METER
The time meter will indicate in the following manner that the lamp must be replaced:
1. Fromhour position 0672, the display will blink every second. The lamp is to be replaced within 4weeks.
2. Fromhour position 0336, the display will blink every half second. The lamp is to be replaced within 2weeks.
3. Fromhour position 0168, the display will blink every 1⁄4 second. The lamp is to be replaced within 1week.
4. At an hour position of 0000, the digits will blink continuously, and the meter will not continue to count down.
The lamp must be replaced.
This function allowsyou to set the clockaccording to the current time.
1. Press the button ‘MENU’ and use the buttons ▲or ▼until you reach the option ‘rest’. Press ‘MENU’ to select.
2. The hour indicator will flash. Press ▲or ▼to select the desired hour. Wait for 10 seconds until it stops flashing
to confirm the hour.
3. Press ‘MENU’ to select the minutes, and minute indicator will flash. Press ▲or ▼to select the desired value.
Wait for 10 secondsuntil it stopsflashing to confirm the settings.
7.3 CLOCK SETTING

P13 MAINTENANCE
This function allows you to schedule the working hours desired for the proper disinfection of the pool. It must
be set in every hour.
1. Press the button ‘MENU’ and use the buttons ▲ or ▼ until you reach the option ‘UV’. Press ‘MENU’ to select.
2. ‘UV00’ means midnight 00:00h; Press ▲ or ▼ to change the time from 0h to 24h. 'UV01' means 01:00am;
'UV02' means 02:00am, etc.
3. Press the button ‘MENU’ to select the hour.
4. The selected hour will be flashing. Press ▲ or ▼ to select if at this hour the device will be switchedon roff.
Wait for 10 seconds until its tops flashing and confirm the selection.
5. Press the button ‘MENU’ if you want to go back or select another hour.
Check Timer Setting
6. If the working hours has been set, follow the steps to check schedule status.
7. For example, press 'MENU' and press ▲ or ▼ until option 'UV' display,
8. Press 'MENU' and press ▼ to select 'UV05',
9. Press 'MENU' and display flashing ‘OFF’, it means switched off at this hour. If 'ON' is flashing, it mean “ON” at
this hour.
10. Press 'MENU' again and repeat the same procedure to check other hours.
*Available for the following models: NT-UV130-F, NT-UV130-TF.
These models are supplied with Amalgam UV lamp recognized as the strongest in the UV-C market.
Consequently, it is very important that the lamp works always with a minimum flow rate. For that reason, the
flow switch installed in the chamber will automatically switch the device off if no water is flowing through it.
7.4 SCHEDULE TIMER SETTING
7.5 FLOW SWITCH*
To ensure the correct operation and a long life of this UV-C system, regularly check the chemical parameters and
maintain them within the recommended range:
8. MAINTENANCE
1. pH: 7.2 –7.6
2. Total alkalinity: 60 – 120ppm
3. Hardness: less than 120mg/l
4. Turbidity: less than 1NTU
5. TSS (Total suspended solids): less than 10mg/l
6. UV Transmittance: more than75%.
7. For NT-UV87-OT O-zone model, clean the air mesh to allow enough air flow into
the system to generate O-zone.
8. For NT-UV130F or NT-UV130-TF check the flow switch is function by power off the
pump to stop water flow circulation. Check the UV-C is off from the transparent
cover.
LAMP AND QUARTZ GLASS MAINTENANCE AND REPLACEMENT P14
The device must be cleaned twice a year. If there is an increase in algae and /or scale, the quartzglass tube in
which the lamp is positioned must be cleaned using a soft cloth with spirit vinegar or acid.
The UV-C lamps must be replaced once they lifetime comes to theend. Please refer to the following table:
Always switch off the power supply when replacing the lamp. If necessary, consult the spare parts drawing during
replacement, maintenance or dismantling.
The procedure for replacing the lamp is asfollows:
1. Stop the circulation pump so that no water is flowing into the unit.
2. Allow the ultraviolet lamp to coolfor at least 30 minutes before handling.
3. Untighten the externalunion nuts, and drain the water from the device.
4. Unthread the top union nut with the cable and carefully remove the lid with the cable gland from the housing.
5. Helped by the own cable, remove the lamp from the UV-C system through the central hole in the quartzglass
holder. As these parts are very fragile, caution is essential. Do not touch the lamp with bare hands;use a soft
cloth or cotton gloves to handle the lamp. If the lamp has been touched, it is recommended to clean it again
using a soft cloth and some alcohol.
6. If the quartzglass needs cleaning or replacing, unthread the quartzglass holder and carefully remove the
quartzglass with the sealing ring. Use a soft cloth or cotton gloves to handle the quartzglass. If it has been
touched, it is recommended to clean it again using a soft cloth.
7. Introduce the cleaned or a new quartzglass. Ensure that it is introduced exactly in the initial position. Do not
forget the sealing ring on the top of the quartzglass.
8. Hand-tighten again the quartzglass holder and introduce the new lamp carefully into the quartzglass through
the same hole in the quartzglass holder.
9. Install the cable gland for water proofing to the lamp cable and thread the externalunion nuts.
9. LAMP AND QUARTZ GLASS MAINTENANCE AND REPLACEMENT
9000 hrs
10000 hrs
12000 hrs
NT-UV16
NT-UV40
NT-UV40-T
NT-UV75
NT-UV75-T
NT-UV87-TO
NT-UV130-F
NT-UV130-TF
Lamp Lifetime (Operating Hours)Model
