XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 1/7
DIGITAL CONTROLLER WITH ADVANCED
ENERGY SAVING MANAGEMENT AND
BLUETOOTH CONNECTIVITY
XRB60CHC
1GENERAL WARNINGS................................................................................................................................... 1
2GENERAL DESCRIPTION.............................................................................................................................. 1
3REGULATION.................................................................................................................................................. 1
4ENERGY REDUCTION ALGORITHM ............................................................................................................ 1
5EXTRA COOLING FUNCTION ....................................................................................................................... 2
6EVAPORATOR FANS ..................................................................................................................................... 2
7DEFROST ........................................................................................................................................................ 2
8INTERNAL COUNTERS.................................................................................................................................. 2
9FRONT PANEL COMMANDS ......................................................................................................................... 3
10 PARAMETERS ................................................................................................................................................ 3
11 DIGITAL INPUT ............................................................................................................................................... 5
12 INSTALLATION AND MOUNTING.................................................................................................................. 5
13 OPTIONAL FEATURES .................................................................................................................................. 5
14 ELECTRICAL CONNECTIONS....................................................................................................................... 5
15 USE THE HOT KEY......................................................................................................................................... 6
16 ALARM SIGNALLING ...................................................................................................................................... 6
17 TECHNICAL DATA.......................................................................................................................................... 6
18 WIRINGS.......................................................................................................................................................... 6
19 APPLICATION NOTES.................................................................................................................................... 6
20 BLUETOOTH COMMUNICATION .................................................................................................................. 6
1GENERAL WARNINGS
1.1 PLEASE READ BEFORE USING THIS MANUAL
•This manual is part of the product and should be kept near the instrument for easy and quick
reference.
•The instrument shall not be used for purposes different from those described hereunder. It cannot be
used as a safety device.
•Check the application limits before proceeding.
•Dixell Srl reserves the right to change the composition of its products, even without notice, ensuring
the same and unchanged functionality.
1.2 SAFETY PRECAUTIONS
•Check the supply voltage is correct before connecting the instrument.
•Do not expose to water or moisture: use the controller only within the operating limits avoiding sudden
temperature changes with high atmospheric humidity to prevent formation of condensation
•Warning: disconnect all electrical connections before any kind of maintenance.
•Fit the probe where it is not accessible by the End User. The instrument must not be opened.
•In case of failure or faulty operation send the instrument back to the distributor or to “Dixell S.r.l.” (see
address) with a detailed description of the fault.
•Consider the maximum current which can be applied to each relay (see Technical Data).
•Ensure that the wires for probes, loads and the power supply are separated and far enough from each
other, without crossing or intertwining.
•In case of applications in industrial environments, the use of mains filters (our mod. FT1) in parallel
with inductive loads could be useful.
2GENERAL DESCRIPTION
The XRB60CHC, 32x74x60mm format, is a microprocessor based controller suitable for applications
on medium or low temperature ventilated refrigeration units. It has 3 relay outputs to control
compressor, fans, light and defrost or auxiliary output. The device is also provided with up to 4 NTC
probe inputs: the first one for temperature control, the second one to be located onto the evaporator to
control the defrost termination temperature and to manage the fan and the third, optional and located
on the HOT-KEY port, used to control the condenser temperature. There is also a configurable digital
input. By using the HOT-KEY it is possible to program the instrument in a quick and easy way.
The controller has Bluetooth 4.2 connectivity.
3REGULATION
The regulation is performed according to
the temperature measured by the
thermostat probe with a positive
differential from the set point: if the
temperature increases and reaches set
point plus differential, the compressor will
start. The compressor will stop when the
temperature reaches the set point value
again.
In case of fault because of the thermostat probe, the start and stop of the compressor are timed
through parameters CoF and Con.
4ENERGY REDUCTION ALGORITHM
4.1 DESCRIPTION
The device permits to set different temperature to be used during normal and reduced power use. The
standard SET-POINT (SET) is used to maintain the temperature at a certain value when the energy
saving status (ES) is not active. On the other side, when the ES status is active a different SET-POINT
(SET_ES), higher than the standard one, will be used. The parameter HES will have to be set to
change the regulation temperature according to the following formula:
SET_ES = SET + HES
There are also two different differential values for SET and SET_ES, which are used for compressor
cut-in and cut-out: when ES status is active the HYE parameter will be used instead of the HY
parameter.
The device uses special Energy reduction Algorithm (ErA algorithm from Dixell) to optimize loads
activation during the day. It is possible to set two different algorithms (ErA=bAS or Aut). They differ for
the used sensor and for the total length of the interval of time involved.
4.2 BASIC ENERGY SAVING ALGORITHM –ErA=bAS
This will be used when ErA=bAS. The energy saving status will be always saved in the internal
memory to resume previous operation if a power failure occurs. It needs the presence of a door switch
to work (i1F=dor).
4.2.1 Parameter involved and suggested values:
-ErA=bAS
-i1F=dor
-StE=4.0 hours
-EtS=6.0 hours
-HES=4.0 to 5.0 °C
-HYE=3 to 4°C
-dS=5 to 10 sec
-LdE=Y
FROM
TO
CHANGED BY
Normal
mode
Energy
Saving
- Push the DOWN button for 3 sec (if enabled).
- Door continuously closed for the StE time.
Energy
Saving
Normal
mode
- Push the DOWN button for 3 sec (if enabled).
- Controller in ES mode for the EtS time.
- If the controller is in ES mode, it returns in Standard mode
(normal set-point) after opening the door more than dS time.
NOTE: the cycling mode (ES - Normal mode - ES - etc.) works if i1F=dor and EtS and StEare
different from zero. If EtS=0 or StE=0, the controller will not change the operating mode, and it will be
possible to change from the normal mode to the energy saving mode by using ES button or by setting
i1F=ES. See the below diagrams where the status changing is depicted:
4.3 AUTOMATIC ENERGY SAVING ALGORITHM
This will be used when ErA=Aut. The operations are controlled by using the Aid parameter. After
powering on the device, it automatically starts to analyze the temperature behavior by using the only
room temperature probe. In this way it can build the best energy saving model according to the
application. The device uses temperature behavior information of the previous Aid interval to manage
the loads during the current period. When Aid is set to use long periods (Aid>1), a day-by-day model
will be used during the first interval of time.
4.3.1 Parameter involved and suggested values:
-ErA=Aut
-HES= 3.0 to 5.0°C
-LdE=Y
-Aid=1 or 7
-nCE=4
-nCC=8
-Pdt=2
-HYE=3 to 4°C
-PPU=P1
-tun=depends on the regulation probe placement
NOTES:
1. In case of any blackout, the calculated energy saving model will be reset.
2. ErA can exclusively drive the light output by using the LdE parameter. When LdE=YES, the
light output status will change according to the energy saving (ES) status:
a. OFF if ES is active
b. ON if ES is not active
3. It is always possible to override the light output status by using the frontal button. Anyway, this
modification will have a temporary impact on the lights if LdE=YES. In fact, ErA will take the
control after the next ES status change.
4. ErA does not need any door switch input to work.
5. Be sure to place the room temperature probe in near the upper zone of the cabinet: this gives
the best results in terms of temperature variation analysis.
6. The Aid parameter indicates the interval of analysis as “number of days”. The suggested
values for it are 1 or 7, depending on the particular application.

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 2/7
7. When Aid=1, the first day will be used to analyze the temperature behavior and to build the
model to apply to the second day. The model will be updated every day in order to better match
the working conditions.
8. When Aid=7, the first 7 days will be used to analyze the temperature behavior and to build the
model to apply to the next 7 days. The model will be updated every 7 days in order to better
match the working conditions.
9. When Aid=7, the first 7 days after power on will use a sub analysis base on 1-day model.
10. nCE is used to define the minimum duration of an energy saving interval of time
11. nCC is used to move the SET-POINT value from normal mode value to the energy saving
mode value by steps (1 step = 1°C or 1°F, starting from the SET value and increasing it every
30 min till reaching the SET_ES value)
12. Pdt is used to anticipate the end of the energy saving mode in order to decrease the
temperature of the bottles before starting the normal mode interval
13. PPU select the probe used for automatic energy saving algorithm
14. tun is used to change the sensibility of the automatic energy saving algorithm. tun=H (high) is
used for cabinet with regulation probe installed near the evaporator air outlet flow. tun=L (low)
is used for cabinet with regulation probe installed far away from the evaporator air outlet flow.
5EXTRA COOLING FUNCTION
The extra cooling function (named Pull Down) is active when the room temperature measured from the probe
1 goes over the SET+oHt+HYvalue. In this case, a special set-point value, lower than the normal SET value,
will be enabled. As soon as the room temperature reaches the SET+CCS value, the compressor will be
stopped and the normal regulation will restart. N.B.: pull down function is disabled when CCS=0 or CCt=0.
The CCt parameter sets the maximum activation time for any pull down. When CCt expires, the pull down will
be immediately stopped and the standard SET-POINT will be restored. NOTE: in case of energy saving mode
active, the used values will be: SET_ES=SET+HES, oHE and CCS.
6EVAPORATOR FANS
With FnC parameter it can be selected the fans functioning:
•FnC=C-n fans will switch ON and OFF with the compressor and not run during defrost; when
compressor is OFF, fans will enter a duty-cycle working mode (see FoF, Fon, FF1 and Fo1
parameters).
•FnC=o-n fans will run even if the compressor is off, and not run during defrost;
•FnC=C-Y fans will switch ON and OFF with the compressor and run during defrost; when
compressor is OFF all fans will enter a duty-cycle working mode (see FoF, Fon, FF1 and Fo1
parameters).
•FnC=o-Y fans will run continuously also during defrost.
After defrost, there is a timed fan delay allowing for drip time, set by means of the Fnd parameter.
An additional parameter FStprovides the setting of temperature, detected by the evaporator probe,
above which the fans are always OFF. By using this parameter it is possible to assure air circulation
only if air temperature is lower than FSt value.
6.1 EVAPORATOR FAN AND DIGITAL INPUT
When the digital input is configured as door switch (i1F=dor), fans and compressor status will depend on the
odC parameter value:
•odC=no normal regulation
•odC=FAn evaporator fan OFF
•odC=CPr compressor OFF
•odC=F-C compressor and evaporator fan OFF
When rrd=Y the regulation will restart after a door open alarm.
7DEFROST
7.1 DEFROST MODE
Any defrost operation can be controlled in the following way:
-EdF=rtC: by using an internal real time clock (only for models equipped with RTC).
-EdF=in: timed defrost, in this case a new defrost will start as soon as the idF timer elapses.
-EdF=Aut: automatic management, in this case the controller will start a new defrost any time a
change from normal to energy saving mode will occur (valid if ErA=Aut).
7.2 TIMED OR PROBE CONTROLLED MODE
Two defrost modes are available: timed or controlled by the evaporator’s probe. A couple of
parameters is used to control the interval between defrost cycles (idF) and its maximum length (MdF).
During the defrost cycle is possible to select some different display indications by using the dFd
parameter. These modes are available with any kind of defrost type:
-tdF=EL: electric heater defrost
-tdF=in: hot gas defrost.
7.3 AUTOMATIC DURATION DETECTION
When a defrost operation is performed by compressor stop (means by stopping the compressor and by
activating the internal ventilators), it will be possible to use an automatic defrost mode by setting od2=ALt. In
this case the device will use the evaporator probe (which MUST to be present and properly mounted on the
evaporator surface) to detect the end of the actual defrost phase. In any case, a maximum period of time
(MdF) and an upper evaporator temperature value will be used to stop the current defrost phase. If ErA=Aut,
the automatic defrost mode will activate a defrost at the beginning of any energy saving mode period. In this
case the idF delay is used as safety function. It forces the controller to activate a defrost operation when idF
runs. NOTE: during the defrost phase the loads (compressor and evaporator fans) will be controlled from the
defrost algorithm.
8INTERNAL COUNTERS
The next table shows the implemented load and function of total counters.
n1H
Number of relay output 1 activation (thousands of)
n1L
Number of relay output 1 activation (hundreds of)
n2H
Number of relay output 2 activation (thousands of)
n2L
Number of relay output 2 activation (hundreds of)
n3H
Number of relay output 3 activation (thousands of)
n3L
Number of relay output 3 activation (hundreds of)
n4H
Number of relay output 4 activation (thousands of)
n4L
Number of relay output 4 activation (hundreds of)
n5H
Number of digital input 1 activation (thousands of)
n5L
Number of digital input 1 activation (hundreds of)
n6H
Number of digital input 2 activation (thousands of)
n6L
Number of digital input 2 activation (hundreds of)
oCH
Compressor working hours (thousands of)
oCL
Compressor working hours (hundreds of)
In this way it is possible to monitor the application and discovering bad functioning that could lead to damages.
They are updated in EEPROM every hour. It is not possible to reset them.
NOTE: the compressor activation counters take into account also defrost in case of inversion (hot gas) mode.
8.1 AUX RELAY CONFIGURATION (PAR. oAX)
An auxiliary relay can be set by the oAx parameters, according to the kind of application. In the
following paragraph the possible settings.
8.1.1 Light relay
With oAx=LiG the AUX relay operates as light output.
8.1.2 Auxiliary relay
a. Relay activation by digital input 1 or digital input 2 (oAx=AUS, i1F or i2F=AUS): with
oAx=AUS and i1F, i2F=AUS the AUX relay is switched on and off by digital inputs.
b. Auxiliary thermostat: anti condensing heater with the possibility of switching it on and off also
by using the frontal keyboard.
Parameters involved:
-ACH: kind of regulation for the auxiliary relay: Ht = heating; CL =cooling.
-SAA: set point for auxiliary relay.
-SHy: differential for auxiliary relay.
-ArP: probe for auxiliary relay.
-Sdd: auxiliary output off during defrost.
-Ao1: output active when in energy saving mode
-AF1: output not active when in energy saving mode
The differential threshold value is set by the SHY parameter.
NOTE:
if oAx=AUS and ArP=nP (no probe for auxiliary output) the AUX relay can be activated
-by digital input if i1F=AUS or i2F=AUS
-by auxiliary button (if set as AUS)
-by serial command (Modbus protocol)
-by fixed interval of time if Ao1>0 and AF1>0 (if Ao1=0 or AF1=0 the auxiliary output is
disabled)
8.1.3 On/off relay (oAx = onF)
When oAx=onF, the AUX relay is activated when the controller is turned on and de-activated when
the controller is turned off.
8.1.4 Neutral zone regulation
With oAx=db the AUX relay can control a heater element to perform a neutral zone action.
•oA1cut in = SET-HY
•oA1cut out = SET

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 3/7
8.1.5 Alarm relay
With oAx=ALr the AUX relay operates as alarm relay. It is activated every time an alarm happens. Its
status depends on the tbA parameter: if tbA=Y, the relay is silenced by pressing any key.
If tbA=n, the alarm relay stay on until the alarm condition recovers.
8.1.6 Activation during energy saving cycles
With oAx=HES, the AUX relay is energised when the energy saving cycle is activated.
9FRONT PANEL COMMANDS
Press to display target set point and the real set point. When in programming mode
it selects a parameter or confirms an operation
(ECO) To switch on and off the Energy Saving mode or the light output. Other
functions related to par. LGC and LG2
(UP) In programming mode it browses the parameter codes or increases the
displayed value. Other functions related to par. UPC and UP2
(DOWN) In programming mode it browses the parameter codes or decreases the
displayed value. Other functions related to the par. dnC and dn2
(ONOFF) Keep it pressed for 3 sec to switch on and off the device
KEYS COMBINATION
+
To lock or unlock the keyboard
+
To enter in programming mode
+
To return to room temperature display
ICON
MODE
MEANING
On
Compressor enabled
Flashing
Anti-short cycle delay enabled (AC parameter)
On
Light output enabled
On
Ventilator output enabled
Flashing
Ventilator delay after defrost
,
On
Measurement unit
Flashing
Programming mode
On
Energy saving mode active
On
An alarm condition is present
Flashing
Start-up operations are pending
On
Auxiliary output is activated
NOTE: start-up operations lasts about 30 sec after powering on the device. At the end of this phase,
the alarm icon will switch off if no alarm is active.
9.1 SET POINT MENU
The SET key gives access to a quick menu where it is possible to see:
-the set point value
-the real set point value (rSE)
Push and release the SET key five times or wait for 60 sec to return to normal visualisation.
9.2 CHANGE THE SETPOINT
1. Push the SET key for more than 2 sec to change the Set point value;
2. The value of the set point will be displayed and the “°C” LED starts blinking;
3. To change the Set value push the UP or DOWN button.
4. To memorise the new set point value push the SET key again or wait for 60 sec.
9.3 START A MANUAL DEFROST
Push the DEFROST button for more than 2 sec to start a manual defrost.
9.4 CHANGE A PARAMETER VALUE
To change the parameter values operate as follows:
1. Enter the Programming mode by pressing the SET+DOWN buttons for 3 sec (“°C”LED starts
blinking).
2. Select the required parameter. Press the SET button to display its value
3. Use UP or DOWN buttons to change its value.
4. Press SET to store the new value and move to the following parameter.
To exit: Press SET+UP buttons or waits for 15 sec without pressing any key.
NOTE: the set value is stored even when the procedure is exited by waiting the time-out to expire.
9.5 ENTERING THE HIDDEN MENU
The hidden menu includes all the parameters of the instrument.
ENTER THE HIDDEN MENU
1. Enter the Programming mode by pressing SET+DOWN buttons for 3 sec (“°C”or “°F”LED starts
blinking).
2. Released the keys and then push again SET+DOWN buttons for more than 7 sec. The “L2”label
will be displayed immediately followed from the HY parameter.
NOW YOU ARE IN THE HIDDEN MENU.
3. Select the required parameter.
4. Press the SET key to display its value
5. Use UP or DOWN to change its value.
6. Press SET to store the new value and move to the following parameter.
To exit: Press SET+UP or wait for 15 sec without pressing any key.
NOTE1: if there are no parameters in L1, after 3 sec the “nP” label will be displayed. Keep the keys
pushed till the “L2”message will be displayed.
NOTE2: the previous set value will be stored even if the programming mode is exited by waiting for the
time-out to expire.
MOVE PARAMETERS FROM THE HIDDEN MENU TO THE FIRST LEVEL AND VICEVERSA.
Each parameter present in the HIDDEN MENU can be removed or put into “THE FIRST LEVEL” (user
level) by pressing SET+DOWN. If a parameter is visible also in the First Level, in the HIDDEN MENU
the decimal point will be lit.
9.6 LOCK THE KEYBOARD
1. Keep both UP and DOWN buttons pressed for more than 3 sec.
2. The “oFF” label will be displayed and the keyboard will be locked. If any button is pressed more
than 3 sec, the “oFF” message will be displayed.
9.7 UNLOCK THE KEYBOARD
Keep both UP and DOWN buttons pressed together for more than 3 sec till the “on” message will be
displayed.
9.8 THE ON/OFF FUNCTION
If onF = oFF, the instrument will be switched off by pushing the ON/OFF button. The
“OFF”message will appear on the display. In this configuration the regulation is
disabled. To switch the instrument on, push again the ON/OFF button.
WARNING: any load connected to the normally closed contacts of the relays is always supplied
from the main voltage, even if the instrument is in standby mode.
10 PARAMETERS
REGULATION
Set
Regulation Set Point: LS to US
LS
Minimum SET POINT: (-55.0°C to SET; -67°F to SET) sets the minimum value for the set
point.
US
Maximum SET POINT: (SET to 150.0°C; SET to 302°F) set the maximum value for set point.
HY
Differential in normal mode (energy saving mode not active): (0.1 to 25.0°C; 1 to 45°F)
differential for set point. Compressor Cut-IN is
[SET-POINT + HY]. Compressor Cut-OUT is when the temperature reaches the set point.
HYE
Differential when energy saving mode is active: (0.1 to 25.0°C; 1 to 45°F) differential for set
point. Compressor Cut-IN is [SET-POINT + HES + HYE]. Compressor Cut-OUT is when the
temperature reaches the [SET-POINT + HES].
odS
Outputs delay activation after power on: (0 to 255 min) this function is enabled after the
power-on of the instrument and inhibits any output activation for the period of time set in the
parameter.
AC
Anti-short cycle delay: (0 to 50 min) minimum interval between a compressor stop and the
following restart.
Rtr
P1-P2 percentage for regulation: 100=P1 only; 0=P2 only
CCt
Maximum duration for pull down: (0.0 to 23h50min, res. 10min) after elapsing this interval of
time the super cooling function is immediately stopped
CCS
Differential for pull down: (-12.0 to 12.0°C; -21 to 21°F) during any super cooling phase the
regulation SETPOINT is moved to SET+CCS (in normal mode) or to SET+HES+CCS (in
energy saving mode)
oHt
Overheating before activating the pull down function (when in normal mode): (1.0 to
12.0°C; 1 to 21°F) this is the upper threshold limit used to activate the super cooling function.
oHE
Overheating before activating the pull down function (when in energy saving mode): (1.0
to 12.0°C; 1 to 21°F) this is the upper threshold limit used to activate the super cooling
function.
Con
Compressor ON time with faulty probe: (0 to 255 min) time during which the compressor is
active in case of faulty thermostat probe. With CY=0 compressor is always OFF.
CoF
Compressor OFF time with faulty probe: (0 to 255 min) time during which the compressor is
OFF in case of faulty thermostat probe. With Cn=0 compressor is always active.
PROBE SETUP
ot
Thermostat probe calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust any possible
offset of the first probe.
P2P
Evaporator probe presence: n= not present; Y= the defrost stops by temperature.

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 4/7
oE
Evaporator probe calibration: -12.0 to 12.0°C; -21 to 21°F) allows to adjust any possible
offset of the third probe.
P3P
Third probe presence: n= not present; Y= the defrost stops by temperature.
o3
Third probe calibration: -12.0 to 12.0°C; -21 to 21°F) allows to adjust any possible offset of
the third probe.
P4P
Fourth probe presence: n= not present; Y= the condenser temperature alarm is managed.
o4
Fourth probe calibration: (-12.0 to 12.0°C; -21 to 21°F) allows to adjust any possible offset of
the condenser probe.
DISPLAY
iCo
Enabling icon visualisation: (n; Y) the icons can be hidden during normal functioning
CF
Temperature measurement unit: (°C; °F) °C = Celsius; °F = Fahrenheit.
rES
Resolution (only for °C): (dE; in) dE = decimal; in = integer.
Lod
Probe displayed: (P1; P2; P3; P4; SEt; dtr; USr) Px=probe “x”; SEt=set point; dtr=do not
use it; USr=do not use it.
dLY
Temperature visualization delay: (0.0 to 20min00sec, res. 10 sec) when the temperature
increases, the display is updated of 1°C or 1°F after this time.
dtr
P1-P2 percentage for display
DEFROST
tdF
Defrost type: EL=electrical heaters; in=hot gas; ALt=uses only for compressor stop defrost.
dFP
Probe selection for defrost control: nP=no probe; P1=thermostat probe; P2=evaporator
probe; P3=third probe (do not use it); P4=Probe on Hot Key plug.
dtE
Defrost termination temperature for defrost control: (-55 to 50°C; -67 to 122°F) it sets the
temperature measured by the evaporator probe (dFP), which causes the end of defrost.
idF
Interval between two consecutive defrost cycles: (0 to 255 hours) determines the time
interval between the beginnings of two defrosting cycles.
MdF
Maximum length for defrost: (0 to 255 min; 0 means no defrost) when P2P=n (no evaporator
probe presence) it sets the defrost duration, when P2P=Y (defrost end based on evaporator
temperature) it sets the maximum length for defrost.
dSd
Start defrost delay: (0 to 255 min) delay in defrost activation.
StC
Compressor stop time before starting any defrost: (0 to 900 sec) interval with compressor
stopped before activating hot gas cycle
dFd
Display during defrost: (rt; it; SP; dF) rt = real temperature; it = start defrost temperature;
SP = SET-POINT; dF = label “dF”.
dAd
Max delay for updating display after any defrost: (0 to 255 min) delay before updating the
temperature on the display after finishing any defrost.
Fdt
Draining time: (0 to 255 min)
dPo
First defrost after start-up: (n; Y) to enable defrost at power on.
dAF
Defrost delay after freezing: (0.0 to 24h00min, res. 10 min) delay before activating a defrost.
od1
Automatic defrost (at the beginning of any energy saving mode): (n; Y) n=function
disabled; Y=function enabled
od2
Optimized defrost function: (n; Alt) n=function disabled; Alt=function enabled
FAN
FAP
Probe selection for evaporator fan management: nP=no probe; P1=thermostat probe;
P2=evaporator probe; P3=do not use it; P4=Probe on Hot Key plug.
FSt
Evaporator fan stop temperature: (-55 to 50°C; -67 to 122°F) setting of temperature,
detected by evaporator probe. Over this value of temperature fans are always OFF. NOTE: it
works only for the evaporator fan, NOT for the condenser fan.
HYF
Differential for evaporator fan: (0.1 to 25.5°C; 1 to 45°F) differential for evaporator ventilator
regulator
FnC
Evaporator fan mode operation: (Cn; on; CY; oY)
•Cn = runs with the compressor, duty-cycle when compressor is OFF (see FoF,Fon,
FF1 and Fo1 parameters) and OFF during defrost
•on = continuous mode, OFF during defrost
•CY = runs with the compressor, duty-cycle when compressor is OFF (see FoF,Fon,
FF1 and Fo1 parameters) and ON during defrost
•oY = continuous mode, ON during defrost
Fnd
Fan delay after defrost: (0 to 255 min) delay before fan activation after any defrosts.
FCt
Differential of temperature for forced activation of fans
Ft
Ventilators controlled during any defrost
Fon
Fan on time when the compressor is off: (0 to 255 min) used when energy saving status is
not active.
FoF
Fan off time when the compressor is off: (0 to 255 min) used when energy saving status is
not active.
Fo1
Fan on time with compressor off in Energy Saving mode: (0 to 255 min) used when energy
saving status is active.
FF1
Fan off time with compressor off in Energy Saving mode: (0 to 255 min) used when energy
saving status is active.
FAC
Probe selection for condenser fan management: nP=no probe; P1=probe Pb1; P2=probe
Pb2; P3=probe Pb3; P4=probe Pb4 on Hot Key plug.
St2
Condenser fan stop temperature: (-55 to 50°C; -67 to 122°F) setting of temperature,
detected by evaporator probe. Over this value of temperature fans are always OFF.
HY2
Differential for condenser fan: (0.1 to 25.5°C; 1 to 45°F) differential for evaporator ventilator
regulator
FCC
Condenser fan mode operation: (Cn; on; CY; oY)
•Cn = runs with the compressor and OFF during defrost
•on = continuous mode, OFF during defrost
•CY = runs with the compressor and ON during defrost
•oY = continuous mode, ON during defrost
AUXILIARY OUTPUT MANAGEMENT
ACH
Kind of regulation for auxiliary relay: (Ht; CL) Ht = heating; CL = cooling.
SAA
Set Point for auxiliary relay: (-55.0 to 150.0°C; -67 to 302°F) it defines the room temperature
set point to switch auxiliary relay.
SHY
Differential for auxiliary relay: (0.1 to 25.5°C; 1 to 45°F) differential for auxiliary output set
point.
•ACH=CL, AUX Cut in is [SAA+SHY]; AUX Cut out is SAA.
•ACH=Ht, AUX Cut in is [SAA–SHY]; AUX Cut out is SAA.
ArP
Probe selection for auxiliary relay: (nP; P1; P2; P3; P4) nP = no probe, the auxiliary relay is
switched only by the digital input; P1 = Probe 1 (Thermostat probe); P2 = Probe 2 (evaporator
probe); P3 = do not use it; P4 = Probe 4.
Sdd
Auxiliary relay switched off during defrost: (n; Y) n= the auxiliary relay operates during
defrost. Y= the auxiliary relay is switched off during defrost.
btA
Base Time for timed activation of auxiliary output: (SEC; Min) SEC=base time is in second
Ato
AUX output in ON state: 0 to 255 (base time defined in par. btA)
AtF
AUX output in OFF state: 0 to 255 (base time defined in par. btA)
ALARMS
ALP
Temperature alarms probe selection: (P1, P2, P3, P4)
ALC
Temperature alarms configuration: (Ab, rE) Ab = absolute; rE = relative.
ALU
Maximum temperature alarm: when this temperature is reached, the alarm is enabled after
the Ad delay time.
•If ALC=Ab ALL to 150.0°C or ALL to 302°F.
•If ALC=rE 0.0 to 50.0°C or 0 to 90°F.
ALL
Minimum temperature alarm: when this temperature is reached, the alarm is enabled after the
Ad delay time.
•If ALC=Ab -55.0°C to ALU or -67°F to ALU.
•If ALC=rE 0.0 to 50.0°C or 0 to 90°F.
AFH
Differential for temperature alarm recovery: (0.1 to 25.0°C; 1 to 45°F) differential for alarms.
ALd
Temperature alarm delay: (0 to 255 min) delay time between the detection of an alarm
condition and the relative alarm signalling.
dot
Delay of temperature alarm with door open: (0.0 to 24h00min, res. 10 min) delay time
between the detection of a temperature alarm condition and the relative alarm signalling, after
powering on the instrument.
dAo
Delay of temperature alarm at start up: (0.0 to 24h00min, res. 10 min) delay time between
the detection of a temperature alarm condition and the relative alarm signalling, after powering
on the instrument.
CONDENSER TEMPERATURE ALARM
AP2
Probe selection for second temperature alarms: (nP; P1; P2; P3; P4) nP=no probe;
P1=thermostat probe; P2=evaporator probe; P3=do not use it; P4=Probe on Hot Key plug
AU1
Second high temperature pre-alarm: (-55.0 to 150.0°C; -67 to 302°F)
AH1
Differential for second temperature pre-alarm recovery: (0.1 to 25.0°C; 1 to 45°F)
Ad1
Second temperature pre-alarm delay: (0 to 255 min; 255 = not used) delay time between the
detection of a condenser pre-alarm condition and the relative alarm signaling.
AL2
Second low temperature alarm: (-55.0 to 150.0°C; -67 to 302°F)
AU2
Second high temperature alarm: (-55.0 to 150.0°C; -67 to 302°F)
AH2
Differential for second temperature alarm recovery: (0.1 to 25.0°C; 1 to 45°F)
Ad2
Second temperature alarm delay: (0 to 255 min; 255 = not used) delay time between the
detection of a condenser alarm condition and the relative alarm signaling.
dA2
Delay for second temperature alarm at start up: (0.0 to 24h00min, res. 10 min)
bLL
Compressor off because of second low temperature alarm: (n; Y) n = no, compressor
keeps on working; Y = yes, compressor is switched off till the alarm is present, in any case
regulation restarts after AC time at minimum.
AC2
Compressor off because of second high temperature alarm: (n; Y) n = no, compressor
keeps on working; Y = yes, compressor is switched off till the alarm is present, in any case
regulation restarts after AC time at minimum.
DIGITAL OUTPUT MANAGEMENT
tbA
Alarm muting: (n; Y) to disable the (optional) buzzer and the output configured as alarm.
oA1
First relay configuration: (nu; CP1; dEF; FAn; ALr; LiG; AUS; db; onF; HES; Cnd) nu=not
used; CP1=compressor; dEF=defrost; FAn=ventilators; ALr=alarm; LiG=light; AUS=Auxiliary
relay; onF=always on with instrument on; db=neutral zone; HES=night blind; Cnd=not select it.
oA2
Second relay configuration: (nu; CP1; dEF; FAn; ALr; LiG; AUS; db; onF; HES; Cnd) nu=not
used; CP1=compressor; dEF=defrost; FAn=ventilators; ALr=alarm; LiG=light; AUS=Auxiliary
relay; onF=always on with instrument on; db=neutral zone; HES=night blind; Cnd=not select it.
oA3
Third relay configuration: (nu; CP1; dEF; FAn; ALr; LiG; AUS; db; onF; HES; Cnd) nu=not
used; CP1=compressor; dEF=defrost; FAn=ventilators; ALr=alarm; LiG=light; AUS=Auxiliary
relay; onF=always on with instrument on; db=neutral zone; HES=night blind; Cnd=not select it.
oA4
Fourth relay configuration: (nu; CP1; dEF; FAn; ALr; LiG; AUS; db; onF; HES; Cnd) nu=not
used; CP1=compressor; dEF=defrost; FAn=ventilators; ALr=alarm; LiG=light; AUS=Auxiliary
relay; onF=always on with instrument on; db=neutral zone; HES=night blind; Cnd=not select it.
AoP
Alarm relay polarity: (oP; CL) oP = alarm activated by closing the contact; CL = alarm
activated by opening the contact
DIGITAL INPUT
ibt
Base time for digital inputs: (SEC; Min) SEC = seconds; Min = minutes. Delay for activating
the function linked to the digital inputs.
i1P
Digital input 1 polarity: (oP; CL) oP = activated by closing the contact; CL = activated by
opening the contact.
i1F
Digital input 1 configuration: (nu; dor; dEF; AUS; ES; MS; EAL; bAL; PAL; HdF; onF)
•nu=not used
•dor = door switch function
•dEF = defrost activation
•AUS = auxiliary output
•ES = energy saving mode activation
•MS = motion sensor
•EAL = external warning alarm
•bAL = external lock alarm
•PAL = external pressure alarm
•HdF = holiday defrost
•onF = ON/OFF status change
Did
Digital inputs 1 alarm delay: (0 to 255) it is the delay between the detection of an external
event and the activation of the relative function.
i2P
Digital input 2 polarity (if d.i.2 present): (oP; CL) oP = activated by closing the contact; CL =
activated by opening the contact.
i2F
Digital input 2 configuration: (nu; dor; dEF; AUS; ES; MS; EAL; bAL; PAL; HdF; onF)
•nu=not used
•dor = door switch function
•dEF = defrost activation
•AUS = auxiliary output
•ES = energy saving mode activation
•MS = motion sensor
•EAL = external warning alarm
•bAL = external lock alarm
•PAL = external pressure alarm
•HdF = holiday defrost
•onF = ON/OFF status change

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 5/7
d2d
Digital inputs 2 alarm delay: (0 to 255) it is the delay between the detection of an external
event and the activation of the relative function.
nPS
Number of external pressure alarms before stopping the regulation: (0 to 15) after
reaching nPS events in the digital input alarm delay (par. dxd) the regulation will be stopped
and a manual restart (ON/OFF, power OFF and power ON) will be required
odC
Compressor and fan status after door opening: (no; FAn; CPr; F-C): no = normal;
FAn = Fans OFF; CPr= Compressor OFF; F-C = Compressor and fans OFF.
rrd
Regulation restart after door open alarm: (n; Y) n= no regulation if door is opened; Y= when
didis elapsed, regulation restarts even if a door open alarm is present.
LCi
Light output controlled by digital input: (0 to 255)
ENERGY SAVING
ErA
Energy reduction algorithm used: (nu; bAS; Aut) nu=no energy saving algorithm used;
bAS=basic energy saving algorithm; Aut=automatic energy saving algorithm.
nbo
Threshold for mode change (normal mode to energy saving mode): (0 to 10)
HES
Differential for energy saving mode: (-30.0 to 30.0°C; -54 to 54°F) it sets the increasing
value of the set point during the Energy Saving cycle.
LdE
Energy saving mode controls the lights (lights off when energy saving goes active): (n;
Y) the light status depends on the energy saving mode and is managed from ErA.
Aid
Period of analysis for ErA (valid if ErA=Aut): (1 to 20 days) set the interval of time for temperature
variation analysis.
nCA
Number of contiguous cells to activate Energy Saving (valid if ErA=Aut): (1 to 20) minimum
pattern (1 cell = 30 min) without activity for energy saving activation
nCC
Number of contiguous cells with energy saving for Set-Point variation (valid if ErA=Aut): (1 to
12) minimum interval of time for SET-POINT variation by steps (1°C or 1°F every 30 minutes)
Pdt
Automatic Pull Down after energy saving: (0 to nCC) energy saving mode is deactivated in advance
(0=0min, 1=30 min)
tun
System tuning: L=low sensibility; H=high sensibility
PPv
Temperature probe used for temperature variation analysis: (P1, P2, P3, P4) which probe is used
from Energy Reduction Algorithm
FEn
Force status change from energy saving mode to normal mode (valid if ErA=Aut): number of
intervals with activity for mode changing
FnE
Force status change from normal mode to energy saving mode (valid if ErA=Aut): number of
intervals without activity for mode changing
StE
Period of time to switch from normal mode to energy saving mode (valid if ErA=bAS):
(0.0 to 24h00min, res. 10 min) if door stay closed for StE time, the energy saving mode will be
activated. NOTE: this will require a door switch to work.
EtS
Period of time to switch from energy saving mode to normal mode (valid if ErA=bAS):
(0.0 to 24h00min, res. 10 min) maximum time for energy saving mode. NOTE: this will require a
door switch to work.
dS
Door open time to switch from EtS to StE (valid if ErA=bAS): (0 to 999 sec) the energy
saving mode will be immediately deactivated as soon as the door stay open more than the dS
time. NOTE: this will require a door switch to work.
TOTAL COUNTERS
n1H
Number of relay output 1 activations (thousands of) (read only)
n1L
Number of relay output 1 activations (hundreds of) (read only)
n2H
Number of relay output 2 activations (thousands of) (read only)
n2L
Number of relay output 2 activations (hundreds of) (read only)
n3H
Number of relay output 3 activations (hundreds of) (read only)
n3L
Number of relay output 3 activations (hundreds of) (read only)
n4H
Number of relay output 4 activations (thousands of) (read only)
n4L
Number of relay output 4 activations (hundreds of) (read only)
n5H
Number of digital input 1 activations (thousands of) (read only)
n5L
Number of digital input 1 activations (hundreds of) (read only)
n6H
Number of digital input 2 activations (thousands of) (read only)
n6L
Number of digital input 2 activations (hundreds of) (read only)
n7H
Number of digital input 3 activations (thousands of) (read only)
n7L
Number of digital input 3 activations (hundreds of) (read only)
n8H
Number of digital input 4 activations (thousands of) (read only)
n8L
Number of digital input 4 activations (hundreds of) (read only)
F1H
Number of working hours for relay output oA1 (thousands of) (read only)
F1L
Number of working hours for relay output oA1 (hundreads of) (read only)
F2H
Number of working hours for relay output oA2 (thousands of) (read only)
F2L
Number of working hours for relay output oA2 (hundreads of) (read only)
F3H
Number of working hours for relay output oA3 (thousands of) (read only)
F3L
Number of working hours for relay output oA3 (hundreads of) (read only)
F4H
Number of working hours for relay output oA4 (thousands of) (read only)
F4L
Number of working hours for relay output oA4 (hundreads of) (read only)
BLUETOOTH
rPS
Reset owner password: (n;Y) select and confirm YES for reset Owner Password and come
back to default factory configuration. NOTE: remember to cancel the device also from the Cloud
database (click on “Delete” link present on the right of the appliance card present on the
“Permissions” webpage.
OTHER
Adr
Serial address for Modbus communication: 1 to 247
bAU
Baudrate: (9.6; 19.2; 38.4; 57.6) select the correct baudrate for serial communication (wired)
LGC
Light button configuration: nu=not used; ES=change working mode from normal to energy
saving mode and vice-versa; LiG=light output control; AUS=auxiliary output control;
dEF=defrost control; Pb2=probe 2 value visualization
LG2
Light button configuration (timed, 3 sec): nu=not used; ES=change working mode from
normal to energy saving mode and vice-versa; LiG=light output control; AUS=auxiliary output
control; dEF=defrost control; Pb2=probe 2 value visualization; ErA=reset of Energy Reduction
Algorithm pattern
dnC
Down button configuration: nu=not used; ES=change working mode from normal to energy
saving mode and vice-versa; oFF=device ON/OFF control; Cnt=counter menu
dn2
Down button configuration (timed 3 sec): nu=not used; ES=change working mode from
normal to energy saving mode and vice-versa; oFF=device ON/OFF control; Cnt=counter
menù
uPC
UP button configuration: nu=not used; AUS=auxiliary output control; dEF=defrost control;
Cnt=counter menu
uP2
UP button configuration (timed 3 sec): nu=not used; ES=change working mode from normal
to energy saving mode and vice-versa; CC=do not select it
d1
Probe P1 value visualization (read only)
d2
Probe P2 value visualization (read only)
d3
Probe P3 value visualization (read only)
d4
Probe P4 value visualization (read only)
rSE
Real Set point (SET + ES + oHx)
FdY
Firmware release: day (read only)
FMt
Firmware release: month (read only)
FYr
Firmware release: year (read only)
rEL
Firmware Release (read only)
Ptb
Parameter code table (read only)
11 DIGITAL INPUT
The free voltage digital input is programmable in different configurations by the i1F and i2F.
DOOR SWITCH (ixF=dor)
It signals the door status and the corresponding relay output status through the odC parameter:
no = normal (any change); FAn = Fan OFF; CPr= Compressor OFF; F-C = Compressor and fan OFF.
Since the door is opened, after the delay time set through parameter did, the door alarm is enabled,
the display shows the message “dA”and the regulation restarts if rrd = Y. The alarm stops as soon
as the external digital input is disabled again. With the door open, the high and low temperature alarms
are disabled.
START DEFROST (ixF=dEF)
It starts a defrost if there are the right conditions. After finishing any defrost, the normal regulation will
restart only if the digital input is disabled, otherwise the instrument will wait until the MdF safety time is
expired.
ENERGY SAVING (ixF=ES)
The energy saving mode will be enabled / disabled with the digital input.
MOTION SENSOR (ixF=MS)
The external motion sensor activation is counted.
AUXILIARY OUTPUT (ixF=AUS)
The AUX output (if present and configured) will be enabled / disabled with the digital input.
EXTERNAL WARNING ALARM (ixF=EAL)
It is used to detect an external alarm. This signal does not lock the regulation.
EXTERNAL LOCK ALARM (ixF=bAL)
It is used to detect any critical external alarm. This signal locks immediately the regulation.
EXTERNAL PRESSURE ALARM (ixF=PAL)
It is used to detect any pressure external alarm. This signal locks the regulation after nPS events in
dxd interval od time.
REMOTE HOLYDAY MODE (ixF=HdF)
It is used to force the holyday mode.
REMOTE ONOFF (ixF=onF)
It is used to switch ON and OFF the device remotely.
12 INSTALLATION AND MOUNTING
Instrument XRB60CHC shall be mounted on vertical panel, in a
29x71 mm hole, and fixed using the special bracket supplied.
The temperature range allowed for correct operation is -20 to
60°C. Avoid places subject to strong vibrations, corrosive gases,
excessive dirt or humidity. The same recommendations apply to
probes. Let air circulate by the cooling holes.
13 OPTIONAL FEATURES
The MDP/CX rear cover can be used to increase the protection
from water and dust.
The HOT-KEY is used for a quick and easy upload (from device
to HOT-KEY) or download (from HOT-KEY to device) of the
parameter map.
The BLU serial interface converts the TTL output into an RS485
signal that can be used to connect the unit to the controlling and
supervising system. Please note that standard version of this
converter does not work with XR-CHC devices.
14 ELECTRICAL CONNECTIONS
The instrument is provided with screw terminal block to connect cables with a cross section up to
2.5mm2. Before connecting cables make sure the power supply complies with the instrument’s
requirements. Separate the probe cables from the power supply cables, from the outputs and the
power connections. Do not exceed the maximum current allowed on each relay, in case of heavier
loads use a suitable external relay.
14.1 PROBES
The probes shall be mounted with the bulb upwards to prevent damages due to casual liquid
infiltration. It is recommended to place the thermostat probe away from air streams to correctly
measure the average room temperature. Place the defrost termination probe among the evaporator
fins in the coldest place, where most ice is formed, far from heaters or from the warmest place during
defrost, to prevent premature defrost termination.

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 6/7
15 USE THE HOT KEY
15.1 SAVE PARAMETERS IN A HOT KEY (UPLOAD FROM INSTRUMENT)
1. Program one controller with the front keypad.
2. When the controller is ON, insert the “HOT-KEY” and push UP button; the “UP”message
appears followed a by flashing “End”
3. Push “SET” key and the “End”will stop flashing.
4. Turn OFF the instrument and then remove the “HOT-KEY”. At the end turn the instrument ON
again.
NOTE: the “Err” message appears in case of a failed programming operation. In this case push again
the UP button if you want to restart the upload again or remove the “HOT-KEY” to abort the operation.
15.2 COPY PARAMETERS FROM A HOT KEY (DOWNLOAD PARAMETER
VALUES)
1. Turn OFF the instrument.
2. Insert a programmed “HOT-KEY” into the 5-PIN receptacle and then turn the Controller ON.
3. Automatically the parameter list of the “HOT-KEY” is downloaded into the Controller memory, the
“do” message is blinking followed a by flashing “End”.
4. After 10 seconds the instrument will restart working with the new parameters.
5. Remove the “HOT-KEY”.
NOTE: the message “Err” is displayed for failed programming. In this case turn the unit off and then on
if you want to restart the download again or remove the “HOT-KEY” to abort the operation.
16 ALARM SIGNALLING
Label
Cause
Outputs
“oFF”
Keyboard locked
Outputs unchanged
“on”
Keyboard unlocked
Outputs unchanged
“P1”
Room probe failure
Compressor output according to Con e CoF
“P2”
Evaporator probe failure
Defrost end is timed
“P3”
Third probe failure
Depends on the alarms
“P4”
Fourth probe failure
Linked temperature alarm is not managed
“HA”
Maximum temperature alarm
Outputs unchanged
“LA”
Minimum temperature alarm
Outputs unchanged
“H2”
Maximum temperature for second
temperature alarm
Outputs unchanged
“L2”
Minimum temperature for second
temperature alarm
Outputs unchanged
“dA”
Door open more than dxd time
Compressor and fans restarts
“EA”
External alarm
Outputs unchanged
“CA”
Serious external alarm
Outputs disabled
“EE”
EEPROM alarm
Outputs unchanged
16.1 ALARM RECOVERY
Probe alarms “P1”, “P2”, “P3”and “P4”start some seconds after the fault in the related probe; they
automatically stop some seconds after the probe restarts normal operation. Check connections before
replacing the probe. Temperature alarms “HA”, “LA”, “H2” and “L2” automatically stop as soon as the
temperature returns to normal values. It is possible to reset the “EE” alarm by pressing any button.
The alarms “EA”, “CA” and “dA” will automatically stop as soon as the digital input is disabled.
The optional buzzer can be muted by pressing any key if parameter tbA=Y.
17 TECHNICAL DATA
Housing: self-extinguishing PC-ABS
Case: frontal 32x74 mm; depth 60mm
Mounting: panel mounting in a 71x29mm panel cut-out
Body Protection: IP20
Frontal protection: IP65
Connections: Screw terminal block 2.5 mm2wiring
Power supply: (according to the model) 230Vac 10%, 50/60Hz; 110Vac 10%, 50/60Hz
Power absorption: 3.5VA max
Display: 3 digits red LED, 14.2 mm high
Inputs: up to 4 NTC probes
Digital input: free voltage contact
Relay outputs: Compressor SPST 16(5)A or 20(8)A, 250VAC
Light: SPDT 5(2)A, 250VAC
Fans: SPST 8(3)A, 250VAC
Data storing: 8 Kbytes (EEPROM)
Kind of action: 1B
Pollution degree: 2
Software class: A
Rated impulsive voltage: 2500V; Overvoltage Category: II
Operating temperature: -20 to 60°C (32 to 140°F)
Storage temperature: -25 to 60°C (-13 to 140°F)
Relative humidity: 20 to 85% (no condensing)
Measuring and regulation range:
NTC -40 to 110°C (-40 to 230°F)
Resolution: 0.1°C or 1°C (selectable)
Accuracy (ambient temp. 25°C): ±0.1°C ±1 digit.
18 WIRINGS
18.1 XRB60CHC, 16+8+8A
Power Supply:
110 or 230 Vac @50 or 60Hz
18.2 XRB60CHC, 20+8+5A
Power Supply:
110 or 230 Vac @50 or 60Hz
19 APPLICATION NOTES
Pay attention to the positioning of the regulation probe. In fact, the XR60CHC can obtain the best
performances of the system under control when the regulation probe is placed by following these guidelines.
NOTE: it is possible to change the sensibility of the energy reduction algorithm (ErA=Aut) by using the
parameter tun (tuning). In case of different temperature probe placement (respect to the ones depicted in the
following table), try to change tun value from Hto L.
Ventilated applications –Evaporator placed on the back of the
refrigerated zone, ventilator placed above the evaporator
-The regulation probe is normally placed in the outlet air flow from the
evaporator
-The regulation probe can be placed both inside or outside the
ventilator pack, paying attention to avoid positions too near to the
motor of the ventilator
-Sensibility for ErA=Aut algorithm to be set to tun=H
Ventilated applications –Evaporator placed on the top side of the
refrigerated zone, ventilator placed on the outlet air flow from the
evaporator
-The regulation probe is normally placed in the inlet air flow to the
evaporator
-The regulation probe has to be installed outside the evaporator,
avoiding any contact with the metallic parts of the evaporator itself
-Sensibility for ErA=Aut algorithm to be set to tun=H
Static applications –Coolers without ventilators:
-The regulation probe is normally placed at the side-wall of the
refrigerated zone, approximately from 30% to 50% (of the internal
height) from the bottom and 20% to 30% (of the internal width) from
the back
-Sensibility for ErA=Aut algorithm to be set to tun=H
20 BLUETOOTH COMMUNICATION
The controller implements a complete Bluetooth 4.2 communication embedded module. This gives the
possibility to create a wireless communication channel with external devices (for example with a mobile APP
able to recognize and decode the device). All controllers use a proper MAC-ADDRESS which is used both for
unique identification and communication. The maximum communication range is about 5 m. Over this distance

XRB60CHC EN r1.1 2018.11.01.docx XRB60CHC 7/7
it is possible to suffer continuous interruption at the communication channel. When discovered, a pairing
secure code will be required for connection. Please follow the APP instruction for more information.
20.1 FIRST INSTALLATION
After connecting and powering-up the controller, it will be possible to manage it by using the Emerson mobile
APP. Il will be required to:
-Install the Emerson mobile APP on your mobile device (smartphone or tablet)
-Create a new user account (email and password for accessing to the APP)
The owner is the only account that is able to:
-Manage the controller via Bluetooth
-Extend right of access to a particular appliance to other users
A Cloud portal has to be used for:
-Extend right of access to a particular appliance to other users
-Select the permission level for any new user
The link for opening the Cloud webpage is on the left side menu of the mobile APP (slide right the screen of
the APP when on the scan page and follow the “Cloud management” link. Please note that the login and
password for the Cloud webpage is the same of the ones used for the mobile APP.
20.2 RESETTING AN APPLIANCE
In case you need to reset an installation, please follow this operations:
-Access to the Cloud webpage and select the appliance you want to reset (search for name and
MAC-ADDRESS)
-Click on the “DELETE” link, the appliance will be removed from the list of owned appliances
-Go to the device controller (with the same MAC-ADDRESS)
-Enter the programming mode
-Go to the “BLE” menu
-Select the par. rPS (reset device ownership)
-Select “Y” and confirm with SET button
-Exit from the programming menu
-Logout and login from the mobile APP
Doing this, the controller will be reset to factory default configuration and it will be ready for a new association
(means a new Owner)
The XRB60CHC is compliant with the following standards:
ETSI EN 300 328 V2.1.1 (2016-11)
IEC EN 60730-2-9: 2008 (Third Edition) and Am.1:2011 in conjunction with IEC 60730-1:2010 (Fourth Edition)
UL 60730-1 Fourth Edition and CAN/CSA-E60730-1:02 Third Edition along with its Amendment 1 dated
February 2007, the Standards for Automatic electrical controls for household and similar use –Part 1: General
requirements.
Hereby, Dixell S.r.l. declares that the radio equipment type XRB60CHC is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
EmersonClimate.com/Dixell
It therefore meets the essential requirements of the following Directives:
Radio equipment Directive 2014/53/EU
Electromagnetic compatibility 2014/30/EU
Low Voltage equipment 2014/35/EU
The XRB60CHC is compliant with the following standards:
FCC 15.247
The XRB60CHC is compliant to Part 15 of the FCC Rules:
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.”
This device has been designed and complies with the safety requirements for portable (<20cm) RF exposure
in accordance with FCC rule part 2.1093 and KDB 447498 D01 as demonstrated in the RF exposure analysis.
Installers must ensure that this device must not be co-located or operated in conjunction with any other
antenna or transmitter except in accordance with FCC multi-transmitter product procedures.
Unauthorized repairs, changes or modifications could result in permanent damage to the equipment and void
your warranty and your authority to operate this device under Part 15 of the FCC Rules.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at
his own expense.
The XRB60CHC is compliant to RSS 102
Cet XRB60CHC instrument répond aux normes RSS 102
The Dixell XRB60CHC complies with the safety requirements for RF exposure in accordance with RSS-102
Issue 5 for portable
use conditions
This device complies with ISED’s license-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the
device
This device complies with the safety requirements for RF exposure in accordance with RSS-102 Issue 5 for
portable use conditions.
Dixell 01XRCHC est conforme aux exigences de sécurité pour l’exposition RF conformément aux CNR
d’Industrie Canada applicables aux appareils radio RSS-210 5e edition.
Le présent appareil est conforme aux RSS exempts de licence d’ISDE. Le fonctionnement de l'appareil est
sujet aux deux conditions suivantes:
(1) Ce dispositif ne doit pas produire de brouillage préjudiciable, et
(2) Ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un
fonctionnement indésirable.
Le présent appareil est conforme aux limites d’exposition aux RF conformément au norme CNR-102 émission
5 pour conditions d’utilisation portable.
