Emerson AS3-FLP Series Installation instructions

1(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-flp-1_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Pre-filter, Series AS3-FLP
Parts assembled: 2 (5)
Consists of following parts: 4 pcs
Parts assembled: 2 (5)

2(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-flp-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Mate
1 –Assemble Body & Reservoir Parts assembled: 2 (4)
Constraint 1(3): Mate
Constraint 2(3): Align
Constraint 3(3): Align
2 –Assemble Top cover Parts assembled: 3 (4)

3(3)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as3-flp-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 2(3) : Insert
Constraint 3(3) : Mate
Constraint 1(2): Insert
Constraint 2(2): Distance (0.5 mm)
3 –Assemble Drain knob Parts assembled: 4 (4)
