Emerson AMS 2140 User manual

Optional – Job Storage
Alignment jobs can also be saved and printed.
This is found under “Job Manager” on the ALT screen
of the main menu.
You can customize
the machine
graphics using a
selection of
different machine
types. Consult the
user manual for
additional details,
advanced functions,
and instructions.
Pocket Guide
For Laser Shaft Alignment
AMS 2140
Machinery Health™Analyzer
Refer to the user
manual to learn
how to upload
saved jobs back to
the PC software.
Introduction:
This guide outlines a quick and easy 3-step
method for precision shaft alignment.
Set-up:
Choose the shortest support posts that will still
allow the laser beam to pass over or through the
coupling. Mount the laser xtures by sliding each
head over the support posts and locking them
into place with the yellow clamping levers.
Mount laser heads as shown above, being careful
to mount the laser on the stationary machine.
Sweep Size:
The “Auto Sweep” method provides a simple,
accurate solution for any alignment task. Start
anywhere. Stop anywhere. While it is always best
to completely rotate the shaft, this method can
be used effectively with partial sweeps down to
45°. Press [ENTER] to retrieve data via Bluetooth.
45°
Operating Notes:
Laser fixtures are for shaft alignment only and
should be operated by properly trained personnel.
As precision instruments, care should be taken to
not subject them to shock.
Laser Safety:
Do not stare directly into the laser beam!
[NOTE: Red LED on Laser Head indicates that
laser is active.]
Do not insert optical
devices into beam.
P/N: MHM-97109, rev 1
Mount laser on
stationary machine
Mount sensor on
machine to be moved
AMS 2140 Machinery Health™Analyzer

Optional: Foot Pre-Check
To check foot condition, press [F12] before
sweeping laser fixtures and follow on-screen
instructions. Use a feeler gauge to determine
required shim correction. The Soft Foot option
provides you with a sense of severity without
showing numbers. The FDI option will provide an
estimate of the required shim.
Bluetooth Set- Up
1. Press [Home] > [F5] Comm Setup >
[F7] Bluetooth Setup.
2. Press [F2] Bluetooth to enable or disable the
Bluetooth radio. When the radio is enabled,
the Bluetooth LED on the top of the analyzer
turns on and the icon appears in the upper corner
of the screen.
3. Press [F7] Pair to pair the sensor.
“Paired” appears next to the device
once the laser heads are connected
to the analyzer. To differentiate
between laser heads and
headphones, a laser image as shown to the right
is displayed next to the serial number.
1 Enter Dimensions 2 Sweep Laser Heads 3 Move Machine
Values for A, B, E and
RPM are required.
Use [<] and [>] to
move between elds.
Optional machines
types enable entry of
values for C and D for
the other machine.
Note: Use [./] to
calculate fractions.
Example: 30 3/8 = [3]
[0] [./] [3] [./] [./] [8]
Press [ENTER]
to initialize
laser xtures.
The Vertical
Machine Move
indicates how much
to shim/drop each
machine foot.
Sweep laser heads.
Start anywhere.
Stop anywhere.
Minimum
recommended
sweep size is 45°.
Press [ENTER]
to retrieve data
via Bluetooth.
When viewing the
Horizontal Move
screen, press [F12]
for ‘LIVE MOVE’.
Place laser xtures
in desired position
and press [ENTER]
to start.
OK = Good
X = Soft
Display Meaning
Way out.
More than 2x tolerance.
Getting close.
1-2x tolerance.
Good job!
Below acceptable tolerance.
Great job!
Below excellent tolerance.
Shaft Alignment Indicator
The bull’s eye display continuously updates
alignment status.
Emerson
Reliability Solutions
835 Innovation Drive
Knoxville, TN 37932 USA
[phone]
www.emerson.com/ams
XX = Bad
XXX = Extreme
