Rosemount 8800D Series Vortex Flowmeter
4004_RevDB.fm Page 1 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
2
© 2011Rosemount Inc. All rights reserved. All marks property of owner.
Rosemount and the Rosemount logotype are registered trademarks of Rosemount, Inc.
The Emerson logo is a trademark and servicemark of Emerson Electric Co.
IMPORTANT NOTICE
This installation guide provides basic guidelines for the Rosemount®8800D Vortex
Flowmeter. It does not provide instructions for detailed configuration, diagnostics,
maintenance, service, troubleshooting, Explosion-proof, Flameproof, or Intrinsically Safe
(I.S.) installations. Refer to the Rosemount 8800D reference manual (document number
00809-0100-4004) for more instruction. The manuals and this QIG are also available
electronically on www.rosemount.com.
WARNING
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance with the
appropriate local, national, and international standards, codes, and practices. Please
review the approvals section of the Rosemount 8800D reference manual for any
restrictions associated with a safe installation.
• Before connecting a handheld communicator in an explosive atmosphere, make sure
the instruments in the loop are installed in accordance with intrinsically safe or
non-incendive field wiring practices.
• Verify the operating atmosphere of the flowmeter is consistent with the appropriate
product certifications.
In an Explosion-proof/Flameproof installation, do not remove the flowmeter covers when
power is applied to the unit.
Electrical shock can result in death or serious injury
• Avoid contact with the leads and terminals. High voltage that may be present on leads
can cause electrical shock.
Rosemount Inc.
8200 Market Boulevard
Chanhassen, MN USA 55317
T (US) 800-522-6277
T (Intnl) [phone]
F [phone]
Emerson Process Management
Neonstraat 1
6718 WX Ede
The Netherlands
T [phone]
F [phone]
Emerson Process
Management Asia Pacific
Private Limited
1 Pandan Crescent
Singapore 128461
T (65) 6777 8211
F (65) 6777 0947 / (65) 6777 0743
4004_RevDB.fm Page 2 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
3
STEP 1: MOUNT THE FLOWMETER
Design process piping so the meter body will remain full, with no entrapped air. The vortex
flowmeter can be installed in any orientation without affecting accuracy. However, the
following are guidelines for certain installations.
Vertical Mounting
If the vortex flowmeter will be installed in a vertical orientation:
• Install upward or downward flow for gas or steam.
• Install upward flow for liquids.
Figure 1. Vertical Installation
Horizontal Mounting
Figure 2. Horizontal Installation
For steam and fluids with small solids content, it is recommended to have the flowmeter
installed with the electronics to the side of the pipe. This will minimize potential
measurement errors by allowing the condensate or solids to flow under the shedder bar
without interrupting the vortex shedding.
High Temperature Mounting
The maximum temperature for integral electronics is dependent on the ambient temperature
where the flowmeter is installed. The electronics must not exceed 185 °F (85 °C).
Figure 3 shows combinations of ambient and process temperatures needed to maintain a
housing temperature of less than 185 °F (85 °C).
Liquid or Gas
Flow
Gas Flow
Themeterbody installed
with the electronics to
the side of the pipe Themeterbody installed
with the electronics
above the pipe
Acceptable
Preferred
4004_RevDB.fm Page 3 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
4
Figure 3. Rosemount 8800D Ambient/Process Temperature Limits
The following orientations are recommended for applications with high process temperatures.
• Install with electronics head beside or below process pipe.
• Insulation around pipe may be necessary to maintain ambient temperature below 185 °F
(85 °C).
NOTE
Insulate pipe and meter body only. Do not insulate support tube bracket so heat can be
dissipated.
Steam Installations
Avoid installation shown Figure 4. Such conditions may cause a water-hammer condition at
start-up due to trapped condensation.
Figure 4. Improper Installation
Upstream/Downstream Requirements
The Rosemount 8800D Flowmeter may be installed with a minimum of ten straight pipe
diameters (D) upstream and five straight pipe diameters (D) downstream by following the
K-factor corrections as described in the 8800 Installation Effects Technical Data Sheet
(00816-0100-3250). No K-factor correction is required if 35 straight pipe diameters upstream
(35D) and 10 straight pipe diameters downstream (10D) are available.
200 (93)
180 (82)
160 (71)
140 (60)
120 (49)
100 (38)
80 (27)
60 (16)
0
200 (93)
300 (149)
400 (204)
500 (260)
600 (316)
700 (371) 800 (427) 900 (482)
1000 (538)
100 (38)
Ambient Temperature °F (°C)
Process Temperature °F (°C)
185 °F Housing
Temperature
Limit
Meter and pipe insulated with 3 inches of ceramic fiber insulation.
Horizontal Pipe and Vertical meter position.
4004_RevDB.fm Page 4 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
5
External Pressure/Temperature Transmitters
When using pressure and temperature transmitters in conjunction with the 8800D for
compensated mass flows, install the transmitters downstream of the Rosemount 8800D
flowmeter as shown in Figure 5.
Figure 5. Upstream/Downstream Piping
Wafer Style Installation
Figure 6. Wafer Style Installation
Flanged-Style Installation
Figure 7. Flanged-Style Flowmeter Installation
P T
4 Downstream
6 Downstream
Flow
Gaskets
(Supplied by
Customer)
Installation
Studs and
Nuts(Supplied
by Customer)
Alignment
Ring
Alignment Ring
Gaskets
(Supplied by Customer)
Installation Bolts
and Nuts (Supplied
by Customer)
Flow
4004_RevDB.fm Page 5 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
6
NOTE
The required bolt load for sealing the gasket joint is affected by several factors, including
operating pressure, gasket material, thickness, and condition. A number of factors also
affect the actual bolt load resulting from a measured torque, including condition of bolt
threads, friction between the nut head and the flange, and parallelism of the flanges. Due to
these application-dependent factors, the required torque for each application may be
different. Follow the guidelines outlined in the ASME PCC-1 for proper bolt tightening. Make
sure the flowmeter is centered between flanges of the same nominal size as the flowmeter.
Insert Integral Temperature Sensor (MTA Option Only)
The Temperature Sensor is coiled and attached to the electronics bracket. Remove the
plastic band holding the sensor to the electronics bracket and insert temperature sensor into
into the hole at the bottom of the meter body. There is no need to remove the opposite end
from the electronics. Tighten with 1/2inch open-end wrench approximately 1 1/4turns past
finger-tight.
Remote Electronics
If you order one of the remote electronics options (options R10, R20, R30, R33, R50, or
RXX), the flowmeter assembly ships in two parts:
1. The meter body with an adapter installed in the support tube and an interconnecting
coaxial cable attached to it.
2. The electronics housing installed on a mounting bracket.
Mounting
Mount the meter body in the process flow line as described earlier in this section. Mount the
bracket and electronics housing in the desired location. The housing can be repositioned on
the bracket to facilitate field wiring and conduit routing.
Cable Connections
Refer to Figure 8 and the instructions on page 7 to connect the loose end of the coaxial
cable to the electronics housing.
Figure 8. Remote Electronics Installation
NOTE
Consult factory for SST installation
1/2NPT Conduit Adapter or Cable
Gland (Supplied by Customer)
Coaxial Cable
Meter Adapter
Union
Washer
Nut
Sensor Cable Nut
Support
Tube
Meter Body
Electronics
Housing
Ground Connection
Housing Base
Screw
Housing
Adapter
Housing Adapter
Screws
Conduit Adapter
(optional-supplied
by customer)
Coaxial
Cable Nut
4004_RevDB.fm Page 6 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
7
1. If you plan to run the coaxial cable in conduit, carefully cut the conduit to the desired
length to provide for proper assembly at the housing. A junction box may be placed in the
conduit run to provide a space for extra coaxial cable length.
CAUTION
The coaxial remote cable cannot be field terminated or cut to length. Coil any extra coaxial
cable with no less than a 2-in. (51 mm) radius.
2. Slide the conduit adapter or cable gland over the loose end of the coaxial cable and
fasten it to the adapter on the meter body support tube.
3. If using conduit, route the coaxial cable through the conduit.
4. Place a conduit adapter or cable gland over the end of the coaxial cable.
5. Remove the housing adapter from the electronics housing.
6. Slide the housing adapter over the coaxial cable.
7. Remove one of the four housing base screws.
8. Attach and securely tighten the coaxial cable nut to the connection on the electronics
housing.
9. Attach the coaxial cable ground wire to the housing via the housing base ground screw.
10.Align the housing adapter with the housing and attach with three screws.
11. Tighten the conduit adapter or cable gland to the housing adapter.
CAUTION
To prevent moisture from entering the coaxial cable connections, install the interconnecting
coaxial cable in a single dedicated conduit run or use sealed cable glands at both ends of
the cable.
NOTE
Refer to the User Manual for details for the CPA option.
STEP 2: CONSIDER HOUSING ROTATION
The entire electronics housing may be rotated in 90° increments for easy viewing. Use the
following steps to change the housing orientation:
1. Loosen the three housing rotation set screws at the base of the electronics housing with
a 5/32" hex wrench by turning the screws clockwise (inward) until they clear the support
tube.
2. Slowly pull the electronics housing out of the support tube.
CAUTION
Do not pull the housing more than 1.5-in. (40 mm) from the top of the support tube until the
sensor cable is disconnected. Damage to the sensor may occur if this sensor cable is
stressed.
3. Unscrew the sensor cable from the housing with a 5/16-in. open end wrench.
4. Rotate the housing to the desired orientation.
5. Hold it in this orientation while you screw the sensor cable onto the base of the housing.
4004_RevDB.fm Page 7 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
8
CAUTION
Do not rotate the housing while the sensor cable is attached to the base of the housing. This
will stress the cable and may damage the sensor.
6. Place the electronics housing into the top of the support tube.
7. Use a 5/32” hex wrench to turn the three housing rotation screws counter-clockwise
(outward) to engage the support tube.
STEP 3: SET JUMPERS
Adjust jumpers to desired settings.
HART
If alarm and security jumpers are not installed, the flowmeter will operate normally with the
default alarm condition alarm high and the security off.
Figure 9. HART Jumpers and LCD
FOUNDATION fieldbus
If security and simulate enable jumpers are not installed, the flowmeter will operate normally
with the default security off and simulate enable off.
Figure 10. FOUNDATION fieldbus Jumpers and LCD
ALARM
HI LO
ON OFF
SECURITY
SIMULATE ENABLE
OFF ON
ON OFF
SECURITY
4004_RevDB.fm Page 8 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
9
STEP 4: CONNECT WIRING AND POWER UP
Power Supply
HART
The dc power supply should provide power with less than two percent ripple. The total
resistance load is the sum of the resistance of the signal leads and the load resistance of the
controller, indicator, and related pieces. Note that the resistance of intrinsic safety barriers, if
used, must be included.
Figure 11. Load Limitation
Maximum Loop Resistance = 41.7 (Power Supply Voltage - 10.8)
The Field Communicator requires a minimum loop resistance of 250
FOUNDATION Fieldbus
The flowmeter requires 9-32 Vdc at the power terminals. Each fieldbus power supply
requires a power conditioner to decouple the power supply output from the fieldbus wiring
segment.
Conduit Installation
Prevent condensation in any conduit from flowing into the housing by mounting the
flowmeter at a high point in the conduit run. If the flowmeter is mounted at a low point in the
conduit run, the terminal compartment could fill with fluid.
If the conduit originates above the flowmeter, route conduit below the flowmeter before
entry. In some cases a drain seal may need to be installed.
Figure 12. Proper Conduit Installation with Rosemount 8800D
Power Supply (Volts)
Operating
Region
1250
1000
500
010.8 42
Load (Ohms)
Conduit Line Conduit Line
4004_RevDB.fm Page 9 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
10
Use the following steps to wire the flowmeter:
1. Remove the housing cover on the side marked FIELD TERMINALS.
2. Connect the positive lead to the “+” terminal and the negative lead to the “-” terminal as
shown in Figure 13 for HART installations and Figure 14 for FOUNDATION fieldbus
installations.
NOTE
FOUNDATION fieldbus terminals are not polarity sensitive.
3. For HART installations utilizing the pulse output, connect the positive lead to the “+”
terminal of the pulse output and the negative lead to the “-” terminal of the pulse output
as shown in Figure 13. A separate 5 to 30 Vdc power supply is required for the pulse
output. Maximum switching current for the pulse output is 120 mA.
CAUTION
Do not connect the powered signal wiring to the test terminals. Power could damage the test
diode in the test connection. Twisted pairs are required to minimize noise pick up in the 4 -
20 mA signal and digital communication signal. For high EMI/RFI environments, shielded
signal wire is required and preferred in all other installations. Use 24 AWG or larger wire and
do not exceed 5,000 feet (1,500 meters). For FOUNDATION fieldbus use wire specifically
designed for fieldbus installations for maximum performance. For ambient temperatures
above 140 °F (60 °C) use wire rated to 176 °F (90 °C).
Figure 13 shows wiring connections necessary to power a Rosemount 8800D and enable
communications with a hand-held Field Communicator.
Figure 14 shows wiring connections necessary to power the 8800D with FOUNDATION
fieldbus.
4. Plug and seal unused conduit connections. Use pipe sealing tape or paste on threads
to ensure a moisture-tight seal. Housing conduit entries marked with M20 will require
M-20 x 1.5 blanking plug thread. Unmarked conduit entries will require a 1/2 -14 NPT
blanking plug thread.
NOTE
Straight threads require a minimum of three (3) wraps of tape to obtain a tight seal.
5. If applicable, install wiring with a drip loop. Arrange the drip loop so the bottom is lower
than the conduit connections and the flowmeter housing.
Rosemount 8800D Vortex units ordered with painted meter body may be subject to
electrostatic discharge. To avoid electrostatic charge build-up, do not rub the meter body
with a dry cloth or clean with solvents.
4004_RevDB.fm Page 10 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
11
Figure 13. Flowmeter Wiring Diagrams for HART protocol
4-20 mA Wiring
4-20 mA and Pulse Wiring with Electronic Totalizer/Counter
RL250 
+
-
Power
Supply
RL250 
-
+-
+
Power Supply
with Counter
Power
Supply
4004_RevDB.fm Page 11 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
12
NOTE
Installation of the transient protection terminal block does not provide transient protection
unless the Rosemount 8800D case is properly grounded.
Figure 14. Flowmeter Wiring Diagram for FOUNDATION fieldbus protocol
Cover Jam Screw
For transmitter housings shipped with a cover jam screw, the screw should be properly
installed once the transmitter has been wired and powered up. The cover jam screw is
intended to disallow the removal of the transmitter cover in flameproof environments without
the use of tooling. Follow these steps to install the cover jam screw:
1. Verify that the cover jam screw is completely threaded into the housing.
2. Install the transmitter housing cover and verify that the cover is tight against the housing.
3. Using an M4 hex wrench, loosen the jam screw until it contacts the transmitter cover.
4. Turn the jam screw an additional 1/2turn counterclockwise to secure the cover.
NOTE:
Application of excessive torque may strip the threads.
5. Verify that the cover cannot be removed.
Field Wiring Diagram
Terminators
Fieldbus
Segment
6234 ft (1900 m) max
(depending upon cable
characteristics)
(Spur)
(Spur)
(Trunk)
Integrated
Power
Conditioner
and Filter
Devices 1 through 16*
*Intrinsically safe installations may
allow fewer devices per I.S. barrier.
(The power supply, filter,
first terminator, and
configuration tool are
typically located in the
control room.)
Power
Supply
4004_RevDB.fm Page 12 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
13
STEP 5: VERIFY CONFIGURATION
Before operating the Rosemount 8800D in an installation, you should review the
configuration data to ensure that it reflects the current application. In most cases, all of these
variables are pre-configured at the factory. Configuration may be required if your 8800D is
not configured or if the configuration variables need revision.
Rosemount recommends the following variables are reviewed before startup:
HART Configuration FOUNDATION fieldbus Configuration
•Tag
• Transmitter Mode
• Process Fluid
• Reference K-Factor
• Flange Type
• Mating Pipe ID
• PV Units
• PV Damping
• Process Temperature Damping
• Fixed Process Temperature
• Auto Adjust Filter
• LCD Display Configuration (For units
with a display only)
• Density Ratio (For Standard or Normal
flow units only)
• Process Density and Density Units (For
mass flow units only)
• Variable Mapping
• Range Values
• Pulse Output Configuration (For units
with a pulse output only)
•Tag
• Transmitter Mode
• Process Fluid
• Reference K-Factor
• Flange Type
• Mating Pipe ID
• PV Units (Configured in the AI block)
•FlowDamping
• Process Temperature Damping
• Fixed Process Temperature
• Auto Adjust Filter
• LCD Display Configuration (For units with
a display only)
• Density Ratio (For Standard or Normal
flow units only)
• Process Density and Density Units (For
mass flow units only)
4004_RevDB.fm Page 13 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
14
NOTE
For detailed configuration information see the Rosemount 8800D Vortex Flowmeter manual
(00809-0100-4004).
Table 1. Fast Keys for Rosemount 8800D Device Revision 1 DD Revision 2 and Device Revision 2 DD
Revision 1
Function HART Fast Key Function HART Fast Key
Alarm Jumpers 1, 4, 2, 1, 3 Meter Body Number 1, 4, 1, 5
Analog Output 1, 4, 2, 1 Minimum Span 1, 3, 8, 3
Auto Adjust Filter 1, 4, 3, 1, 4 Num Req Preams 1, 4, 2, 3, 2
Base Time Unit 1, 1, 4, 1, 3, 2 Poll Address 1, 4, 2, 3, 1
Base Volume Unit 1, 1, 4, 1, 3, 1 Process Fluid Type 1, 3, 2, 2
Burst Mode 1, 4, 2, 3, 4 Process Variables 1, 1
Burst Option 1, 4, 2, 3, 5 Pulse Output 1, 4, 2, 2, 1
Burst Variable 1 1, 4, 2, 3, 6, 1 Pulse Output Test 1, 4, 2, 2, 2
Burst Variable 2 1, 4, 2, 3, 6, 2 PV Damping 1, 3, 9
Burst Variable 3 1, 4, 2, 3, 6, 3 PV Mapping 1, 3, 6, 1
Burst Variable 4 1, 4, 2, 3, 6, 4 PV Percent Range 1, 1, 2
Burst Xmtr Variables 1, 4, 2, 3, 6 QV Mapping 1, 3, 6, 4
Conversion Number 1, 1, 4, 1, 3, 4 Range Values 1, 3, 8
D/A Trim 1, 2, 5 Review 1, 5
Date 1, 4, 4, 5 Revision Numbers 1, 4, 4, 7
Descriptor 1, 4, 4, 3 Scaled D/A Trim 1, 2, 6
Density Ratio 1, 3, 2, 4, 1, 1 Self Test 1, 2, 1, 5
Device ID 1, 4, 4, 7, 6 Signal to Trigger Ratio 1, 4, 3, 2, 2
Electronics Temp 1, 1, 4, 7, 1 STD/ Nor Flow Units 1, 1, 4, 1, 2
Electronics Temp Units 1, 1, 4, 7, 2 Special Units 1, 1, 4, 1, 3
Filter Restore 1, 4, 3, 3 Status 1, 2, 1, 1
Final Assembly Number 1, 4, 4, 7, 5 SV Mapping 1, 3, 6, 2
Fixed Process Density 1, 3, 2, 4, 2 Tag 1, 3, 1
Fixed Process Temperature 1, 3, 2, 3 Total 1, 1, 4, 4, 1
Flange Type 1, 3, 4 Totalizer Control 1, 1, 4, 4
Flow Simulation 1, 2, 4 Transmitter Mode 1, 3, 2, 1
Installation Effects 1, 4, 1, 6 TV Mapping 1, 3, 6, 3
K-factor (Reference) 1, 3, 3 Trigger Level 1, 4, 3, 2, 5
Local Display 1, 4, 2, 4 URV 1, 3, 8, 1
Loop Test 1, 2, 2 User Defined Units 1, 1, 4, 1, 3, 3
Low Flow Cutoff 1, 4, 3, 2, 3 USL 1, 3, 8, 4
Low Pass Filter 1, 4, 3, 2, 4 Shedding Frequency 1, 1, 4, 6
LRV 1, 3, 8, 2 Variable Mapping 1, 3, 6
LSL 1, 3, 8, 5 Velocity Flow 1, 1, 4, 3
Manufacturer 1, 4, 4, 1 Velocity Flow Base 1, 1, 4, 3, 3
Mass Flow 1, 1, 4, 2, 1 Volumetric Flow 1, 1, 4, 1
Mass Flow Units 1, 1, 4, 2, 2 Wetted Material 1, 4, 1, 4
Mating Pipe ID (Inside Diameter) 1, 3, 5 Write Protect 1, 4, 4, 6
Message 1, 4, 4, 4
4004_RevDB.fm Page 14 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
15
Table 2. Fast Keys for Rosemount 8800D Device Revision 2 DD Revision 3
Function HART Fast Key Function HART Fast Key
Alarm Direction 1, 3, 1, 3, 2 Percent of Range 3, 4, 3, 2
Analog Output 3, 4, 3, 1 Polling Address 2, 2, 7, 1
Analog Trim 3, 4, 3, 6 Primary Variable Damping 2, 1, 4, 1
Base Time Unit 2, 2, 2, 3, 2 Primary Variable 2, 2, 2, 1, 1
Base Volume Unit 2, 2, 2, 3, 1 Process Density Units 2, 2, 2, 2, 6
Burst Mode 2, 2, 7, 2 Process Fluid Type 2, 2, 1, 1, 2
Burst Option 2, 2, 7, 3 Process Temp Units 2, 2, 3, 1, 2
Burst Slot 0 2, 2, 7, 4, 1 Process Variables 3, 2, 1
Burst Slot 1 2, 2, 7, 4, 2 Pulse Output 3, 2, 4, 4
Burst Slot 2 2, 2, 7, 4, 3 Pulse Output Test 3, 5, 3, 4
Burst Slot 3 2, 2, 7, 4, 4 Recall Factory Calibration 3, 4, 3, 8
Burst Variable Mapping 2, 2, 7, 4, 5 Reference K-Factor 2, 2, 1, 2, 1
Compensated K-Factor 2, 2, 1, 2, 2 Reset Transmitter 3, 4, 1, 2
Conversion Number 2, 2, 2, 3, 4 Restore Default Filters 2, 1, 4, 6
Date 2, 2, 8, 2, 1 Revision Numbers 2, 2, 8, 3
Descriptor 2, 2, 8, 2, 2 Scaled Analog Trim 3, 4, 3, 7
Density Ratio 2, 2, 3, 3, 2 2nd Variable 2, 2, 2, 1, 2
Device ID 2, 2, 8, 1, 5 Self Test 3, 4, 1, 1
Display 2, 1, 1, 2 Set Variable Mapping 2, 2, 2, 1, 5
Electronics Temp 3, 2, 5, 4 Shedding Frequency 3, 2, 4, 2
Electronics Temp Units 2, 2, 2, 2, 5 Signal Strength 3, 2, 5, 2
Final Assembly Number 2, 2, 8, 1, 4 Special Flow Unit 2, 2, 2, 3, 5
Fixed Process Density 2, 2, 1, 1, 5 Special Volume Unit 2, 2, 2, 3, 3
Fixed Process Temperature 2, 2, 1, 1, 4 Status 1, 1, 1
Flange Type 2, 2, 1, 4, 2 Tag 2, 2, 8, 1, 1
Flow Simulation 3, 5, 1 3rd Variable 2, 2, 2, 1, 3
4th Variable 2, 2, 2, 1, 4 Total 1, 3, 6, 1
Installation Effects 2, 2, 1, 1, 7 Totalizer Configuration 1, 3, 6, 3
Lower Range Value 2, 2, 4, 1, 4 Totalizer Control 1, 3, 6, 2
Lower Sensor Limit 2, 2, 4, 1, 5, 2 Transmitter Mode 2, 2, 1, 1, 1
Loop Test 3, 5, 2, 6 Trigger Level 2, 1, 4, 5
Low Flow Cutoff 2, 1, 4, 3 Upper Range Value 2, 2, 4, 1, 3
Low-pass Corner Frequency 2, 1, 4, 4 Upper Sensor Limit 2, 2, 4, 1, 5, 1
Manufacturer 2, 2, 8, 1, 2 Velocity Flow 3, 2, 3, 4
Mass Flow 3, 2, 3, 6 Velocity Flow Units 2, 2, 2, 2, 2
Mass Flow Units 2, 2, 2, 2, 4 Velocity Measurement Base 2, 2, 2, 2, 3
Mating Pipe ID (Inside Diameter) 2, 2, 1, 1, 6 Volume Flow 3, 2, 3, 2
Message 2, 2, 8, 2, 3 Volume Flow Units 2, 2, 2, 2, 1
Meter Body Number 2, 2, 1, 4, 5 Wetted Material 2, 2, 1, 4, 1
Minimum Span 2, 2, 4, 1, 6 Write Protect 2, 2, 8, 1, 6
Optimize DSP 2, 1, 1, 3
4004_RevDB.fm Page 15 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
16
PRODUCT CERTIFICATIONS
Approved Manufacturing Locations
Rosemount Inc. — Eden Prairie, Minnesota, USA
Emerson Process Management BV - Ede, The Netherlands
Emerson Process Management Flow Technologies Company, Ltd - Nanjing, Jiangsu
Province, P.R. China
Flameproof enclosure Ex d protection type in
accordance with IEC 60079-1, EN 60079-1
• Transmitters with Flameproof enclosure type protection shall only be opened when
power is removed.
• Closing of entries in the device must be carried out using the appropriate Ex d cable
gland or blanking plug. Unless otherwise marked on housing, the standard conduit entry
thread forms are 1/2-14 NPT.
Type n protection type in accordance with IEC 60079-15, EN 60079-15
Closing of entries in the device must be carried out using the appropriate Ex e or Ex n cable
gland and metal blanking plug or any appropriate ATEX or IECEx approved cable gland and
blanking plug with IP66 rating certified by an EU approved certification body.
European Directive Information
The CE Declaration of Conformity for all applicable European directives for this product can
be found on our website at www.rosemount.com. A hard copy may be obtained by
contacting our local sales office.
ATEX Directive
Rosemount Inc. complies with the ATEX Directive.
European Pressure Equipment Directive (PED)
Rosemount 8800D Vortex Flowmeter Line Size 40 mm to 300 mm
Certificate Number 59552-2009-CE-HOU-DNV
0575
Module H Conformity Assessment
Mandatory CE-marking for flowmeters in accordance with Article 15 of the PED can be
found on the flowtube body.
Flowmeter categories I – III use module H for conformity assessment procedures.
Rosemount 8800 Vortex Flowmeter
Line Size 15 mm and 25 mm
Sound Engineering Practice
Flowmeters that are SEP are outside the scope of PED and cannot be marked for
compliance with PED.
4004_RevDB.fm Page 16 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
17
Hazardous Location Certifications
Rosemount 8800D
North American Certifications
Factory Mutual (FM)
E5 Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Dust-ignition proof for Class II/III, Division 1, Groups E, F, and G;
Temperature Code T6 (-50 °C 
 Ta  70 °C)
Factory Sealed
Enclosure Type 4X
I5 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Non-incendive for Class I, Division 2, Groups A, B, C, and D.
NIFW (Non-incendive Field Wiring) when installed per Rosemount Drawing
08800-0116
Temperature Code T4 (-50 °C Ta70 °C) 4-20 mA HART
Temperature Code T4 (-50 °C Ta60 °C) Fieldbus
IE FISCO for Class I, Division 1, Groups A, B, C, and D.
FNICO for Class 1 Division 2, Groups A, B, C, and D.
Temperature Code T4 (-50 °C Ta60 °C)
when installed per Rosemount control drawing 08800-0116.
Enclosure Type 4X
K5 E5 and I5 Combination
Special conditions for safe use (x)
When fitted with 90V transient suppresors (T1 Option), the equipment is not capable of
passing the 500V insulation test. This must be taken into account upon installation.
The enclosure may be made of an aluminum alloy, and given a protective polyurethane
paint finish: care should be taken to protect the housing from impact or abrasion.
Canadian Standards Association (CSA)
E6 Explosion-Proof for Class I, Division 1, Groups B, C, and D;
Dust-ignition proof for Class II and Class III, Division 1, Groups E, F, and G;
Class I, Zone 1, Ex d[ia] IIC CSA 06.1674267
Temperature Code T6 (-50 °C Ta70 °C)
Factory Sealed
Single Seal.
Enclosure Type 4X
I6 Intrinsically safe for use in Class I, II, III Division 1, Groups A, B, C, D, E, F, G;
Non-incendive for Class I, Division 2, Groups A, B, C and D
Temperature Code T4 (-50 °C Ta70 °C) 4-20 mA HART
Temperature Code T4 (-50 °C Ta60 °C) Fieldbus
Single Seal.
Enclosure Type 4X
4004_RevDB.fm Page 17 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011
Rosemount 8800D
18
IF FISCO for Class I, Division 1, Groups A, B, C, and D;
FNICO for Class 1 Division 2, Groups A, B, C, and D.
Temperature Code T4 (-50 °C Ta60 °C).
When installed per Rosemount drawing 08800-0112
Enclosure Type 4X
K6 E6 and I6 Combination
Combination Certifications
KB E5, I5, E6, and I6 Combination
European Certifications
ATEX Intrinsic Safety
EN 60079-0 : 2009
EN 60079-11 : 2007
I1 Certification No. Baseefa05ATEX0084X
ATEX Marking II 1 G
Ex ia IIC T4 Ga (-60 °C 
 Ta70 °C) 4-20 HART
(-60 °C 
 Ta60 °C) Fieldbus
0575
ATEX FISCO/FNICO
IA Certification No. Baseefa05ATEX0084X
ATEX Marking II 1 G
Ex ia IIC T4 Ga (-60 °C 
 Ta   60 °C)
0575
Input Parameters:
Ui = 17.5 Vdc
Ii= 380 mA
Pi= 5.32 W
Ci= 0 F
Li< 10 H
Special conditions for safe use (x)
When fitted with 90V transient suppressors (T1 Option), the equipment is not capable of
passing the 500V isolation test. This must be taken into account upon installation.
4-20 mA HART
Entity Parameters Fieldbus Entity Parameters
Ui= 30 VDC Ui= 30 VDC
Ii(1)
(1) Total for transmitter
= 185 mA Ii= 300 mA
Pi(1) = 1.0 W Pi= 1.3 W
Ci= 0 F Ci= 0 F
Li< 0.97 mH Li< 10 
4004_RevDB.fm Page 18 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Quick Installation Guide
00825-0100-4004, Rev DB
December 2011 Rosemount 8800D
19
The enclosure may be made from aluminium alloy and given a protective polyurethane paint
finish; however, care should be taken to protect it from impact or abrasion when located in
Zone 0 environment. The polyurethane paint finish may constitute an electrostatic hazard
and must only be cleaned with a damp cloth.
When the equipment is installed, particular precautions must be taken to ensure taking into
account the effect of process fluid temperature, that the ambient temperature of the
electrical housing of the equipment meets the marked protection type temperature range.
ATEX Type N Certification
EN 60079-0 : 2009
EN 60079-11 : 2007
EN 60079-15 : 2010
N1 Certification No. Baseefa05ATEX0085X
ATEX Marking II 3 G
Ex nA ic IIC T5 Gc (-50 °C 
 Ta70 °C) 4 -20 mA HART
(-50 °C 
 Ta60 °C) Fieldbus
Input Parameters:
Maximum Working Voltage = 42 VDC Max 4-20 mA HART
Maximum Working Voltage = 32 VDC Max Fieldbus
Special conditions for safe use (x)
When fitted with 90V transient suppressors (T1 Option), the equipment is not capable of
passing the 500V isolation test. This must be taken into account upon installation.
The enclosure may be made from aluminium alloy with a protective polyurethane paint
finish. The polyurethane paint finish may constitute and electrostatic hazard and must only
be cleaned with a damp cloth.
When the equipment is installed, particular precautions must be taken to ensure, taking into
account the effect of process fluid temperature, that the ambient temperature of the
electrical housing of the equipment meets the marked protection type temperature range.
ATEX Flameproof Certification
EN 60079-0 : 2009
EN 60079-1 : 2007
EN 60079-11 : 2007
4004_RevDB.fm Page 19 Wednesday, November 23, 2011 3:06 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
