EMS FireCell FC-171-001 User manual

63 mm
THIS WAY
UP WHEN
WALL
MOUNTING
SIZE C SIZE C SIZE C
SIZE AA
SIZE AA
SIZE AA
Wireless Beacon
Installation Guide
1 Pre installation
4 Power device
To unlock, insert a 1.5
mm allen key to depress
the locking clip and turn
anticlockwise to release
as shown.
Unclip the battery retaining plate from the wireless module.
When fitting / replacing batteries; observe correct polarity,
using only specified batteries.
Connect the power jumper across the PIN header.
3 Fix mounting plate
2 Components
Part no Product description
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
!
Installation must conform to applicable local installation
codes and
should only be installed by a fully trained
competent person.
Ensure that the device is installed as per the site survey.
The use of a non-metallic spacer should be considered if
mounting the device on to a metal surface.
Do NOT Press the Log On button on a pre-programmed
device, as this will cause communication with the Control
Panel to be lost. Should this happen, delete the device from
the system and add it back on.
This device contains electronics that may be susceptible to
damage from Electrostatic Discharge (ESD). Take
appropriate precautions when handling electronic boards.
Beacon Wireless module
Mounting plate
14
2
Remove the mounting plate by turning the device
ANTICLOCKWISE, to release it from the mounting plate.
3
Battery retaining plate
5 Optional device locking 6 Configuration
To lock the beacon into the
wireless module, remove
the cut out section as
shown.
Use both fixing positions to ensure a firm fixing.
Use suitable fasteners and fixings.
Once powered, reassemble the device.
When wall mounting, ensure the mounting plate is fitted in the
orientation shown.
See the Specification section for compliance information.
CPR
FC-171-001
FC-171-002
FC-323-CA1
FC-323-CA2
FC-323-WA1
FC-323-WA2
White Wireless Sounder Base Only
[2]
Red Wireless Sounder Base Only [2]
White Ceiling Beacon Only [1]
Red Ceiling Beacon Only [1]
White Wall Beacon Only [1]
Red Wall Beacon Only [1]
Example shown:
FC-323-CA1
FC-171-001
1
4
2
3
©2021 EMS Ltd. All rights reserved Page 1 of 2 TSD068-99 Iss 8 24/11/2021 AJM
Cut out section
(shaded area)
The device’s loop address is configured within the user interface’s
menu structure.
Refer to the programming manual for full programming details.
Free to download from
www.emsgroup.co.uk
FireCell = MK98
Fusion = TSD062
WZM = TSD143

Configuration continued
Beacon flash rate (Set on beacon)
Audio monitoring (Set on wireless module)
Switch 2 on the two way switch is used to
configure the beacon flash rate. Switch 1 is
not used on this product.
www.emsgroup.co.uk
Wireless Module
PRESS HERE TO
LOG ON
IDENT
Beacon
Default setting: 1 Hz flash rate
Default setting: Audio monitoring disabled
ON
12
2
2
OFF
ON
SWITCH
2
FLASH
RATE
1Hz
0.5Hz
21
SWITCH 1 = NOT USED
The device has an audio self test feature which
is not used on this version of product.
Both switches should be OFF as shown.
2
21
SWITCHES 1 & 2 = NOT USED
Operating
temperature -10 to +55 °C
Storage
temperature 5 to 30 °C
Humidity 0 to 95% non-condensing
Supply 3x AA alkaline (Panasonic LR6AD Powerline / Varta
4006 Industrial) 3x C alkaline (Panasonic LR14AD
Powerline / Varta 4014 Industrial)
CAUTION!
Fitting of an incorrect battery type invalidates the product certification and
may result in poor performance.
IP rating IP54
Operating
frequency 868 MHz
Output
transmitter
power Auto adjusting 0 to 14 dBm (0 to 25 mW)
Beacon element
voltage 17 to 60 VDC operating at 18 VDC
Beacon element
current max. 40 mA at 1 Hz flash rate
Flash rate 0.5 Hz / 1 Hz (selectable)
Beacon coverage C-3-15 (ceiling mounted variant)
W-3.1-11.3 (wall mounted variant)
Dimensions (Ø x D) 120 x 145 mm
Weight 0.65 kg
Location Type A: For indoor use
Specification
Carrier Manufacturing Polska Sp. Z o.o. Ul. Kolejowa
24. 39-100 Ropczyce, Poland
Manufacturer
Year of
manufacture See devices serial number label
2012/19/EU (WEEE directive):
Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this
product to your local supplier upon purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more information
see www.recyclethis.info
Dispose of your batteries in an environmentally
friendly manner according to your local regulations.
European Union
directives
EMS declares that this device is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following
internet address: www.emsgroup.co.uk
Approved to
See part listing for associated products:
EN54-23:2010. Fire detection and fire alarm
systems. Part 23: Fire alarm devices. Visual alarm
devices.
[1]
EN54-25:2008. Incorporating corrigenda
September 2010 and March 2012. Fire detection
and fire alarm systems.
Part 25: Components using radio links.
[2]
Certification
Certification
body
CPR DoP 0359-CPR-00292
0905
14
Regulatory information
©2021 EMS Ltd. All rights reserved Page 2 of 2 TSD068-99 Iss 8 24/11/2021 AJM
