Enclume Dr4 User manual

Enclume DR4 Classic Oval w/Grid

Enclume Décor racks are the ultimate in

quality, design, strength and function.

Congratulations for owning one of the finest

storage racks made.

WARNING:

READ ALL OF THE INSTRUCTIONS BEFORE ASSEMBLING

AND USING YOUR RACK.

Enclosed you willfind everythingneed ed forthe assembly

and u se ofyou rpotrack.Twopeople make assembly

and installationeasier.The parts and hard ware inclu ded are:

Hardware included:

2 –SmallC eilingH ooks

2 –'S'H ooks 2"

2 -6”C hain

2 –5/16”x 7 /8 ”B u ttonhead Screws

4–5/16”x 1/2”B u ttonH ead Screws

2 –5/16”H ex N u ts

1 -3/16" H ex Key

Toggle Kit

Components included:

4–UprightA rms

1 –TopB ar

1 –O valRackB od y

6-Grid brackets -EGB

12 -P othooks -EP H S

1 -Grid

ASSEMBLY AND INSTALLATION INSTRUCTIONS

1) L ayrackbod y(oval)onfirm su rface.P rotectsu rface withcorru gated box ifnecessary.

2) Id entifythe fou r"UprightA rms." Usingthe 5/16" x 1/2" bu ttonhead screws attachthe u prightstothe ovalasshown.D onotfu lly

tightenscrewsatthistime.

3) L ocate the " TopB ar" and attachtothe fou r"UprightA rms" as shownindrawingu singthe two5/16" x 7 /8 " bu ttonhead screws

and the two5/16" hex nu ts.Tightenallscrews atthistime

4) Y ou rRackmaybe carefu llyanchored intosolid wood ofthe ceilingjoistorbeams.C arefu llymeasu re the areawhere the rackis

tobe hu ngand installthe ceilingscrew hooks(approximately16" apart).Ifyou are mou ntinginplasterboard ,u se the Toggles and

follow the instru ctionprovided inthe kit.

5) P lace the six grid bracketsoverthe sidesofthe rack,twooneachend ofthe ovaland fou rju stinside eachofthe u prightarms

withthe straightend ofthe brackets facingtoward sthe inside ofthe rack.N extplace the grid ontopofthe grid brackets.(See

note and d rawingnextpage).

6) Insertthe " S" hooks intoeachofthe remainingholes inthe topbarand the otherend throu ghone end ofthe chain.C arefu llylift

you rrackintoplace and attachthe otherend ofthe chainontothe ceilinghooks.

7 ) H angyou rheavieritemsonthe straightportionofthe rackbod yorthe centerofthe grid area.

8 ) A llofou rhammered steelracks are finished withanindu strialwax designed to give yearsofprotectiontothe rack.C leaningis

easilyd one withadampcloth.D rythorou ghlyaftercleaning.Ifatou ch-u piseverneeded we recommend a"P ledge" like wax

produ ct C ontinu ed

5/16" x 7 /8 "

5/16" x 1/2"

Note: Grid as shown in drawings is upside down for illustration purposes. Please turn grid over so crossbars that extend the

width of the grid are facing down. This will help to keep grid from sliding out of position when rack is in use.

It is important that your rack is assembled correctly. If the unit is assembled or

used incorrectly, it could become unstable and collapse, possibly causing injury.

If you need help, please call 1-877-ENCLUME REV. 5.22.03

Enclume Design Products, Inc.

24C olwellStreet,P ortH adlock,W A .98 339

P hone 360-38 5-6100 Fax 360-38 5-6156

www.enclu me.com

WARNING

Limited Warranty:Thisprod u ctiswarranted tobe free ofmaterialdefectsforaperiod offive yearsfrom the d ate ofpu rchase.C u stomer'sexclu sive remed yshall

be the repairorreplacementofthe defective prod u ctand shallbe su bjecttothe followingcond itions:(1)notice ofanydefectisreceived byEnclu me withinthe

warrantyperiod and (2)cu stomerretu rnsthe defective produ cttoEnclu me D esignP rod u cts,Inc.,24C olwellSt..,P ortH ad lock,W A 98 339,postage prepaid

within20 d aysfollowingaretu rnau thorizationnu mber(whichmaybe obtained bytelephoningthe nu mberatthe bottom ofthis instru ctions)beingprovided tothe
