Enclume CWS8KD User manual

Enclum e 8 -TierC ookware Stand
KnockD own V ersion
C W S8 kd
Thank you for selecting Enclume.
You will not be disappointed.
Enclume is the No. 1 brand in pot racks and
You now own one of the finest racks made.
W A RNING:
REA D A L L O FTH ESE INSTRUC TIO NS B EFO RE
FINISHED PRODUCT IN USE A SSEM B L ING A ND USING Y O UR RA C K.
Enclosed you will find everything needed for the ASSEMBLY POSITION
assembly and use of your storage rack.Twopeople At Step 6) Completion
are highlyrecommended forassemblyand make
this process much easier and less frustrating,
The parts and hardware included are:
H ardware inclu ded:
24 – Barrel Bolt – #10 x 24 x 7/16”
24 – Barrel Screw – #10 x 24 x 5/16”
3 – Felt Pads
2 – 5/32” Hex Key Wrenches
C omponents inclu ded:
3 – Uprights
8 – Shelf Sets (numbered 1 - 8);
Each set contains 3 shelf pieces for a total 24 pieces
ASSEMBLY INSTRUCTIONS
1) Unpack the rack box, layout the contents, and match them to the hardware and component lists above
2) Place two of the three uprights on a firm surface with what will be the lower ends of the uprights (marked with a
small piece of masking tape)extending to your right
3) Locate ShelfSet#8 (set of three), the largest and bottom layer of shelves. Using two of the three shelf pieces,
attach the two shelf pieces to an upright by inserting the barrelscrews and bolts as follows:
a) First through the hole in one end of shelf piece,
b) Then through the lowest hole in the upright, and then
c) Through the hole in the other shelf.
Connect the two shelf pieces surrounding the upright by inserting a barrelscrewand bolt,making sure the
upright is between the two shelves. You may use both hex wrenches to tighten this connection, but please,donot
fu llytighten atthis time.
NO TE:Y ou willbe revisitingthe process ofthis instru ction 3)withothershelfsets.
4) Using the third shelf piece from the Shelf Set you are working with, repeat Step 3) to connect the two remaining
open shelf pieces to the second upright.
** PLEASE TURN THIS INSTRUCTION OVER **
Three Uprights
Shelf Set #1
Shelf
Set #8
Shelf
Set #2 Shelf
Set #3 Shelf
Set #4
Shelf
Set #5 Shelf
Set #6 Shelf
Set #7

CWS8kd 8-Tiered Cookware Stand –Knock Down Version PAGE 2
ASSEMBLY INSTRUCTIONS, continued
5) Locate the third upright, make sure the marked lower end is to the right, and then connect this upright to the
remaining two open shelf pieces with the barrel screws and bolts, as in Steps 3) and 4).
6) Locate ShelfSet#1, move to the far left of your rack, and repeat steps 3)-5) to install the highest (and smallest)
shelf layer to at the top of your cookware stand.
7) Your cookware stand can now be stood up, so you have the option of finishing assembly with the stand lying
down or upright, whichever is the easiest for you and your partner to work from.
8) Repeat Steps 3 – 5 to connect the remaining six ShelfSets (sets 2-7 )to the three uprights.
9) Place the assembled rack upright on a level surface and using the two hex wrenches, tighten the TO P shelves
first, then the B O TTO M shelf, then square up the stand and securely tighten all barrel screws and bolts on the
remaining six shelves.
10) Apply the enclosed felt pads to the underside of the bottom tab of each of the three uprights.
.
USE INSTRUCTIONS
1) Take care to place your cookware rack on a solid, level surface in an area out of the way from foot traffic.
2) Place heavier pots on the lower shelves and avoid over-loading top shelves to create a possible top-heavy
condition and rack instability.
3) Enclume’s hammered steel racks are finished with an industrial wax which is designed to provide years of
protection to your cookware stand. Cleaning is easily done with a damp cloth, and dry thoroughly after cleaning.
If a touch-up is ever needed a commercial wax product is recommended.
It is important that your rack is assembled correctly. If assembled or used
incorrectly, it could become unstable and collapse, possibly causing injury.
L imited W arranty:This product is warranted to be free of defects in material or workmanship for a period of five years from the
date of your purchase. Your exclusive remedy shall be the repair or replacement of the defective product, and shall be subject to the
following conditions: (1) you provide notice of any defect to Enclume within the warranty period, and (2) you return the defective
product to Enclume Design Products, Inc.( 24 Colwell St., Port Hadlock, WA 98339), postage prepaid within 20 days of obtaining a
return authorization number from Enclume (which may be obtained by telephoning the number at the bottom of this instructions).
There are no other warranties, expressed or implied, applicable to this product. TH ERE A RE NO W A RRA NTIES O FM ER-
C H A NTA B IL ITY O R FITNESS FO R A P A RTIC UL A R P URP O SE.ENC L UM E SP EC IFIC A L L Y D ISC L A IM S A L L
INC ID ENTA L O R C O NSEQ UENTIA L D A M A GES A RISING O UT O FTH E P URC H A SE O R US E O FTH IS P RO D UC T.
If you need help, please call 1-877-362-5863
Enclu me D esign P rodu cts,Inc.
24 Colwell Street, Port Hadlock, WA 98339
Phone [phone] Fax [phone]
www.enclume.com
WARNING
