Safety Warnings
• This product is only suitable for connection to 240V~50Hz supply. It is recommended that this light is
installed by a electrician in accordance with current IEE Wiring Regulations and local Building
Regulations
• Before installing your light always switch off the mains supply and remove the appropriate fuse or
switch off the appropriate circuit breaker before commencing installation.
• This is a Class I and must be connected to Earth. The terminal blocks are supplied according to
requirements of the
• Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type H05RN-F
1.0mm2 (not supplied) to selected site, ensuring it is adequately protected through the full length of the
cable run, it must come out of the surface of the mounting surface in line with the entry to the
• Except where installed in a conduit or duct , which provides equivalent protection against mechanical
damage, a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable
for use as a protective conductor, or be of insulated concentric construction. Buried cables shall be marked
by cable covers or a suitable marking tape. Buried conduits and ducts shall be suitably Buried
cables, conduits and ducts shall be at a depth to avoid being damaged by any reasonably
foreseeable disturbance of the ground.
• Never bulbs of a higher wattage than those on the label (as these may cause overheating and
damage the
• This product contains delicate parts. Take care during installation and maintenance to avoid breakages
• If you are in any doubt about your competence please consult a electrician.
• If any is made it will invalidate the warranty and may render the product unsafe.
• This product must only be installed to a solid, surface, such as concrete, decking or paving slabs. It
must NOT be installed on soil.
Assembly/ User Instructions
Please read these instructions carefully before and retain for reference.
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly.
Ensure that the product is fully assembled as illustrated before use.
The Light pack contains:
Light
Terminal connection block(s).
Fixing pack.
6 x Glass panels
The following tools may be required:
Selection of cross and head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
These assembly diagrams are intended as a guide – if in doubt consult a electrician.
Before you start
Care Information
Allow 10 minutes to cool before replacing, adjusting or cleaning.
Clean with a dry cloth only. Do not use liquid or abrasive cleaners on this product.
Installation and Safety Instructions
Outdoor Post Light Fitting
76549_05052023
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
UK Manufacturer: BH17 7BY

1. Determine the position of your light taking into account the entry position of the cable and make sure
there is cable coming out of the to connect to the terminal block. Ensure that the mounting
surface is solid, preferably a brick or block and ensure that there are no other cables or pipes beneath
the surface.
2. Diagram A: Connect the house wiring to the terminal block (Fig 2.). Remove the terminal bracket from the
base. Remove the terminal block box lid. Connect the mains supply. Replace terminal block box lid. Replace
terminal bracket onto base. NOTE: This is a Class I and must be earthed. Check the seal, use
sealant if required.
3. Diagram B. Use appropriate to secure the post to the mounting surface (1&2)
4. Fit the glass pieces into their slots in the frame (3).
5. Fit the bulb (not supplied) into the lamp holder (4). NOTE: Never a bulb of a higher wattage than that
on the label (as this may cause overheating and damage the
6. Attach the lid of the with the hex nuts (5), ensuring a good seal to maintain ingress protection.
7. Turn on the power and test.
Assembly/ User Instructions Continued
Diagram A
Diagram B
4
5
3
