Endon YG-861-SS User manual

The Light pack contains:
Wall light and bracket.
Terminal connection block.
The following tools may be required:
Selection of cross and flat head screwdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Electrical insulation tape.
INSTRUCTION MANUAL
These products are only suitable for connection to a 240V~50Hz supply.
It is recommended that these lights are installed by a qualified electrician in accordance with current IEE
Wiring Regulations and Building Regulations (Part P).
These fittings should be connected to a lighting circuit protected by a 5 amp fuse (or a 6 amp miniature circuit
breaker).
These lights have an IP44 (splash proof) rating suitable for use outdoors.
Run supply wire from a 5-amp electrical supply using double insulated 3-core cable of type H05RN-F 1.0mm2
(not supplied) to selected site, ensuring it is adequately protected through the full length of the cable run, it
must come out of the flat surface of the mounting surface in line with the entry to the fitting.
Except where installed in a conduit or duct , which provides equivalent protection against mechanical damage,
a cable buried in the ground shall incorporate an earthed armour or metal sheath or both, suitable for use as a
protective conductor, or be of insulated concentric construction. Buried cables shall be marked by cable
covers or a suitable marking tape. Buried conduits and ducts shall be suitably identified. Buried cables,
conduits and ducts shall be at a sufficient depth to avoid being damaged by any reasonably foreseeable
disturbance of the ground.
These products contain breakable parts – be careful during handling and maintenance to avoid breakage.
The shades can become hot in use. Switch off and allow 10 minutes to cool before cleaning (using a dry cloth
only – do not use liquid or abrasive cleaners).
If the covers are broken or cracked then they must be replaced immediately to preserve the water ingress
protection, please consult your retailer. This is represented by the symbol
IMPORTANT: To achieve maximum corrosion resistance the surface of the Stainless Steel must be kept clean.
Surface contamination and the formation of deposits are critical factors which may lead to drastically reduced
life. An example is salt deposits from marine conditions. Cleaning with soap or a mild detergent and warm
water followed by a careful clean water rinse and finally wiping dry is usually adequate for most S/S items
used in the domestic environment. Care must be taken to turn off the mains supply until the cleaning process
has been completed and the fitting is completely dry.
If any modification is made it will invalidate the warranty and may render the product unsafe.
Before you start
Please read these instructions carefully before fitting your new light and retain for reference.
Switch off the mains supply and remove the appropriate fuse or switch off the appropriate circuit breaker
before commencing installation.
Ensure that no one else has access that would enable the supply to be inadvertently reconnected.
Check the packaging and make sure that you have all the required parts.
Follow each assembly step in order to prevent incorrect assembly
Make sure all screws / nuts, including electrical connections etc are fully tightened before use.
This type of Light Fitting may be connected to a Dimmer if a Tungsten incandescent bulb is used. If
a CFL type bulb is fitted then these cannot (generally) be controlled by a dimmer.
YG-861-SS and YG-862-SS / Outdoor wall fittings.
Safety Warnings

These assembly diagrams are intended as a guide – if in doubt consult a qualified electrician.
NOTE – The uplight unit YG-862-SS CANNOT be used as a downlight and the downlighter – YG-861-
SS CANNOT be used as an uplight. This is because of the position on the drain holes in the two
construction.
Assembly / user instructions
Endon Lighting
LS9 0SE
20150807
N210 117
Diagram A
Diagram B
Diagram C
1. Determine the position of your light
fitting taking into account the exit
position of the cable. Ensure that the
mounting surface is solid, preferably
a brick or block wall and ensure that
there are no other cables or pipes
beneath the surface. Use
appropriate fixings. Wall plugs and
screws as supplied are shown here.
2. Diagram A. Separate the plastic
back plate from the fitting by
removing the two domed nuts /
washers (1) on the front of the
fitting. Leave the threaded (2) bolts
in the back plate.
3. Diagram B. The internal terminal
block (3) can be removed from its
mounting position inside the back
plate to ease fitment of the back
plate. Use the back plate as a
template to mark the screw holes.
Make sure the back plate is
correctly aligned with the drain
hole (4) at the lowest position.
4. Use a sharp object such as a
screwdriver to pierce the rubber
grommet in the back plate. Feed the
incoming cable (5) through the
rubber grommet and attach the back
plate to the wall. Do not over tighten
as this could damage the back plate.
5. Connect the house wiring to the
internal terminal block (3). NOTE:
This is a Class I fitting and must
be earthed.
See wiring details.
6. Diagram C. Place the fitting over
the back plate, ensuring that the
bolts in the back plate are aligned
with the holes in the front of the
fitting. Replace the domed nuts /
washers to secure the fitting. Fit the
bulb (6) (not supplied) into the lamp
holder. NOTE: Never fit bulbs of a
higher wattage or of a type other
than those specified on the label
(as these may cause overheating
and damage the fitting).
7. Fit the cage (7) and cover (8)
together with the 3 x securing
screws.
8. Turn on the power and test.
Uplighter
Downlighter
