EngyCal® RS33
Steam calculator
These instructions are Brief Operating Instructions.
For detailed information, refer to the Operating Instructions and other
documentation on the CD-ROM provided or under "www.endress.com/
deviceviewer".
These Brief Operating Instructions do not replace the Operating Instructions.
The complete device documentation consists of:
•These Brief Operating Instructions
• A CD-ROM with:
– The Operating Instructions.
– Approvals and safety certificates.
– Other device-specific information.
KA00293K/09/EN/01.11
71134232

Table of contents EngyCal® RS33
2 Endress+Hauser
Table of contents
1 Safety instructions ......................................... 3
1.1 Designated use ............................................... 3
1.2 Installation, commissioning and operation .................................. 3
1.3 Operational safety .............................................. 3
1.4 Return ................................................... 3
1.5 Notes on safety conventions and icons .................................... 3
2 Identification ............................................. 5
2.1 Device tag ................................................. 5
2.2 Scope of delivery .............................................. 5
2.3 Certificates and approvals .......................................... 6
3 Installation .............................................. 6
3.1 Incoming acceptance, transport and storage ................................. 6
3.2 Dimensions ................................................. 7
3.3 Installation conditions ............................................ 9
3.4 Installation instructions ........................................... 9
3.5 Temperature sensor installation instructions ................................. 14
3.6 Pressure sensor installation instructions ................................... 15
4 Wiring ................................................. 16
4.1 Connection requirements ......................................... 16
4.2 Quick wiring guide ............................................. 16
4.3 Connecting the sensors ........................................... 19
4.4 Outputs .................................................. 25
4.5 Communication .............................................. 25
4.6 Post-connection check ........................................... 27
5 Operation .............................................. 28
5.1 General notes for operation ......................................... 28
5.2 Display and operating elements ....................................... 28
5.3 Operating matrix .............................................. 31
6 Commissioning ........................................... 32
6.1 Quick commissioning/make it run ..................................... 32

EngyCal® RS33 Safety instructions
Endress+Hauser 3
1 Safety instructions
Safe operation of the device is only guaranteed if the Operating Instructions have been read and
the safety instructions they contain have been observed.
1.1 Designated use
The steam calculator is a flow computer for calculating the mass and energy flow of steam. The
mains powered device is designed for use in industrial environments.
• The manufacturer cannot take responsibility for any damage caused by misuse of the device.
It is not permitted to make any changes or reconstruction to the device.
• The device may be operated in built-in state only.
1.2 Installation, commissioning and operation
The device is safely manufactured using state-of-the-art technology and complies with the
respective regulations and EU Directives. The device could be dangerous if it is incorrectly
installed or used.
Installation, wiring and maintenance of the device must be carried out only by trained, skilled
personnel authorized to perform such work and instructed by the facility's owner-operator. The
skilled personnel must have read and understood these Operating Instructions and it is mandatory
for them to follow the instructions they contain. The operator must ensure that the measuring
system is correctly wired in accordance with the wiring diagrams. When the housing cover is
removed, the shock protection is disabled (danger of electrocution). The housing may be opened
by trained skilled personnel only.
The device may be operated in built-in state only.
1.3 Operational safety
Technical improvement
The manufacturer reserves the right to improve and update the technical details. For details of
improvements or additions to these instructions, please contact your local sales organization.
1.4 Return
For a return, e.g. in case of repair, the device must be sent in protective packaging. The original
packaging offers the best protection. Repairs must only be carried out by your supplier's service
organization.
When sending in for repair, please enclose a note with a description of the error and the
application.
1.5 Notes on safety conventions and icons
The devices are safely manufactured and tested using state-of-the-art technology and have left
the factory in safety-related flawless condition. The devices comply with the respective
regulations and EU Directives. The devices could be dangerous if incorrectly installed or used.

Safety instructions EngyCal® RS33
4 Endress+Hauser
Therefore, consequently observe safety notes which are labeled with the following safety icons
and symbols in these operating instructions:
Symbol Meaning
DANGER
A0011189-EN
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will
result in serious or fatal injury.
WARNING
A0011190-EN
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can
result in serious or fatal injury.
CAUTION
A0011191-EN
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can
result in minor or medium injury.
NOTICE
A0011192-EN
NOTICE!
This symbol contains information on procedures and other facts which do not result
in personal injury.

EngyCal® RS33 Identification
Endress+Hauser 5
2 Identification
2.1 Device tag
2.1.1 Nameplate
Compare the nameplate on the device with the following figure:
A0013583
å 1 Device nameplate (example)
1 Device tag
2 Order code and serial number
3 Supply voltage
4 Power consumption
5 Firmware version
6 Approvals, if available
7 Ambient temperature range
8 Device revision
9 Equipment protected throughout by double insulation or reinforced insulation
10 Place and year of manufacture
2.2 Scope of delivery
The scope of delivery of the steam calculator comprises:
•Steam calculator (field housing)
• Brief Operating Instructions in paper form, Operating Instructions and additional
documentation (on CD-ROM)
• Optional interface cable and DVD set with FieldCare Device Setup parameter configuration
software

Installation EngyCal® RS33
6 Endress+Hauser
• Optional Field Data Manager software MS20
•Optional mounting hardware for top-hat rail, panel mounting, pipe mounting
• Optional overvoltage protection
Please note the device accessories in Section 8 ’Accessories’ of the Operating Instructions
on CD-ROM.
2.3 Certificates and approvals
The steam calculator complies with the general requirements for steam calculators according to
OIML R75 and EN-1434.
According to European law, steam calculators are not subject to mandatory verification.
However, approval as part of individual measuring point verification is possible. Furthermore,
national type approvals are currently pending for the device.
CE mark, declaration of conformity
The device is safely built and tested according to state-of-the-art technology and has left the
factory in perfect condition as regards technical safety. The device meets the relevant standards
and directives as per EN 61010-1 "Safety requirements for electrical equipment for measurement,
control and laboratory use".
Thus, the device described in these Operating Instructions meets the legal requirements of the
EU Directives. The manufacturer confirms successful testing of the device by affixing to it the
CE mark.
3 Installation
3.1 Incoming acceptance, transport and storage
The permitted environmental, storage and transportation conditions must be complied with. For
detailed specifications, refer to the "Technical data" chapter in the Operating Instructions on CD-
ROM.
3.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Are the packaging or contents damaged?
• Are the delivered goods complete? Compare the scope of delivery with your order information.
3.1.2 Transport and storage
Observe the following points:
• Pack the device in such a way as to protect it reliably against impact for storage (and
transportation). The original packaging provides optimum protection.
• The permitted storage temperature range is –40 to +85 °C (–40 to +185 °F); storage in the
temperature limit ranges is possible for a limited time only (maximum of 48 hours).

EngyCal® RS33 Installation
Endress+Hauser 7
3.2 Dimensions
A0013438
å 2 Dimensions of the device

Installation EngyCal® RS33
8 Endress+Hauser
A0014169
å 3 Dimensions of mounting plate for wall, pipe and panel mounting
A0014171
å 4 Dimensions of the panel cutout

EngyCal® RS33 Installation
Endress+Hauser 9
A0014610
å 5 Dimensions of top-hat rail adapter
3.3 Installation conditions
The device with field housing and accessories is suitable for wall mount, pipe mounting, panel
mounting and top-hat rail installation 1).
The orientation is only determined by the legibility of the display. Connections and outputs are
fed out of the bottom of the device. The lines are connected via coded clamps.
Operating temperature range: –20 to 60 °C (–4 to 140 °F)
Further information, see "Technical data".
NOTICE
Overheating of the device due to insufficient cooling
►To prevent heat build-up, do not expose the device to excessive heat or strong direct sunshine.
Operating the device in the upper temperature limit range decreases the operating life of the
display.
3.4 Installation instructions
3.4.1 Wall mounting
1. Use the mounting plate as the template for drilled holes, dimensions (® å 3, ä 8)
2. Attach the device to the mounting plate and fasten it in place from the rear using 4 screws.
3. Fasten the mounting plate to the wall using 4 screws.
1) According to UL approval panel or surface mountable only.

Installation EngyCal® RS33
10 Endress+Hauser
A0014170
å 6 Wall mounting
3.4.2 Panel mounting
1. Make the panel cutout in the required size, dimensions (® å 4, ä 8)
2.
A0014172
å 7 Panel mounting
Attach the seal (item 1) to the housing.

EngyCal® RS33 Installation
Endress+Hauser 11
3.
A0014173
å 8 Montageplatte für Schalttafel-Montage vorbereiten
Screw the threaded rods (item 2) into the mounting plate (dimensions (® å 3, ä 8)).
4.
A0014174
å 9 Panel mounting
Push the device into the panel cutout from the front and attach the mounting plate to the
device from the rear using the 4 screws provided (item 3).
5. Fasten the device in place by tightening the threaded rods.

Installation EngyCal® RS33
12 Endress+Hauser
3.4.3 Support rail/top-hat rail (to EN 50 022)
1.
A0014176
å 10 Preparing for top-hat rail mounting
Fasten the top-hat rail adapter (item 1) to the device using the screws provided (item 2)
and open the top-hat rail clips.
2.
A0014177
å 11 Top-hat rail mounting
Attach the device to the top-hat rail from the front and close the top-hat rail clips.

EngyCal® RS33 Installation
Endress+Hauser 13
3.4.4 Pipe mounting
1.
A0014178
å 12 Rohrmontage vorbereiten
Pull the steel belts through the mounting plate (dimensions (® å 3, ä 8)) and fasten
them to the pipe.
2.
A0014179
å 13 Pipe mounting
Attach the device to the mounting plate and fasten it in place using the 4 screws provided.

Installation EngyCal® RS33
14 Endress+Hauser
3.5 Temperature sensor installation instructions
A0008603
å 14 Installation types for temperature sensors
A - B For cables with a small cross-section, the sensor tip must reach to the piping axis or a little farther
(=L).
C - DSlanted orientation.
The immersion length of the thermometer influences the accuracy. If the immersion length is
too small, errors in the measurement are caused by heat conduction via the process connection
and the container wall. For installation in a pipe, therefore, the recommended installation depth
ideally corresponds to half of the pipe diameter.
• Installation possibilities: Pipes, tanks or other plant components
• Minimum immersion depth = 80 to 100 mm (3.15 to 3.94 in)
The immersion depth should be at least 8 times the diameter of the thermowell. Example:
Thermowell diameter 12 mm (0.47 in) x 8 = 96 mm (3.8 in). We recommend a standard
immersion depth of 120 mm (4.72 in).
For pipes with small nominal diameters, ensure that the tip of the thermowell extends far
enough into the process so that it also protrudes past the axis of the pipe
((® å 14, ä 14), item A and B). Another solution may be diagonal installation
((® å 14, ä 14), item C and D). To determine the immersion length or installation depth,
all parameters of the thermometer and the process to be measured must be taken into
account (e.g. flow velocity, process pressure).
See also recommendations for installation EN1434-2 (D), figure 8.

EngyCal® RS33 Installation
Endress+Hauser 15
3.6 Pressure sensor installation instructions
A0014527
å 15 Measuring arrangement for pressure measurement in steams
1 Pressure sensor
2 Shutoff device
3 U-shaped water pocket
4 O-shaped water pocket
• Mount the pressure sensor with the water pocket pipe above the tapping point.
The water pocket pipe reduces the temperature to almost ambient temperature.
• Fill the water pocket pipe with liquid before commissioning.

Wiring EngyCal® RS33
16 Endress+Hauser
4 Wiring
4.1 Connection requirements
!WARNING
Electrical hazard
►The entire electrical connection must be carried out only while the device is de-energized.
!CAUTION
Observe additional information
►Before commissioning, ensure that the supply voltage corresponds to the specification on the
nameplate..
►Provide a suitable switch or power-circuit breaker in the building installation. This switch
must be installed close to the device (so that it is easily accessible) and marked as a circuit
breaker.
►An overload protection unit (rated current = 10 A) is required for the power cable.
4.2 Quick wiring guide
A0013439-EN
å 16 Connection diagram of the device
Terminal assignment
Terminals Terminal assignment Inputs
1 + RTD power supply Temperature
(Optionally RTD or current input)
2 - RTD power supply
5 + RTD sensor

EngyCal® RS33 Wiring
Endress+Hauser 17
6 - RTD sensor
52 + 0/4 to 20 mA input
53 Ground for 0/4 to 20 mA input
3 + RTD supply Pressure
4 - RTD supply
7 + RTD sensor
8 - RTD sensor
54 + 0/4 to 20 mA input
55 Ground for 0/4 to 20 mA input
10 + pulse input (voltage) Flow
(Optionally pulse or current input)
11 - pulse input (voltage)
50 + 0/4 to 20 mA or current pulse (PFM)
51 Ground for 0/4 to 20 mA input, flow
80 + digital input 1 (switch input) • Activate tariff counter 1
• Time synchronization
• Lock device
81 - digital input (terminal 1)
82 + digital input 2 (switch input) • Activate tariff counter 2
• Time synchronization
• Lock device
81 - digital input (terminal 2)
Outputs
60 + pulse output 1 (open collector) Energy, volume or tariff counter.
Alternative: limits/alarms
61 - pulse output 1 (open collector)
62 + pulse output 2 (open collector)
63 - pulse output 2 (open collector)
70 + 0/4 to 20 mA/pulse output Current values (e.g. power) or
counter values (e.g. energy)
71 - 0/4 to 20 mA/pulse output
13 Relay 1 normally open (NO) Limits, alarms
14 Relay 1 normally open (NO)
23 Relay 2 normally open (NO)
24 Relay 2 normally open (NO)
90 24V sensor power supply (LPS) 24 V power supply
(e.g. for sensor power supply)
91 Power supply ground
Power supply

Wiring EngyCal® RS33
18 Endress+Hauser
L/+ L for AC
+ for DC
N/- N for AC
- for DC
4.2.1 Opening the housing
A0014071
å 17 Opening the housing of the device
1 Terminal assignment labeling
2 Terminals

EngyCal® RS33 Wiring
Endress+Hauser 19
4.3 Connecting the sensors
4.3.1 Flow
Flow sensors with external power supply
A0013521
å 18 Connecting a flow sensor
wVoltage pulses or contact sensors including EN 1434 Type IB, IC, ID, IE
xCurrent pulses
y0/4 to 20 mA signal
Flow sensors with power supply via the steam calculator
A0014180
å 19 Connecting active flow sensors
w4-wire sensor
x2-wire sensor

Wiring EngyCal® RS33
20 Endress+Hauser
Setting for flow sensors with pulse output
The input for voltage pulses and contactors is subdivided into various types as per EN1434 and
provides a supply for switch contacts.
Pulse output of the flow
sensor
Setting at the
Rx33
Electrical connection Notes
Mechanical contact
A0015360
Pulse ID/IE up to
25 Hz
A0015354
wSensor
xRx33
As an alternative,
"Pulse IB/IC+U"
up to 25 Hz can
be chosen. The
current flow via
the contact is
then lower
(approx.
0.05 mA instead
of approx. 9 mA).
Advantage: lower
power
consumption,
disadvantage: less
immunity to
interference.
Open collector (NPN)
A0015361
Pulse ID/IE up to
25 Hz or up to
12.5 kHz
A0015355
wSensor
xRx33
As an alternative,
"Pulse IB/IC+U"
can be chosen.
The current flow
via the transistor
is then lower
(approx.
0.05 mA instead
of approx. 9 mA).
Advantage: lower
power
consumption,
disadvantage: less
immunity to
interference.
Active voltage
A0015362
Pulse IB/IC+U
A0015356
wSensor
xRx33
The switching
threshold is
between 1 V and
2 V
