Eneo HDB-2280Z10IR D User manual

DE
EN
FR
Quick Installation Guide
1/3” HDcctv Camera, WDR,
Day&Night, 1920x1080, 5.1-
51mm, 10x AF Zoom, Infra-
red, 12/24V
HDB-2280Z10IR D

2
Table of content
Notes on safety .............................................................................................................3
Parts supplied ...............................................................................................................3
Part names .....................................................................................................................4
Installation instructions ...............................................................................................5
Pan & Tilt adjustments.....................................................................................................................................................6
Power supply connections.............................................................................................................................................7
Operating instructions .................................................................................................9
Using OSD controller........................................................................................................................................................9
Description of the joystick operation ..........................................................................................................9
Description of the ZOOM&FOCUS adjustment .......................................................................................9
Set the video format according to system, EX-SDI or HD-SDI........................................................................ 10
OSD menu startup ......................................................................................................................................................... 10
OSD menu table.............................................................................................................................................................. 11
Further information ....................................................................................................13

3
EN
Parts supplied
• Plastic Anchor: 6 x 30mm (4pcs)
• Mounting Screw: 4 x 30mm (4pcs)
• Camera
• Cable Signal Sticker
• Operating Instruction
• Mounting Template
• Assembly Screw: 4 x 14mm (4pcs)
• Torque Wrench: 3mm (1pc)
• Wiring Connector: (1pc)
• Video Sub-out Cable (1pc)
• Easy Bracket
Notes on safety
Please also pay attention to the enclosed safety instructions, and carefully read through
this instruction guide before initial operation.
Important points of warning are marked with a caution symbol.
iImportant points of advice are marked with a notice symbol.

4
Part names
Sunshield bolt
Power cable
OSD setup control cover
Dual window
Front case Rear case
Lock/unlock screw
Bracket Easy bracket
Sunshield

5
EN
Part names
Sunshield bolt
Power cable
OSD setup control cover
Dual window
Front case Rear case
Lock/unlock screw
Bracket Easy bracket
Sunshield
Installation instructions
CAUTION: The camera’s base should be attached to a structural
object, such as concrete, hard wood, wall stud or ceiling rafter
that supports the weight of the camera. If necessary use appro-
priate mounting material (e.g. anchors) instead of the material
enclosed with the camera.
1. Locate the mounting template at the installation position and drill the ceiling or
wall if needed. iThe easy bracket can not be installed on the ceiling.
2. Place the easy bracket on pre-drilled position and x it through using mounting
screws(4x30mm). Skip this step when an easy bracket is not installed.
3. Route the power cable to the connecting place. Hook up the camera bracket with
the easy bracket as illustrated below.
4. Fix the camera bracket through using assembly screws (4x14mm).
5. Set the camera’s viewing angle.
6. Put the sunshield to the camera unit and tighten the sunshield-bolts.
1
2
3
4
Assembly Screw: 4x14mm
TorqueWrench
Mounting Screw 1: 4x30mm
Cable exit

6
CAUTION:
Extreme care should be taken NOT to scratch the window in front
of lens.
Care should be taken the cable is NOT to be damaged, kinked or
exposed in the hazardous area.
Do not expose the camera directly to a strong light source such
as the sun or spot light.
Pan & Tilt adjustments
• Unlock the screw on the camera bracket through using the torque wrench supplied
• Set the camera’s viewing angle then lock the screw on the bracket.
Adjustment of viewing angle with a bracket
1. Pan limit: Pan is limited to +/- 90°.
90
°9
0°
Torque wrench
Lock/Unlock Screw

7
EN
2. Tilt limit: Tilt is limited to 0°(2°) min ~ 90° max. for wall(ceiling) installation respec-
tively with reference to the wall(ceiling) when the inclination of camera module is
0°, that is, the image is aligned horizontally.
90° 88°
on the wall on the ceiling
3. Inclination limit (Horizontal image alignment): Inclination limited to +/-90° max.
±90°
Power supply connections
Make sure the power is removed before the installation. Camera can work with either
24AC or 12VDC, dual voltage power. Primary and secondary grounds are completely
isolated to avoid the possible ground-loop problems.
iIn case that HD-SDI/EX-SDI Inputs are not supported in monitor, please use HD-SDI/
EX-SDI Converter to connect HD-SDI/EX-SDI cable with monitor. Some computer moni-
tors or TVs may not support 30p/25p. In this case, HD-SDI/EX-SDI DVR which can convert
the frame rate to 60p/50p is highly recommended. Please check specication of monitor
before installation.

8
Attach the Signal Assignment Sticker in a visible spot for wiring reference.
VIDEO (BNC)
AC24V/DC12V (Red wire)
AC24V/GND (Black wire)
RTX+/RS485 (White wire)
RTX-/RS485 (Gray wire)

9
EN
Operating instructions
Using OSD controller
Setup menu can be accessed and controlled by OSD control joy stick on the side of cam-
era unit. Five commands are available with the joy stick.
SUB-OUT
Description of the joystick operation
1. SET Key (●) : Access to the menu or enter the setting.
2. UP/DOWN Key (▲/▼) : Choose the desired sub-menu and to move the cursor up or
down.
3. LEFT/RIGHT Key (◄/►) : Set up the value of the selected menu. Used to adjust the
desired menu selection and to move the cursor left or right.
Description of the ZOOM&FOCUS adjustment
iWorks only when OSD Menu is inactive.
1. ▲: Zoom In
2. ▼: Zoom Out
3. ◄: Focus Near
Video Sub-out Connector
Cover Open
Video format Switch OSD Control Joy Stick

10
4. ►: Focus Far
Set the video format according to system, EX-SDI or HD-SDI
To select the camera’s output video format (EX-SDI or HD-SDI), use the Video format
Switch on the side of the camera. Only one format can be used at a time (see also“Using
OSD controller”).
OSD menu startup
Press‘●’ (OSD menu Joy stick key) down to access the setup menu mode.
• EXIT : Exits the setup menu without save.
• SAVE : Saves the menu settings.
• DFLT : Reset to the factory defaults.
• BACK : Go back to the previous menu.
1M~120M via RG59u or 5C2V cable
Camera (HD-SDI) DVR (HD-SDI)
Camera (HD-SDI)
1M~120M via
RG59u or 5C2V
cable 350M+ via RG59u or
5C2V cable
HDA-3000E
(EX-SDI) HDA-3000E (EX-SDI)
1M~120M via
RG59u or 5C2V
cable
DVR (HD-SDI)
Camera (EX-SDI)
350M+ via RG59u or 5C2V cable
HDA-3000E
(EX-SDI)
1M~120M via
RG59u or 5C2V
cable
DVR (HD-SDI)
350M+ via RG59u or 5C2V cable
Camera (EX-SDI) DVR (EX-SDI)
Camera (HD-SDI) DVR (HD-SDI)
1M~120M via
RG59u or 5C2V
cable 1M~120M via RG59u or
5C2V cable
HDA-3000E
(HD-SDI) HDA-3000E (HD-SDI)
1M~120M via
RG59u or 5C2V
cable
