ENFORCER SB-P1012-26Q User manual

ENFORCER Plug-and-Play Backup Power
4SECO-LARM U.S.A., Inc.
Backup time is shorter than
claimed
•On initial installation, be sure that batteries have been charged for
24 hours before testing backup time
The power plug does not fit my
unit
•You may need to provide a power tip adapter to connect to your
device (two adapters, both male and female for the B-L10V1-20Q)
Device does not turn on when
installed
•Check to see that all plugs are firmly connected at the device, the
Backup Power unit, power adapter, and the AC wall outlet
•Check to see that the AC outlet is live
•Ensure that the Backup Power unit's power LED is lit
•Check for a short or overload. The Backup Power unit is designed
to cut power when a short-circuit or overload is detected
•Ensure that the battery’s polarity is correct and reverse if needed
( B-P1012-26Q)
•Check that the device’s voltage is compatible (12VDC for the
B-P1012-26Q, and either 5, 7.5, 9, or 12VDC for the
B-L10V1-20Q)
•If using the B-L10V1-20Q, press the “Off/Reset” button to reset
voltage output
During a power outage, power is
not provided to device
•Check for a short or overload. The Backup Power unit is designed
to cut power when a short-circuit or overload is detected
•Ensure that the Backup Power unit battery’s polarity is correct and
reverse if needed ( B-P1012-26Q only)
The alarm sounds (long beep) and
the red alarm LED
( B-L10V1-20Q) is lit
•Ensure that the input voltage is either 5, 7.5, 9, or 12VDC
•Ensure that the original power adapter is working and providing
power to the Backup Power unit
•Ensure that the device current draw is no more than 10W
•Check for a short-circuit at the device
Note:
Your Enforcer
Backup Power unit
was originally supplied with
a high
-
quality battery
by GE
™
. When
replacing a battery, for continued dependability and safety, be sure to use the same GE™ 18650 Li-Ion battery
(for B-P1012-26Q). Using an inferior battery could result in a fire or explosion.
Troubleshooting:
NOTICE
:
The information and specifications printed in this manual are current at the time o
f publication.
However, the
ECO-LARM policy is one of continual development and improvement. For this reason, ECO-LARM reserves the right to
change specifications without notice. ECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2014 ECO-LARM U. .A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or
in part, without the written permission of ECO-LARM.
WARRANTY:
This ECO
-
LARM product is warranted against defects in material and
workmanship while
used in normal
service for 1 (one) year from the date of sale to the original customer. ECO-LARM’s obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to ECO-LARM. This Warranty is void if
damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason ECO-LARM determines that such equipment
is not operating properly as a result of causes other than defects in material and workmanship. The sole obligation of
ECO-LARM and the purchaser’s exclusive remedy, shall be limited to the replacement or repair only, at ECO-LARM’s
option. In no event shall ECO-LARM be liable for any special, collateral, incidental, or consequential personal or property
damage of any kind to the purchaser or anyone else.
SECO
-
LARM
®
U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website:
www.seco
-
larm.com
Phone: (949) 261
-
2999 | (800) 662
-
0800
Email: sales@seco
-
larm.com
®
PITPW3
Mi B
-
x10xx
-
2xQ_150609.docx
SB-P1012-2 Q / SB-L10V1-20Q
Plug-and-Play Backup Power
Manual
ENFORCER
Plug
-
and
-
Play Backup
Power
unit
s
provide
automatic
continual
power to CCTV
cameras, routers, modems, VOIP phone systems, alarm systems, or other small electronic device
s
during power outages. In addition, they include protection against short-circuits and power surges.
The high quality GE
™
batteries are protected from short-circuit, overcharge, over-discharge, and
overload.
Note: All trademarks named herein are the property of their respective owners.
B-L10V1-20Q In-line Backup Power
B-P1012-26Q Plug-in Backup Power

ENFORCER Plug-and-Play Backup Power
2SECO-LARM U.S.A., Inc.
Model
SB
-
P1012
-
2 Q
SB
-
L10V1
-
20Q
Type
Plug
-
in UP adapter
In
-
line UP
Input
85~265VAC@50/60Hz
5/7.5/9/
12
V
DC±
10
%
Input protection
Overload and short
-
circuit fuse
Output
12VDC±
5
%
Auto
-
configure
5/7.5/9/12VDC
±
5%
Output power rating
10W
Output protection
Over
-
discharge, overload, short
-
circuit protection
Battery
Replaceable
GE
™
18650
Li
-
Ion
3.7VDC/2600mAh
GE
™
Lithium Polymer
3.7VDC/2000mAh
Battery Protection
Overcharge, over
-
discharge,
overload, short-circuit, battery polarity
Overcharge, over
-
discharge,
overload, short-circuit
Backup time
Half Load
70 min
6
0
min
Full Load
30 min
2
5 min
LED indicators
Power
,
b
ackup
Voltage,
power
, alarm, backup
Output cord
5.5ft / 1.4m
12
"
(30.5cm)
Output jack
5.5x2.1mm
Operating temperature
32~104°F (0~40°C)
Operating humidity
0~95% non
-
condensing
Dimensions
3
7
/
16
"
x
2
7
/
8
x"1
5
/
32
"
(87x59.8x29mm)
3
3
/
8
"
x
2
1
/
4
x"1
21
/
32
"
(85x57x42mm)
Weight
4.3
-
oz (122g)
4.3
-
oz (121
g)
Specifications
:
•
Real-time backup power with no break
when input power is lost
•DC UP Auto-start
•User-replaceable 2600mAh GE
™
18650
Li-Ion battery ( B-P1012-26Q only)
•Over-discharge, overcharge, overload,
short-circuit, surge, and ( B-P1012-26Q
only) battery polarity protection
Parts List:
•
LED indicators for power and charging
•Batteries provided by GE
™
Additional features for SB-L10V1-20Q
•Auto-recognize voltage (5/7.5/9/12VDC)
input and sets corresponding output
•2000mAh lithium polymer battery
•Additional indicator LEDs for output voltage
and alarm (alarm is also audible)
LED Indicators
Power
Backup
12V 9V 7.5V 5V
Overview:
Power Input
Off/Reset
12V 9V 7.5V 5V
ENFORCER
®
SB
-
P1012
-
2 Q
SB
-
L10V1
-
20Q
1x
UP with battery
and power cord
1
x
Manual
LED Indicators
tatus Indication
Voltage (Green)
On
:
Indicates detected input voltage and
supplied output voltage
Power (Green) On: UP protection on Off: UP protection off
Alarm (Red)*
On
:
Overload
, input voltage out of range, or, input
voltage failure, Flashing: Battery low
Backup (Yellow) On: Backup mode Off: Line mode
*Audible alarm – Continuous long beep indicates alarm or failure (see troubleshooting), 5 short beeps
indicate transferring to backup power, and continuous short beeps indicate low battery
Features
:
ENFORCER Plug-and-Play Backup Power
SECO-LARM U.S.A., Inc. 3
Note: For devices with non-standard DC plugs, DC plug adapters (not included) may be needed.
Note: To reach full power backup time, please allow the unit's battery to charge for 24 hours.
SB-P1012-2 Q:
1.
Disconnect the original power adapter
first
from the
device
to be powered and
then
the AC
wall outlet.
2. Connect the Plug-In Backup Power unit to the device to be powered
3. Plug the Plug-In Backup Power unit into the AC wall outlet. Both LED indicators should light.
4. To test for correct installation, unplug the adapter from the AC wall outlet momentarily. The
yellow “Backup” LED should remain lit and the device should remain powered.
1.
Disconnect the original power adapter
from the
device to be powered
and plug it into the
In-line Backup Power unit. The correct voltage for the powered device will be automatically
detected and the voltage indicator LED should light up showing the correct voltage.
2. Connect the In-line Backup Power unit's output line to the device to be powered.
The voltage
indicator LED should light within 5 seconds for the correct supplied voltage and the “power”
LED should also be lit.
3. To test installation, unplug the adapter from the AC wall outlet momentarily. The yellow
“Backup” LED should be lit and 5 short “beeps” will indicate that backup mode has started.
The device should remain powered. Continuous short “beeps” with the flashing red “alarm”
LED indicates a low battery.
Note: If the In-line Backup Power unit is later used for another device, be sure to press the
‘off/reset’ button before installation to allow it to again detect the correct voltage.
SB
-
L10V1
-
20Q
Sample Installation:
*
DC plug adapters (not Included) may be required for non-standard 2.1mm DC plug devices.
*
DC plug adapter (not included) may be required for non-standard 2.1mm DC plug devices.
1 2 3
4 5 6
7 8 9
*
0 #
12V 9V 7.5V 5V
B
-
L10V1
-
20Q
Original Power
Adapter
ENFORCER
®
*
*
Original Power
Adapter (Unneeded)
B
-
P10
1
2
-
26
Q
*
1 2 3
4 5 6
7 8 9
*
0 #
