EOC5611P
THE LEADER IN LONG RANGE BUSINESS CLASS WIRELESS DATA
Business Class
802.11a/b/g Outdoor Dual Band Wireless
Client Bridge/Access Point
with Dual Antenna Polarity
Key Differentiators
INTEGRATED DUAL POLARITY
ANTENNA DESIGN
Selectable vertical or horizontal antenna polarization
Operates in horizontal polarity to avoid interference from standard
vertical-polarized Wi-Fi devices
Allows service provider to utilize multi-polarization for best
performance
WATERPROOF CABLE ACCESSORY KIT
Prevents rain and dew get into the device through cables and
connector holes
Ensures higher waterproof quality against water and moisture
HIGH 600MW WIRELESS POWER
Ensures robust signal to overcome long distances
Offers superior WiFi coverage over leading brands
802.11A/B/G DUAL BAND SUPPORT
Provides 5GHz or 2.4GHz wireless frequency
Operates in 5GHz band to avoid interference from 802.11b/g network
devices
802.11a offers more wireless channels than 802.11b/g
DUAL ANTENNA DESIGN
Embedded 14dBi DUAL POLARITY panel antenna with external RP-
SMA connector for upgradeable antenna
High gain antenna for wireless power up to 41dB EIRP in 802.11a
band
Perfect for both Point-to-Point and Point-to-MultiPoint applications
Upgradeable antenna to increase range and receive sensitivity
MULTIPLE WIRELESS NAMES (AP MODE)
Broadcasts multiple SSID's in one device
Permits different levels of network access (VLAN Tagging)
POWER-OVER-ETHERNET (24V POE) CAPABLE
Power and data over one single cable for convenient installation
Capable of 300 feet PoE cable length
Power Injector Included
OUTDOOR WIFI
OUTDOOR CPE
OUTDOOR WIRELESS
SURVEILLANCE VIDEO
OUTDOOR WIRELESS
SIGNAGE
POINT-TO-POINT
POINT-TO-
MULTIPOINT
Ideal For:
NEW
NEW
Client
Bridge
Access
Point
CB
CB
CB
AP
03_EOC-5611P DataSheets.qxd 6/28/2010 6:32 PM Page 1

MANAGEMENT
Configuration Web-based configuration (HTTP)
Firmware Upgrade Upgrade firmware via web-browser
Keep latest setting when f/w update
Administrator Setting Administrator password change
Reset Setting Reboot (press 1second) • Reset to Factory Default (press 5 seconds)
System monitoring Status, Event Log
SNMP v1, v2c
MIB MIB I, MIB II (RFC1213)
Backup & Restore Settings through Web
Time setting NTP (Auto-setting)
Manual Setting
ENVIRONMENT &PHYSICAL
Temperature Range Operating: -20°C to 70°C (-4°F to 158°F)
Storage: -30°C to 80°C (-22°F to 176°F)
Humidity (non-condensing) 0% ~ 95% typical
Dimensions L: 10.24” (260mm) x W: 3.31” (84mm) x H: 2.17” (55mm)
Weight 0.66 lb. (300g)
ETI—Brands that communicateTM www.engeniustech.com
THE LEADER IN LONG RANGE BUSINESS CLASS WIRELESS DATA
EOC5611P – Technical Specifications
Specifications may change without notice.
EnGenius Technologies
1580 Scenic Avenue
Costa Mesa, CA 92626 • USA
888.735.7888
HARDWARE SPECIFICATION
MCU/RF Atheros AR2313+AR5112
Memory 32MB SDRAM
Flash 8MB
Physical Interface
One 10/100 Fast Ethernet RJ-45
Reset Button
Antenna Switch ( Internal and External Switch )
2 x RP-SMA Connector ( One is for 2.4GHz and another is for 5GHz )
LED Indicators
Power (Status)
LAN (10/100Mbps)
WLAN (Wireless is up)
3x Link Quality (Client Bridge mode)
Green: Excellent Quality
Yellow: Good Quality
Red: Poor Quality
Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design
Power Adapter 24V / 1A DC
Regulation Certifications FCC Part 15C/15B/15E, EN301 893, EN 300 328, EN 301 489-1/-17,
EN60950, IC Certification
RF SPECIFICATION
Frequency Band 880022..1111aa: 5.150~5.350GHz, 5.470~5.725GHz, 5.725~5.825GHz
880022..1111bb//gg: 2.412~2.472GHz
Modulation Technology OFDM: BPSK, QPSK, 16-QAM, 64-QAM
DSSS: DBPSK, DQPSK, CCK
Operation Channels 880022..1111aa: 21 for North America
880022..1111bb//gg: 11 for North America, 14 for Japan, 13 for Europe
Receive Sensitivity (Typical)
IEEE 802.11a: -92dBm @ 6Mbps • -73dBm @ 54Mbps
IEEE 802.11g: -92dBm @ 6Mbps • -75dBm @ 54Mbp
IEEE 802.11b: -97dBm @ 1Mbps • -91dBm @ 11Mbps
Available transmit power
(Average power)
FCC ETSI
Frequency Power Frequency Power
5.150~5.350 GHz
5.470~5.725 GHz
5.725~5.825 GHz
802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.150~5.350 GHz
5.470~5.725 GHz
5.725~5.825 GHz
802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
2.412~2.462 GHz
802.11g
26dBm@6~24Mbp
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2.412~2.472 GHz
802.11g
26dBm@6~24Mbp
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2.412~2.462 GHz
802.11b 27dBm@1~11Mbps 2.412~2.472 GHz 802.11b 27dBm@1~11Mbps
Internal Antenna
Gain 14dBi
Radiation Directional
Frequency Band Range 5.1-5.8GHz
Horizontal -3dB Bandwidth 35o
Vertical -3dB Bandwidth 15o
Antenna Polarity: Dual-Polarized; Vertical/Horizontal
Polarity Selection: Software Controlled
External Antenna 2 x RP-SMA Female connector (for 2.4GHz and 5GHz individually)
SOFTWARE FEATURES
Topology Infrastructure
Protocol / Standard
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.11a/b/g (5GHz/2.4GHz WLAN)
Operation Mode 802.11a/b/g: Access Point/Client Bridge/Client Router/WDS AP/WDS Bridge
LAN DHCP Server • DHCP Client
VPN VPN pass-through
Wireless
Channel Selection (Setting varies by countries)
Transmission Rate
11a/b/g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps
Long distance transmission: 1km to 30km (ACK timeout)
Auto Channel Selection • Traffic Shaping • Transmit Power Table • AP Detection
Narrow Bandwidth 5MHz/10MHz/20MHz Support • Signal Strength indicator
PPPoE & PPtP ( Client Router mode )
Preferred SSID
Multiple SSID & VLAN Tagging (up to 4)
Security
WEP Encryption-64/128/152 bit
WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
WPA/WPA2 Enterprise (WPA-EAP using TKIP)
802.1x Authenticator • Layer 2 Isolation
Hide SSID in beacons
MAC address filtering, (up to 50)
Wireless STA (Client) connected list
QoS WMM
Signal Indicators
External 5GHz
RP-SMA Connector
External 2.4GHz
RP-SMA Connector
RJ-45 LAN Port
Reset
Antenna
Switch
4.8GHz 5.15GHz 5.35GHz 5.5GHz 5.7GHz 5.825GHz
4.8GHz 5.15GHz 5.35GHz 5.5GHz 5.7GHz 5.825GHz
Internal Antenna Pattern - Horizontal
Internal Antenna Pattern - Vertical
Azimuth Elevation
Azimuth Elevation
