Ercol BALLATTA 2205 User manual

2205 BALLATTA DRINKS CABINET
Thank you for purchasing this Ballatta drinks cabinet. Please ensure instructions are read in full before attempting to
assemble product.
1
Ref: 2507 / 2205
This product is heavy, it should be assembled as near as possible to the point of use.Take care when lifting to avoid
personal injury and (or) damage to the product.
The fittings pack contains small items which should be KEPT AWAY FROMYOUNG CHILDREN.
Read this leaflet in full before commencing assembly.
WARNING:
IN ORDER TO PREVENT OVERTURNING,THIS PRODUCT PRODUCT MUST BE USED WITH THE WALL
ATTACHMENT DEVICE PROVIDED.
Installation should be carried out exactly according to the manufacturers instructions, otherwise a safety risk can
occur if incorrectly installed. Cabinets and shelving over 600mm high can be unstable and should be supported until
fixed to the wall.

Please check the pack contents before attempting to assemble this product. A full checklist of components is given
in this leaflet. If any components are missing, please contact the retailer from whom you bought this product.
2
Ref: 2507 / 2205
Pre-assembly preparation
This is a two person operation
Items you will need
Fitting checklist
A2 x screw (chrome - 3.5mm x 16mm)
B2 x screw (chrome - 4mm x 30mm)
2 x wooden handle
C
D1 x allen key (M.4)
4 x shelf retainer
E
1 x wedge
F
Step 1
Attach 2x wooden handles (C) to the doors by using 2x screws (B) and a screw driver.
C
C
C
B
B
B

Door Adjustment
You can adjust the door hinges as shown below.
Note: Ercol do not hold stock of replacement glass, however if needed the specifications of the glass shelf and the
door glass are
Shelf: 961mm x 256 mm x 10 mm - 4 edges chamfered, tempered glass
Door glass: 432 mm x 474 mm x 4 mm - 4 edges sanded, tempered glass
Ref: 2507 / 2205 3
Changing Door Glass
In order to change the door glass, first remove the three screws from the top-back side of the door. Then take out
the top-front frame to be able to remove the glass. Replace the glass by sliding it downwards and fix the top-front
frame back with the same three screws.

Shelf Retainer Placement
Insert 4x shelf retainers (E) into a desired level by hand as shown below and place the glass shelf on top of them.
Wedge Instructions
If the drinks cabinet is not level on your floor use the wedge (F) provided, and snap it off so that it does not
protrude out from the cabinet’s leg, you can also snap it lengthways if desired.
F F F
Ref: 2507 / 2205 4
Centre Leg Adjustment
You can adjust the centre leg height by turning it clockwise or counter-clockwise. Screw the leg in fully before
moving the cabinet.
E
EE
E
E
E

Ref: 2507 / 2205 5
Wall Fixing Instructions
Parts, fittings and tools
1 Remove the inner top panel by
removing two allen head bolts using
an allen key (D).
2 Place your product in the final
position. Loosen the screws on the
metal brackets just enough so that
the slotted bracket can be extended
to meet the wall.
3 Then re-secure the screws.
4Mark the wall for drilling through
the hole in the short face of the
bracket.
Then move the unit away from the
wall so that the marked holes can
be drilled.
Ensure you use an appropriate fixing
type for your wall (see page 6).Then
return the unit to its final position.
5 Secure the unit to the wall fixings
with own screws through the
brackets.
6Finally add the extra securing
screws (A) to the holes in the long
faces of the brackets and tighten.
Warning
Serious or fatal crushing
injuries can occur from
furniture tipping over.
To prevent this furniture
tipping over it must be
permanently fixed to the
wall.
D
1
2 3 4
A
5 6

A guide to wall mounting and fixings
Warning
Serious or fatal crushing injuries can occur from furniture tipping over.
To prevent this furniture from tipping over it must be permanantly fixed to the wall.
Wall fixing screws are not included, since different wall materials require different types of screws / fixings.
Please ensure you use the correct screws / fixings for your type of walls and seek professional advice if you
are not sure.
Failure of the product due to incorrect fixings is the responsibility of the installer.
Important: When drilling into the walls always check that there are no hidden wires or pipes etc.
1. General Purpose wall plug
Generally aerated blocks should not be used to support heavy loads, use a
specialist fitting in this case. For light loads, general - purpose wall plugs can
be used.
6. Shield Anchor wall plug - Heavy loads
For use with heavier loads such as TV and Hi-Fi speakers and satellite dishes
etc.
5. Hammer Fixing wall plug
For use with walls stuck with plasterboard. The hammer fixing allows it to
be fixed to the wall rather than the plasterboard. Always check the fixing is
secure to the retaining wall.
4. Cavity Fixing - Heavy Duty wall plug
For use when fitting or supporting heavy loads such as shelving, wall
cabinets and coat racks.
3. Cavity Fixing wall plug
For use with plasterboard partitions or hollow wooden doors.
2. Plasterboard wall plug
For use when attaching light loads on to plasterboard partitions.
Types of walls
You can use one of the following types of wall plug if your walls are made of
brick, breezeblock, concrete, stone or wood.
Safety: Periodically check all fittings and wall fixings to ensure they
have not come loose and retighten as necessary.
Ref: 2507 / 2205 6

Care and maintenance
Wood Furniture
Wood displays different grain patterns depending on which way it is cut - for example, the ‘medullary ray’ which
can appear on oak furniture is a mark of good quality timber - these are just characteristics of the natural beauty
of the wood. Some furniture is also deliberately aged and rustic.
All timber surfaces will change colour and mellow over time. New furniture will initially vary in shade from items
that have been previously purchased.
How to care for your wood furniture
Furniture with hard lacquer, wax polish or painted surface should be dusted with a dry cloth.When using the
surface for serving food and drinks it is best to use protective mats and coasters. Spillages should be wiped up as
soon as possible.
Spray polishes are best avoided as they contain silicones which may spoil the furniture’s surface by building up
over time. Use of cleaning materials containing abrasive compounds, acidic or caustic reagents and any bleaches
containing oxidising reagents should be avoided as prolonged use may damage the lacquer surface.Wipe up spills
immediately. If sticky marks occur on the surface they can be removed with a dilute solution of warm soapy water.
The offending area should be rubbed lightly and then completely dried immediately afterwards, before replacing
any mats etc.
Our furniture will endure most temperatures in the home but it is best to avoid placing furniture next to heat
sources such as radiators or fires. Be particularly careful with solid wood as the lack of humidity caused by central
heating can cause damage such as warping.
Safety Instructions
Never drag furniture when moving it, always lift it. Please take care when handling or moving the furniture as
careless handling may cause damage or injury. No liability will be accepted for damage or injury caused by
incorrectly installed furniture.
PLEASE KEEP THESEINSTRUCTIONS FOR FUTURE REFERENCE
Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX ercol.com
YNG TAL 14 / ERBDT2 D: 18.09.2018 / RN 001
Ref: 2507 / 2205 7
