Ercol Ancona 5152 User manual

Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product
Necessary Tools
This item is HEAVY
Please check the pack contents before attempting to assemble this product. A full checklist of components is
given in this leaflet. If any components are missing, please contact the retailer from whom you bought this
product.
This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN
LIFTING to avoid personal injury and (or) damage to the product.
This product takes approximately 30 MINUTES to assemble with 2 PEOPLE.
The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROMYOUNG
CHILDREN.
Ref: 00237/5152
5152 Ancona Console Table
Thank you for purchasing this Ancona console table, Please read the instructions carefully before use to ensure
safe and satisfactory operation of this product.

Fittings and parts checklist
ATop panel x 1
BShelf panel x 1
FM4 Allen key x 1
8*25mm Bolt x 8
CSide legs x 2
DFront&Back legs x 2
I
J
8*50mm Bolt x 8
G
H
Half moon washer x 8
ECross rail x 2
6*45mm Bolt x 8
K
M5 Allen key x 1
A
BC
C
D
DE
E

Step by step assembly instructions
1. Insert the legs (C) onto the edges of connection cross rails E(Length direction) and insert the legs (D)
onto the edges of connection cross rails E(Width direction)as shown below.
2. Using the M4 Allen key (F) to fix the 8pcs 6*45mm bolts (I) and 8pcs half moon washer (J) on the legs
and cross rails so that they are completely immobilized as shown below.
C
D
D
C
E
E
Fittings
I * 8
J * 8
I * 8
J * 8
F * 1
F

3.Put the top panel (A) and shelf panel (B) on the cross rails appropriate places as shown below.
4. Using the M5 Allen key (G) to fix the 8pcs 8*50mm bolts (H) to the shelf panel (B) and top panel (A)
via the predrilled holes on the cross rails (E).
Using the M5 Allen key (G) to fix the 8pcs 8*25mm bolts (K) to the shelf panel (B) and top panel (A)
via the predrilled holes on the cross rails (E).
Assembly completed and put the console table up.
A
B
Fittings
G*1
H*8
K * 8
H * 8
K*8
Using 8*25 bolt（K）
K*8
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Ercol Furniture Ltd, Summerleys Road, Princes Risborough, Buckinghamshire. HP27 9PX www.ercol.com
