Ergotron WorkFit-A, Single LCD Mount, LD User manual

888-45-297-W-03 revK • 08/15
1 of 14
WorkFit-A, Dual
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l’utente - Italiano
Användarhandbok - svenska
ユーザーガイド:日本語
用户指南 : 汉语
Includes
Constant Force™
Technology
ENGLISH
For local customer care phone numbers visit: http://contact.ergotron.com
ASSEMBLY INSTRUCTIONS
For the latest User Installation Guide please visit: www.ergotron.com

888-45-297-W-03 rev.K • 08/15
2 of 14
360˚
85˚
20"
(508 mm)
5"
(127 mm)
6 - 14 lbs
(2.72-6.35 kg)
6 - 14 lbs
(2.72-6.35 kg)
A
B
A+B=9-
20 lbs (4.1-9.1 kg)
A+B+C+D <25
lbs (11.3 kg)
< 5 lbs
(2.27 kg)
< 2 lbs
(0.9 kg)
C
D
0.78"-2.56" (20-65mm)
0.78"-2.56" (20-65mm)
0.5"-2.5" (13-64mm)
Arm lowers along an arc.
Pull Arm toward you as
you lower from the
highest position. 827-975
ENGLISH
Warning: Because mounting surface materials can vary widely, it is imperative that you make sure mounting surface is strong enough to handle mounted product
and equipment.
Important! You will need to adjust this product after
installation is complete. Make sure all your equipment
is properly installed on the product before attempting
adjustments. This product should move smoothly and
easily through the full range of motion and stay where you
set it. If movements are too easy or difficult or if product
does not stay in desired positions, follow the adjustment
instructions to create smooth and easy movements.
Depending on your product and the adjustment, it may take
many turns to notice a difference.Any time equipment is
added or removed from this product, resulting in a change
in the weight of the mounted load, you should repeat these
adjustment steps to ensure safe and optimum operation.
Adjust the height of your desk (or chair and footrest) to allow the keyboard to lower to your sitting elbow height for ergonomic computing.
Caution:
To avoid the potential to pinch cables it is important to follow the cable routing instructions in this manual. Failure to follow these
instructions may result in equipment damage or personal injury.
Arm lowers along an arc. Pull arm towards you as you lower from the highest
position.

888-45-297-W-03 revK • 08/15
3 of 14
ABCDEF
1
2
3
4
5
6
7
1x
8x
4x 2x
M6 x 6mm
1x
1x
2x
M4 x 10mm
M4 x 10mm
8x
12x
4 mm
1x
1x
2x
M4 x 5mm
2x 4x
1/4"
1/4”
8mm
1x
M4x16mm
1x
1x
1x
1x
1x
1x
2x
M6 x 45mm
1x
1x
M4 x 8mm
2x
2x
M5 x 35mm
ENGLISH
Learn more about ergonomic computer use at:
www.computingcomfort.org
Set Your Workstation to Work For YOU!
Height Position top of screen slightly below eye level.
Position keyboard at about elbow height with wrists at.
Distance Position screen an arm's length from face—at least 20” (508mm).
Position keyboard close enough to create a 90˚ angle in elbow.
Angle Tilt screen to eliminate glare.
Tilt the keyboard back 10° so that your wrists remain at.
To Reduce Fatigue
Breathe - Breathe deeply through your nose.
Blink - Blink often to avoid dry eyes.
Break • 2 to 3 minutes every 20 minutes
• 15 to 20 minutes every 2 hours.

888-45-297-W-03 rev.K • 08/15
4 of 14
1
12"
(300 mm)
18"
(460 mm)
16"
(410 mm)
10"
(260 mm)
12.75"
(320 mm)
12.75"
(320 mm)
12.75"
(320 mm)
12.75"
(320 mm)
Top View
Top View
12.75"
(320 mm)
9.5"
(250 mm)
9.5"
(250 mm)
9.5"
(250 mm)
9.5"
(250 mm)
10"
(260 mm)
16"
(410 mm)
12.75"
(320 mm)
1 2
3 4
6
55
6
ENGLISH
With Expanded Arm Extension With Expanded Arm Extension
Arm Extension and Desk Size:
The keyboard tray is designed to extend over the edge of your desk. You can expand the extension of the arm if
you need to based on your desk size. To determine if you need to expand your arm extension, refer to the 4 desk
dimensions below:
CLAMP
CLAMP
CLAMP
GROMMET HOLE
GROMMET HOLE
GROMMET HOLE
To expand the arm extension, follow instructions on
next page.
Grommet hole can
be located anywhere
along this arch.
Grommet hole can
be located anywhere
along this arch.
To expand the arm extension, follow instructions on next page.
CAUTION: Base must be completely on desk surface.
Failure to follow these instructions may result in
equipment damage or personal injury.

888-45-297-W-03 revK • 08/15
5 of 14
4 mm
d1 d2 d3
bcda
180˚ 180˚
ENGLISH
How to expand the arm extension.
Remove the 4 screws at the
base using the provided 4mm
hex wrench.
Flip the base around (turn
180 degrees.
Re-insert the 4 screws and tighten
with the 4mm hex wrench.

888-45-297-W-03 rev.K • 08/15
6 of 14
2
0.78"-1.78" (20-45mm) 1.70"-2.56" (43-65mm)
4 mm
1/4"
1/4”
8mm
1x
1x
1x
4 mm
b
c
d
a
4 mm
1x
ENGLISH
CAUTION: Bolt must be
centered in hole.
CLAMP GROMMET HOLE
DESK THICKNESS

888-45-297-W-03 revK • 08/15
7 of 14
4 mm
2x
M6 x 45mm
3
2x
a
b
c
M5 x 35mm
ENGLISH
WARNING!
Screws must be tightened to keep
product secure. Failure to follow these
instructions will create an unstable
situation and may result in equipment
damage or personal injury.

888-45-297-W-03 rev.K • 08/15
8 of 14
5
4x
M6 x 6mm
4 mm
41x
ab
c2x
M4x16mm
ENGLISH

888-45-297-W-03 revK • 08/15
9 of 14
6
7
8
6.5˚1.5˚
2x
1x
M4 x 5mm
M4 x 5mm
1x
M4 x 10mm
M4 x 10mm
4x
4x
0°
M4 x 8mm
2x
ENGLISH
Center total width of mounted equipment on
stand.

888-45-297-W-03 rev.K • 08/15
10 of 14
11
1x
4x
101x
M4 x 10mm
4x
9
8x
1x
ENGLISH
NOTE: Leave enough slack in cable to allow full range of motion.
Caution:
To avoid the potential to pinch cables it is important to follow the cable routing instructions in this manual. Failure to
follow these instructions may result in equipment damage or personal injury.

888-45-297-W-03 revK • 08/15
11 of 14
12
1/4"
1/4”
8mm
1
2
3
a
ENGLISH
Adjustment Step
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
Important! You will need to adjust this product after installation is complete. Make sure all your equipment is
properly installed on the product before attempting adjustments. This product should move smoothly and easily
through the full range of motion and stay where you set it. If movements are too easy or difficult or if product
does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
Depending on your product and the adjustment, it may take many turns to notice a difference.Any time
equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you
should repeat these adjustment steps to ensure safe and optimum operation.

888-45-297-W-03 rev.K • 08/15
12 of 14
b1/4"
1/4”
8mm
c
1/4"
1/4”
8mm
ENGLISH
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
Increase Friction
If this product moves too easily from
side-to-side, then you'll need to
increase friction:
Decrease Friction
If this product is too difficult to move
from side-to-side, then you'll need to
decrease friction:

888-45-297-W-03 revK • 08/15
13 of 14
e
4 mm
d1/4"
1/4”
8mm
ENGLISH
Increase Friction
If this product moves too easily, then
you'll need to increase friction:
Decrease Friction
If this product is too difficult to move,
then you'll need to decrease friction:
Increase Friction
If this product moves too easily, then
you'll need to increase friction:
Decrease Friction
If this product is too difficult to move,
then you'll need to decrease friction:

888-45-297-W-03 rev.K • 08/15
14 of 14
f
4 mm
1
2
3
ENGLISH
Loosen these two screws.
Loosen or tighten this bolt to adjust tilt to desired angle.
Tighten to tilt up.
Loosen to tilt down.
After desired tilt is achieved, retighten these
two screws to secure.
WARNING!
Screws must be tightened to keep product secure.
Failure to follow these instructions will create an
unstable situation and may result in equipment
damage or personal injury.
Angle Setting Adjustment
