Ergotron Neo-Flex User manual

888-24-075-W-01 rev. J • 02/14
1/19
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l’utente - Italiano
Användarhandbok - svenska
ユーザーガイド:日本語
用户指南 : 汉语
Neo-Flex™ WideView WorkSpace
ENGLISH
For the latest User Installation Guide please visit: www.ergotron.com
User's Guide

888-24-075-W-01 rev. J • 02/14
2/19
WARNING
DO NOT load Cart below minimum or above
maximum weight capacities. DO NOT mount a
display larger than the recommended size.
Failure to comply with warning may result in
Cart instability leading to equipment damage or
personal injury.
Min. 11 lbs (5 kg)
Max. 46 lbs (20.9 kg)
Min. 14 lbs (6.35 kg)
Max. 49 lbs (22.2 kg)
WARNING
Impact Hazard!
Moving Parts can Crush and Cut.
Minimize Lift Tension BEFORE
Removing Mounted Equipment.
To Minimize Lift Tension
1. Lower worksurface to lowest position.
2. Turn adjustment nut at top of riser
counterclockwise until it stops (may require
40-60 turns to minimize lift tension).
3. After removing or adding equipment adjust
lift tension to compensate for weight
of new load.
Failure to heed this warning may result in
serious personal injury or property damage!
14mm
9/16”

WARNING
A primary mechanism within the Cart
is under tension and can be
hazardous to people exposed to it
under certain conditions.
DO NOT open the Cart tower or base.
DO NOT attempt to service the Cart.
DO NOT remove safety guards or
labels designed to protect or inform
of possible hazards.
Only Ergotron-approved installers
may service or otherwise modify
Cart. Failure to heed this Warning
may result in serious Personal Injury
and Damage both to the cart and
equipment.
STORED ENERGY HAZARD!
DO NOT OPEN TOWER OR BASE.
DO NO REMOVE SAFETY GUARD.
240-027-00
TIPPING HAZARD!
DO NOT allow children to climb on Cart.
DO NOT route electric cords or equipment
cables within reach of children.
LOCK CASTERS when Cart is stationary.
DO NOT move Cart with Display in highest
position.
DO NOT move Cart over cords or uneven, dirty,
soft or sloping surfaces.
DO NOT move Cart by pushing on Display.
Failure to comply with this warning may result
in Cart instability leading to equipment
damage or personal injury.
WARNING
TO MOVE CART
1. Push Display down to lowest position.
2. Disconnect power cord and secure to Cart.
3.
Unlock casters; point casters in direction of travel.
4. Use rear handle to push Cart.
ENGLISH
Safety

888-24-075-W-01 rev. J • 02/14
3/19
12"-18"
(305-457 mm)
3"- 8.5"
(76-216 mm)
<40 lbs. ( 18.1 kg)
20"
(50.8 cm)
20"
(50.8 cm)
16 - 30 lbs
(7.3 - 13.6 kg)
20˚*
10˚*
90˚
*±5˚
ENGLISH
Features & Specifications
CAUTION: DO NOT EXCEED
MAXIMUM LISTED WEIGHT
CAPACITY. SERIOUS INJURY
OR PROPERTY DAMAGE MAY
OCCUR!
CPU Holder
Stand
Sit
Important! You will need to adjust this product after installation is complete. Make sure all your equipment
is properly installed on the product before attempting adjustments. This product should move smoothly
and easily through the full range of motion and stay where you set it. If movements are too easy or
difficult or if product does not stay in desired positions, follow the adjustment instructions to create
smooth and easy movements. Depending on your product and the adjustment, it may take many turns to
notice a difference.Any time equipment is added or removed from this product, resulting in a change in
the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum
operation.

888-24-075-W-01 rev. J • 02/14
4/19
AB C D E F
1
2
3
4
5
6
7
8
9
14mm (9/16")
19mm
(3/4")
>9" (229 mm)
8mm
(5/16")
1x
M4 x 12mm
4x
3mm
1x 1x
1x
1x 1x
1x
1x
2x 4x
M5 x 18mm
4x
2x
1x
2x
1x
2x
1x
1x 1x
2x
1x
1x 2x 2x
2x
M5 x 10mm
M5 x 8mm
4x
2x
1x 4x 1x
1x
M3 x 6mm
M6 x 14mm
M6x33mm
4x
4x 4x 4x 4x
4x
M5 x 12mm M5 x 20mm
M5 x 7mm M6 x 12mm
ENGLISH
Components
Tools Needed
CPU Holder
5-sided Security Wrench
Security Screw
Mounting Holes
M8M5 Converter

888-24-075-W-01 rev. J • 02/14
5/19
2x
3mm
2
cd
efg
ab
1180˚
a
b
cd
19mm
(3/4")
ENGLISH
5-sided Security Wrench
CPU Holder NOTE: If you are not attaching a CPU to your
cart, skip step 2 and proceed to step 3.

888-24-075-W-01 rev. J • 02/14
6/19
h
kl
ij
3mm
2x
mn
ENGLISH
5-sided Security Wrench
5-sided Security Wrench
Caution: Do Not over tighten fasteners.
NOTE: Position at bottom of tower.
Do not tighten at this time.
Tipping Hazzard: Position bracket so that CPU
attaches as low as possible on the tower.

888-24-075-W-01 rev. J • 02/14
7/19
t
s
1x
op
qr
M5 x 18mm
ENGLISH
5-sided Security Wrench
5-sided Security Wrench
Security Screw

888-24-075-W-01 rev. J • 02/14
8/19
3a
b
c
2x
1x
ENGLISH
Mounting Holes

888-24-075-W-01 rev. J • 02/14
9/19
4abcd
e
2x
M5 x 10mm
2x
1x
iiiii
d
i
ENGLISH

888-24-075-W-01 rev. J • 02/14
10/19
5abc
d
2x
2x
egf
6
2x
>9" (229 mm)
2x
M6x33mm
M6x33mm
ENGLISH

888-24-075-W-01 rev. J • 02/14
11/19
ab
WARNING
DO NOT load Cart below minimum or above
maximum weight capacities. DO NOT mount a
display larger than the recommended size.
Failure to comply with warning may result in
Cart instability leading to equipment damage or
personal injury.
Min. 11 lbs (5 kg)
Max. 46 lbs (20.9 kg)
Min. 14 lbs (6.35 kg)
Max. 49 lbs (22.2 kg)
8”
(203mm)
a
b
*Shelf Clearance
9”
(229mm) 11”
(280mm) 13”
(330mm)
4x
M6 x 14mm
8x
M6 x 14mm
7
8”
(203mm)
8M5 x 8mm
1x
16 - 30 lbs
(7.3 - 13.6 kg)
< 2 lbs (0.9 kg)
< 3 lbs (1.4 kg)
A
B
C
A+B+C= 14 - 53 lbs (6.35 - 24 kg)
ENGLISH
Optional Camera Shelf (ordered separately)No Camera Shelf

888-24-075-W-01 rev. J • 02/14
12/19
9
A
B
C
D
75x75mm
100x100mm
100x200mm
200x200mm
200x100mm
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
13
14
14
14
ENGLISH
VESA Adapter
Congurations
TV/Monitor Hole
Pattern Sizes
Check size of
TV/Monitor hole
pattern

888-24-075-W-01 rev. J • 02/14
13/19
A
75x75mm
100x100mm 100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
75mm (2-15/16”)
9
10 16
M4 x 12mm
4x
ENGLISH
Mount Type A TV/Monitor to Arm

888-24-075-W-01 rev. J • 02/14
14/19
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
BCD
9a
100x200mm 200x200mm 200x100mm
4x
M5 x 7mm
15
9b
4x4x 4x
M4 x 12mm M5 x 12mm M6 x 12mm
ENGLISH
Mount VESA Adapters to Arm based on TV/Monitor hole
pattern size (B, C, or D) .
Mount Type B, C, or D TV/Monitor to Arm
NOTE: To reduce M8
holes for use with M5
screws, or if you have a
model with Samsung
holder rings, follow the
M8M5 KIT instructions
on the next page.

888-24-075-W-01 rev. J • 02/14
15/19
4x
4x
4x
4x
M5 x 20mm
M5 x 20mm
ENGLISH
M8M5 KIT Instructions
NOTE: Follow this step only if your TV/monitor has M8 holes which need to be
reduced to M5.
NOTE: Follow this step only for Samsung models using the holder ring.
Install M8M5 reducer bushing to TV/Monitor and use M5 x 20 mm monitor
screws to secure.
Install M8M5 reducer bushing to TV/Monitor then use M5 x 20 mm monitor screws
and Samsung holder ring to secure.
TV/Monitor Mounting
M8 size hole
TV/Monitor Mounting
M8 size hole
Holder Ring
(Not included *Samsung Only)

888-24-075-W-01 rev. J • 02/14
16/19
10 ab
2x
ENGLISH
Cable Routing Route display cables down riser and into the cable box mounted under
the worksurface. Use cable box to store excess cables.

888-24-075-W-01 rev. J • 02/14
17/19
11
a
ENGLISH
Adjustment Step
Important! You will need to adjust this product after installation is complete. Make sure all your equipment is
properly installed on the product before attempting adjustments. This product should move smoothly and easily
through the full range of motion and stay where you set it. If movements are too easy or difficult or if product
does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
Depending on your product and the adjustment, it may take many turns to notice a difference.Any time
equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you
should repeat these adjustment steps to ensure safe and optimum operation.
CAUTION! The bottom nut will turn
during adjustment of the top nut; DO
NOT apply any tool to the bottom nut.
Serious damage to the Pivot may occur
if these instructions are not followed.
Increase Friction
If this product moves too easily, then
you'll need to increase friction:
Decrease Friction
If this product is too difficult to move,
then you'll need to decrease friction:
Tilt – Forward and Backward

888-24-075-W-01 rev. J • 02/14
18/19
b
ab c
1x
14mm
20"
(50.8 cm)
12
ENGLISH
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
Lift – Up and down

888-24-075-W-01 rev. J • 02/14
19/19
ENGLISH
For local customer care phone numbers visit: http://contact.ergotron.com
Learn more about ergonomic computer use at:
www.computingcomfort.org
Set Your Workstation to Work For YOU!
Height Position top of screen slightly below eye level.
Position keyboard at about elbow height with wrists flat.
Distance Position screen an arm's length from face—at least 20” (508mm).
Position keyboard close enough to create a 90˚angle in elbow.
Angle Tilt screen to eliminate glare.
Tilt the keyboard back 10° so that your wrists remain flat.
To Reduce Fatigue
Breathe - Breathe deeply through your nose.
Blink - Blink often to avoid dry eyes.
Break • 2 to 3 minutes every 20 minutes
• 15 to 20 minutes every 2 hours.
