ESI ESPREE Installation instructions

ASSEMBLY AND OPERATION
ESPREE Model 2ESP-C48-ADJ-___
Model 2ESP-C60-ADJ-___
___ = SLV, BLK or WHT
PNEUMATIC TABLE BASE
2ESP Rev A 1/17

2
ESPREE PNEUMATIC TABLE BASE PARTS AND TOOLS
PLEASE REVIEW these instructions before beginning the assembly procedures. Check that all the parts shown
below were provided with your order. Contact your supplier if any materials are missing. Do not discard the
packaging until satised that the product operates to your satisfaction.
ADDITIONAL TOOLS REQUIRED
• #2 and #3 Phillips screwdriver
• Power drill and 1 /8" drill bit
PARTS AND TOOLS PROVIDED
Frame Support Brackets,
LH and RH (1 each)
Frame Assembly (1)
Cable Clip (2)
Allen Keys (1 each)
5mm
6mm
CAUTION: Hand-tighten screws only. Do not use power tools.
Fasteners
Adjustable Feet (2)
M8x15 SHCS (7)
M8x14 SHCS (8) M8x25 FHCS (1) #12x1 PPH (8) #8x¾ PPH (6)
WARNING:
Do not activate the release lever until the table is fully assembled and
in the upright position. Do not remove any bolts or hardware from the leg columns. Do not
remove the safety pin, safety ring and warning tags until the table is fully assembled and
in the upright position. Sudden extension of the table legs may cause serious injury if these
instructions are not followed.
IMPORTANT: The columns of this table contain high force pneumatic springs that are sized to lift the work
surface and its contents. Proper sizing, handling, and assembly is critical to prevent damage to the columns
or serious injury. All persons not involved in the installation should remain at a safe distance until set-up is
complete and tested by a qualied installer.
Review the lift rating decal on the frame to learn the minimum and maximum lift weight for the unit. The lift
weight is the total weight of the work surface and the contents it supports.
CAUTION: Always check that screws
used to attach components to the
work surface are not too long for the
thickness of the surface.
Work
Surface

3
Pivot
Screw
M8x14
M8x14
Frame
Support
Bracket
Tapped
Holes
Pivot
Screw
ASSEMBLY ESPREE PNEUMATIC TABLE BASE
STEP 1
Lay the tabletop face down on a soft, clean
surface. Center the frame assembly with the release
cable facing the front.
STEP 2
Raise the top table leg to the vertical position.
• Align the holes on each side of the leg column
with the holes in the frame channel.
WARNING: Do not remove the safety pin
or the safety ring until the table is fully
assembled and in the upright position.
STEP 3
Attach a frame support bracket to the frame
channel and leg column. IMPORTANT: The long
side of the bracket must be toward the front of the
table, as shown.
• There are tapped holes in the leg column,
which are threaded for the M8x14 screws.
• The bottom of the support bracket ts under
the column and the holes on the bracket side
pieces align with the tapped holes.
• Use a 5mm Allen key to attach the support
bracket with four M8x14 screws, two on
each side. Do not tighten down the
screws yet.
STEP 4
Tighten the two pivot screws, one on each side.
• Use a 6mm Allen key.
STEP 5
Use the 5mm Allen key to tighten the four M8x14
screws to 7 ft.-lbs.
Release
Cable
Leg
Column
Frame
Channel
Align
Holes
Safety
Ring
Safety
Pin

4
ESPREE PNEUMATIC TABLE BASE ASSEMBLY
STEP 6
Repeat steps 2 through 5 for the other leg column.
• Raise leg to the vertical position.
• Loosely attach frame support bracket with four
M8x14 screws (again, with the long side of the
support bracket toward the front of the table).
• Tighten the pivot screws on each side of the
frame channel.
• Tighten the four M8x14 screws to 7 ft.-lbs.
WARNING: Do not activate the release lever
until the table is completely assembled and in
the upright position, and the safety ring has
been removed.
STEP 7
Change the length of the adjustable feet, if necessary.
• The length of the feet may be either 22" (55.9cm) or 28" (71.2cm). The feet are shipped in the 28" length.
• To change the length to 22", rst remove the adjustment plate. Then use a 5mm Allen key to remove the
four screws, as shown.
• Slide the feet to the 22" length and reinstall the four screws with the 5mm Allen key.
Pivot Screw
Frame
Support
Bracket
Do Not Activate
Release Lever
Adjustment
Plate
5mm
Allen Key
Slide In
22"
Adjustable
Length
28"

5
Right-Side
Column
Left-Side
Column
M8x25
5mm
Allen Key
M8x15
6mm
Allen Key
M8x15
6mm
Allen Key
ASSEMBLY ESPREE PNEUMATIC TABLE BASE
STEP 8
Attach a foot to each of the legs.
Refer to the illustrations.
• The left side foot is attached with
four M8x15 screws using the 6mm
Allen key.
• The right side foot is attached with
three M8x15 screws and one
M8x25 screw. The M8x25
screw ts into the threaded
insert on the leg column.
Tighten it with a 5mm Allen key.
STEP 9
Adjust the position of the frame before screwing
it to the table.
• The frame should be centered from side to side.
• The rear of the feet should align with the rear
of the table.
STEP 10
Once the frame is in its nal position, attach the
frame supports to the table, as shown.
• Use six #12x1 screws (6 total required).
STEP 11
Attach the release lever at the front of the table
on the left or right side for easy access by the user.
• Use four #8x¾ screws.
• Slide cable clips over the release lever
cable. Position the clips to support
the cable from sagging and attach
the clips with #8x¾ screws.
IMPORTANT: When securing the cable,
the cable should be gently curved to
ensure smooth operation. Do not kink
the cable or form corners with it.
Align Rear of Feet with Rear of Table
Center Frame Side to Side
#8x¾
Cable
Clip
Release
Lever
#12x1

6
ESPREE PNEUMATIC TABLE BASE ASSEMBLY
Cable
Adjustment
Nut
STEP 12
With the assistance of a helper, turn the table
upright and place it in its nal position.
IMPORTANT: There must be 1" (25mm)
of clearance on all sides of the work
surface (and other moving parts) to
ensure free, unobstructed movement.
• Adjust the leveling glides on the feet
to level the work surface, if necessary.
STEP 13
Test operation.
• Place the contents on the table that
have been specied for the work surface.
The weight of the contents is important when
testing operation.
• Verify that the weight of the work surface and contents is
within the lift rating shown on the bottom of the frame.
• Remove the safety pin. Unsnap the safety ring to remove it and
the warning tag. IMPORTANT: The safety pin and safety ring must
be removed or else the table will not operate.
• Check operation by pulling the release lever toward you with one hand and using the other hand to raise
or lower the table.
WARNING: The table may suddenly raise upward or fall downward when the release lever is pulled. The
table is designed to be balanced when the weight of the work surface and its contents is at the midpoint
of the load rating.
STEP 14
Adjust cable tension, if necessary.
• If the table does not lock into place when the lever is released,
tighten the cable adjustment nut one-half turn and recheck.
• If the table stays locked in one place or moves slowly,
loosen the cable adjustment nut one-half turn and
recheck.
• Call ESI Customer Service if you have questions
about operation or adjustment.

7
OPERATION ESPREE PNEUMATIC TABLE BASE
OPERATION
IMPORTANT: When adjusting the table, always make sure area is cleared of any obstructions or pinch points.
• Pull the release lever toward you with one hand and using the opposite hand to raise or lower the table.
WARNING: The table may suddenly raise upward or fall downward when the release lever is pulled. The
table is designed to be balanced when the weight of the work surface and its contents is at the midpoint
of the load rating.
Release Lever
