ETEKCITY Apex EFS-A591S-KUS User manual

1
Apex™HR Smart Fitness Scale
Model: EFS-A591S-KUS
User Manual
Questions or Concerns?
Mon–Fri, 9:00 am–5:00 pm PST/PDT
[e-mail] • [phone]

2
Thank you for purchasing the
Apex™HR Smart Fitness Scale
by Etekcity.
If you have any questions or concerns, please reach out to our
helpful Customer Support Team at [e-mail].
We hope you enjoy your new scale!

3
Table of Contents
Package Contents
7TIGMƼGEXMSRW
Safety Information
Function Diagram
Display Diagram
VeSync App Setup
Using the Smart Scale
Maintenance
Troubleshooting
Warranty Information
Customer Support
4
4
5
8
9
10
13
15
17
22
24

4
ˆˣ˘˖˜Ѓ˖˔˧˜ˢˡ˦
Package Contents
Weight Capacity 400 lb / 180 kg / 28 st
Increments 0.1 lb / 0.05 kg
Weight Units lb / kg / st
Platform Tempered Glass
Battery 500mAh Li-ion Battery
Input 5.0V500mA (USB Type-C Charging)
Auto-Off 3 seconds (after displaying body indexes)
Dimensions 11.8 x 11.8 x 1.1 in / 30 x 30 x 2.9 cm
Operating Systerm iOS®10.0+ or Android™ 5.0+
1 x Apex™ HR Smart Fitness Scale
1 x USB Type-C Charging Cable
1 x Quick Start Guide

5
Safety Information
Please read and follow all instructions and safety guidelines in
this manual.
READ AND SAVE THESE INSTRUCTIONS
• This scale should not be used to diagnose or treat any medical
condition.
• Scale data should not be used as a substitute for medical advice
from a healthcare professional.
• This scale uses a harmless electrical current to measure body fat.
Consult a healthcare professional before using the smart scale if
you use electronic medical equipment such as a pacemaker.
Medical

6
• Check the scale before using. Do not use the scale if it is damaged
in any way.
• Do not strike or bang on the scale.
• Do not use the scale if there is a crack on the glass. While
tempered glass is stronger and fractures more safely than
ordinary glass, it may shatter unexpectedly after developing a
slight crack. If you see a crack, contact Customer Support (see
page 24).
• The glass platform is slippery when wet. Always make sure
the platform and your feet are dry before stepping on for
measurement.
• 4PEGIXLIWGEPISRELEVHƽEXWYVJEGIXSEZSMHXMTTMRK
• To weigh safely and accurately, stand with your feet shoulder-
width apart while on the scale.
• Do not stand on the edge of the scale or jump on the scale.
• Avoid standing on the scale for a long period of time, or when not
measuring yourself.
• Do not overload the scale. Maximum weight capacity is
400 lb / 180 kg / 28 st.
General Use

7
• Keep the scale in a cool area with low humidity.
• Keep the scale away from heat sources, such as ovens or heaters.
%ZSMHXIQTIVEXYVIƽYGXYEXMSRW
• Store the scale in a horizontal position, not a vertical position.
• This scale is not to be used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Handle with care. Not for commercial use. Household use only.
SAVE THESE INSTRUCTIONS

8
Function Diagram
A. Conductive Areas
B. Display
C. Weighing Platform
B
A
C
F
D
E
D. Reset Button
E. USB Charging Socket
F. Anti-Skid Padding

9
Display Diagram
A. Bluetooth®Icon
B. Wi-Fi®Icon
C. Zero-Current Mode
D. Baby Mode
E. Battery Indicator
F. 4 Corners Stability Indicator
G. Weight Unit
H. 9WIV4VSƼPI
I. Weight Measurement
AB CD E
F
G
I
H

10
VeSync App Setup
1. To download the VeSync app, scan the QR code or search
“VeSync” in the Apple App Store®or Google Play Store.
Note: The VeSync app is continually being improved and may change over
time. If there are any differences, follow the in-app instructions.
Note:
• This scale uses the VeSync app, not the VeSyncFit app.
• For Android™ users, you may need to select Allow to use VeSync.
Note: You must create your own VeSync account to use third-party
services and products. These will not work with a guest account. With a
VeSync account, you can also allow your family and friends to use your
WQEVXƼXRIWWWGEPI
2. Open the VeSync app. If you already have an account, tap
Log In. To create a new account, tap Sign Up.

11
Note: You can change the name and icon at any time in the smart
ƼXRIWWWGEPIWIXXMRKW
3. Make sure your phone has Bluetooth®turned on.
4. Tap +MRXLI:I7]RGETTERHWIPIGX]SYVWQEVXƼXRIWWWGEPI
5. *SPPS[XLIMRETTMRWXVYGXMSRWXSGSRRIGXXS]SYVWQEVXƼXRIWW
scale.

12
Important: Entering inaccurate information will make the scale’s
measurements less accurate.
If you are a new user, you will need to enter physical information
FIJSVI[IMKLMRK]SYVWIPJJSVXLIƼVWXXMQIWSXLIWGEPIGERGEPGYPEXI
your body metrics. Follow the in-app instructions to create a user
TVSƼPI
Creating a User
Weighing Children
• Children under 3 years old cannot measure body metrics other
than weight.
•Minors will need a guardian’s consent to create a VeSync
account.
Note: If you don’t identify with the available gender options (or are unsure)
pick the option that you think best physically matches you. This choice is
used for physical measurements, such as body fat percentages.
The scale only displays up to 10 user avatars. If there are more than
YWIVWWIPIGXXLITVSƼPIW]SY[ERXXSHMWTPE]EWYWIVWSR]SYV
scale by tapping Members, and then tapping the Choose Members
icon.
If you need to change your avatar, click in Edit Member, and select
your new avatar.

13
Using the Smart Scale
Note:
•Placing the scale on soft surfaces such as shaggy carpet may cause
inaccurate measurements or tipping.
•8LMWWGEPIGERFIYWIHSRPS[TMPIGEVTIX[MXLEƼFIVPIRKXLSJ
0.4 inches / 10 mm or less.
Note: You can customize the scale’s display by selecting Customize
Screens in the Device Settings menu.
1. 4PEGIXLIWGEPISRELEVHƽEXWYVJEGI
2. Step on the scale, then step off. Wait for the screen to display
“0.0” before using.
3. Place dry, bare feet on the scale’s conductive areas. Continue
WXERHMRKSRXLIWGEPIYRXMPXLIHMKMXWSRXLIHMWTPE]ƽEWLIW
WIZIVEPXMQIWWLS[MRK]SYVƼREPQIEWYVIQIRX-J]SYVWQEVX
scale is connected to the VeSync app, additional metrics
(such as body fat, heart rate, etc.) will show in the app and on
the display.

14
To switch between pounds (lb), stone (st), and kilograms (kg), open
the VeSync app and select the weight unit in the Device Settings
menu. To see measurements besides weight, you must connect the
scale to the VeSync app (see page 10).
Weighing Modes
Switching Units
•Zero-Current Mode: Turn off the scale’s electrical current and
only provide measurements for weight and BMI. This mode can
be helpful for users who are pregnant or who have implanted
medical devices, such as pacemakers.
•Baby Mode: To measure your baby or pet, turn on this mode
and follow the in-app instructions for weighing. Baby Mode will
not measure other body metrics and will only measure weight
and BMI.

15
Maintenance
-JXLIWGEPILEWFIIRQSZIHSVƽMTTIHYTWMHIHS[RMXQYWXFI
cleared to ensure accurate results.
Clearing the Smart Scale
1. 4PEGIXLIWGEPISRELEVHƽEXWYVJEGI
2. Step on the scale until digits appear on the display, then step
off. [Figure 1.1]
3. The scale will show “C” while clearing, then “0.00” when ready
[Figure 1.2].
[Figure 1.1] [Figure 1.2]

16
Cleaning the Smart Scale
• Use a slightly damp cloth to clean the surface of the scale,
followed by a soft, dry cloth to wipe away any remaining
moisture.
•Do not use chemical or abrasive cleaning agents to clean the
scale.
Charging the Batteries
1. Insert the USB charging cable into the USB charging socket.
2. Plug the USB charging cable into a DC 5V adapter and plug
into an outlet. You can also plug the cable into a powered USB
outlet.
3. The bars of the [MPPGSRXMRYSYWP]ƼPPEWXLIWGEPIGLEVKIW
When completely charged, the [MPPFIƼPPIH
The display will show “ ” (Low Battery) when the batteries need to
be charged.

17
Troubleshooting
The scale doesn’t turn on.
•The scale may need to be charged. Plug it in and charge for 3 hours.
When I stand on the scale or control it through the app, the scale doesn’t
respond.
•The scale may need to be reset. Use a safety pin or paper clip to press
the reset button next to the charging port.
`
•The batteries are low and may need to be charged.
The smart scale doesn’t connect to the VeSync app.
•Make sure your phone’s operating system is running on iOS®10.0+ or
Android 5.0+.
•Close and relaunch the VeSync app. Make sure you’re using the latest
version.
•Make sure your phone has Bluetooth turned on. For Android users,
make sure your Location is turned on as well.
•Make sure your scale and phone are within 30 ft / 10 mm of each
other.
• Make sure the scale is not currently connected to any other phone or
app.

18
• Try turning off any VPN apps.
• The scale may need to be cleared. Follow instructions to clear the
scale (see page 15).
The scale readings seem unstable or inaccurate.
•1EOIWYVIXLIWGEPIMWSRELEVHƽEXWYVJEGI
•The scale may need to be reset. Use a safety pin or paper clip to press
the reset button next to the charging port.
My scale will only measure my weight, not my other biometrics.
• If you’re wearing shoes or socks, the scale cannot measure biometrics
such as body fat. Step on the scale with bare feet. [Figure 2.1]
•Make sure to place your feet on the scale’s conductive areas.
[Figure 2.2]
• Make sure Bluetooth is turned on.
• Check if Zero-Current Mode is on. If it is, the scale will only provide
measurements for weight and BMI, not other biometrics.
If you still need help, please contact Customer Support (see page 24).
Figure 2.1 Figure 2.2
Conductive Areas

19
Attributions
iOS is a registered trademark of Cisco Systems, Inc. and/or its
EƾPMEXIWMRXLI9RMXIH7XEXIWERHGIVXEMRSXLIVGSYRXVMIW
App Store is a trademark of Apple Inc.
Google, Android, and Google Play are trademarks of Google LLC.
The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Etekcity
Corporation is under license. Other trademarks and trade names are
those of their respective owners.
Wi-Fi®is a registered trademark of Wi-Fi Alliance®.

20
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: %R]GLERKIWSVQSHMƼGEXMSRWRSXI\TVIWWP]ETTVSZIHF]XLITEVX]VIWTSRWMFPI
for compliance could void the user’s authority to operate this equipment.
Federal Communication Commission
Interference Statement - Part 15
