EUFY MACH V1 User manual

Owner's Manual
V1

English 01
Français 19
Italiano 37
Español 55
Nederlands 73
Deutsch 91
Pусский 109
Türkçe 127

Table of Contents
Overview…………………………………………… 02
Button Control………………………………… 03
Charging …………………………………………… 04
Turning On………………………………………… 05
Initial Setup
Using the MACH Vacuum Cleaner 06
Add Water and Floor Cleaner
Start / Stop cleaning
LCD Screen Guide…………………………… 09
Selecting a Cleaning Mode ………… 10
Using the Trigger …………………………… 10
Using the Menu ……………………………… 11
Status Light Indication ………………… 12
Turning Voice Prompts On or O 12
Maintenance …………………………………… 13
Self-Cleaning and Self-Drying
Drying of the Rolling Brush
Clean the Dirty Water Tank
Clean the Rolling Brush Manually
Clean the High-Performance Filter
Clean the Removable Cover
Troubleshooting ……………………………… 17
Specications ………………………………… 17
Customer Service…………………………… 18

EN 02
Overview
max
mach
Mode button
Power button
LCD display screen
Rubber cover
Clean water tank
High-performance lter
Dirty water tank
Rolling brush cover
Multi-surface rolling brush
(Not suitable for use on
high-pile rugs)
Removable cover
Charging base
Self-cleaning button
Handle bar
Floor cleaner switch
Trigger
Rubber cover
Floor cleaner tank
Power cord
Additional
high-performance lter Floor cleaner Additional multi-surface
rolling brush
Cleaning tool

EN 03
Button Control
Action Function
1s
Press and hold the power button for
1 second • Turn on or o
Press the power button • During cleaning, pause or resume current task
• During menu setting, skip to the previous menu option
1s
Press and hold the mode button for
1 second • Enter menu setting mode
Press the mode button
• Select a mode
• Smart mode (default)
• Suction mode
• During menu setting, skip to the next menu option
Press the self-cleaning button • Start self-cleaning and self-drying
Press and hold the self-cleaning
button for 2 seconds • Turn voice prompts on or o
Hold the trigger • In smart mode, activate more powerful cleaning
• In suction mode, activate more powerful suction
Hold the trigger for 2 seconds
(when placed on the charging base) • Dry the rolling brush
Press the trigger • During menu setting, conrm a selection
Turn anticlockwise Turn the oor cleaner switch on
Turn clockwise Turn the oor cleaner switch o

EN 04
Charging
Before first use, fully charge the MACH Vacuum Cleaner for 4 hours.
1
2
max
m a c h
3
1Wrap your power cable as needed and keep your cable organized.
2Connect the power cord to a power outlet.
3Place the MACH Vacuum Cleaner onto the charging base.
• The LCD display lights up and you will hear a voice prompt, indicating that the MACH Vacuum Cleaner
starts charging.
• The power plug varies by region.
• The charging speed depends on the working mode and ambient temperature. Before use, wait patiently
until the charging is complete.

EN 05
Turning On
1
max
max
mach
1s
2
1Gently step on the foot pedal and push the handle bar backward until you hear a click.
2Press and hold the power button for 1 second to turn on the MACH Vacuum Cleaner.
• The LCD display lights up.
Initial Setup
Before you start, make sure that:
• Your smartphone or tablet is running iOS 10.0+ or Android 5.0+.
• The 2.4GHz band wireless signal is enabled on your wireless router.
For first-time use, the boot animation will guide you to learn the basic operations, select a voice prompt language,
scan the QR code to download the eufy Clean app, and complete the Wi-Fi connection.
• To better understand the operation and maintenance of this device, and obtain the latest product
services and information, please scan the QR code to download the eufy Clean app.

EN 06
Using the MACH Vacuum Cleaner
Add Water and Floor Cleaner
Add Clean Water
1
max
2
max
max
3 4
max
Click
1Remove the clean water tank from the MACH Vacuum Cleaner.
2Open the rubber cover.
3Add tap water until it reaches the MAX water line.
• Do not use mineral or purified water.
4Replace the clean water tank.
• You will hear a click when the clean water tank is locked in place.

EN 07
Add Floor Cleaner
Click
12 3 4
1Remove the floor cleaner tank.
2Open the rubber cover.
3Add floor cleaner into the floor cleaner tank.
4Replace the floor cleaner tank. You will hear a click when it is locked in place.
• To use the floor cleaner during cleaning, make sure the floor cleaner switch is turned on.
• Do not add hot water above 50 degrees, alcohol and corrosive liquid into the water tank.
• Use the floor cleaner designated by eufy only. Use with any other cleaner may cause severe damage to
the MACH Vacuum Cleaner.
• Do not add floor cleaner with too much foam as it will cause false alarms.
• Do not put the water tank into a microwave for heating.

EN 08
Start / Stop cleaning
• The MACH Vacuum Cleaner cannot clean high-pile rugs more than 1cm in height.
• Do not clean carpets which are made of materials including wool or other animal furs.
• It is recommended to clean your carpets in suction mode.
3
2
max
mach
1s
1
max
max
mach
max
After Wi-Fi setup, start cleaning in the smart mode by default.
• To change the cleaning mode, refer to the "Selecting a
Cleaning Mode" section.
• To pause or resume current task, press the power button.
3
2
max
mach
1s
1
max
max
mach
max
Click
To stop cleaning,
• press and hold the power button for 1 second; or
• push the handle bar forward until you hear a click.
3
2
max
mach
1s
1
max
max
mach
max
Place the MACH Vacuum Cleaner onto the charging base to
charge, and then press the self-cleaning button to start
self-cleaning and self-drying (see the Maintenance section).

EN 09
LCD Screen Guide
The LCD screen will show you the working status of the MACH Vacuum Cleaner.
4
2
7
3
5
1
6
1Shows current volume level of voice prompts
(High / Low / Mute)
2Shows the animation of current work mode
3 Lights up when oor cleaner switch is turned on
4Shows current charging status / battery level
Shows current mode name when switching work modes
5Lights up when operating the device under maximum power condition
6 Intelligently shows current cleanliness status of your oor
7Lights up when ozone disinfection is enabled
Smart mode Suction mode
The different color of light bar indicates different cleanliness status.
Dirty Half-dirty Clean

EN 10
Selecting a Cleaning Mode
During cleaning, press the mode button to select a cleaning mode.
• You will hear the corresponding voice prompt when a mode is selected.
Mode Use
Smart mode (default) For daily mopping and hard oor washing
Suction mode Ideal for carpet cleaning or soaking up dry / liquid waste on the oor
Using the Trigger
max
• In smart or suction mode, press and hold the trigger. The current function will be strengthened.
• Release the button to deactivate the feature.

EN 11
Using the Menu
From the menu, you can access additional features and information.
mach
1s
1
Press and hold the mode button for 1 second to access the menu options.
• Select a language.
• Adjust volume.
• Enable or disable EcoClean™ Ozone disinfection. The icon is
displayed when this feature is enabled.
• Reset the Wi-Fi connection: The Wi-Fi connection may be interrupted
due to network change. In this case, reset the Wi-Fi connection, re-add
the device via the eufy Clean app, and complete the Wi-Fi setup.
• View the basic information of the MACH Vacuum Cleaner.
• Restore factory settings.
•
Show the life span of consumable materials including rolling brush and lter.
If the consumable material has been replaced with a new one, you can reset
the progress bar to re-monitor its life span.
mach
2Press the mode / power button to select an option, and then press the
trigger to confirm.
Select the next menu option
Select the previous menu option
Confirm a selection
mach
3
To select a sub-menu, repeat step 2.
mach
1s
4
After menu setting, press and hold the mode button for 1 second to exit.

EN 12
Status Light Indication
Status lights Indication Status
Ozone status light
Steady white Enable ozone disinfection
O Disable ozone disinfection
Ozone status light Flashing red
Indicate that you need to start
self-cleaning or clean the dirty
water tank
• When the MACH Vacuum Cleaner is upright and idle for 5 minutes, and you have not started self-cleaning or
cleaned the dirty water tank, the red status lights will ash and continue for up to 5 minutes.
• To turn o the red warning lights, follow the on-screen instructions to start self-cleaning or clean the dirty
water tank.
• You can also turn o the red lights via the eufy Clean app.
Turning Voice Prompts On or Off
Press and hold the self-cleaning button for 2 seconds to turn the voice prompts on or off.
mach
2s

EN 13
Maintenance
Self-Cleaning and Self-Drying
• Make sure you have filled more than half of the clean water tank before self-cleaning.
•
To avoid any damage to the mopping head of the MACH Vacuum Cleaner, do not rinse or soak it in
water.
• Do not remove the rolling brush cover during self-cleaning. Make sure the rolling brush cover is installed
in place to avoid any damage to the MACH Vacuum Cleaner or hurting your fingers.
1
2
mach
max
After cleaning, place the MACH Vacuum Cleaner onto the charging base.
1
2
mach
max
Press the self-cleaning button.
• The MACH Vacuum Cleaner will clean and self-dry the rolling brush
automatically.
• For a better cleaning effect, turn on the floor cleaner switch before
self-cleaning.
• When the rolling brush starts self-drying, the system will prompt
you to clean the dirty water tank.

EN 14
Drying of the Rolling Brush
If only the rolling brush needs to be dried, hold the trigger for 2 seconds when the MACH Vacuum Cleaner is on the
charging base.
• The device begins drying of the rolling brush.
max
m a c h
Clean the Dirty Water Tank
Click
1 2
6
max
3
45
max
max
max
max
1Remove the dirty water tank.
2Separate the top container from the dirty water tank.
3Remove the dry waste separator.
4Rinse the dirty water tank and all components thoroughly with water.
5Reassemble the dirty water tank.
6Push the dirty water tank back into the MACH Vacuum Cleaner.

EN 15
Clean the Rolling Brush Manually
The multi-surface rolling brush can be cleaned automatically through self-cleaning, but some foreign substances, such as
hair, can easily get tangled in the rolling brush, so it is best to clean the rolling brush manually if it occurs.
• Before removing the rolling brush cover, make sure the MACH Vacuum Cleaner has been turned off.
45
123
1
Pull out to open the cover.
2Press the release button and then pull up to remove the
rolling brush.
3Clean the rolling brush with the supplied cleaning tool.
4Reinstall the rolling brush: Insert the end of the rolling brush into the right side of the holder, then press down
the release button into the left side of the holder. Make sure the rolling brush is installed properly, otherwise it
may be damaged during use.
5
Reinstall the rolling brush cover.

EN 16
Clean the High-Performance Filter
It is recommended to clean the lter once a week.
12 3
max
max
1
Remove the dirty water tank.
2
Remove the high-performance lter.
3
Rinse the lter and dry it completely before next use.
Clean the Removable Cover
It is recommended to clean the cover once a week.
m a c h
m a c h
12
1
Remove the cover.
2
Rinse the cover thoroughly.

EN 17
Troubleshooting
MACH Vacuum Cleaner is not working normally:
• Make sure the battery is fully charged.
• Make sure the handle bar has been pushed backward and you have heard a click before use.
• Check if the rolling brush is stuck.
Suction power is decreased or there is a loud noise:
• Check if any objects are stuck in the opening.
• Check if the dirty water tank is properly installed.
• Check if the dirty water tank and lter are clean.
Specifications
Model V1
Rated voltage (charging base) AC 100-240 V
Battery life Runtime up to 45 minutes(in smart mode)
* According to lab data. May vary based on actual usage and environment.
Battery energy 84.36 Wh
Battery capacity 3800 mAh
Charging time ≤4 hours
Noise 65 dBA, measured according to SPL (sound pressure level)
Clean water tank capacity 820 ml
Dirty water tank capacity 720 ml

EN 18
Customer Service
For tutorial videos, FAQs, manuals, and more information, please visit:
https://support.eufylife.com
Warranty: 24-month limited warranty
Contact Us
[e-mail]
(US/CA) [phone]
(UK) [phone]
(DE) [phone]
(日本) [phone]
www.eufylife.com
For more support phone numbers, please visit:
https://support.eufylife.com/s/phonecontactus
Or scan the QR code below:
Scan this QR code to get the online
user manuals in other languages.
MACH strives to improve product performance and ensure the accuracy of the Owner's Manual. If there is
any inconsistency between the illustrations and the actual operation due to software updates, actual product
performance shall prevail. MACH reserves the right to modify this Owner's Manual without prior notice.
