Euro Video EVD-04/100A1RN User manual

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -1- www.eurovideo-cctv.com
EVD-04/100A1RN
EVD-08/100A4RN
EVD-16/100A4RN
4
44
4, 8, 16
, 8, 16, 8, 16
, 8, 16 Channel Digital Video Recorder
Channel Digital Video RecorderChannel Digital Video Recorder
Channel Digital Video Recorder
User’s Manual

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -2- www.eurovideo-cctv.com
WARNING: To prevent a risk of fire of electric shock, do not expose this product to rain or
moisture.
• This installation should be made by a qualified service person and should conform to all local
codes.
• This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Copyright This manual is the intellectual property of Manufacturer and is
protected by copyright. All rights are reserved. No part of this
document may be reproduced or transmitted for any purpose,
by whatever means, be they electronic or mechanical, without
the express written permission of Manufacturer.
Edition : May.2008
Copyright 2008 Manufacturer
Note This Manual was compiled with the greatest of care and all information
double checked. At the time of printing the description was complete
and correct. Because of the further development of products, the
content of the manual might change without prior notice. Manufacturer
will not be liable for damage which is directly or indirectly due to errors,
incompleteness, or discrepancies the manual and the product described.
Trade marks All names used in this manual for hardware and software are very
probably registered trade marks and must be treated as such.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -3- www.eurovideo-cctv.com
Contents
FOR THE SAFETY OF CUSTOMERS………………....………………………….…………………………4
DESCRIPTION OF PARTS AND FUNCTION…………...…………………………………………………....7
COMPOSITION OF UNIT……………………………….....…………………………………………………7
FEATURES …………………………………………………...……………………………….……………….....8
DESCRIPTION OF PARTS AND FUNCTION ……………...………….…………..……..……………….. 9
Front Panel……………………………………………………….……………………………..…………........9
Rear Panel………………………………………………………….……………………………………… …11
Connection diagram………………………………………………………..……………………………….13
OSD Description................................................................................................................................................15
MENU………………………………………………………………...………….…………………………......16
MENU TREE…………………………………………………………..………………………………………16
MAIN MENU…………………………………………………………..……………….………………………..18
Display Set……………………………………………………..……………….……………………..18
Recording Set ….……..………..……………………………………..………………………………………..20
System Set…………………………………………………………..……………………………………….30
Network Set……………………………………………………………..…………….……………………..34
Event Notification……………………………….………………………..……………………………….….35
SEARCH……………………………………….……………………………………………………….………37
Date / Time Search……………………………….………………………………………………….………37
Calendar Search……….…………………………………………………………………………….………37
BACKUP….….……….……………………….……………………………………………………….………39
CLIENT PROGRAM……………………………………………………………………………........................42
Q & A……………….…………………….………………………………………………………….…………59
Appendix 1…...…………………………….……………………………………….........…………………….61
Appendix 2...………………………………….…………………………………….........…………………….63
Appendix 3…...........…………………………….………………………………….........…………………….66
Appendix 4…...........……………………………….……………………………….........…………………….70
Appendix 5…...........………………………………….…………………………….........…………………….73
Appendix 6…...........…………………………………….………………………….........…………………….74
Appendix 7 (Specification)…………………...…………..…………………...................…………………….81
PRODUCT WARRANTY.....………………...…………..…………………...................…………………….82

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -4- www.eurovideo-cctv.com
1. FOR THE SAFETY OF CUSTOMERS
Caution before use
Please read this manual for proper use.
The caution described in this manual contains very important information for the safe use, so,
please follow the instruction.
Please keep it whether you could reach after read.
For the safety and proper use, it marked various symbol. So, please read it to prevent your
physical or financial loss.
Tips for installation
Please avoid water which could be the reason of firing or electric shock.
Clean the plug and socket.
Please keep the socket and plug clean so that you could avoid the fire. The plug should be tightly
connected to the wall socket.
Do not put the unit on an unstable place.
Do not put the unit on an unstable place like rugged table or slope place.
Be careful for the installation position.
Don’t put the device in humid, direct sunlight, dusty, hot, greasy condition.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -5- www.eurovideo-cctv.com
Caution for proper usage
During use
In following cases, please turn off the power and remove the plug then, please contact technical
support.
If you use it continually, it could be a reason for a fire or electric shock.
If smoke comes out of the device or when you smell something burning.
If a alien substance is split into the device.
If the device is dropped or the case is damaged.
If the power cable has been damaged ( ex. slipped etc.)
No picture being displayed.
Don’t open the case or modify.
There is the high voltage sector inside the unit so, if you open the case
or modify it, it could cause the fire or electric shock.
Don’t put a cup containing water or juice and small material on the device
If you spilt water or alien substance into the device, it could cause the fire or electric shock.
Don’t put any alien substance.
..
.
Don’t put alien substance through the fan.
Don’t touch when lightning .
..
.
When the lightning starts, don’t touch the plug or cable. It could cause the electric shock.
Don’t touch the power plug with wet hand.
..
.
Don’t unplug with wet hands. It could cause a electric shock.
Don’t pull out the power cable.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -6- www.eurovideo-cctv.com
Use the designated HDD
Please use the designated SATA HDD. Otherwise, recording may be operated improperly.
Maker HDD Capacity
Western Digital
Seagate 80GB, 160GB, 250GB, 320GB, 640GB, 1TB (8,16 channel only)
*
**
*Manufacturer guarantees the combination of some HDD capacity only.
i.e.) 320GB X 2pcs : Okay. But, 250GB + 80GB : not guaranteed.
Don’t pull out the cable when plug out from the wall socket.
It could damage the cable and cause the fire.
Please pull out holding the plug.,
When you move, please remove plug.
..
.
If you move the device while the plug is in the socket, it could cause a fire by damaging the cable.
Don’t block the ventilation window.
When the ventilation window is blocked, it could cause the fire by the generation of Internal
heat.
Don’t put a heavy item on the device.
..
.
When it looses the balance and falls down, the customer could be hurt.
Keep the plug and socket clean.
Regarding the cleaning, please contact your Installer.
If there is too much dust inside the device, it could cause the fire or internal short.
Clean the plug and socket.
Please keep the socket and plug clean to avoid fire. The plug should be tightly connected to the
wall socket.
Caution when you don’t use the device for a long time.
If you don’t use the device for a while, please switch off and unplug.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -7- www.eurovideo-cctv.com
2
2. . D DE ES SC CR RI IP PT TI IO ON N O OF F P PA AR RT TS S A AN ND D F FU UN NC CT TI IO ON N
2-1 COMPOSITION OF UNIT
Standard Accessories
When you have received a product “without HDD” , the accessories
1) stand for HDD installing 2) fixing screws will be supplied.
※Accessories are subject to change without notice.
Power Cable
Digital Video Recorder System
Please read this manual before using
User Manual
Remote Controller
Battery

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -8- www.eurovideo-cctv.com
2-2 FEATURES
● Convenience
- User-friendly GUI( Graphic Based User Interface)
- Easy-to-use menu composition
- Easy-to-use recorded data search (Time, Date, Motion, Alarm)
●Stability
- Auto restart after power interruption
-DB structure offers data stabilization and best storage utilization
●Expandability
-Various remote multi DVR’s can be controlled by Web browser (PC Client System)
●Technology
-Embedded LINUX OS
-Totally maximum recording rate 120 fps
-High-resolution & high-quality MPEG-4 algorithm
-Using Water marking & scrambling technologies,
-Strong protection recorded data
-MPEG-4 : 1 ~ 2 Kbytes per image with resolution 360x240
●Functionality
- Variable recording function (normal, alarm, motion, schedule)
- Full channel real-time monitoring
- Live monitoring, recording, playback, backup, remote access at the same time
- Multi channel playback
- Variable events notification to e-mail, buzzer or PC Client system

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -9- www.eurovideo-cctv.com
2-3 DESCRIPTION OF PARTS AND FUNCTION
2-3-1 Front Panel
(1) LED
- REC : Recording status (When recording is on, the red light is blinking)
- PWR : System Power On/Off (When power is on, the green light is lit up)
(2) USB 2.0 PORT
- USB2.0 connector
(3) POWER BUTTON
- System Power On/Off
(4) NUMERIC & CHARACTER
- Input for numeric & character
(5) MENU
- Displays on the menu on the screen
(6) SEARCH
- Entering search mode directly
(7) PLAY▶
▶▶
▶(
((
(▶
▶▶
▶)
))
)
- Playback on the recorded data
- one more button on play mode, fast forward will be executed
(8) REWIEND (◀
◀◀
◀)⊳
⊳⊳
⊳
- Playback on the reverse
(9) PAUSE ( ▌▌
▌▌▌▌
▌▌)
))
)
- To freeze picture on playback mode and live mode.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -10- www.eurovideo-cctv.com
(10) STOP/ EJECT ( █)
- To stop playback and go back to live mode.
- To eject CD-RW
(11) REC (●
●●
●)
))
)
- It starts & stop manual recording of relevant camera in a full screen live mode.
(12) VOL (▲▼)
- To make the volume up and down.
(13)AUDIO (8/16CH Only)
- when user select “audio” key, available audio will be switched.
(14)ARROW KEY
- Curse shifting on the menu
- Shows the divided screen
(15) SELECT
- Menu selection
2-3-2 Rear Panel
< 4CH DVR>

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -11- www.eurovideo-cctv.com
(1) Video Input (BNC)
- 4,8,16 Camera input (1.0 v p-p, 75Ω)
(2) Video Out (BNC / S-VIDEO / VGA)
- Composite Output through BNC / S-VIDEO / VGA
(3) Line Audio Input
- 1Audio (Economic 4ch / 4ch), 4Audio Input through line
(4) Audio Output
- 1 Audio Output
(5) RS232(8/16 ch only)
- 1 Serial Communication
(6) Network Port (RJ-45)
- Available to monitor live screen and recorded data on the HDD through Internet or LAN
(7) DIPswitch (NTSC/PALVideo Selection)
-Selectable either NTSC or PAL
(8) RS 485
< 8/16 CH DVR>

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -12- www.eurovideo-cctv.com
- 1 Serial Communication for Pan / Tilt Camera
(9) Alarm/Sensor
- Alarm / 4 Sensor input / 1 output port
(10)AC Power
- AC 110~240 V (Free Voltage)
ATTENTION
When the video format is changed, the system should be re-booted
The video format should be selected before booting
Default Passwords
“00000000” i.e. 8x Zero’s. Password is required if you need to down-power or stop recording,
prompt will be displayed asking for password.
Web Client
User ID “admin” (not case sensitive). Admin ID cannot be changed this is full administrator ID.
Password “00000000” i.e. 8x Zero’s

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -13- www.eurovideo-cctv.com
2-3-3 System Connection Diagram
< 4CH DVR >
< 8/16 CH DVR >

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -14- www.eurovideo-cctv.com
2-3-4. Remote Controller
1.Power : Power ON/OFF
2. Rec : Start & Stop Recording
3.ⓞ~⑨:Key for figure and character
4. P/T/Z: Entering PTZ menu directly
5. OSD : Operating OSD ON/OFF
6. SEQ : Key for SEQ operation
7. LOG : Direct access Log list
8. INFO: Direct access system Info.
9. ID : Reserved.
10. MUTE :Audio Mute
11. AUDIO : Available audio switching when
user select this key
12. MENU : Entering system menu
13. SEARCH : Entering search
14. ARROW & SPLIT : Key moving left,
right, up and down. Also, Screen split display
shows
15. VOL”+,-“ : Up, down volume
16. CH “+,-“ : Up, down channel(s)
17. ▶(▶) : Play(or fast forward)
18. ◀(◀) : Reverse play
19 II : Pause
20. █: Stopping playback
21. Cam : Changing PTZ icon
22. P/T : Pan &Tilt
23. Z/F : Zoom/ & Focus
24. DIS : Channel Division
*21~24 :
Non
-
working for 120/100fps

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -15- www.eurovideo-cctv.com
2-3-5. OSD Description
Recording on
HD :99%, This shows how much as a percentage is
occupied on the Hard Disk Drive
04-11-2008 15:26:12 : It shows the system date & time
It shows ; “Power fail”, “USB stick in”
“Network”. You would see other icons as
well if happens such as Video loss.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -16- www.eurovideo-cctv.com
3
3. . M ME EN NU U- -
3-1. Menu tree
Display Set
Recording Set
System Set
MonitorAdjustment (4CH Only)
Camera Covert
Camera Name
OSD On/Off
Event Clear
Frame Rate
Recording Quality
Setup Motion
(post motion/area/sensitivity)
P.Alarm Duration
Global Parameter
Normal Recording
Alarm Recording
Motion Recording
Schedule Recording
Audio
Basic
Disk Format
Password Change
Client Account
Program Update
Main Menu
Repeat Recording
Setup Schedule
Watermark
Date Format
Initialization
Date/Time/DST set
Language
Recording Priority
Sensor
Information
Add New
Account
Delete Account
Record Resolution
Save and exit
Save and exit
P.T.Z
Set Display Sequence
Auto Delete Mode
Client List
Camera Control

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -17- www.eurovideo-cctv.com
Network Set
DDNS SET
IP SET
Date/Time Search
Calendar Search
Backup
Search
E-Mail Registration
E-Mail Report
Notification Out
Event Notification
Alarm Out
Beep
E-Mail
Log
DDNS
DDNS User ID
DDNS Password
HOST Name
DDNSStatus
Check
Save and Exit
Use Dynamic IP
IP address
Gate Way
Net Mask
DNS Server
XDSLUser ID
XDSLPassword
DVR Port
Web Server Port
Save and Exit
F.F.: Exclusive / AVI
B.D.: CD-RW / Flash

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -18- www.eurovideo-cctv.com
3-2 Main Menu
NOTE
Before using, be sure to setup the unit properly.
Below menu shows when you press the menu button on the front while the system is on.
Please use UP() or DOWN() on the front cover to move to next menu. To move to the
submenu, use the “SELECT” button.
Display Set
(4ch only)
(4ch only)(4ch only)
(4ch only)
(
((
(
8/16
8/168/16
8/16
ch
chch
ch
only)
only)only)
only)

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -19- www.eurovideo-cctv.com
MonitorAdjustment- (4CH Only)
It controls the verticality and horizontality of live picture. With the background screen shown,
use Left( ◀), Right(▶), Up(▲), Down(▼) button for setting the location.
Camera Covert
It allows hidden Camera, which mean, even live monitoring screen isn’t shown on the
screen(just blue screen), the recording( if recording is “on” condition) is activating.
Camera Name
Camera title can be written on the screen.
OSD On/Off
OSD on/ off : Selecting whether the OSD displaying is on/off
Set Display Sequence (8 / 16ch only)
Sequence dwell time can be selected among 5,10,15,30,45,60 sec. When you select “ Start Full or
Quad Display Sequence”, monitor switch will be started(Or, user can select “ SEQ” button on
the remote controller)
Event Clear
It is for erasing OSD characters related with events.

MPEG4 – 4/8/16 CH DVR
EVD-xx-100AxRN -20- www.eurovideo-cctv.com
Camera Control
Recording Set
In our system, all recorded data can be saved in the format of watermark or scrambling when
user select “watermark :On” So, After downloading the saved data you want to check , user can
confirm it whether is changed by someone using our PC software we provided.
Global Parameter
All the setup values for Audio/ Repeat/ Watermark / Resolution will be applied globally to all
channels.
Normal Recording
It executes the continuous recording according to the designated set-up value.
