EUROM B-4 1800 User manual

(page 24)
(sida 41)
Instruction manual (EN)
Instruktionsbok (SV)
B-4 1800
This product is only suitable for well insulated spaces of occasional use.

2
Informatie eisen voor elektrische toestellen voor lokale ruimteverwarming
Model: B-4 1800
Item
Symbool
Waarde
Eenheid
Item
Eenheid
Warmteafgifte
Type warmte-input, uitsluitend voor
elektrische warmte opslagtoestellen (selecteer
één)
Nominale warmteafgifte
Pnom
1.8
kW
Handmatige sturing van de
warmteopslag met geïntegreerde
thermostaat
Neen
Minimale warmteafgifte
(indicatief
Pmin
0.034
kW
Handmatige sturing van de
warmteopslag met kamer- en/of
buitentemperatuur feedback
Neen
Maximale continue
warmteafgifte
Pmax,c
1.8
kW
Elektrische sturing van de
warmteopslag met kamer- en/of
buitentemperatuur feedback
Neen
Aanvullend elektriciteitsverbruik
Door een ventilator bijgestane
warmteafgifte
Neen
Bij nominale
warmteafgifte
elmax
N/A
kW
Type warmteafgifte/sturing kamertemperatuur
(selecteer één)
Bij minimale
warmteafgifte
elmin
N/A
kW
Eentrapswarmteafgifte, geen sturing
van de kamertemperatuur
Neen
In stand-by modus
elSB
N/A
kW
Twee of meer handmatig in te
stellen trappen, geen sturing van de
kamertemperatuur
Neen
Mechanische sturing van de
kamertemperatuur door thermostaat
Ja
Elektronische sturing van de
kamertemperatuur
Neen
Elektronische sturing van de
kamertemperatuur plus dag-
tijdschakelaar
Neen
Elektronische sturing van de
kamertemperatuur plus week-
tijdschakelaar
Neen
Andere sturingsopties (meerdere selecties
mogelijk)
Sturing van de kamertemperatuur,
met aanwezigheidsdetectie
Neen
Sturing van de kamertemperatuur,
met openraamdetectie
Neen
Met de optie van afstandsbediening
Neen
Met adaptieve sturing van de start
Neen
Met beperking van de werkingstijd
Neen
Met black-bultsensor
Neen
Contactgegevens
Eurom - Kokosstraat 20 - 8281JC - Genemuiden - The Netherlands

3
Erforderliche Angaben zu elektrischen Einzelraumheizgeräten
Modell: B-4 1800
Angabe
Symbol
Wert
Einheit
Angabe
Einheit
Wärmeleistung
Nur bei elektrischen Speicher-
Einzelraumheizgeräten: Art der Regelung der
Wärmezufuhr (bitte eine Möglichkeit auswählen)
Nennwärmeleistung
Pnom
108
kW
Manuelle Regelung der Wärme-zufuhr
mit integriertem Thermostat
Nein
Mindestwärme-leistung
(Richtwert)
Pmin
0.034
kW
Manuelle Regelung der Wärme-zufuhr
mit Rückmeldung der Raum- und/oder
Außertemperatur
Nein
Maximale kontinierliche
Wärmeleistung
Pmax,c
1,8
kW
Elektronisch Regelung der
Wärmezufuhr mit Rückmeldung der
Raum- und/oder Außertemperatur
Nein
Hilfsstromverbrauch
Wärmeabgabe mit Gebläse-
unterstützung
Nein
Bei Nennwärmeleistung
elmax
N/A
kW
Art der Wärmeleistung /
Raumtemperaturkontrolle (bitte eine Möglichkeit
auswählen)
Bei Mindestwärme-
Leistung
elmin
N/A
kW
Einstufige Wärmeleistung, keine
Raumtemperaturkontrolle
Nein
Im Bereitschafts-zustand
elSB
N/A
kW
Zwei oder mehr manuell einstellbare
Stufen, keine Raum-Temperatur
Kontrolle
Nein
Raumtemperaturkontrolle mit
mechanischem Thermostat
Ja
Mit Elektronische Raum-Temperatur
Kontrolle
Nein
Elektronische Raumtemperatur-
kontrolle und Tageszeitregelung
Nein
Elektronische Raumtemperatur-
kontrolle und Wochentags Regelung
Nein
Sonstige Regelungsoptionen (Mehrfach-
nennungen möglich)
Raumtemperaturkontrolle mit
Präsenzerkennung
Nein
Raumtemperaturkontrolle mit
Erkennung offener Fenster
Nein
Mit Fernbedienungsoption
Nein
Mit adaptiver Regelung des
Heizbeginns
Nein
Mit Betriebzeitbegrenzung
Nein
Mit Schwarzkugelsensor
Nein
Kontaktangaben
Eurom - Kokosstraat 20 - 8281 JC - Genemuiden - The Netherlands

4
Information requirement for the electric local space heaters
Model identifier(s): B-4 1800
Item
Symbol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat output
Pnom
1.8
kW
manual heat charge control, with
integrated thermostat
No
Minimum heat output
(indicative)
Pmin
0.034
kW
manual heat charge control with room
and/or outdoor temperature feedback
No
Maximum continuous
heat output
Pmax,c
1.8
kW
electronic heat charge control with
room and/or outdoor temperature
feedback
No
Auxiliary electricity consumption
fan assisted heat output
No
At nominal heat output
elmax
N/A
kW
Type of heat output/room temperature control
(select one)
At minimum heat output
elmin
N/A
kW
single stage heat output and no room
temperature control
No
In standby mode
elSB
N/A
kW
Two or more manual stages, no room
temperature control
No
with mechanic thermostat room
temperature control
Yes
with electronic room temperature
control
No
electronic room temperature control
plus day timer
No
electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
room temperature control, with
presence detection
No
room temperature control, with open
window detection
No
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact details
Eurom - Kokosstraat 20 - 8281 JC - Genemuiden - The Netherlands

5
Exigences d'information applicables aux dispositifs de chauffage décentralisés électriques
Modèle: B-4 1800
Caractéristique
Symbole
Valeur
Unité
Caractéristique
Unité
Puissance thermique
Type d'apport de chaleur, pour les dispositifs de
chauffage décentralisés électriques à accumulation
uniquement (sélectionner un seul type
Puissance thermique
nominale
Pnom
1.8
kW
Contrôle thermique manuel de la
charge avec thermostat intégré
Non
Puissance thermique
minimale (indicative)
Pmin
0.034
kW
Contrôle thermique manuel de la
charge avec réception d'informations
sur la température de la pièce et/ou
extérieure
Non
Puissance thermique
maximale continue
Pmax,c
1.8
kW
contrôle thermique électronique de la
charge avec réception d'informations
sur la température de la pièce et/ou
extérieure
Non
Consommation d'électricité auxiliaire
Puissance thermique réglable par
ventilateur
Non
Á la puissance
thermique nominale
elmax
N/A
kW
Type de contrôle de la puissance thermique/de la
température de la pièce (sélectionner un seul type)
Á la puissance
thermique minimale
elmin
N/A
kW
Contrôle de la puissance thermique à
un palier, pas de contrôle de la
température de la pièce
Non
En mode veille
elSB
N/A
kW
Contrôle à deux ou plusieurs paliers
manuels, pas de contrôle de la
température de la pièce
Non
Contrôle de la température de la pièce
avec thermostat mécanique
Oui
Contrôle électronique de la
température de la pièce
Non
Contrôle électronique de la
température et programmateur
journalier
Non
Contrôle électronique de la
température et programmateur
hebdomadaire
Non
Autres options de contrôle (sélectionner une ou
plusieurs options)
Contrôle de la température de la
pièce, avec détecteur de présence
Non
Contrôle de la température de la
pièce, avec détecteur de fenêtre
ouverts
Non
Option contrôle à distance
Non
Contrôle adaptatif de l'activation
Non
Limitation de la durée d'activation
Non
Capteur à globe noir
Non
Coordonnées de contact
Eurom - Kokosstraat 20 - 8281 JC - Genemuiden - The Netherlands

24
Thank you
Thank you very much for choosing for a EUROM device. You have made a good
choice! We hope you will be satisfied about its functioning.
To get maximum profit from your product, it is important to read this manual
attentive and totally before use, and to understand what is written. Read especially
the safety instructions: they are there to protect you and your environment.
Keep the manual in a safe place for future reference. Store also the package: that
is the best protection for your product in times of no-use. And if you at any time
pass the appliance on, pass on the manual and package too.
We wish you a lot of fun with the B-4 1800!
Eurom
Kokosstraat 20
8281 JC Genemuiden (NL)
[email protected]
www.eurom.nl
This manual has been complied with the utmost care. Nevertheless, we reserve the
right to optimize this manual at any time and to adjust it technically. The image
used may differ.
___________________________________________________________
Symbol Explanation
Do not cover the device!
Technical data
Supply voltage
220-240V~50Hz
Maximum capacity
1800/2000 W
Settings
0-900/1000-1800/2000 W
Thermostat
+
Dimensions
25 x 14 x 25,5 cm
Weight
1,1 kg

25
Warning electric heaters
Safety warning –general
1. Read the user instructions carefully and completely before using
(and installing) this device. Keep the instruction leaflet somewhere
safe so that you can consult it and pass it on in future.
2. Before use, check your new device (including cable and plug) for
any visible damage. Never use a damaged device but take it back
to the supplier for a replacement.
3. In the event of incorrect usage or installation, there is a risk of
electric shocks and/or a fire hazard.
Device position warnings
1. This device is not suitable for wall or ceiling installation.
2. Do not use this device in the immediate vicinity of a bath, shower
or swimming pool.
3. This device is not suitable for use in damp spaces such as
bathrooms, wash rooms etc. Never locate the device near water-
points and reservoirs (tap, bath, shower, toilet, sink, swimming
pool, etc.). Make sure that the device cannot fall into water and
that it cannot be penetrated by water. If the device falls into water
make sure you remove the plug from the socket! Do not use a
device that is wet inside but take it to be repaired. Never immerse
the device, cable or plug in water or any other fluid and never touch
device with wet hands.
4. The air around the device must be able to circulate freely. Never
install it too close to walls or large objects and never under a shelf,
cupboard, curtains or similar. When locating the device, make sure
you have the following minimum free space:
Front, minimum free space 100 cm
Back, minimum free space 30-50 cm
Sides, minimum free space 100 cm
Top, minimum free space 100 cm
5. Always place the unit on a sturdy, flat horizontal surface
6. The base on which the device is placed must not be made of
flammable materials. It must be resistant to temperatures of at
least 125°C without burning, melting, deforming or bursting into
flames. Check regularly to ensure that the surface is not
overheating; this could be dangerous!

26
7. Never place the device on surfaces such as beds or deep-pile carpet
as openings could be blocked.
8. Do not place the device near an open window as rain could blow in;
do not place on wet surfaces and avoid any liquids being spilt
nearby. Do not place the device behind a door or along a walking
route to avoid accidental trips.
9. Do not place the device near, under or facing an electrical socket
and not in the vicinity of an open fire or heat source.
10. Do not use the device nearby or facing furniture, curtains, paper,
clothing, bedding or other flammable materials. Keep at least 1
metre from device!
11. Do not use the heater outdoors or in areas that are smaller than
15m³.
12. The device contains hot and/or glowing and sparking components.
Do not, therefore, use where fuels, paint, flammable fluids and/or
gases are stored. Do not use the device in an environment that
poses a fire risk, e.g. near gas tanks, gas pipes or aerosols. This is
an explosion and fire risk!
Warnings –use
1. Do not use additions/accessories on the device that have not been
supplied or approved by the manufacturer.
2. Only use the device for its intended purpose and in the manner set
out in this instruction leaflet.
3. Some parts of this device will get very hot and could cause
burns. You must pay particular attention to children,
vulnerable persons and pets that are present near the
device. Never leave them alone with a working device.
4. Never cover or block the device; it will overheat and this could lead
to a fire risk. Never hang or place objects such as clothing,
blankets, cushions, paper, etc. on the device. The minimum
distance of 1 metre between the device and flammable materials
must always be applied. Ventilation openings should never be
blocked as this may pose a fire risk. Never use the device to dry
clothing or place anything on it. Do not let anything lean against
the device!
5. Do not set the device to come on automatically using a timer, clock
or other facility. You must always check for safe conditions before
using the fireplace! Never use the device with an external voltage
regulator such as a dimmer or similar, as this could be dangerous!

27
6. The device is exclusively intended for normal, household usage.
Only use for providing heat in your home.
7. Connection voltage and frequency, as given on the device, must
correspond to that of the socket to be used and the electrical
installation must be equipped with an earth leakage circuit breaker
of 30 mA . The electrical socket that you are using must be to hand
at all times in order to be able to remove the plug from the socket
in the event of an emergency.
8. To avoid overloading and/or fuses being blown, do not use any
other equipment on the same socket or electrical group as the one
used for the device.
9. Unroll the electric cable for the device fully before inserting the plug
into the socket and ensure that the electrical cable does not come
into contact with the fireplace or get hot. Do not run the electrical
cable under carpet, cover with mats, runners or similar and do not
place in areas that are walked on frequently. Ensure that it cannot
be stepped on and that no furniture is placed on top of it. Do not
bend the electrical cable around sharp corners and do not roll up
too tightly after use! Prevent the electrical cable coming into
contact with oil, solvents and sharp objects. Check the cable and
plug regularly for damage. Do not bend or pinch the electrical cable
and do not wind it around the device; this could damage the
insulation!
10. The use of an extension cable is not advised as this can lead to
overheating and fire. If the use of an extension cable is
unavoidable, make sure that it is not damaged and that it is an
approved extension cable with a minimum diameter of 2x2,5
mm²and a minimum permitted capacity of 2000 Watt. Always fully
extend the cable in order to prevent overheating.
11. Only connect the device to a fixed socket. Do not use multi-plug
adapters or similar.
12. During use, the plug may begin to feel warm; this is normal. If it’s
really warm, there may be something wrong with the socket. Please
contact your electrician.
13. Always turn off the device and remove the plug from the power
socket: Never turn the device off using the plug!
14. Prevent foreign objects entering the radiation/ventilation or outlet
openings on the device. This may cause electric shock, fire or
damage.

28
15. Never leave a working device unattended but switch off and then
remove the plug from the socket.
16. Always remove the plug from the socket when the unit is not in
use! Always remove plug by pulling on the plug itself; never pull on
the electrical cable!
17. This device gets hot during use. Never touch the device when it is
on or shortly thereafter; it could burn you.
18. Never operate the device with wet hands.
Warnings by whom the device may be used
1. Children younger than 3 must be kept out of the vicinity of the
device unless they are continuously supervised.
2. Children between the ages of 3 and 8 may only switch the device
on or off if it is set up or installed at its usual location and they are
supervised or have received instructions regarding the safe use of
the device and understand the corresponding hazards. Children
between the ages of 3 and 8 may not insert the plug into the
socket, adjust the device settings or clean or maintain it.
3. This device can only be used by children from the age of 8 and
elderly persons and persons with diminished physical or mental
capacities or a lack of experience and expertise if they are
supervised or have received instructions regarding the safe use of
the device and understand the corresponding hazards.
4. Children may not clean or maintain the device without supervision.
5. Children may not play with the device.
Warnings for maintenance
1. Keep the device clean. Dust, dirt and/or deposits in the device often
lead to overheating. Ensure that this type of build-up is regularly
removed.
2. Always switch the device off, remove plug from socket and let the
device cool down before you:
- clean the device
- users maintain the device.
- touch or move the device.
3. Never switch the device on if you have noticed damage to the
device itself, the cable or plug or if it does not work properly,
makes strange noises, smells odd or you can see smoke, or if it has
fallen or shows any other signs of damage. Remove the plug from
the socket immediately. Take the entire device back to your
supplier or a recognized electrician to be checked and/or repaired.
Always ask for original parts to be used.
