evertz 7700 Series User manual

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
2.1. VIDEO CONNECTIONS.............................................................................................................. 3
2.2. GENLOCK REFERENCE........................................................................................................... 4
2.3. AUXILIARY I/O........................................................................................................................... 4
2.3.1. AES Audio Connections (7711HDC-SN-EAES4 version)............................................... 4
2.3.2. General Purpose Inputs and Outputs.............................................................................. 5
3. SPECIFICATIONS............................................................................................................................... 6
3.1. SERIAL VIDEO INPUT ............................................................................................................... 6
3.2. SERIAL VIDEO OUTPUT ........................................................................................................... 6
3.3. GENLOCK INPUT....................................................................................................................... 6
3.4. ANALOG MONITOR VIDEO OUTPUT....................................................................................... 7
3.5. ANALOG VIDEO OUTPUT (7711HDC-SN-EAES4 ONLY).......................................................... 7
3.6. AES AUDIO OUTPUTS (7711HDC-SN-EAES4 ONLY)............................................................... 7
3.7. GENERAL PURPOSE INPUTS.................................................................................................. 7
3.8. GENERAL PURPOSE OUTPUT................................................................................................. 8
3.9. INPUT TO OUTPUT PROCESSING DELAY.............................................................................. 8
3.10. ELECTRICAL ............................................................................................................................. 8
3.11. PHYSICAL.................................................................................................................................. 8
4. STATUS INDICATORS....................................................................................................................... 9
4.1. AUDIO STATUS LEDS............................................................................................................... 9
5. CARD EDGE CONTROLS ................................................................................................................ 10
5.1. DISABLING THE ON SCREEN DISPLAY ON THE PROGRAM VIDEO OUTPUTS ................ 10
5.2. CONTROLLING THE OUTPUT VIDEO STANDARD ON LOSS OF VIDEO............................. 10

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
6. ON SCREEN MENUS........................................................................................................................ 11
6.1. NAVIGATING THE ON SCREEN MENU SYSTEM................................................................... 11
6.2. ON SCREEN DISPLAY –MAIN MENU .................................................................................... 11
6.3. CONFIGURING THE VIDEO CONTROLS................................................................................ 12
6.3.1. Setting the Video Input and Output Standard................................................................ 13
6.3.2. 3:2 Pulldown Processing............................................................................................... 13
6.3.2.1. Selecting the 3:2 Pulldown Reference with 1080p/23.98sF Input Video........ 14
6.3.2.2. Accommodating Non-Standard 3:2 Sequences ............................................. 14
6.3.3. Setting up the Video Output Timing .............................................................................. 16
6.3.3.1. Calculating the Delay through the Downconverter ......................................... 16
6.3.3.2. Setting the Vertical Phase of the Output Video – 525 Line Video.................. 18
6.3.3.3. Setting the Horizontal Phase of the Output Video – 525 Line Video.............. 18
6.3.3.4. Setting the Vertical Phase of the Output Video – 625 Line Video.................. 18
6.3.3.5. Setting the Horizontal Phase of the Output Video – 625 Line Video.............. 19
6.3.3.6. Setting the Colour Frame sequence of the Analog Output Video – 525 Line
Video .............................................................................................................. 19
6.4. CONFIGURING THE OUTPUT PICTURE ................................................................................ 19
6.4.1. Setting the Aspect Ratio of the Output Picture.............................................................. 20
6.4.2. Setting the Action to take when Input Video Is Missing................................................. 21
6.4.3. Set the Colour of the Letterbox Panels ......................................................................... 22
6.5. CONFIGURING THE DEINTERLACER.................................................................................... 22
6.5.1. Setting the De-Interlacer Mode ..................................................................................... 23
6.5.2. Setting the Freeze Frame Threshold............................................................................. 23
6.5.3. Setting the Noise Reduction.......................................................................................... 23
6.5.4. Setting the Detail Enhancement.................................................................................... 24
6.5.5. Setting the Edge Enhancement Controls...................................................................... 24
6.5.6. Setting the Motion Detection Controls........................................................................... 25
6.6. CONFIGURING THE SCALER................................................................................................. 25
6.6.1. Setting the Scaler Horizontal filter Sharpness............................................................... 25
6.6.2. Setting the Scaler Vertical filter Sharpness................................................................... 25
6.7. CONFIGURING THE VERTICAL INTERVAL PROCESSING
(MODEL 7711HDC-SN-EAES4 ONLY) .................................................................................... 26
6.7.1. Displaying Closed Captions on the Program Video Outputs......................................... 26
6.7.2. Putting VITC on the Program Video Outputs ................................................................ 26
6.7.3. Setting the Contents of the VITC User Bits................................................................... 27
6.7.4. Setting the VITC Line for 525 Line Video Outputs ........................................................ 27
6.7.5. Setting the VITC Line for 625 Line Video Outputs ........................................................ 27
6.8. CONFIGURING THE AUDIO PROCESSING (MODEL 7711HDC-SN-EAES4 ONLY)............. 27
6.8.1. Selecting the Audio Groups That Will Be De-Embedded.............................................. 28
6.8.2. Selecting the Audio Groups That Will Be Embedded.................................................... 28

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
6.9. SETTING UP THE BROADCAST ANALOG OUTPUT PARAMETERS
(MODEL 7711HDC-SN-EAES4 ONLY).................................................................................... 29
6.9.1. Setting the Composite Display Mode – Colour or Monochrome ................................... 29
6.9.2. Setting the Analog Video Output Level ......................................................................... 29
6.9.3. Setting the Hue ............................................................................................................. 30
6.9.4. Setting the Saturation.................................................................................................... 30
6.9.5. Setting the Contrast ...................................................................................................... 30
6.9.6. Setting the Brightness...................................................................................................30
6.9.7. Setting the NTSC Setup Pedestal on the Broadcast Analog Video Output................... 30
6.9.8. Setting the NTSC Setup Pedestal on Line 21 of the Broadcast Analog Video Output.. 31
6.10. SETTING UP THE MONITOR ANALOG OUTPUT PARAMETERS......................................... 31
6.10.1. Displaying the module Status Window.......................................................................... 32
6.10.2. Setting the NTSC Setup Pedestal on the Monitor Analog Output................................. 32
6.10.3. Displaying Closed Captions on the Monitor Analog Output
(7711HDC-SN-EAES4 version only)............................................................................. 32
6.11. UTILITIES................................................................................................................................. 33
6.11.1. Recalling Configurations to the User Presets or the Factory Preset............................. 33
6.11.2. Saving Configurations to the User Presets ................................................................... 33
6.11.3. Initiating a Software Upgrade........................................................................................ 34
6.11.4. Accessing Information About this Module and its Firmware.......................................... 34
7. JUMPERS.......................................................................................................................................... 35
7.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS ........................................................................................ 35
7.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 36
7.3. SELECTING WHETHER THE GENLOCK REFERENCE INPUT IS TERMINATED................. 36
7.4. SELECTING THE GPI PULLUP VOLTAGE............................................................................. 36
8. VISTALINK®REMOTE MONITORING/CONTROL........................................................................... 37
8.1. WHAT IS VISTALINK®?............................................................................................................... 37
8.2. VISTALINK®MONITORED PARAMETERS .............................................................................. 37
8.3. VISTALINK®CONTROLLED PARAMETERS ........................................................................... 38
8.4. VISTALINK®TRAPS.................................................................................................................. 39
9. MENU QUICK REFERENCE............................................................................................................. 40

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
Figures
Figure 1-1: 7711HDC Block Diagram....................................................................................................................2
Figure 2-1: 7711HDC Rear Panels.......................................................................................................................3
Figure 2-2: GPI Input Circuitry ..............................................................................................................................5
Figure 2-3: GPO Output Circuitry..........................................................................................................................5
Figure 6-1: 3:2 Pulldown Sequence Insertion – 1080p/23.98sF Input Video .....................................................15
Figure 6-2: 6 Hz Pulldown Sequence A Frame Alignment – 1080p/23.98sF Input Video..................................15
Figure 6-3: RP188 Pulldown Sequence A Frame Alignment – 1080p/23.98sF Input Video ..............................15
Figure 6-4: Aspect Ratio Conversions ................................................................................................................21
Figure 7-1: Location of Jumpers – Main Module.................................................................................................35
Figure 7-2: Location of Jumpers – Sub Module..................................................................................................35
Figure 7-3: Setting the GPI Input Pullup Voltage................................................................................................36
Tables
Table 2-1: 9 Pin D Connector Pin Definitions .......................................................................................................4
Table 3-1: Video Input Formats.............................................................................................................................6
Table 4-1: Audio Group Status LEDs....................................................................................................................9
Table 5-1: Overview of DIP Switch Functions.....................................................................................................10
Table 5-2: On Screen Display Control Switch Settings.......................................................................................10
Table 5-3: Default Video Switch Settings............................................................................................................10
Table 6-1: Video Delay – Locked to Genlock Input.............................................................................................17
Table 6-2: Video Delay – Locked to Input Video.................................................................................................17
Table 8-1: VistaLINK®Monitored Parameters – all Versions..............................................................................37
Table 8-2: VistaLINK®Monitored Parameters – 7711HDC-SN-EAES4 Versions..............................................38
Table 8-3: VistaLINK®Controlled Parameters – All Versions.............................................................................38
Table 8-4: VistaLINK®Controlled Parameters – 7711HDC-SN-EAES4 Versions..............................................39

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
REVISION HISTORY
REVISION DESCRIPTION DATE
0.2 Preliminary Version Aug 02
0.3 Updated with features of first firmware version 1.01 build 310 Feb 03
1.0 Updated with Vistalink™features, added Delay in Table 6-1 and Table 6-2 Mar 03
Updated menus to current firmware level
1.0.1 Updated Delay Tables Aug 03
1.1 Updated formatting May 09
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1
This page left intentionally blank

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 1
1. OVERVIEW
The 7711HDC High Definition Downconverter provides broadcast quality down conversion of your
1.5 Gb/s HDTV signals. This High Definition Downconverter has 10-bit processing with Serial Digital &
optional Composite Analog outputs and is designed to fit easily into a plant that is fully digital, analog or
mixed. The 7711HDC accepts all the major HD video formats as shown in Table 3-1 and provides
extensive control over the downconversion process. When the 7711HDC downconverts 1080p/24sf input
video to 525i/60 with a 3:2, the 3:2 pulldown can be free run or locked to embedded RP188 or an external
6Hz input.
The 7711HDC provides card edge LEDs to indicate signal present, genlock present and audio groups
present. The 7711HDC has colour space conversion from ITU rec. 709 to ITU rec. 601, and will provide
various down converted formats such as 16:9 letterbox, 14:9 letterbox, 13:9 letterbox, 4:3 center crop, and
4:3 anamorphic squeeze.
The 7711HDC is available in two versions to support a wide variety of customer applications.
Model Video Audio
TimeCode/
Captions
SDI
Monitor
Analog Broadcast Analog Embedded In Embedded Out AES Out
7711HDC-S 2 2 --- ---
7711HDC-SN-EAES4 2 2 2 2 groups 2 groups 4 Yes
The 7711HDC-SN-EAES4 version de-embeds two groups of audio and re-embeds the audio on the SDI
output in time with the video. The audio is also available as 4 unbalanced AES outputs. The
7711HDC-SN-EAES4 also handles VANC data like captioning and timecode on the HD and moves it onto
the SDI outputs.
The 7711HDC occupies two card slots in the 3 RU frame, which will hold up to 15 modules or one slot in
the 1RU frame, which will hold up to three modules.
Features:
•Broadcast quality HD -> SD down conversion
•Optional broadcast quality analog outputs
•Supports 16:9 letterbox, 14:9 letterbox, 13:9 letterbox, 4:3 center crop, and 4:3 anamorphic squeeze
aspect ratio conversions
•1080p/24sF conversion to 525i/60 with 3:2 pulldown sequence determined by RP188 or 6Hz input
•HD to SD colour space conversion (ITU rec. 709 to ITU rec. 601)
•Reference input allows for phasing of output video
•Module supports min. delay or variable delay for video output without reference
•Module supports video output referenced to genlock with variable delay
•Analog monitor output on screen display used to configure the operating modes
•EAES4 version de-embeds Audio from HD video and embeds into SD video (2 groups)
•EAES4 version moves VANC data (e.g. captioning, timecode) from the HD video onto the SDI outputs
•VistaLINK®- enabled offering remote monitoring, control and configuration capabilities via SNMP.
VistaLINK®is available when modules are used with the 3RU 7700FR-C frame and a 7700FC
VistaLINK®Frame Controller module in slot 1 of the frame

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 2 Revision 1.1
*Genlock
Analog
Monitor
Outputs
Broadcast
Composite Analog
Outputs
SDI Outputs
(SMPTE 259M)
EQ + S/P
ARCI P
Audio +
Metadata
Extractor
Audio +
Metadata
Proc Delay
3:2
Pulldown
Audio &
Metadata
Embedder
AES Formatter
GPI/O + 6Hz Input
Frame
Buffer
Reference
Timing
Generator
Module
Status
Card Edge
Control &
Indicators
Video
Present
Audio
Groups
Present
Reference
Present
HD
Input
D to A
Converter
P/S
On
Screen
Display
Cable
Driver
Cable
Driver
Cable
Driver
(N-EAES4 option)
D
to
A
* A genlock loop is provided for output
phasing capability only
1
2
3
4
Figure 1-1: 7711HDC Block Diagram

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 3
2. INSTALLATION
The 7711HDC-S comes with a companion rear plate that occupies two slots in the frame and has 7 BNC
connectors, and one female DB9 connector. The 7711HDC-SN-EAES4 comes with a companion rear
plate that occupies two slots in the frame and has 9 BNC connectors, and one female DB9 connector. For
information on mounting the rear plate and inserting the module into the frame see section 3 of the
7700FR chapter.
Figure 2-1: 7711HDC Rear Panels
2.1. VIDEO CONNECTIONS
HD INPUT: Input BNC connector for 10-bit serial digital video signals compatible with the SMPTE 292M
standard. The 7711HDC can be set to automatically detect the standard or set to a specific
video standard using the on screen menu. See Table 3-1 for a list of the video standards
supported.
SDI OUTPUT:These two BNC connectors are used to output the downconverted input video as serial
component video, compatible with the SMPTE 259M standard.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 4 Revision 1.1
MON OUTPUT: These two BNC connectors are used to output the downconverted input video as
monitor grade analog composite video. They can be used to conveniently view the on
screen menu and status display on a low cost analog monitor.
ANALOG OUTPUT: (7711HDC-SN-EAES4 only) These two BNC connectors are used to output the
downconverted input video as broadcast quality analog composite video.
2.2. GENLOCK REFERENCE
For proper synchronization of the output video, the downconverter must be locked to a genlock signal of
the output video format.
GENLOCK: These two BNCs form a loop through for connecting an analog Genlock reference. The
genlock signal may be NTSC or PAL colour black, and is auto-detected by the module.
Jumper J9 on the APB3FMTCON submodule selects whether the reference input is
terminated to 75 ohms or high impedance (default). (See section 7.3). The output video
can be timed with respect to the genlock video using the H Phase Offset and V Phase
Offset menu items. (See section 6.3.3) When no Genlock is provided, the output video is
timed with respect to the input video.
2.3. AUXILIARY I/O
On the 7711HDC-S a 9 pin D connector labeled AUX I/O contains 2 GPI inputs, a 6 Hz input and 1 GPO
output. On the 7711HDC-SN-EAES4 a 9 pin D connector labeled AUDIO AND AUX I/O contains 2 GPI
inputs, a 6 Hz input, 1 GPO output and 4 unbalanced AES outputs. The connector pinout is shown in
Table 2-1.
Pin # Name Description
1 AES1 AES 1 Output **
2 GPO General Purpose Output – Not used at this time
3 Gnd Signal Ground
4 GPI2 Select User Preset 2
5 AES4 AES 4 Output**
6 6 Hz 6 Hz sequence input
7 AES2 AES 2 Output**
8 AES3 AES 3 Output**
9 GPI1 Select User Preset 1
** AES outputs on EAES4 version only.
Table 2-1: 9 Pin D Connector Pin Definitions
2.3.1. AES Audio Connections (7711HDC-SN-EAES4 version)
Four unbalanced AES outputs are provided on the 9 pin D connector. These outputs are for unbalanced
AES signals conforming to SMPTE 276M. Two groups of embedded audio from the HD input are extracted
and re-embedded on the output video. The transferred audio is also output as four AES channels.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 5
2.3.2. General Purpose Inputs and Outputs
Three pins on the 9 pin D connector are used for three general purpose inputs (GPIs). One of these inputs
is used for a 6 Hz input to the downconverter. The GPI1 and GPI2 inputs are used to select user presets
1 and 2 respectively. The GPIs are active low with an internal pull up (3.6k ohm) resistor to +5V or +12V.
The user can activate GPIs simply by connecting the GPI input pins to Ground. This can be done with a
button, switch, relay or an open collector transistor. See section 7.4 for information on selecting the pull-up
voltage. Figure 2-2 shows the input circuit for the general purpose inputs.
GPI
GND
GPI
Command
+ 12
VDC
to
internal
circuit
3.6 K
+ 5
VDC
J80
Figure 2-2: GPI Input Circuitry
The GPO is active low with internal pull up (10k Ohm) resistors to +5V. When the output goes low it is able
to sink up to 10mA. When high, the signal will go high (+5V). Do not draw more than 100µA from the
output. Figure 2-3 shows the circuit for the general purpose output. The GPO output is not used at this
time.
From Internal
Circuit
+ 5 Volts
GND
GPO
10 ohm
10 K
Figure 2-3: GPO Output Circuitry

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 6 Revision 1.1
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standard: 1.485 Gb/sec SMPTE 292M – menu selectable.
SMPTE 260M, SMPTE 274M, SMPTE 296M, SMPTE 349M
Common Name Pixels /
Active Lines Frame Rate Progressive /Interlace SMPTE Standard Output Format
1080i/59.94 1920 x 1080 29.97 (30/1.001) I 274M 525i/59.94 (NTSC)
1080i/50 1920 x 1080 25 I 274M 625i/50 (PAL)
1080p/29.97sF 1920 x 1080 29.97 (30/1.001) P (sF) 274M 525i/59.94 (NTSC)
1080p/25sF 1920 x 1080 25 P (sF) 274M 625i/50 (PAL)
1080p/23.98sF 1920 x 1080 23.98 (24/1.001) P (sF) 274M 525i/59.94 (NTSC)
1035i/59.94 1920 x 1035 29.97 (30/1.001) I 260M 525i/59.94 (NTSC)
720p/59.94 1280 x 720 59.94 (60/1.001) P 296M 525i/59.94 (NTSC)
480p/59.94 720 x 483 59.94 (60/1.001) P 293M, 349M 525i/59.94 (NTSC)
Table 3-1: Video Input Formats
Connector: BNC per IEC 169-8
Input Equalization: Automatic to 100m @ 1.5Gb/s with Belden 1694 or equivalent cable
Return Loss: >10 dB up to 1. 5Gb/s
3.2. SERIAL VIDEO OUTPUT
Standard: SMPTE 259M-C 270 Mb/s
Number of Outputs: 2
Connector: BNC per IEC 169-8
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 740ps nominal
Overshoot: <10% of amplitude
Return Loss: > 15 dB to 270 Mb/s
3.3. GENLOCK INPUT
Type: NTSC or PAL Colour Black 1 V p-p
Connector: BNC Loop per IEC 169-8
Termination: High impedance loop or internal 75 ohm termination (jumper selectable)

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 7
3.4. ANALOG MONITOR VIDEO OUTPUT
Standard: NTSC, SMPTE 170M
PAL, ITU624-4
Number of Outputs: 2
Connector: BNC per IEC 169-8
Signal Level: 1V nominal
DC Offset: 0V ±0.1V
Return Loss: > 35dB up to 5MHz
Frequency Response: 0.8dB to 4 MHz
Differential Phase: < 0.9°(<0.6°typical)
Differential Gain: < 0.9% < 0.5% typical)
SNR: > 56dB to 5 MHz (shallow ramp)
3.5. ANALOG VIDEO OUTPUT (7711HDC-SN-EAES4 only)
Standard: NTSC, SMPTE 170M
PAL, ITU624-4
Number of Outputs: 2
Connector: BNC per IEC 169-8
Signal Level: 1V nominal (user adjustable from menu)
DC Offset: 0V ±0.02V
Return Loss: > 35dB up to 5MHz
Frequency Response: 0.1dB to 4 MHz, 0.15dB to 5.5 MHz
Differential Phase: < 0.5°
Differential Gain: < 0.5%
SNR: > 78dB to 5 MHz
3.6. AES AUDIO OUTPUTS (7711HDC-SN-EAES4 only)
Number of Outputs: 4
Standard: SMPTE 276M, single ended synchronous or asynchronous AES
Connectors: Female 9 pin D
Resolution: 24 bits
Sampling Rate: 48 kHz
Impedance: 75 Ω
Signal Level: 1 V p-p nominal
3.7. GENERAL PURPOSE INPUTS
Number of Inputs: 3
Type: Opto-isolated, active low with internal pull-ups to +5 or +12V (jumper settable)
Connector: 3 pins (plus ground) on female 9 pin D
Signal Level: closure to ground
Function: 6 Hz reference, and user Preset 1 & 2 select

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 8 Revision 1.1
3.8. GENERAL PURPOSE OUTPUT
Number of Outputs: 1
Type: Opto-isolated, active low with internal pull-ups to +5V
Connector: 1 pin plus ground on Female 9 pin D
Signal Level: +5V nominal
Function: Not used at this time
3.9. INPUT TO OUTPUT PROCESSING DELAY
Minimum Delay Mode: 2 to 4 frames depending on input video format and processing mode. (See
Table 6-1 and Table 6-2)
Additional Delay: up to 1 additional frame dependent on output phasing to genlock reference.
Audio and VANC: Audio, captions and VITC are delayed and re-embedded in time with the
output picture (7711HDC-SN-EAES4 only)
3.10. ELECTRICAL
Voltage: +12VDC
Power: 26 Watts.
EMI/RFI: Complies with FCC regulations for class A devices.
Complies with EU EMC directive.
3.11. PHYSICAL
Number of slots:
7700 frame mounting: 2
7701 frame mounting: 1

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 9
4. STATUS INDICATORS
The 7711HDC has 3 LED Status indicators on the main circuit board front card edge to show operational
status of the card at a glance. Figure 7-1 shows the location of the LEDs and card edge controls.
Two large LEDs on the front of the board indicate the general health of the module:
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid input signal or if a local input power fault exists (i.e.: a blown fuse). The LOCAL
FAULT indication can also be reported to the frame through the FRAME STATUS
jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid input
signal is present, and the board power is good.
VIDEO PRESENT This Green LED will be ON when there is a valid video signal present at the module
input.
GENLOCK This Green LED will be ON when there is a signal present at the module genlock
input. This LED does not indicate that a correct signal appropriate for the current
video format is present.
4.1. AUDIO STATUS LEDS
Four LEDs located on the lower end of the module (near the card extractor) indicate which audio groups
are present in the input video. Audio group LED 1 is located closest to the center of the module.
Audio Group
LED Colour Audio Group Status
1 Off No group 1 present on input video.
Green Group 1 present on input video.
2 Off No group 2 present on input video.
Green Group 2 present on input video.
3 Off No group 3 present on input video.
Green Group 3 present on input video.
4 Off No group 4 present on input video.
Green Group 4 present on input video.
Table 4-1: Audio Group Status LEDs

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 10 Revision 1.1
5. CARD EDGE CONTROLS
The 7711HDC series modules are equipped with an 8 position DIP switch to allow the user to select
various functions. All positions are assigned sequentially such that the DIP switch 1 is located at the top
of the DIP switch (farthest from the card ejector). Table 5-1 gives an overview of the DIP switch functions.
Sections 5.1 to 5.2 describe the assigned DIP switch functions. The On position is down, or closest to the
printed circuit board. There is also a toggle switch and pushbutton which are used to navigate the on
screen menu. (See section 6)
DIP Switch Function
1 On screen display on program out
2 Default video standard when no video in
3
4
5
6
7
8
Reserved for future use
Table 5-1: Overview of DIP Switch Functions
5.1. DISABLING THE ON SCREEN DISPLAY ON THE PROGRAM VIDEO OUTPUTS
DIP switch 1 determines whether the On screen menu display will be shown on the Program SDI outputs
and the broadcast analog outputs (on the 7711HDC-SN-EAES4 version).
DIP 1 DESCRIPTION
Off On Screen Menus disabled on program video outputs (SDI OUTPUT and ANALOG OUTPUT). On screen
menus will only be on the analog MON OUT outputs.
On
(default)
On Screen Menus enabled on program video outputs
(SDI OUTPUT and ANALOG OUTPUT) and the analog
MON OUT outputs.
Table 5-2: On Screen Display Control Switch Settings
5.2. CONTROLLING THE OUTPUT VIDEO STANDARD ON LOSS OF VIDEO
DIP switch 2 controls the behaviour of the down converter when there is no input video.
DIP 2 DESCRIPTION
Off Output 525i/59.94 (NTSC) video on loss of input video.
On Output 625i/50 (PAL) on loss of input video.
Table 5-3: Default Video Switch Settings

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 11
6. ON SCREEN MENUS
6.1. NAVIGATING THE ON SCREEN MENU SYSTEM
A toggle switch and pushbutton allow card edge navigation on a set of on-screen menus used to configure
the card. To enter the on-screen menu system, press the pushbutton once. This will bring you to the
main setup menu where you can use the toggle switch to move up and down the list of available sub-
menus. An arrow (Î) moves up and down the left hand side of the menu items to indicate which item you
are currently choosing. Once the arrow is on the desired item, press the pushbutton to select the next
menu level.
On all menus, there are two extra selectable items: Back and Exit. Selecting Back will take you to the
previous menu (the one that was used to get into the current menu) while Exit will return the display to its
normal operating mode. On the main menu, BACK and EXIT will both take you to the normal operating
mode.
Once in a sub-menu, there may be another menu layer, or there may be a list of parameters to adjust. If
there is another set of menu options, use the toggle switch to select the desired menu item and press the
pushbutton.
To adjust any parameter, use the toggle switch to move up or down to the desired parameter and press
the pushbutton. The arrow will move to the right hand side of the line (Í) indicating that you can now
adjust the parameter. Using the toggle switch, adjust the parameter to its desired value. If the parameter
is a numerical value, the number will increase if you lift the toggle switch and decrease if you push down
on the toggle switch.
When you have stopped at the desired value, depress the pushbutton. This will update the parameter to
the selected value and move the arrow back to the left side of the parameter list (Î). Continue selecting
and adjusting other parameters or use the BACK or EXIT commands.
6.2. ON SCREEN DISPLAY – MAIN MENU
The OSD menu is arranged in a layered structure that groups similar configuration items together. The
following section gives a brief description of the first level of menus that appear when you enter the OSD
screens. Selecting one of these items will take you to the next menu level. Sections 6.3 to 6.11 provide
detailed descriptions of each of the sub-menus. The tables in sections 6.3 to 6.11 are arranged in an
indented structure to indicate the path taken to reach the control. Menu items or parameters that are
underlined indicate the factory default values.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 12 Revision 1.1
Video Sets the input and output video standards and timing for the video output.
Output Picture Configuration of the output picture aspect ratio, action on loss of input, panel
colours, and other items related to the output picture.
De-interlacer Configuration of the de-interlacer modes.
Scaler Configuration of the scaler filter sharpness.
VANC Data Processing Controls how vertical interval data is processed.
(7711HDC-SN-EAES4 version only)
Audio Sets the Audio groups (7711HDC-SN-EAES4 version only)
Broadcast Analog
Output Configuration of the Broadcast Analog output parameters.
(7711HDC-SN-EAES4 version only)
Monitor Analog Output Configuration of the Monitor Analog output parameters.
Utilities Card preset management and various debug and maintenance features.
6.3. CONFIGURING THE VIDEO CONTROLS
The Video menus are used to configure parameters associated with the input and output video standards
and output video timing. The chart below shows the items available in the Video menu. Sections 6.3.1 to
6.3.3.5 give detailed information about each of the menu items.
Video Standard Selects the video input and output standards.
Output Pulldown
Reference Selects the reference source when 3:2 pulldown is being added on the
output.
A Frame Offset Sets the offset of the A Frame from the Pulldown Reference when 3:2
pulldown is being added on the output.
525 V Phase Offset Sets the vertical phase of the output signal to the NTSC Genlock reference
input.
525 H Phase Offset Sets the horizontal phase of the output signal to the NTSC Genlock
reference input.
625 V Phase Offset Sets the vertical phase of the output signal to the PAL Genlock reference
input.
625 H Phase Offset Sets the horizontal phase of the output signal to the PAL Genlock reference
input.
NTSC Colour Frame
Offset Sets the offset in frames between colour frame 1 of the NTSC output signal
with respect to colour frame 1 of the NTSC Genlock reference input.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
Revision 1.1 7711HDC - 13
6.3.1. Setting the Video Input and Output Standard
Video
Video Std
Auto
1080i/59.94 to 525i/59.94
720p/59.94 to 525i/59.94
1080i/50 to 625i/50
1080p/23.98sF to 525i/59.94
1080p/29.97sF to 525i/59.94
1080p/25sF to 625i/50
1035i/59.94 to 525i/59.94
480p/59.94 to 525i/59.94
With this control, you can set the input and output video
standards.
Note: When set to Auto, the module cannot distinguish between
1080i/59.94 and 1080p/29.97sF, so it will be treated as
1080i/59.94. Similarly 1080p/25sF will be treated as 1080i/50.
6.3.2. 3:2 Pulldown Processing
When using a 1080i/59.94 input video feed containing 3:2 pulldown, the 7711HDC must be operated in
Field Mode in order to minimize motion artifacts. In Field mode each field of the incoming image will be
downconverted to one field of output image, so there will be no pulldown related de-interlacing artifacts on
film originated material with 3:2 pulldown, or video originated material acquired at a nominal 24 frames per
second.
When using a 720p/59.94 input video feed the 7711HDC will operate in Frame Mode where each frame of
the incoming image will be downconverted to one field of output image, so there will be no pulldown
related artifacts on film originated material with 3:2 pulldown, or video originated material acquired at a
nominal 24 frames per second.
When using a 1080p/23.98sF input video feed the 7711HDC operates in Frame Mode where each
segment of the incoming image is combined back to a progressive frame before down conversion. After
down conversion, extra fields are inserted to create a 3:2 pulldown at the output. The Pulldown Reference
menu is used to determine the cadence of the 3:2 output.

7700 MultiFrame Manual
7711HDC HD Broadcast Quality Down Converter
7711HDC - 14 Revision 1.1
6.3.2.1. Selecting the 3:2 Pulldown Reference with 1080p/23.98sF Input Video
"This menu setting is only used when the input video is 1080p/23.98sF. In other
input video formats it is not applicable
Video
Pulldown Reference
Auto
RP 188
6 Hz Input
Free Run
On 1080p/23.98sF video inputs the Pulldown Reference menu is used to
identify the input frame that will become an A frame at the output. This
frame is called the A frame candidate (see Figure 6-1). The output of the A
frame candidate frame will be delayed by 2 frames, will consist of two video
fields and will normally be in time with the genlock input. (See sections
6.3.3 and 6.3.3.3 for information on phasing of the output video with respect
to the genlock.) Additionally, an offset can be added to the A Frame
reference using the A Frame Offset control to accommodate situations
where the A frames are not in time with the A Frame reference. (See
section 6.3.2.2)
When you select Auto the 7711HDC will auto detect the pulldown reference
according to the following priority:
•6 Hz pulse if present
•RP188 ancillary timecode if present (model 7711HDC-SN-EAES4 only)
•Free Run pulldown if neither 6 Hz pulse or RP188 is present
Select RP 188 when the embedded ancillary timecode present on the input
video is used to determine the pulldown. The input frames with time code
frame numbers divisible evenly by 4 will normally identify the input A frame
candidates.
Select 6 Hz Input when a 6 Hz pulse connected to pin 6 of the AUXILIARY
I/O connector is used to determine the pulldown. The 6 Hz pulse should be
a 1/30th second wide TTL level active high pulse occurring 6 times per
second and must be coincident with the start of an input frame. The 6 Hz
pulse will normally identify the A frame candidates.
Select Free Run when you want a continuous 3:2 pulldown on the output
but do not care if it matches specific frames of the input video.
6.3.2.2. Accommodating Non-Standard 3:2 Sequences
"This menu setting is only used when the input video is 1080p/23.98sF. In other
input video formats it is not applicable
Video
A Frame Offset
0
1
2
3
This control allows the user to select other frames as the A Frames.
Figure 6-2 shows how this control defines the A frame candidate when the 6
Hz pulse is present. Figure 6-3 shows how this control defines the A frame
when RP188 Ancillary data is used to control the 3:2 pulldown.
