EXFO FTB-1v2 Pro User manual


FTB-1v2 and FTB-1v2 Pro
Accessing Connectors and Ports
Headset/microphone port
(for 3.5 mm connectors)
MicroSD card slot
(for cards compatible with the SDXC format)
USB 2.0 host ports
Ethernet (RJ-45) port
AC adapter/charger
connector
USB 3.0 host port
Module
Built-in power meter and VFL
(optional)
Mating connector
Replacing the Battery
1
2
Turn off the unit (shutdown) and disconnect it from AC power.
Using a flat screwdriver, turn the screws
counterclockwise until the module is loose.
Charging the Battery
Connect your unit to AC power with the
provided AC adapter/charger.
Pull on the battery’s tab to free it from its socket.
Slide in the new battery (poles facing down and
pointing to the same side of the case as
the mating connector). 7
8
Battery status LED
Green: Fully charged
Green, blinking: Charging
Yellow: Battery level is low
Position the unit so that its front panel rests on a flat surface such as a table.
6
Mating connector
Battery poles
Using a flat screwdriver, turn the screws clockwise until they are tighten.
10
3
4While holding the front panel and the module firmly together, turn the unit over, and position it so that the
module rests on a flat surface such as a table.
5Hold the front panel by its sides and pull it up.
Connection slot for the
module
Place the front panel on the module making sure that
the mating connector of the module is well aligned
with the corresponding slot on the front panel.
9While holding the front panel and the module firmly together, turn the unit over, and position it so that its
front panel rests on a flat surface such as a table.
Quick Reference Guide
© 2017 EXFO Inc. All rights reserved.
Printed in Canada (2017-05)
P/N: 1071546 Version: 2.0.0.1 For more information,
refer to the user guide.

Using Your Unit Attaching Modules
1
WARNING
To avoid electrical shock, always shut down the unit, and
disconnect it from its external power source BEFORE removing a
module.
Never remove a module while the unit is turned on. This will result
in immediate and irreparable damage to both the module and unit.
2Place the front panel on the module making sure that the mating connector of the module is well
aligned with the corresponding slot on the front panel.
Using a flat screwdriver, turn the screws clockwise
until they are tightened.
To adjust brightness
Information about the connected module
To start the applications related to the module
To retrieve information about your unit
To view the online help
Keyboard/screen capture button
Press once to show the on-screen keyboard.
Press once again to hide it.
Hold down for a few seconds to take a screen
capture.
Task-switching button
Press once to view the list of running applications.
Press as many times as needed to select the desired
application.
On/Off button
Press to turn the unit on.
Press to shut down the unit (default
behavior).
Button bar
To access modules and instruments, test
tools, utilities, documentation, and
to configure your unit
Mating connector
Connection slot for the module
3While holding the front panel and the module firmly together, turn the unit over, and position it so that
its front panel rests on a flat surface such as a table.
Position the module so that its back panel rests on a flat surface such as a table.
The battery should be visible.
4
