UV/VISIBLE
RADIOMETER
250 - 600 nm
USER'S GUIDE
Model R5000

Table of Contents
1Introduction5
2Control Functions & Features6
3Familiarizing Yourself with
the EXFO Radiometer7
4Using the EXFO Radiometer10
4.1 Turning on the EXFO Radiometer10
4.2 Irradiance Measurement10
4.3 Power Measurement11
4.4 Peak Measurement11
4.5 Relative Measurement12
4.6 Using a Non-standard Light Guide13
5Glossary of Symbols/ Safety
Precautions14
6Technical Specifications16
6.1 Optical16
6.2 Electrical 16
6.3 Mechanical17
6.4 Environmental Conditions17
6.5 Regulatory Compliance 18
6.6 Feature Summary20
7Trouble Shooting Guide21
8Accessories23
9Warranty25
9.1 Contact Information26
9.2 Returning the EXFO Radiometer26
9.3 Servicing27

i
i
1

5
1Introduction
Congratulations on your purchase of the EXFO
Radiometer. This radiometer includes revolutionary
technology that elevates the performance and accuracy of
hand held radiometers to new heights. It joins the EXFO
family of spot cure and illumination systems, offering the
same high level of innovation, quality and reliability that
customers have come to expect from EXFO.
At the heart of the EXFO Radiometer are two proprietary
systems: a non-imaging optical interface that virtually
eliminates measurement variation caused by radiance and
intensity variations in the light source; and a flat response
optical detector system that responds to energy at all
wavelengths between 250 and 600 nm. The result is a
hand held, robust and versatile radiometer with an
accuracy unmatched in the industry.
Standard and optical accessories include optical adapters
and band pass filters to adapt the EXFO Radiometer to
your specific radiometric application.
The EXFO Radiometer is a high quality product manufac-
tured in accordance to ISO 9001 and certified to CE, UL
and CSA standards.

6
Features Benefits
Provides accurate broadband
measurements between
250-600 nm
Versatile measurement capability
suitable for many different light
sources
Measures power or irradiance Allows for industry specific
measures
Optical interface collects light
over a large area
Eliminates beam intensity and
radiance dependence
Externally changeable bandpass
filters used to select wavelength
ranges for measurement
Fast, simple filter changes
Auto-ranging Maintains precision over full range
Peak Hold Mode measures and
displays maximum value
Identification of maximum value in
achanging signal
Real-time Mode Allows for tracking of a varying
signal
Relative Mode References all measurements to a
pre-set value
Absolute Mode References all measurements to
NIST traceable units
Fits standard light guides
(3mm, 5mm, 8mm)
Automatically senses light guide
diameters & accommodates indus-
try standard light delivery systems
CE marked; complies with IEC,
Canadian and US Standards
Ready for use worldwide
Calibration traceable to NIST* Quality assurance
Auto turn on and auto turn off Extends battery life and makes
operation easier
2Control Functions & Features
*Using Blank removable filter.

7
3Familiarizing yourself with the
EXFO Radiometer
EMFO
AdinTomo2oa-
aia-daffirrsaro
RALAN PEN(L PpWER!

8
A) LCD Display:
3'/2 digit display with indicators for low battery, over
range, Peak Hold, % (for Relative mode), Power mode
and Irradiance mode.
Automatic scaling function -
Power: Low range: 10— 990 mW
High range: 1.0— 15.00 W
Irradiance: Low range: 50— 990 mW/cm2
High range: 1.0— 225 W/cm2
B) Bandpass Filters:
User selectable and convenient external installation.
The standard filter is blank. Refer to the accessories in
section 8 for available optional filters.
C) Light Guide Port:
Accepts industry standard light guides and automatically
senses 3, 5 and 8 mm light guide diameters.
(adapters provided for 3 & 5 mm)
D) Relative/Absolute Mode Keypad:
Enables the user to select either Absolute
mode for standard power or irradiance
readings, or Relative mode which displays
readings as a percentage of an
established reference. The display will indicate "%" in
Relative mode. Absolute mode is the initial default.

9
E) Peak Hold Keypad:
Allows the display to indicate the
peak value being measured. The
display will indicate "P" when this
feature is activated.
F) Power/Irradiance Keypad:
Provides the user with the ability to select between
measuring power in "mW" or 'W" or irradiance in
"mW/cm2" or "W/cm2". When in Irradiance mode, the
Radiometer automatically senses 3, 5 or 8 mm light guide
diameters when the appropriate adapter is used.
Power
Irradiance
G) Ergonomically Designed Enclosure:
Compact, hand-held, and portable so it may be used
where it is needed most.

Using the EXFO Radiometer
NOTE: The EXFO Radiometer defaults to the
measurement mode it was in when it last automatically
turned off.
4.1 Turning on the EXFO Radiometer
The hand held Radiometer is not fitted with an ON / OFF
switch. Instead, the Radiometer has been designed with
an auto turn ON and auto turn OFF feature.
The Radiometer will automatically turn on when it detects
an optical signal of 10 mW or greater. When the light
source is removed, the display will remain on for 10
seconds. At that point, the display will flash for 5 seconds
as a warning of impending turn off. The Radiometer will
then turn off.
4.2 Irradiance Measurement:
Insert the light guide into the optical port on the top of the
Radiometer and turn on the light source. The display will
automatically turn on and display the irradiance in either
"mW/cm2" or "W/cm2". If the display indicates power, as
evident by the lack of the "/cm2" icon, press the
Power/Irradiance button once.

11
The display will indicate the irradiance for approximately
10 seconds after the light guide has been removed. The
display will flash for 5 seconds before powering down. The
EXFO Radiometer automatically detects 3, 5 or 8 mm
diameter light guides and calculates the irradiance
accordingly when the appropriate adapter is used.
4.3 Power Measurement:
Insert the light guide into the optical port on the top of the
Radiometer and turn on the light source. The display will
automatically turn on. Power measurements are indicated
by the units of Watts. If the unit icon includes "/cm2",
momentarily press the Power/ Irradiance button.
The display will indicate power in "mW" or 'W" and will
remain active for approximately 10 seconds after the light
guide has been removed. The display will flash for
approximately 5 seconds before powering down.
4.4 Peak Measurement:
To obtain a peak value of a measurement in Irradiance or
Power, follow the steps as outlined in sections 4.2 or 4.3.
Once the Radiometer is in the correct measurement
mode, momentarily press the Peak Hold button. The LCD
display will indicate a "P" in the bottom left hand
corner. The unit will track all subsequent readings and

12
display the peak value. Any subsequent measurements
that are lower than the Peak mode reading will not be
displayed.
4.5 Relative Measurement:
The Relative mode allows the user to display measure-
ments as a percentage of a reference value. Begin by
inserting the light guide into the optical port on the top of
the Radiometer. Select either Power or Irradiance as
described in sections 4.2 or 4.3. Adjust the optical source
to the desired reference level, then press the Relative/
Absolute button. The Radiometer will now be in Relative
mode. All subsequent measurements will be displayed as
apercentage of the reference. A reading of "100%" will
indicate that the current measurement is the same value
as the reference. A reading of "50%" will indicate that the
current measurement is half of the initial reference
measurement.
After removing the light guide, the display will remain on
for 10 seconds. Inserting a light guide from a different
source prior to the display turning off, will provide a
measurement which is relative to the initial reading as
described above.

13
4.6 Using Non-Standard Light Guides:
NOTE: If a light guide with an active area diameter other
than a 3, 5 or 8 mm is to be used in conjunction with this
Radiometer:
1. Select the light guide adapter that is the closest
match to the diameter of the light guide to be used.
2. Configure the Radiometer to measure power.
(irradiance readings will not be accurate)
3. If irradiance values are desired, divide the power
readings by the output area of the light guide being
used.
4. The specifications listed in section 6 cannot be
guaranteed.

Glossary of Symbols/ Safety Precautions
-4
ATTENTION
Consult accompanying documents
WARNING
Eye damage may result from directly
viewing Ultraviolet light. Always wear UV
protective eyewear/ face shield and
protective clothing.
+Battery
=MUM IMMO
D.C. Current

15
SAFETY PRECAUTIONS:
CAUTION!
Never look into the light emitting end of a
light guide. The light could severely damage
the cornea and retina of the eye if the light is
observed directly. Eye shielding must be
used at all times as well as protective
clothing to protect exposed skin.
WARNING!
Should the EXFO Radiometer be used in a
manner not specified by EXFO, the protection
provided by the equipment may be impaired.

16
6Tech n ica l Specifications*
6.1 Optical:
Wavelength Range: 250-600 nm
Maximum Range: Power: 10 mW— 15.0 W
Irradiance: 50 mW/cm2— 225.0 W/cm2
Resolution: Power: 10 mW
Irradiance: 10 mW/cm2
Accuracy: +/- 5% typical,
+/- 10% maximum
Auto-raging: Power: 10— 990 mW,
1.0— 15.00 W
Irradiance: 50— 990 mW/cm2,
1.0— 225 W/cm2
Removable filters: Standard: blank
Optional: 250-450 nm
320-500 nm
365 nm
320-390 nm
400-500 nm
6.2 Electrical:
Battery Type: Standard: 9 volt D.0
Battery Life: 2 years, typical
(intermittent use)

17
6.3 Mechanical:
Dimensions: LxWxH
5.22 x 3.5 x 1.5 inches
13.2 x 8.9 x 3.8 cm
Weight: 0.90 lbs. / 400 g
Includes: adapters for 3 and 5 mm light
guides, carrying case, one
Proximity Measurement
Adapter ,manual
Warranty: 1 year
6.4 Environmental Conditions:
Operating Environment Conditions
Installation Category II, Pollution Degree 2
Temperatur e : 10 to 40 degrees Celsius
Relative Humidity: 30% to 75% (non-condensing)
Atmospheric Pressure: 700 to 1060 hPa
Altitude: 2000 meters (maximum)

18
Transport and Storage Conditions
Temperature:
Relative Humidity:
Atmospheric Pressure:
-10 to 60 degrees Celsius
10% to 100%
(non-condensing)
500 to 1060 hPa
•Specifications are subject to change without notice.
6.5 Regulatory Compliance:
Complies to the following directives/standards
Council Directive 73/23/EEC Low Voltage Directive
Council Directive 89/336/EEC EMC Directive
CE Representative
GENTEC Benelux
Chausse de Louvain, 270
B-1410 Waterloo
Belgium
CE

19
Information to User
FCC Class A Digital Device or Peripheral
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
when the equipment is operated in a commercial
environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Warning
Changes or Modifications not expressly approved by
EXFO Photonic Solutions Division could void the user's
authority to operate the equipment.

20
6.6 Feature Summary:
Features: Power measurement
Irradiance measurement
Automatic light guide (size) detection
Relative mode
Over range indication
Low battery indication
Peak Hold measurement
Absolute measurement
Real-time measurement
Auto turn on/off
Replaceable filters
NOTE: Calibration is recommended every 6 months
and is available through EXFO Photonic Solutions
Division. Please refer to section 9 of the manual.
