Exmark Ultravac Bagger 126-8680 Manual

ULTRAVAC®BAGGER
126-8680
SetupInstructions
ForUltravacSerialNos.406,294,345&Higher
(TotLazerZDieselUnitsSerialNos.790,000&Higher)
Important:DuetotheaddedweightoftheUltravac,itisimportanttoensuretheparkingbrakeonyour
mowerisadjustedproperly.BeforeinstallingtheUltravac,makesuretore-adjusttheparkingbrakeon
yourmowerasoutlinedinthe“AdjustingtheParkingBrake”procedureintheMaintenancesectionof
themowerOperator'smanual.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer
extranet.
DealerPack
PartNo.DescriptionQty.Use
—Fillouttheonlinewarrantyregistration
form.
LiteraturePack
Manual-Operator's
ModelsandRequiredCompletingKits
CompletingKits
Note:UsethefollowingchartstoverifythekitsrequiredforthemachineyouareinstallingtheUltraVacon.
DeckCompletingKit
80T-60(60inchdeckwith80TEngine)126-8675
80T-72(72inchdeckwith80TEngine)126-8677
88C-60(60inchdeckwith88CEngine)126-8676
88C-72(72inchdeckwith88CEngine)126-8678
©2019—ExmarkMfg.Co.,Inc.
2101AshlandAve
Beatrice,NE68310
PartNo.4504-789Rev.A
PrintedintheUSA.
AllRightsReserved*4504-789*A

AdjustingtheParkingBrake
Re-adjusttheparkingbrakeonyourmowerasoutlined
inthe“ParkingBrakeAdjustment”procedureinthe
MaintenancesectionofthemowerOperator'smanual.
InstallingtheMountBrackets
1.Installalowermountbracketontheleftandright
sideoftherearbumpercrosstubeasshownin
Figure1.Alignthemountholesandinstalltwo
3/8-16x21/2inchscrews,washer,and3/8inch
angednylocnutsineachbracket.
g242061
Figure1
1.Lowermountbracket4.3/8inchangednylocnut
2.3/8-16x21/2inchscrew5.Rearbumpercrosstube
3.Washer
2.Installone3/8-16x3inchcarriagebolt,washer,and
3/8-16inchnylocnutintoeachlowermountbracket
throughthefrontoftherearbumperasshownin
Figure2.Install3/8-16x21/2inchscrewthrough
thesideoftherearbumperandsecurewith3/8inch
angednylocnut.Theheadofthescrewisfacing
outwardoneachbracket(seeFigure2).
g242062
Figure2
1.3/8-16x3inchcarriage
bolt
3.3/8inchangednylocnut
2.Washer4.3/8-16x21/2inchscrew
InstallingtheWeightAssembly
Note:Theremovableweightsareheavy.Usecarewhen
liftingthem.Makesurethatyoucanholdthemsecurely
beforeliftingthem.Usecautionwhenpositioningyour
handssothatyouDoNotsetthemdownonyourhands
orngers.
WARNING
Casterortoeboardweightsinstalledwithoutthe
collectionsystemmaycauselossoftractionand
steeringcontrol.Lossofcontrolcanresultinan
accidentwhichmaycausedeath,injury,orproperty
damage.
InstallcasterortoeboardweightsONLYwhenthe
collectionsystemisinstalled.
1.OntheLHside,insertthe3/8-16x61/2inchscrew
intoholeonthebottomsideofthebracketandthe
rearoftheremovable45lb(20.4kg)casterweight
asshowninFigure3.Carefullyplacetheweightand
bracketassemblyontothecasterarmcenteringthe
holeoftheweightoverthecasterwheel.
2

g242048
Figure3
1.3/8-16x61/2inchscrew6.Hairpin
2.Knob7.20lb(9.1kg)casterweight
3.Bracket8.3/8-16inchnylocnut
4.45lb(20.4kg)caster
weight
9.Washer
5.Clevispin10.3/8-16x8inchscrew
2.Securethebottomofthebrackettothecasterarm
withaclevispinandhairpin.
3.Tightentheknobonweightassemblyuntilitis
clampedsecurelytothecasterarm.
4.Installthree20lb(9.1kg)casterweightsoverthe
weightassemblyscrewandstackthemsecurelyonto
the45lb(20.4kg)casterweight.Securetherearof
theweightassemblywitha3/8-16inchnylocnut.
5.Install3/8-16x8inchscrewandwasherthroughthe
topofthefrontholesoftheweightassemblyand
securewith3/8-16inchnylocnut.
6.RepeatallstepsfortheRHside.
Note:TheportionsoftheUltraVaccollectionsystem
thatarenotboltedtothemoweraredesignedtobe
installedorremovedintheirentirety.DoNotoperate
themowerwithonlyaportionoftheUltraVacinstalled.
InstallingtheBeltCoverBracket
1.Lowerthedeckfully.Removeandretainthe
standardrightsidebeltcover,wireformbracketand
itshardware.
2.Installthebeltcoverbracketusingthetwo3/8-16x
11/4inchcarriageboltsandtwo3/8-16inchnyloc
nuts(seeFigure4).
g242122
Figure4
1.3/8-16inchnylocnut
2.Beltcoverbracket
3.3/8-16x11/4inchcarriagebolt
InstallingtheBlowerDriveSheave
1.Removehairpin,chutepivotpin,anddischarge
chute.Pivotpinandhairpinmaybestoredinthe
pivotholesofthedischargechuteduringbagging
operation.
2.Removethedeckdrivebeltfromaroundtheright
handspindlesheave.
3.Supporttherightmowerbladeandshaftsothatit
willnotfalloutofthedeckwhentherightsheave
nutisremoved.
4.Removetherightsheavenut,springdiscwasher,and
sheavefromthespindleshaft.
Blockthebladerotationwithablockofwood
betweenthebladeandbafesasindicatedinthe
bladeservicesectionoftheOperator’smanual.
DoNotusethebladebolttopreventrotation.
3

5.ApplyalightcoatofMobilHTSgrease(orfood
gradeantisieze)tothetopportionofthespindle
shaftwherethesheavemounts.
6.Installdoublesheaveontotherightspindleshaft.
Installthespringdiscwasherandnut.Makesure
thatthespringdiscwasherconeisinstalledtowards
nut(seeFigure5).Torquethesheavenutto140-145
ft-lb(190–197N-m).
Blockthebladerotationwithablockofwood
betweenthebladeandbafesasindicatedinthe
bladeservicesectionoftheOperator’smanual.
DoNotusethebladebolttopreventrotation.
g007021
Figure5
1.Torquesheavenutto140-145ft-lb(190–197N-m).
2.Installwithconetowardsnut.
Checkbladebolttorqueaftercompletingthis
installation.
Torquebladeboltto50-60ft-lb(75-81N-m).
7.Re-installthedeckdrivebeltinthelowergrooveof
thedoublesheave.Installtheplugintotheboreof
thedoublesheave.
g242158
Figure6
1.Beltcoverbracket4.Belt
2.Beltcover5.Decksheaveandnyloc
plug
3.Knob
InstallingtheBlowerAssembly
1.Pullthespringloadedidlerbackandslipthebelt
overthetopdecksheave.
g009311
Figure7
1.Impellersheave3.Springloadedidler
2.Decksheave
2.Positionthebeltcoveratanangleandslideitunder
themowerframe(seeFigure8).
4

g242180
Figure8
1.Blower3.Mowerframe
2.Beltcover
3.Pushdownonthebackofthecoverandslideit
backwardsundertheblower.
4.Withthebeltcoverrestingonthedeck,slideit
forwarduntilitisseatedunderbothlipsonthedeck.
g009341
Figure9
1.Blower3.Decklip
2.Beltcover
5.Installtheknobanditshardware.
InstallingtheHopperAssembly
1.Laythehopperassemblydownbehindthemachine.
Pickupthebaggerframelegsandhookthenotch
ontothelowerbaggermountbarasshownin
Figure10.
g242492
Figure10
1.Lowerbaggermountbar2.Frameleg
2.Liftthehopperassemblyandpivotitupwardtowards
thebackofthemachine.Attachtherodsupportto
eachsideoftherearframeasshowninFigure11.
g242046
Figure11
Rightsideshown
1.Rodsupportassembly4.Mountpinwithlanyard
2.Baggerpin5.1/2inchlocknut
3.Washer
3.Raisethehoodandinstallthebagassembliesby
slidingthebagframehooksontotheretainingslots
onthehopperframe.
4.Closeandlatchthehood.
5

AssemblingtheTubes
1.For60inchdecks,shortentheuppertube.
A.Locatethethreeholesintheuppertube.Measure
61/2inches(165mm)upfromtheendofthe
tubeandmarkthelocationinallthreeareas(see
Figure12).
g009351
Figure12
1.Newholelocation
2.Measure61/2inches(165mm)
3.Measure3–31/2inches(76–89mm)
4.Cuttube
B.Drillthree3/16inch(4.8mm)diameterholes.
C.Measure3–31/2inches(76-89mm)fromthe
endofthetube,createmarks,andapplymasking
tapearoundthetubeasaguide.
D.Carefullycutthetubeanddiscardtheend.
2.Sliptheupperandthelowertubestogether.
3.Inserttheuppertubeintothehopperseal–pushin
thenpulloutsothatthesealisextendedoutward.
4.Alignthedimpleontheuppertubewiththeendof
hoppersealandcenterbetweenthetwoscrewsas
showninFigure13.
g007027
Figure13
1.Dimple
5.Setthedeckinlowestcuttingposition.
6.Slidethelowertubeontotheblowerandattachthe
latches.(Makesurethattheuppertubedoesnot
moveoutofalignment).
7.Drillthe7/32inch(5.6mm)diameterholesinthe
lowertubeusingtheuppertubeholesasreference.
SeeFigure14.
8.Removethetubesfromunitandassembletheupper
andthelowertubesusingthree#10-24x3/4inch
hexwasherheadscrews,three#10washers,and
three#10-24nylocnuts.Thescrewheadshould
beinstalledtotheinsideofthetubetoprovide
minimumobstructiontoow.Makesurethatthe
upperandthelowerendsareorientedproperlyasthe
tubesareassembled.(Partinglinesshouldroughly
belinedup.)
g007028
Figure14
1.Drilltheholeshere
FillOutWarrantyRegistration
Form
Fillouttheonlinewarrantyregistrationform.
