ULTRAVAC®BAGGER
126-6122
SetupInstructions
ForUltraVacSerialNos.402,082,300&Higher
(TotRadiusModelsSerialNos.400,000,000&Higher)
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer
extranet.
DealerPack
PartNo.DescriptionQty.Use
—Fillouttheonlinewarrantyregistration
form.
LiteraturePack
Manual-Operator's
©2017—ExmarkMfg.Co.,Inc.
P .O.Box808
Beatrice,NE68310
PartNo.4503-657Rev.A
PrintedintheUSA.
AllRightsReserved*4503-657*A

ModelsandRequiredCompletingKits
CompletingKits
Note:UsethefollowingchartstoverifythekitsrequiredfortheunityouareinstallingtheUltraVacon.
E-andS-Series
DeckCompletingKit
48inch126-6196
52inch126-6197
60inch126-6198
X-Series
DeckCompletingKit
48inch126-6209
52inch126-6210
60inch126-6211
2

InstallingtheHopperMount
Brackets
1.Raisethedecktothetransportposition.Raisethe
backofthemachineupandsupportthemachine
withjackstands.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbe
enoughsupportormaymalfunctionallowing
theunittofall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstandsor
equivalentsupport.
2.Removethereartiresfromthemachine.
3.Removeandretaintherearweightanditsmounting
hardware(ifapplicable).
4.Removeandretainthenutsfromtheboltsonthe
bottomofeachhydroasshowninFigure1.Install
thetransmissionsupportbracketandsecurewith
nuts.
g189992
Figure1
1.Retainnuts3.Rearweight
2.Transmissionsupport
bracket
4.Torxbolts
5.Removeanddiscardthetorxboltsandnutsonthe
leftandrightsidesoftherearguardthatattaches
ittotheframe.
6.InstallthelegsoftheLHandRHbaggersupport
bracketontothetransmissionstudsandsecurewith
thenutsretainedinstep4(seeFigure2).
g037961
Figure2
1.LHsupportbracket4.5/16atwasher
2.RHsupportbracket5.5/16inchangednylocnut
3.5/16-18x31/4inchhex
screw
7.Securethesidesofthebaggersupportbracketsto
therearframeusing5/16-18x31/4inchhexscrews
and5/16inchangednylocnuts(seeFigure2).
8.Ifequipped,removeanddiscardthescrewsandnuts
thatsecuretheleftandrightuppersupportbracket
totherearguard.Installtheupperrearmount
brackettotheLHandRHbaggersupportbrackets.
3

g189991
Figure3
1.Upperrearmountbracket4.Hitchcover
2.5/16-18x31/4inch
carriagescrew
5.Uppersupportbracket(if
equipped)
3.5/16inchangednylocnut
9.Placethehitchcoverontotherearguard(see
Figure3).
Note:Itmaybenecessarytotapitintoplacewith
amallet.
InstallingtheWeightAssembly
WARNING
Casterortoeboardweightsinstalledwithoutthe
collectionsystemmaycauselossoftractionand
steeringcontrol.Lossofcontrolcanresultinan
accidentwhichmaycausedeath,injury,orproperty
damage.
InstallcasterortoeboardweightsONLYwhenthe
collectionsystemisinstalled.
Note:Theremovableweightsareheavy.Usecarewhen
liftingthem.Makesurethatyoucanholdthemsecurely
beforeliftingthem.Usecautionwhenpositioningyour
handssothatyouDoNotsetthemdownonyourhands
orngers.
1.Assembletheweightsbyplacingtheweightbracket
plateinsidethemountchannel.Installthetabbed
weightbracketplateinsidethemountchanneland
againsttheweightbracketplateasshowninFigure4.
Securethemountchannelassemblytotheweight
usingtwo3/8-16x21/2inchboltsandtwo3/8
inchwhizlocknuts.
g185955
Figure4
1.Weight4.Tabbedweightbracket
plate
2.Mountchannel5.3/8-16x21/2inchsquare
headbolt
3.Weightbracketplate6.3/8inchwhizlocknut
For48InchDeckOnly:
Removeandretainthetwomountingnutsonthe
topsideofthecasterweight.Installtheextraat
weightontopofthecasterweightandsecurewith
thetwonuts(seeFigure5).
g037628
Figure5
1.Nut3.Casterweight
2.Flatweight
2.Installoneremovablecasterweightoneachcaster
armasshowninFigure6.
4

g037183
Figure6
1.Bolt3.Washer
2.Knob4.Casterweight
3.Inserttheboltthroughthebracketholeandinstall
thewasherandknob.
4.Tightentheknobonweightassemblyuntilthe
weightisclampedsecurelytothecasterarm.
Note:TheportionsoftheUltraVaccollection
systemthatarenotboltedtothemoweraredesigned
tobeinstalledorremovedintheirentirety.Do
Notoperatethemowerwithonlyaportionofthe
UltraVacinstalled.
InstallingtheBeltCoverBracket
1.Removeandretainthedischargedeectorandits
mountinghardware.
2.Lowerthedeckfully.Removeandretainthe
standardrightsidebeltcover,wireformbracketand
itshardware.
3.Installthebeltcoverbracket.
•48and52InchDecks:Usetwo3/8-16x1
1/4inchcarriageboltsandtwo3/8inchanged
nylocnutsasshowninFigure7.
g037341
Figure7
48and52InchDecks
1.3/8-16x11/4inchcarriagebolt
2.Beltcoverbracket
3.3/8inchangednylocnut
•60InchDeck:Usetwo3/8-16x11/4inch
carriageboltsandtwo3/8inchangednyloc
nutstoinstallcoverbracketasshowninFigure8.
Installtheblockerplatetotheoutsideofthedeck
using3/8-16x11/4inchcarriageboltand3/8
inchangednylocnut.
g037349
Figure8
60InchDecks
1.3/8-16x11/4inchcarriage
bolt
4.Blockerplate
2.Beltcoverbracket5.3/8-16x11/4carriagebolt
3.3/8inchnylocnut
5

InstallingtheBlowerDriveSheave
1.Removethedeckdrivebeltfromaroundtheright
handspindlesheave.
2.Supporttherightmowerbladeandshaftsothatit
willnotfalloutofthedeckwhentherightsheave
nutisremoved.
3.Removetherightsheavenutandsheavefromthe
spindleshaft.
4.Installthedoublesheaveontotherightspindleshaft
andinstallthenut.Torquethesheavenutto130-160
ft-lb(176–217N-m).
Blockthebladerotationwithablockofwood
betweenthebladeandbafesasindicatedinthe
bladeservicesectionoftheOperator’smanual.
DoNotusethebladebolttopreventrotation.
g007021
Figure9
1.Torquesheavenutto130-160ft-lb(176–217N-m).
2.Installwithconetowardsnut.
Checkbladebolttorqueaftercompletingthis
installation.
Torquebladeboltto50-60ft-lb(75-81N-m).
5.Re-installthedeckdrivebeltinthelowergrooveof
thedoublesheave.Installtheplugintotheboreof
thedoublesheave.
g190023
Figure10
1.Beltcoverbracket4.Belt
2.Beltcover5.Decksheaveandnyloc
plug
3.Knob
InstallingtheBlowerAssembly
1.Mountthebloweronthedeckbyinsertingthe
mountingpinintothetubeweldedtotherearcorner
ofthedeck.UseFigure11todeterminethepin
locationintheblowerframe.
g037990
Figure11
1.Mountingpin4.48inchdecklocation
2.Rollpin5.60inchdecklocation
3.52inchdecklocation
2.Pivottheblowertowardsthedeckandpulloutward
onthelatchpin.Releasethelatchpinwhenitaligns
withtheholeonthetabofthedecktolockthe
blowerinthisposition.
6

3.Pullthespringloadedidlerbackandslipthebelt
overthetopdecksheave.Thebeltshouldberouted
asshowninFigure12.
g190065
Figure12
ViewfromT opofBlower
4.Positionthebeltcoveratanangleandslideitunder
themowerframe(seeFigure13).
g038057
Figure13
1.Blower3.Mowerframe
2.Beltcover
5.Pushdownonthebackofthecoverandslideit
backwardsundertheblower.
6.Withthebeltcoverrestingonthedeck,slideit
forwarduntilitisseatedunderbothlipsonthedeck.
g038066
Figure14
1.Blower3.Decklip
2.Beltcover
7.Installtheknobanditshardware.
InstallingtheHopperFrame
1.Removethehairpinfromthehopperframe.Insert
thehopperframeintotheLHhoppermountbracket
(seeFigure15).Resttheotherendofthehopper
framebetweenthetabsontheRHhoppermount
bracket.Reinstallthehairpintosecurethehopper
frame.
Note:Ifthehopperframedoesnotseatproperlyin
themountbrackets,carefullyusethehopperframe
toslightlyadjustthealignmentofthebrackets.The
frameisdesignedtoinitiallyttightinthemounting
brackets.Itmaybenecessarytouseamalletto
install.
7

g190024
Figure15
1.LHhoppermountbracket
2.Hopperframe
3.Hairpin
4.RHhoppermountbracket
5.Holddownrod
2.Removethehairpinfromtheholddownrod.Insert
theholddownrodintothehopperframeand
reinsertthehairpin(reference).
InstallingtheHopper
1.Removeandretainthehairpinsfromtheairvent.
2.Pressthetabsontheairventintothenotchesonthe
insideofthehopperandsecurewithhairpins.
g037999
Figure16
1.Hopperframepin3.Hopperhinge
2.Seal(partiallyremovedfor
clarity)
4.Airvent
3.Slidethehopperhingesontothehopperframepins.
4.Makesurethesealispositionedaroundthebrackets
wherethebagsmount.
AssemblingtheTubes
1.Sliptheupperandthelowertubestogether.
2.Inserttheuppertubeintothehopperseal–pushin
thenpulloutsothatthesealisextendedoutward.
3.Alignthedimpleontheuppertubewiththeendof
hoppersealandcenterbetweenthetwoscrewsas
showninFigure17.
g007027
Figure17
1.Dimple
4.Setthedeckinthelowestcuttingposition.
5.Slidethelowertubeontotheblowerandattachthe
latches.(Makesurethattheuppertubedoesnot
moveoutofalignment).
For60InchDeckOnly:Ifthereistoomuch
overlapbetweentheupperandlowertubes,itmay
benecessarytoshortentheuppertube.
Toshorten:
A.Determinehowmuchneedstobecutofffrom
theendofthetube.Locatethethreeholes
intheuppertube.Measurefromtheendof
thetubetwicethedistancethatneedstobe
removed.Markthelocationofallthreeholes
(seeFigure18).
8

g204645
Figure18
1.Newholelocation
2.Measurefornewholelocation
3.Measureforcutline
4.Cuttube
B.Drillthree3/8inchholes.
C.Measurefromtheendofthetubetheamountto
remove,createmarks,andapplymaskingtape
aroundthetubeasaguide.
D.Carefullycutthetubeanddiscardtheend.
6.Drillthe7/32inchholesinthelowertubeusingthe
uppertubeholesasreference.SeeFigure19.
7.Removetubesfromtheunitandassembletheupper
andthelowertubesusingthree#10-24x3/4inch
hexwasherheadscrews,three#10washers,and
three#10-24nylocnuts.Thescrewheadshould
beinstalledtotheinsideofthetubetoprovide
minimumobstructiontoow.Makesurethatthe
upperandthelowerendsareorientedproperlyasthe
tubesareassembled.(Partinglinesshouldroughly
belinedup.)
g007028
Figure19
1.Drilltheholeshere
InstallingtheROPSPin
TopreventtheROPSbarfromdamagingthehopper,
installtheROPSpinassembly.
1.Using11/64or#19drillbit,drilltheinnerRHROPS
hole3/4inch(19mm)deepasshowninFigure20.
g038069
Figure20
1.Drill3.#10-24x3/4inchhex
screw
2.#10washer4.ROPSpinwithlanyard
2.Placethe#10washerandlanyardcableendonto
the#10-24x3/4inchhexscrewandinstallintothe
RHROPShole.
3.InstalltheROPSpin.
4.Repeatsteps1through3fortheLHROPS.
FillOutWarrantyRegistration
Form
Fillouttheonlinewarrantyregistrationform.
