Extech Instruments BR146 User manual

User's Guide
Flexible Borescope
Model BR146

BR146 V2.0 9/08
2
Introduction
Congratulations on your purchase of the Extech BR146. This product is used for
inspection of areas generally inaccessible to the naked eye, such as internal inspection
of engines, gear train components, interior structures of walls, and industrial applications.
Illumination is provided by two solid state LEDs which are controlled by a three position
switch, giving low, off, and high output. Lighting is powered by 4 “AA” batteries located in
the handle. The adjustable eyepiece focus allows the user to fine tune for object distance.
The scope comes in a protective case for storage. An accessory mirror allows the user
to see 90 degrees to the axis of the shaft. The Magnet accessory will pick up approx 1/4
lb. This device is shipped fully tested and, with proper use, will provide years of reliable
service
Safety
STOP IMPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE
OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO COULD CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP
THESE INSTRUCTIONS FOR FUTURE USE.
•DO NOT use flexible inspection scope if damaged
•Do not point the tip toward the Sun or other intense source of light while viewing.
Permanent eye damage may occur.
•Maintain your scope in new condition as detailed in MAINTENANCE for long service
•Be aware of your surrounding environment while using your inspection scope
•Account for all tools and parts being used or serviced and do not leave loose parts
near moving parts of an engine
Specifications
Viewing distance: 0.4”(10mm) to infinity
Viewing Angle 48°
Side View Adaptor: 90°
Tip Diameter 0.39” (10mm)
Working Length: 46” (1168mm)
Maximum bend radius 3” (7.62cm)
Optical system: fiber optic (7400 fibers)
Illumination LED (2) (High/Low intensity selection)
Max probe temperature 158°F / 70°C
Shaft material HDPF
Housing material Nylon
Compatibility Water, diesel, gasoline, brake
fluid, antifreeze, motor oil, gear oil and other liquids
Power 4 AA batteries
Weight: 1.15lb (0.52kg)
Carrying Case Dimensions: 17 x 13 x 4.5” (432mm x 330mm x 114mm)

BR146 V2.0 9/08
3
Description
1. Eyepiece and Focus
2. LED ON and intensity switch
3. Handle
4. Battery compartment
5. Shaft
6. Tip and Light source
Operation
WARNING! Be carefulwheninsertingorremoving the scope shaft fromthe equipmentunder
inspection.
WARNING! Use extra care when using mirror or magnet accessories. Accessories may
detach if snagged.
DO NOT bend any part of the shaft tighter than a 3 inch radius ( 6 inch
diameter).
DO NOT expose the scope housing to water or other fluids.
DO NOT insert the scope shaft and tip into locations whose temperature is
greater than 158º/F70ºC.
1. Note the location and distance of the object to be inspected and determine
the best route to it. Bend the shaft to follow the route.
2. View the object through the eyepiece. Adjust the focus as necessary by
turning the eyepiece.
3. Press the switch below the eyepiece to turn on the LED light. A left press
is high intensity, right press is low intensity (extends battery life).
4. Attach the side view mirror or retrieval magnet to the tip as shown. Make
sure the spring clip is fully secure in the recessed groove provided.
NOTE: The base of the mirror or magnet should be aligned over the flat side of
the tip.
Maintenance
BATTERY REPLACEMENT
WARNING ! Make sure switch is in the off position prior to maintenance and/or battery
replacement.
1. Remove the battery housing door with a Phillips screwdriver.
2. Un-clip the connector - if required - and replace batteries in the pack. Dispose of
batteries properly.
3. Re-attach connector and re-insert battery pack into bottom of handle.
4. Re-assemble battery door. Do not over tighten screw.
CLEANING AND STORAGE
After each use, wipe down the tip and shaft with a clean, dry cloth to remove fluids and
residue. If needed, clean the shaft with a cloth dampened with a mild soap detergent
Gently clean the lens and eyepiece with a cotton swab dampened with a lens cleaner
such as isopropyl alcohol.
NOTE: Your inspection scope MUST be completely dry before returning it to the
storage case.
1
2
3
4
5
6

BR146 V2.0 9/08
4

Support line [phone]
Technical Support: Extension 200; E-mail: [e-mail]
Repair & Returns: Extension 210; E-mail: [e-mail]
Product specifications subject to change without notice
For the latest version of this User Guide, Software updates, and other
up-to-the-minute product information, visit our website: www.extech.com
Extech Instruments Corporation, 285 Bear Hill Road, Waltham, MA 02451
