Fairford XFE Series Owner's manual

1 M-85E0-F O81121
F A I R F O R D
E L E C T R O N I C S
Basic Guide to the
Installation and Operation
Of the Soft StarterXfe
Soft Starters and Energy
Optimising Soft Starters
Guide to contents - applicable to
5MC software V67
1 Mechanical Outlines
Referring to the appropriate size of XFE, mount the XFE ensuring that correct clearances are maintained
for adequate ventilation and operation of the XFE.
2 Wiring Diagrams
Referring to the appropriate Wiring Diagram, install the XFE electrical connections ensuring that the correct
control supply voltage is used and is within its specified operating limits as described on the product
specification
ACCESS
Caution:Always replace the cover panelon the unit after gainingaccess
to the electricalconnections.
The unit requires two AC supplies:
A 3 phase balanced Mains Supply to provide the source of power for the controlled motor.
A single phase supply: 115V/230V, 50Hz/60Hz, for the internal control circuitry.
XFE 300 series need a separate 115V or 230V supply to power the fans.
Voltage must be specified prior to supply of the XFE.
IMPORTANT Ensure that the voltage selector switch position corresponds to
the control supply before you apply the control supply voltage.
115
230 select
ISOLATION
Caution: The XFE uses semiconductor devices in the main circuit and is not designed to provide
isolation. For this reason isolation means must be installed in the supply circuit in accordance with
the appropriate wiring and safety regulations.
The Mains Supply and the Control Supply each require protection. Although all units have electronic
overload protection, the installer should always place fuse protection between the unit and the Mains
Supply, not between the unit and the motor. Semiconductor fuses can be supplied for short circuit
protection of the semiconductors.
3 Keypad operation and basic set-up
Refer to this, for familiarisation with the keypad controls of the XFE. Use the illustration of the Basic Menu
structure to find XFE menu items on the display.
4 Set-up examples
Set-up basic XFE operating parameters, if necessary, by following one or all of the examples described
here.
5 Product information
Refer to product information for details of Design Standards and Approvals, operating and storage limits
and other installation instructions.
Further Information
Further information about the XFE soft start motor controller, detailed manuals and application notes are
available on the Fairford website or from Fairford direct (see back page for contact details).

2 M-85E0-F O81121
XFE300 Series IP00
T1,T2,T3 L1,L2,L3
B
AC
Mountings suitable for M10 fixings.
Allow clearance of:-
sides - 25mm
Top & bottom - 200mm
Front - 25mm
Weight
Dimensions (mm) A B C
XFE302 to XFE308 490 648 285 65Kg
XFE310 508 738 282 72Kg
XFE312 to XFE319 635 746 322 72Kg
XFE320 635 782 322 77Kg
XFE322 to XFE328 775 775 475 82Kg
XFE100 Series IP20 XFE200 Series IP20
All dimensions in mm
Mounting Centres 250 x 500
suitable for M6 fixings
2 "keyholes" at top 2 open
slots at the bottom.
unit weights
XFE202 to XFE204 - 16Kg
XFE206 to XFE212 - 22Kg
Allow clearance of:-
15mm each side
75mm top & bottom
25mm front
420
222
195
380
150
125
400
All dimensions in mm
Mounting holes suitable for M6
fixings
Unit weights:-
XFE102 to XFE124 7.3Kg
XFE126 to XFE140 8.3Kg
Allow clearance of:-
15mm each side
75mm top & bottom
25mm front
520
340
265
500
250
1 Mechanical Outlines
Enclosure Ventilation
When fitting the XFE into a cabinet, ventilation must
be provided if the heat output of the unit is greater
than the cabinet will dissipate.Use the following
formula to determine the fan requirement. An
allowance has been incorporated into the formula
so that the figure for “Q” is the air delivery quoted
in the fan suppliers data.
An approximation of the heat produced (Watts) by
the XFE, when in circuit, can be made by multiplying
the line current by three.
When the XFE is bypassed the heat output can be
approximated with the formula:-
Watts (soft starter) = Start current x start time in
seconds x number of starts per Hour / 800
Exact figures for unit full load current are in the XFE
manual.
Q = volume of air (cubic metres per hour - m3/h)
Wt = heat produced by the unit and all other heat
sources within the enclosure (Watts)
tmax = maximum permissible temperature within
the enclosure (40ºC for a fully rated XFE)
tamb = temperature of the air entering the
enclosure (ºC)
If you prefer to work in CFM, substitute ºF for ºC.
Q is now in CFM.
Q =
4 x Wt
( tmax - tamb )

3 M-85E0-F O81121
Note
Contactor K3 is required for the 'Op-
eration in Bypass Power Circuit' and
is controlled by the programmable
relay set as a 'Top of Ramp' relay.
The Electronic control card is located underneath
the cover in the all units.
Connections shown in the control circuit wiring diagram
are made to the electronic control card terminals as
shown in fig.2.2 below.
Programmable output,
Changeover contacts
Default: - Run Relay
Programmable output,
Changeover contacts
Default: Ramp
Complete
Programmable Input,
Control Input 1.
Default: Start/Stop
D5
J8J9J10
Relay
22 24 21 12 14 11 S0 S1
Micro-
controller
Relay
D5 (Green) indicates the presence
of the control supply.
Fig 2.2
Control
Supply
Emergency
Stop
STOP
START
K2.1
K2 K1
K2.2
Electronic
control
card
S0, 00
S1
X2
X1
24
21
14
11
K3
Control
supply
card
Note: Extra X1-X2 on 300 Series for fan supply
For this
configuration,
applying the
equation,
Ie(XFE)
allows lower current
rating XFE than
the motor.
Fig 2.3 Power circuit for
In-Line connection of
motors (see note 3).
Induction
Motor
1
L1
3
L2
5
L3
2
T1
4
T2
6
T3
EARTH
(Electrical
Ground)
Isolation and Protection
Switch-gear
(provided by the customer)
K1
Feeder
cables
Mains
Supply
Busbar
L1
L2
L3
Circuit
Contactor
Fig 2.4 Power circuit for In-Delta
connection of motors (see note 4).
Induction
Motor
U1
V1
V2
W2
W1
U2
In-deltaconnectionsfor
correct rotation of motor
Terml Fwd Rev
T1
T2
T3
L1
L2
L3
W1
V1
U1
V2
U2
W2
V1
W1
U1
W2
U2
V2
EARTH
(Electrical
Ground)
Isolation and Protection
Switch-gear
(provided by the customer)
Feedercables
Mains
Supply
Busbar
L1
L2
L3
Circuit
Contactor
K1
1
L1
3
L2
5
L3
2
T1
4
T2
6
T3
Fig 2.5 Power circuit for bypass
operation (see note 5).
Bypass
Contactor
Induction
Motor
EARTH
(Electrical
Ground)
Isolation and Protection
Switch-gear
(provided by the customer)
Feedercables
Mains
Supply
Busbar
L1
L2
L3
Circuit
Contactor
K1
1
L1
3
L2
5
L3
2
T1
4
T2
6
T3
K3
Fig 2.1 Control circuit wiring
2 Wiring Diagrams
Use the control circuit with one of these power circuits
Note 1: Correction capacitors:
Power factor correction capacitors must NOT be positioned on the output of the power circuit.
Note 2: Fuse Selection:
Where semiconductor type fuses are required, they should be selected from the table in Section 5.
Note 3: The in-line configuration shown in Fig 2.3 requires that the firing mode be set to ‘0’.
Note 4: The In-Delta configuration as in Fig 2.4 requires that the Firing Mode be set to ‘1’.
An in-line contactor controlled by the XFE MUST be used with the In-Delta firing mode.
Note 5: The bypass configuration as in Fig 2.5 is automatically detected as “Auto bypass” is set as default.

4 M-85E0-F O81121
Selects or deselects optimising (providedkeypad control is selected).
Notavailable when“InDelta”or Bypassed
Returnsuserto previousmenu level and
cancels any changes made tosettings.
Allowsuserto moveup a menu group
or incrementasetting value.
Allowsuserto movedown a menu group
or decrementasetting value.
Takes userto next menu level and enters
any changes made tosettings.
Starts or stopsmotor (providedkeypad control is selected).
Keypad controls
Optimise
Start
Stop Enter
3 Keypad operation and basic set-up
ALWAYS ENSURE THAT THE KEYPAD CABLE IS PLUGGED IN BEFORE APPLYING POWER TO THE UNIT
When wired as Fig 2.1,page 3, the XFE
display will indicate start up messages
followed by ‘Stopped and ready’. At this
point:
• the XFE will start the motor when
the keypad ‘START/STOP’ key is
pressed but not when the START
switch as shown in Fig.2.1 is closed.
• the XFE parameters are set to
factory default which may not be
ideal for the required application.
The examples in section 4 show how to
set up some of the essential XFE operating
parameters using the keypad. Once these
are understood, other XFE settings, as
indicated in the programming Menu
Structure, can be set in a similar manner
(The corresponding default settings are
shown in brackets). For the full menu
structure see page 6 .
XFE Soft Starts are either supplied pre-set to a Start Class or ready to set. An appliction selector chart is available
from FE to aid in the selection of the correct XFE. If the unit is supplied ready to set then it will force the selection
of a starting Class when first powered up.
It is always possible to change the starting Class through menu item >Advanced > current > P106 start class
When the motor is running the XFE can display current (default) or Estimated Power. Pressing the # key at the
top of the menu structure allows the user to toggle between these 2 options.
Starter Enable/Disable
An additional safety feature has been added so that following certain actions the XFE will be disabled. It is
strongly recommended that before any changes to parameter values are made, that the XFE is disabled via the
Basic Menu. Once disabled, the XFE remains unable to drive the load, until it has been enabled via the Basic
Menu, or the control supply is removed and reapplied, or the key is pressed when prompted.
Cooling
The XFE is designed so that the rated start current/time is close to the maximum allowed. If the start duty is
exceeded the unit will trip. All XFE Soft Starts have a forced off cooling time between starts.
In line with the stated IEC starting duties, all XFE 100 series have an enforced off period of 2 minutes, likewise all
XFE 200 and XFE 300 series have an enforced off period of 7 minutes set as standard. During this period the
display indicates “Stopped.Cooling” and the XFE will not respond to a start signal.
AC53a ratings are for Optimising or use without a bypass contactor.
AC53b rating is only for use with a bypass contactor and will trip if one is not used
Keypad
start-up
message
FAIRFORDXFE 132
98A AC53a 10
Model
FLC Rating
of unit
IEC
non bypassed
Starting Class

5 M-85E0-F O81121
XFE Soft Starters may be set up to 1 of 8 overload start duty settings. The applicable motor current and duty
ratings for all the range are shown in the table on the back page of the main manual.
The following tables give the full operating data for 2 sample Soft Starts.
Setting the XFE Start Class
With ‘Starter Disabled’ shown on the display,
press ENTER key once.
!With ‘Applications’ shown on the top line of
the display press ""
""
"key three times until
“Advanced” is shown at the top of the display.
#Press ENTER once to show “Current” at the
top of the display.
$Press ENTER once more to show “Rated
current” at the top of the display.
%Press ""
""
"key once to display “P106 Start
Class” on the top line.
&Press ENTER once to show “Set Start Class”
at the top of the display. Press ""
""
"''
''
'keys until
the required class is shown. Press ENTER.
Keypad should display “Loading” then
“Saved”.
(At any of the above stages pressing #will return
the user to the previous menu. The XFE will
not start until the control display indicates
‘Stopped and ready’.
 
Applications
Auto features
Rated current
P106 Start Class
Current
Optimise rate
ENTER
# # #
ENTER ENTER ENTER
Starter Disabled
1:qto Enable
Advanced
Monitoring
P106 Start Class
Lowcurrent



 
Start
Class
Maximum
Motor FLC
IEC
Utilisation
Category
Motor
Overload
Class
Maximum unit
current
xMotor FLC
Start
Time
Starts
perHr
Duty Ratio
(AC53a)
Bypased+Off Time
(AC53b)
1 10B 370A AC53a 10A 3.5 12 3 60%
2 10 350A AC53a 10 3 23 3 60%
3 20 247A AC53a 20 419 3 60%
430 248A AC53a 30 429 3 60%
5 10B 390A AC53b 10A 3.5 12 3 1188S
6 10 364A AC53b 10 3 23 3 1177S
720 288A AC53b 20 419 3 1181S
8 30 256A AC53b 30 429 3 1171S
XFE138
Start
Class
Maximum
Motor FLC
IEC
Utilisation
Category
Motor
Overload
Class
Maximum unit
current
xMotor FLC
Start
Time
Starts
perHr
Duty Ratio
(AC53a)
Bypased+Off Time
(AC53b)
1 10B 154A AC53a 10A 3.5 12 5 75%
2 10 166A AC53a 10 3 23 5 75%
3 20 131A AC53a 20 419 5 75%
430 124A AC53a 30 429 5 75%
5 10B 171A AC53b 10A 3.5 12 5 708S
6 10 186A AC53b 10 3 23 5 697S
720 143A AC53b 20 419 5 701S
8 30 134A AC53b 30 429 5 691S
XFE210

6 M-85E0-F O81121
*1 The “Firing mode” must be set to ‘1’ for the In-Delta configuration.
*2 The “Cooling time” is dependant on the Model range, Duty rating and Heatsink temperature.
*3 The “Rated current” setting is for reference only and is not user adjustable.
*4 “P106 Start Class” is either factory pre-set on set by the user on Initial Start-up.
Stopped and ready
1:
Settings
Default (keypad)
Small Pump
Large Pump
Conveyor
LowInertia Fan
High Inertia Fan
Recip Compressor
ScrewCompressor
Rotary Compressor
Crusher
Grinder
Hi torque start
Motor gen set
Aerator
Flywheel press
Moulder
Default Auto
Current
Optimise rate (5)
Kick start (Off)
Kick pedestal (75%)
Kick time (25cycles)
Dwell time (5s)
Lowvolts stop (Off)
Contactor delay (160ms)
Trip sensitivity (1)
Station number (1)
(0) *1
Stop smoothing (5)
Cooling (On)
Cooling time *2
Line contactor (On)
Thermistor Trip (Off)
P126 Comms Trip (On)
Optimise+ (Off)
Firing mode
Full
Full + optimise (Default)
Start + bypass
Phase loss only
Power
Protection (full + optimise)
Current
P27 Peak Start
P40 supply volts (416)
Real PF
P22 Delay angle
P23 Max angle
P20 Reference PF
P21 Internal PF
Temperature I/P
Enter password
Change password
Save parameters
Power on parameters
Default parameters
Applications
Auto features
Basic
Advanced
Monitoring
Permanent store
Permanent store
Password
Password
Inputs
Outputs
Parameters
Trips
Auto features
Basic
Settings
Auto Jog (Off)
Auto Pedestal (Off)
Auto end start (Off)
Auto stop (Off)
Auto end stop (Off)
Auto bypass (On)
Auto 3MC (On)
Auto Ramp (Off)
Auto All >> Off
Stop smoothing (Off)
ENTER ENTERENTER ENTER
Rated current (Ie) *3
P106 Start Class *4
Lowcurrent (Off)
Lowamps level (0.1xFLC)
Lowamps time (50cycles)
C/L time out (On)
Current limit (3.5xIe)
Limit time out (30s)
Shearpin (On)
Shearpin level (3.125xIe)
Shearpin time (100cycles)
Overload level (1.1xIe)
# #
#
#
Advanced
Monitoring
Disable starter?
Enable starter
Starting (Keypad)
Start pedestal (20%)
Start time (5s)
Stop pedestal (10%)
Stop time (0s)
Current limit (3.5xIe)
Power on Param
Protection (Full +Optimise)
Starter Disabled
1:qto Enable
Menu structure
Typical Keypad menu. Contact Fairford for more details.

7 M-85E0-F O81121
4 Set-up examples
1 Setting the XFE for large pump application
With ‘Starter Disabled’ shown on the display, press
ENTER key once.
!With ‘Applications’ shown on the top line of the
display press ENTER once.
#With ‘Settings’ shown at the top of the display press
""
""
"key three times until ‘Large pump’ is shown at
top of display.
$Press ENTER once to select large pump. The
display will indicate the parameters changing in
short intervals.
%With the display top line indicating ‘Send to store?’,
press ENTER to save the settings for a large pump
to permanent store. Display will flash the message
‘Storing’ twice to indicate this has been done.
&At any of the above stages pressing #will return the user to the previous menu. The XFE will not start until
the control display indicates ‘Stopped and ready’.



Applications
Auto features
Settings
Default (keypad)
Send to store?
#=no Enter=yes
Large Pump
Conveyor
ENTER
# # #
ENTER ENTER ENTER
Starter Disabled
1:qto Enable
2 Setting the XFE for remote starting and stopping.
With ‘Starter Disabled’ shown on the display,
press ENTER key once.
!With ‘Applications’ shown on the top line of
the display press ""
""
"key twice until ‘Basic’ is
shown at the top of the display.
#Press ENTER once to select Basic menu.
$Press ""
""
"key twice until ‘Starting’ is shown at
top of the display then press ENTER once to
select starting option menu.
%With display now indicating ‘Starting’ on top line
press ENTER to toggle from ‘Keypad Starting’
to ‘Remote Starting’ as shown on bottom line
of display.
&At any of the above stages pressing #will return
the user to the previous menu.
The XFE will now start and stop remotely from the START and STOP switches shown in Figure 2.1, but will return to
keypad starting if the control supply on terminals X1 and X2 is removed. Alternatively, to return to keypad starting and
stopping, repeat the above procedure and select ‘Keypad Starting’ at step 5. To keep the remote start/stop setting
after removal of the control supply, the settings must be permanently saved (See 3 below).



Applications
Auto features
ENTER
# # #
ENTER ENTER ENTER

Basic
Advanced
Starting
Keypad starting
Starting
Remote starting
ENTER

Disable starter
Enable starter
Starting
Starter Disabled
1:qto Enable
3 Permanently saving parameters set by user.
With ‘Starter Disabled shown on the display, press
ENTER key once.
!With ‘Applications’ shown on the top line of the
display press ""
""
"))
))
)key four times until ‘Permanent
Store’ is shown at top of display.
#Press ENTER once to select Permanent Store menu.
$With ‘Save Param’ shown at top of display press
ENTER once to permanently save parameters.
Display will flash twice to indicate this has been done.
%At any of the above stages pressing #will return the
user to the previous menu.



Save parameter
Power on param
ENTER

# #
ENTER ENTER
Permanent store
Password

Applications
Auto features
Starter Disabled
1:qto Enable
The XFE should always be disabled before making changes. The Soft Starter then remains unable to drive the
load until it has been enabled via the Basic Menu, or the control supply is removed and reapplied, or the key
is pressed when prompted. If the Remote Start/stop is active the XFE cannot be enabled.

8 M-85E0-F O81121
Overcurrent trip curve
0.1
1
10
100
1000
1.1
1.522.53 3.544.5 5 5.5
6
Class 10B
Class 10
Class 20
Class 30
Trip Level Current x In
Seconds toTrip
'Current limit' and 'Overload level' settings are adjustable. The XFE monitors current in one phase only and this
limits overload currents in accordance with the trip curves shown here (See Menu structure for default settings).
Parameter P106 may be changed to select Class 10B, 10, 20 or 30. This will automatically change the motor
current rating (Trip level) of the unit to maintain over current protection.
Note: The overload monitors one of the phases only and the 'Current Limit' level is only active during motor
starting.
IMPORTANT
It is recommended that the control supply is maintained between starts to ensure the integrity of the overload,
which will reset on it's removal.
5 Product information
Cooling
The XFE is designed so that the rated start current/time is close to the maximum allowed. If the start duty is
exceeded the unit will trip. All XFE Soft Starts have a forced off cooling time between starts.
In line with the stated IEC starting duties, all XFE 100 series have an enforced off period of 2 minutes, likewise all
XFE 200 and XFE 300 series have an enforced off period of 7 minutes set as standard. During this period the
display indicates “Stopped.Cooling”, and the XFE will not respond to a start signal.
AC53a ratings are for Optimising or use without a bypass contactor.
AC53b rating is only for use with a bypass contactor and will trip if one is not used
Trip curves show the nominal times for operation from cold (40°C)

9 M-85E0-F O81121
Fault Code Explanation
1 Phase Loss Input sidephase loss at theramp start, during theramp or during normalrunning.
2 Too HotTheheatsink is above themaximum allowedtemperatureor i/p opencircuit.
3 CommsTherehavebeen a number of serial communication errorsbut communications
are still active.
4SCR Firing Short circuit thyristor during normalrunning.
5 SCR SignalShort circuit thyristor or
Motor sidephase loss during theramp during normalrunning.
6 SCR Signal
Input sidephase loss during normalrunning.
Short circuit thyristor or motor sidephase loss
during theramp or during normalrunning.
7Sensing SignalShort circuit thyristor, externalnoise or motor sidephase loss
during theramp or during normalrunning.
8 Motor, SCR LosShort circuit thyristor or
motor sidephase loss at the startof theramp.
9 Sensing SignalShort circuit thyristor or externalnoise during theramp or during normalrunning.
10 SCR Shorted Short circuit thyristor or motor sidephase loss during theramp.
11 Low CurrentCurrenthasfallen below the
under-current level.
Only activeduring during normalrunning
12 C/L TimeOutCurrent limit during theramp has exceededthe current limit
time-out period.
13 Overload Currenthas exceededthe
overload level .
Activeatall stages of operation.
14ShearpinCurrenthas exceededthe
shearpin current level.
Only activeduring normalrunning
15 Thermistor Thermistor Input is opencircuit or thermistor resistance has exceededit's trip point.
16 UserAtripinputfrom the
user tothe soft starter.
17CommsTimeoutSerial communicationshavebeenlost.
18 Bypass failed Bypass contactor failedtoclose on AC53b unit.
Stopped.Cooling Displayed during theperiod for whichthe soft starter will notrestart to allow
heatsink cooling.
XFE Trip/Fault Codes
Items in bold text are user adjustable

10 M-85E0-F O81121
Short circuit
co-ordination Type 1
Special purpose fuses, for the protection of semi-conductor devices, rated 700 Vac, can be used to obtain the
required short circuit ratings. Suitable for use on a circuit capable of delivering not more than the RMS Symmetrical
Amperes indicated in this table at maximum rated operational voltage, when protected by Semiconductor Fuse
type, Manufactured by Company and Mod. No. indicated.
These fuses are for short circuit protection of the semiconductors and must be mounted externally by the user
between the unit and the mains supply, not between the unit and the motor.
5 63
5 63
5 63
5 63
5 80
5 80
5 80
5 100
5 100
5 100
10 250
10 250
10 250
10 250
10 250
10 400
10 400
10 400
10 450
18 500
SIBA Fuse
Amps
Short
circuit
Amp
RMS
(kA)
2018920.63
2018920.80
2018920.100
2061032.250
2061032.400
2061032.450
2061032.500
2018920.63
2018920.63
2018920.63
2018920.80
2018920.80
2018920.100
2018920.100
2061032.250
2061032.250
2061032.250
2061032.250
2061032.400
2061032.400
18 630
18 630
18 630
18 800
18 800
30 900
30 2068132.800 800
30 2067132.1000 1000
42 2067132.1000 1000
42 2068132.1250 1250
85 2068132.1400 1400
85 2068132.1400 1400
85 2068132.1400 1400
85 2068132.1400 1400
85 2 x 2067132.1000 2000
85 2 x 2067132.1250 2500
100 2 x 2067132.2000 4000
100 2 x 2067132.2000 4000
Short
circuit
Amp
RMS
(kA)
SIBA Fuse
Amps
2068132.1400
85
2068132.1250
42 1250
1400
2061032.630
2063032.630
2063032.800
2063032.900
2061032.630
2063032.800
XFE
No.
XFE
No.
Document No TF0120 ‘Guide to Soft Start Drive Product Information’, describes the rating index and the meaning
of other IEC 60947-4-2 product information in more detail. This is available upon request from Fairford.
Basic standard Level
IMMUNITY IEC 61000-4-2 6kV contact or 8kV air discharge
Severity level 3 IEC 61000-4-6 140dBuV over 0.15-80MHz
IEC 61000-4-3 10V/m over 80 -1000MHz
IEC 61000-4-4 2kV/5kHz
IEC 61000-4-5 2kV line to ground and 1kV line to line
EMISSION EN 55011 Class A
Equipment Class A (Industrial)
EMC Emission and Immunity levels
EMC compliance is in accordance with EN 60947-4-2 which refers to the following basic standards:
Note: EN 60947-4-2 is published as a harmonized standard under European Council Directive No.89/336/EEC
in relation to the electromagnetic compatability.
Semiconductor Fuse types
XFE202
XFE204
XFE206
XFE208
XFE210
XFE212
XFE302
XFE304
XFE306
XFE308
XFE310
XFE312
XFE314
XFE316
XFE318
XFE319
XFE320
XFE322
XFE324
XFE326
XFE102
XFE104
XFE106
XFE108
XFE110
XFE112
XFE114
XFE116
XFE118
XFE120
XFE122
XFE124
XFE126
XFE128
XFE130
XFE132
XFE134
XFE136
XFE138
XFE140

11 M-85E0-F O81121
Cable cross section
AWG mm2
All models -
Terminals
Terminal type Wire type
Min. Max. Min. Max.
Terminal tightening
torque
X1,X2,
S0,S1
11,12,14
21,22,24
Screw clamp
terminals
Solid or stranded. 22 14 0.3 2.5 4.4 Ib.in. (0.5 Nm.)
Cable cross section*Terminal type Conductor type
AWG mm2
Terminal tightening
torque
Power L1, L2, L3,
T1, T2, T3.
M8 metric
threaded studs
Ground PE M8 metric
threaded stud
Use 75°C copper
(CU) conductor only
and the wire shall be
fitted with close
eyelet lug.
1/0 50 106 Ib.in. (12 Nm.)
Cable cross section*Terminal type Conductor type
AWG mm2
Busbar
size (mm)*
Terminal tightening
torque
Power L1, L2, L3,
T1, T2, T3.
M8 metric
threaded studs
Ground PE M8 metric
threaded stud
Use 75°C copper
(CU) conductor only
and the wire shall be
fitted with close
eyelet lug or use
busbar.
2 x
250MCM
2 x 120 20 x 6 106 Ib.in. (12 Nm.)
Terminal type Conductor type Busbar size (mm)* Terminal tightening
torque
Power L1, L2, L3,
T1, T2, T3.
Two off M10
nuts and bolts
Ground PE M10 metric
threaded stud
Use Busbar 45 x 20
60 x 10
80 x 10
212 Ib.in. (24 Nm.)
XFE 100 Series
terminals
XFE 200 Series
terminals
XFE 300 Series
terminals
Normal service conditions.
Design standards and Approvals
IEC 60947-4-2; EN 60947-4-2 ‘AC Semiconductor Motor Controllers and Starters’.
Ambient temperature
0°C to 40°C. Above 40°C de-rate linearly by 2% of unit FLC per °C to a maximum of 40% at 60°C.
Transport and Storage
-25°C to +60°C (continuous), -25°C to +75°C (not exceeding 24 hours).
Altitude
Above 1000m de-rate linearly by 1% of unit FLC per 100m to a maximum altitude of 2000m.
Humidity
max. 85% non-condensing, not exceeding 50% at 40°C.
Rated insulation voltage (Ui) 690V
Ingress Protection IP20 or IP00 Pollution degree 2
Operational Voltage (Ue) 230-460VAC rms, 400-575VAC rms or 500-690VAC rms 3-Phase (-15% +10%)
Rated Frequency 50 - 60Hz +/- 2Hz Form Designation Form 1
Control Supply Us X1, X2 115V or 230V AC rms (-15% +10%)
Control Supply Uc S0, S1 12V/24V DC or 115/230VAC.
Auxiliary Circuits (programmable relays) Run - 11,12,14, Top of Ramp - 21,22,24. AC1 230VAC 3A
To maintain approvals for cable connections, the Wire Terminals should conform to local regulations and be
fitted using specified Crimping Tools as indicated by the manufacturer.
* The conductor sizes indicated in the above table are the maximum allowed for each chassis size. The actual
conductor used must comply with local wiring regulations.

Class10B
AC53a 3.5-12:75-5
Class10
AC53a 3-23:75-5
Class20
AC53a 4-19:75-5
Class30
AC53a 4-29:75-5
Class10B
AC53b 3.5-12:708
Class10
AC53b 3-23:697
Class20
AC53b 4-19:701
Class30
AC53b 4-29:691
3A 3A 3A 3A 5A 4A 3A 3A
6A 6A 6A 6A 9A 9A 7A 6A
8A 8A 8A 7A 12A 12A 9A 8A
13A 13A 10A 9A 18A 19A 12A 11A
19A 19A 18A 17A 23A 28A 21A 20A
23A 23A 22A 21A 31A 34A 26A 24A
27A 27A 25A 24A 35A 40A 30A 29A
33A 33A 31A 30A 45A 49A 37A 35A
35A 35A 30A 28A 46A 43A 33A 31A
41A 44A 35A 33A 47A 51A 39A 37A
44A 46A 44A 43A 56A 72A 55A 51A
55A 55A 55A 54A 85A 89A 69A 64A
70A 70A 59A 58A 85A 84A 63A 61A
77A 85A 66A 64A 86A 92A 70A 67A
88A 98A 75A 73A 94A 105A 80A 77A
98A 108A 83A 81A 107A 117A 89A 85A
116A 128A 99A 96A 126A 139A 106A 101A
132A 135A 112A 106A 146A 159A 122A 115A
154A 166A 131A 124A 171A 186A 143A 134A
179A 190A 151A 142A 203A 215A 167A 156A
Continuous/Optimising Externally Bypassed
-1-2-3-4 -5-6-7 -8
Class10B
AC53a 3.5-12:60-3
Class10
AC53a 3-23:60-3
Class20
AC53a 4-19:60-3
Class30
AC53a 4-29:60-3
Class10B
AC53b 3.5-12:1188
Class10
AC53b 3-23:1177
Class20
AC53b 4-19:1181
Class30
AC53b 4-29:1171
209A 225A 174A 164A 218A 232A 178A 167A
243A 261A 202A 190A 253A 270A 208A 195A
314A 314A 242A 222A 330A 322A 250A 230A
350A 320A 258A 235A 360A 344A 272A 242A
370A 350A 274A 248A 390A 364A 288A 256A
440A 412A 325A 295A 460A 433A 342A 305A
500A 500A 445A 420A 520A 515A 460A 430A
540A 540A 460A 425A 560A 562A 480A 435A
630A 630A 480A 430A 662A 655A 500A 442A
780A 750A 600A 530A 817A 780A 628A 543A
795A 780A 615A 545A 825A 800A 640A 560A
850A 850A 724A 650A 875A 895A 754A 665A
950A 950A 810A 727A 1000A 1000A 842A 744A
1060A 1060A 904A 812A 1100A 1115A 940A 830A
1150A 1150A 980A 880A 1209A 1210A 1020A 900A
1150A 1150A 980A 880A 1209A 1210A 1020A 900A
1320A 1320A 1050A 930A 1360A 1360A 1080A 950A
1400A 1400A 1110A 950A 1400A 1430A 1160A 970A
1550A 1520A 1230A 1050A 1560A 1580A 1280A 1075A
1850A 1750A 1460A 1190A 1998A 1810A 1520A 1225A
Continuous/Optimising Externally Bypassed
-1-2-3-4 -5-6-7 -8
XFE No. XFE No.
The owner, installer and user is responsible for the correct installation and use of the XFE and must ensure that
only qualified personnel install the XFE and that the installation, operation and maintenance of the unit complies
with the relevant Codes of Practice, Regulations and Statutory Requirements. The Manufacturer or his agent do
not assume any liability, expressed or implied, for any consequence resulting from inappropriate, negligent or
incorrect installation, application, use or adjustment of the product or circuit design, or from the mismatch of the
unit to a motor. To prevent an electrical shock hazard the XFE must be connected to a safety earth. The unit is not
designed for use in hazardous areas. Use in such an area may invalidate the hazardous area certification.
XFE Current Ratings
Index Ratings
In line with the stated IEC starting duties, all XFE 100 series have an enforced off period of 2 minutes, likewise all
XFE 200 and XFE 300 series have an enforced off period of 7 minutes set as standard. During this period the
display indicates “Stopped.Cooling”, and the XFE will not respond to a start signal.
XFE202
XFE204
XFE206
XFE208
XFE210
XFE212
XFE302
XFE304
XFE306
XFE308
XFE310
XFE312
XFE314
XFE316
XFE318
XFE319
XFE320
XFE322
XFE324
XFE326
XFE102
XFE104
XFE106
XFE108
XFE110
XFE112
XFE114
XFE116
XFE118
XFE120
XFE122
XFE124
XFE126
XFE128
XFE130
XFE132
XFE134
XFE136
XFE138
XFE140
