Falcon PHASER2 User manual

FALCON
WORL D CLASS SE CUR IT Y
FALCON PHASER2
Advanced Keyless Entry System
NATIONWIDE INSTALLATION SERVICE
0800 622 474
HELPLINE: 0906 700 10 20
(All calls charged at 50p/min)
Internet: http://www.falcon-security.com
Email: [email protected]

1. Features
Remote lock and unlock
Car finder
Total closure
Remote boot release
Code learning (up to 4 remotes)
Flashes hazard lights
Universal Central Locking
Siren/horn output
2. Button Function Table
button door lock door unlock
ignition on
button #1 once lock lock lock
button #1 2 sec. car finder car finder
button #2 once unlock unlock unlock
button #3 2 sec. boot release
boot release
2.04 Button definition
3. Code Learning
The remotes have programmed to the system when leaving the
factory. If necessary there are 2 methods to program a new
remote to the system as follows:
- Power on the system
- Lights flash twice
- Within 10 sec., press the onboard switch 6 times
- The system enters into the code learning mode and the indicator
lights turn on to confirm
- Within 10 sec., press any button of 1st remote

- Lights flash once then stay on again to confirm the 1st remote is
programmed to the system
- Follow the same procedure as above to program the 2nd, 3rd and
4th remote. You have up to 10 sec. for the learning of each
remote
The system will quit the learning mode as follows and the
indicator lights will turn off to confirm:
*Upon programming 4 remotes to the system
*If doing nothing for 10 sec.
The 2nd method of programming the new remote to the system:
- Unlock the door by remote control
- Within 20 sec. turn the ignition on-off 5 times then back to on
- The system enters into code learning mode and the indicator
lights will turn on to confirm
- Within 10 sec. press any button of 1st remote
- Lights will flash once and then stay on again to confirm the 1st
remote is programmed to the system
- Follow the same procedure as above to program 2nd, 3rd and 4th
remote. You have up to 10 sec. for the learning of each remote.
- The system will quit the learning mode as follows and the
indicator lights will be off to confirm:
*
Turn the ignition off during the code learning
*
Upon programming 4 remotes to the system
*
If doing nothing for 10 sec.
4. System Operation & Installation
4.01 Door lock
- Press the lock button once with the ignition off
- Doors lock
- Lights flash once
- The siren/horn chirps once (if connected)
- Then window closure output will be on for 40 sec.
*
If pressing the lock button with ignition on then the window
closure output won’t be activated

4.02 Door unlock
- Press the unlock button once
- Doors unlock
- Lights flash twice
- The siren/horn chirps twice (if connected)
4.03 Boot release
- Press the boot release button (#) for 2 sec. will operate the boot
release output.
4.04 Car finder
- Press the lock button for 2 sec. the horn/siren will chirp once (if
fitted) and the lights will flash 12 times to help you locate the car.
4.05 Programming lock and unlock time
- 1 sec. pulse -> put the onboard jumper on
- 4 sec. pulse -> remove the onboard jumper

4.06 Wiring diagram
- C1-1 and C1-3 White -> Lights flash outputs[+]
Connect C1-1 and C1-3 to indicator lights.
- C1-2 White/Red -> Polarity input for C1-1 & C1-3[+ or -]
Connect C1-2 to positive or negative depending on the polarity of
the cars indicator wires.

- C1-6 Brown -> Siren/Horn output [1A]
Connect the red (+) wire of an optional siren for confirmation
chirps. An additional relay will be required when connecting this
output to the car horn instead of a siren; see the wiring below:
- C1-7 Yellow <- Ignition input [+]
Connect to an ignition wire that shows +12V when the key is in
both [on] and [start] positions
- C1-8 Gray/Black -> Window closure output [-500mA]
Can be connected to a window closure module or for cars with
total closure/comfort closure to the cars total closure wire where
applicable (max 500mA). If the car does not have a separate total
closure wire a relay will be required.
- C1-9 Gray -> Boot release output[-500mA]
An additional relay will be required when wiring, see the wiring
below:

4.07 Lock & unlock wiring
