Fbt HiMaxx40A User manual

FBT H i M axx TM
Speaker Systems
Hi MaxX 40a
2 WayBi-AmpedProcessed ActiveMonitor System
The Hi Maxx 40a weighs only 39.5 lbs
and delivers 127dB SPL !
>500w RMS Class D (LF) Power Amplifier
>150w RMS Class G (HF) Power Amplifier
Comparing to the FBT Maxx 4a, these
New Class D & G amplifiers offer an
Increased power capacity of +200w for
the LF woofer and +50w for the HF
driver. Peak power has almost
DOUBLED with up to 1000 watts to the
12” B&C LF woofer.
>+4dB more SPL than the Maxx 4a,
thanks to the higher power handling and
a woofer offering lower power
compression and FBT’s Exclusive New
ADAP® 2 -
(Advanced Dynamic Active Protection)
Limiter/Protection Circuitry.
>90% amplifier efficiency with FBT’s new
switch mode power supply
and Class G amplifierfortheB&C®HF
customcompressiondriver.
>1%-5%Militaryspecelectronic
componentsusedinallelectroniccircuitry
forsuperior soundandreliability.
> Excellent WEIGHT to POWER Ratio.
The Hi Maxx 40a weighs just about 4 lbs. more
than the FBT MaxX 4a while the total power
capacity has almost doubled.
>New FBT proprietary designed 12” (3' VC)
B&C®custom neodymium magnet woofer,
with a more efficient ventilation system
results in
a 1.5dB reduction of power compressionand
featuresanew rigid coneforincreasedreliability.
>New B&C 1.7”HF Neodymium Magnet
Compression Driver coupled to a 90°H x 60°V
CD horn.
>The New FBT proprietary gas-injection
polypropylene molded asymmetrical
trapezoidal design enclosure offers: a
lightweight, yet extremely sturdy cabinet with the
flexibility for many sound system applications.
Hi Maxx 40a Vs Maxx 4a
:The total cabinet
volume has increased by +5Lt of load to
the woofer, while maintaining the same
width and height of theFBTMaxX 4awhile
producing a more powerful (+4 dB) bass
response.
Thereflextuningportsareanewdesign
andareoptimized to reduce turbulence
and compression.
>New Combined Gain and Volume
Functions in the same rotary
potentiometer offer easier and quicker
volume settings and provide an improved
dynamic range and S/N ratio at the input
stage.
*2 independent input channels
1 x XLR/ combo Jack, 1 x AUXL/R RCA
jacks and volume control to connect to
external devices such as MP3, PC and
CD players.
*This feature may replace the use of an
external mixer for a simple application
such as using 1 microphone and a music
player source.
>Control Panel also features:
3-band Equalization (High/Mid/Low)
Ground Lift Switch,
3 Status LED’s: Power, Limiter,
Protection
>3 yr. Parts & Labor Warranty
>COMPLETELY MADE IN ITALY
Hi Max
x
40a
NEW - NOT JUST ANOTHER ORDINARY 2 way Powered Plastic Speaker Cab!
The New FBT Hi Maxx 40a.easily Crushes all other Competitors similar 2 way models in
sound quality, SPL and weight to power ratio.

FBT H i M axx
Speaker Systems
Specifications: FBT Hi MaxX 40a
Configuration
2 way
Built-in amplifiers 500 LF/150 HF watts RMS
Frequency response
@
-
6dB 45Hz
-
20KHz
Low frequency woofer 12” with 3” voice coil
High frequency driver
1.7” voice coil
Sensitivity (@1W/1m) 99 dB
Maximum SPL
127 dB
Dispersion 90°H x 60°V
Input impedance
22 k ohms
kOhm
Crossover frequency 1.6k
Input connectors:
XLR & Ste
reo RCA aux jacks
Power cord 16 ft.
Net Dimensions 16.02”w x24.96” h x14.56” d
Net Weight 39.46 Lbs.
ShippingDimensions 19.48”w x28.34”hx18.50”d
Shipping Weight 45.19 Lbs.
Hi MaxX Speakers have 4 M
-
10 Fly points for wall or ceiling
installation, horizontally or vertically by using optional FBT
mounting brackets.
H
i
M
axx
40
a
H
i
M
axx
40
a
a s a f l o o r m o n i t o r
The two ergonomic positioned carrying handles
provide easy handling and the Hi Maxx 40a ‘s
39.5 lb. weight allows easy placement on a
Speaker Stand.
The FBT Hi Maxx 40a is Completely
Manufactured in Italy utilizing the best
1% - 5% Military Spec electronic components
available in the amplifier circuitry, a New FBT
propr
ietary designed custom made B&C® 12”
neodymium magnet woofer with an aluminum die
cast frame and a New B&C® 1.7” neodymium
magnet high frequency driver coupled to a 90°H x
60°V CD horn.
Along with FBT’s NEW Class D & G amplifiers
with switch mode power supplies which are light
in weight, but hefty in power deliver 90% amplifier
efficiency and FBT’s Exclusive ADAP® 2
(Advanced Dynamic Active Protection) circuitry
prevents component failures, without thermal
shutdowns that plague many other powered
speakers. Simply put, the New FBT Hi Maxx
40a outperforms any other 2 way powered
speaker in its category, including our own
World Renowned FBT Maxx 4a.
The FBT Hi Maxx 40a Control Panel features the
same 3 band EQ, Mic/Line switching, and ground
lift switch as the Maxx 4a and Maxx 2a.
The New control panel features are a Combined
Preamp Gain and Master Volume Control to
precisely regulate the proper preamp gain
structure in accordance with the volume out,
which results in easier and quicker volume
settings, superb dynamic range and signal to
noise ratio. A RCA Stereo Input channel with
individual volume control offers additional mixing
capabilities. All in all, the FBT Hi Maxx 40a
“Raises the Bar” in polypropylene cabinet
powered speakers.
FBT USA, Inc.
P.O. Box 8144
Berlin, Ct. 06037
800 333 9383
Email: [email protected]
U.S. Website: www.fbtusa.net
