Fein ASW14-6 Setup guide

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 1/42
Repair instructions

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 2/42
1. Models described
2. Technical data
3. Notes / requirements
4. Tools required
5. Lubricants and auxiliary substances required
6. Disassembly
7. Assembly
8. Troubleshooting
9. Connection diagram
Contents

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 3/42
These instructions describe how to repair the following models:
Model Order no.
ASW 14-6 7 112 40 00 95 0
ASW 14-10 7 112 42 00 95 0
ASW 14-14 7 112 58 00 95 0
ASW 14-6-PC 7 112 50 00 95 0
ASW 14-10-PC 7 112 51 00 95 0
ASW 14-14-PC 7 112 52 00 95 0
1. Models described

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 4/42
2. Technical data
Technical data
The complete technical data can be found in the operating instructions for the model.
Test data
Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service → Repair Guides).
Lubricants
The lubricants and container sizes available from FEIN can be found on the FEIN Extranet
(Customer Service → Repair Guides).
Lists of spare parts
Lists of spare parts and exploded views are available online at www.fein.com

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 5/42
3. Notes / requirements
Note
These instructions are only intended for persons with suitable technical training. It is assumed
that the reader has mechanical and electrical training.
Only use original FEIN spare parts!
Requirements
Please note that power tools may only be repaired, maintained and checked by a trained
electrician, as improper repair can result in serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations of the employers’ liability insurance associations are
to be observed when commissioning.
The German Equipment and Product SafetyAct applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 6/42
Standard tools Special tools
- Torx 10 screwdriver
- Small slotted screwdriver
- Circlip pliers
- Circlip pliers (ground)
- Open-ended spanner 26 mm
- Flat-nose pliers
- Feeler gauge
- Torque wrench 3 21 23 002 00 6
- Drawing-off socket cap 6 41 04 150 00 8
- Puller 6 41 07 019 00 7
NOTE
You can only order special tools with an order number from FEIN.
4. Tools required

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 7/42
Lubricants
Grease 3 21 600 14 23 0 0.6 g Tool holder; switch ring; cam ring
5. Lubricants and auxiliary substances required

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 8/42
6. Disassembly
Removing the angled head
1. Loosen the thread ring (1).
2. Remove the angled head (2) and the clutch part (3).
3. Lever the coded sleeve (4) down.
Tools:
- Open-ended spanner 26 mm
- Slotted screwdriver
2
4
3
1

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 9/42
6. Disassembly
Removing the housing
1. Loosen the eight screws (1).
2. Remove the upper section of the housing (2). Tools:
-Torx T10 screwdriver
1
2

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 10/42
6. Disassembly
Removing the clutch
1. Carefully remove the electronic strip (1).
2. Lift the clutch (2) slightly with a screwdriver.
NOTE
When the slide switch is removed, the spring (4) may jump out slightly.
3. Remove the slide switch (3).
4. Remove the spring (4).
Tools:
- Slotted screwdriver
- Flat-nose pliers
2
1
3
4

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 11/42
6. Disassembly
Removing the clutch
1. Remove the clutch (1).
2. Remove the straight pins (2) from the flange.
2
1

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 12/42
6. Disassembly
Removing the clutch
1. Tension the spring (1) fully to allow better access to the circlip.
The adjusting ring has a left-handed thread.
2. Remove the circlip (2).
NOTE
You need modified circlip pliers to dismantle the circlip. The upper side of the pliers must be ground
flat.
Tools:
- Torque wrench (supplied)
- Circlip pliers (ground)
1
2

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 13/42
6. Disassembly
Removing the clutch
NOTE
The compensating discs in front of and behind the ball bearing must be replaced in the same position on
assembly. The discs are used to adjust the play between the slide switch and the switch ring on the
clutch.
1. Remove the flange (1) and take the disc(s) (2) out of the flange.
2. Remove the circlip (3).
Use a new circlip for assembly each time.
3. Pull off the ball bearing (4).
Tools:
-Circlip pliers
- Drawing-off socket cap
(6 41 04 150 00 8)
- Ball bearing puller 19 mm
(6 41 07 019 00 7)
3
1 4
2

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 14/42
6. Disassembly
Removing the clutch
1. Remove the discs (1).
2. Remove the circlip (2).
2
1

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 15/42
6. Disassembly
Removing the clutch
1. Release all the tension on the spring (1).
2. Unscrew the adjusting ring (2) (left-handed thread).
3. Remove the ring (3) and the spring (4).
Tools:
-Torque wrench
1 2
3
4

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 16/42
6. Disassembly
Removing the clutch
1. Remove the nine balls (1) from the inner clutch ring (2).
2. Shake the nine balls (3) out of the hole in the outer clutch ring (4).
3. Remove the two clutch rings (5 and 6).
NOTE
Degreasing the clutch ring before disassembly makes it easier to remove the balls.
3 4
1
3
2 4
5
6

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 17/42
6. Disassembly
Removing the switch pushbuttons
1. Remove the two switch pushbuttons (1).
2. Remove the leaf spring (2).
3. Remove the pressure piece (3).
Tools:
- Flat-nose pliers
21
3

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 18/42
6. Disassembly
Removing the electronics
1. Carefully remove the ribbon cable (1) from the plug on the motor circuit board.
2. Take out the electronics circuit board (2).
3. Carefully pull the ribbon cable (3) from the electronics circuit board.
4. Remove the pressure piece (4) from the ribbon cable.
4
3
2
1

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 19/42
6. Disassembly
Removing the electronics
1. Holding the electronic strip by the reinforcement, carefully pull it out of the plug.
2. Unclip the LED with the electronic strip from the holder.
NOTE
If the electronic strip is defective, the replacement strip must be kinked slightly at the same place.
The kink (3) is located between the two notches on the electronic strip.
Tools:
- Flat-nose pliers
(withoutridges)
2
3
1

ASW 14-6, 14-6-PC, 14-10, 14-10-PC, 14-14, 14-14-PC
C-SC_CSSM VERSION 1.0 13-07-18 All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation. 20/42
6. Disassembly
Removing the motor/gearbox unit
1. Remove the motor/gearbox unit (1) from the lower section of housing.
2. Remove the bush (2) from the gearbox.
3. Pull the gearbox (3) from the flange.
NOTE
Do not pull the gearbox jerkily as otherwise the gear-wheels may fall out of the gearbox housing.
2 3
1
