Ferm FTB-13 User manual

Ferm B.V. • P.O. Box 134 • 8280 AC Genemuiden • NL • www.ferm.com 0209/25
Ferm Table drilling machine
FTB-13
USER’S MANUAL
Art.nr. 733500
Screwfix nr. 9847
UK Subject to change

Ferm 11
EXPLODED VIEW
Fig.A
Fig.B
Fig.C
Fig.D
Fig.E
Fig.F Fig.G
Fig.H Fig.I
Fig.J
19
20
21
5
4
3
2
1
1 cm
14
15
17
18
7
8
9
10
6
11
12
13
4
1
2
35
6
2Ferm

10 Ferm
SPARE PARTS LIST
REF NR DESCRIPTION FERM NR
27 MOTOR 311053
37 MAGNETIC SWITCH 311051
50 COVER FOR SPRING 311059
51 SPRING 311058
56 CHUCK GUARD 311055
58 V-BELT 800157
10 CHUCK 311054
-CHUCK KEY 311057
- CONDENSER 311056
TABLE DRILLING MACHINE
TECHNICAL SPECIFICATIONS
PRODUCT INFORMATION
Fig.A
1. On/off switch
2. Drill dept gauge
3. Protection guard
4. Motor
5. Drill dept lever
6. Table adjustment
Check first whether or not the delivery has been dama-
ged by transport and/or whether all the parts are pre-
sent.
SAFETY INSTRUCTIONS
The following pictograms are used in these instructions
for use:
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
instructions in this manual.
Denotes risk of electric shock.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual with the machine.
Warning! When using electric tools, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and personal injury. Read all
these instructions before attempting to operate this product
and save these instructions.
1. Keep work area clean
Cluttered areas and benches invite injuries.
2. Consider work environment
Do not expose power tools to rain. Do not use
power tools in wet or damp locations. Keep work
area well lit. Do not use power tools in the presence
of flammable liquids or gases.
3. Guard against electric shock
Prevent body contact with grounded surfaces (e.g.
pipes, radiators, ranges, refrigerators).
4. Keep children and pets away
Do not let children or pets come in contact with the
tool or the extension cable. All children and pets
should be kept away from work area.
5. Storing tools
When not is use, tools should be stored in dry, high,
or locked location out of reach of children.
6. Do not force the tool
It will work better and safer at the rate for which it
was intended.
7. Use right tool
Do not force small tools or attachment to do the job
of a heavy duty tool. Do not use tools for purposes
for which they are not intended: for example, do not
use a circular saw for cutting trees or logs.
8. Dress properly
Do not wear loose clothing or jewellery. It can get
caught in moving parts. Rubber gloves and non-skid
footwear are recommended when working out-
doors. Wear protective hair covering to contain long
hair.
9. Use safety glasses
Also use safety goggles. A dust mask should be worn if
cutting or drilling operation is dusty, in particular
chipboard and MDF.
10.Do not abuse cable
Never carry tool by the cable or pull it to disconnect
it from the power socket. Keep cable away from
heat, oil and sharp edges.
11.Secure work
Use clamps or a vice to hold work. It is safer than
using your hand and it frees both hands to operate
tool.
12.Do not over-reach
Keep a proper footing and balance at all times.
13.Maintain tools with care
Keep tools sharp and clean for better and safer per-
formance. Follow instructions for lubricating and
changing accessories. Inspect tool cable periodically
and, if damaged, have repaired by an authorised ser-
vice facility or electrician. Inspect extension cable
periodically and replace if damaged. Keep handles
dry, clean and free from oil and grease.
14.Disconnect tools from the power supply
When not in use, before servicing and when changing
accessories such as blades, bits and cutters. Always
disconnect the appliance from the power supply.
15.Remove adjusting keys and wrenches
Ensure that keys and adjusting wrenches are remo-
ved from the tool before switching on.
16.Avoid unintentional starting
Do not carry plugged-in tools with finger on the
switch. Ensure that switch is off before being plugged
in.
17.Outdoor use extension cables
When tool is used outdoors, use only extension
cable intended for use outdoors and marked accor-
dingly. Do not use in the rain.
18.Stay Alert
Watch what you are doing. Use common sense. Do
not operate tools when you are tired.
Voltage | 230V
Frequency | 50Hz
Powerinput | 350W
Noloadspeed | 580-2650/min
Numberofspeeds | 5
Chuckcapacity/MorseConical | 13mm/B-16
Weight | 20 kg
Lpa(soundpressurelevel) | 62.1dB(A)
Lwa(soundpowerlevel) | 75.1dB(A)
Vibrationvalue | <2,5m/s2
Ferm 3

Ferm 9
19.Check damaged parts
Before further use of the tool, a guard or other part
that is damaged should be carefully checked to deter-
mine that it will operate properly and perform its
intended function. Check for alignment of moving
parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its
operation. A guard or other part that is damaged
should be properly repaired or replaced by an autho-
rised service centre unless otherwise indicated
elsewhere in the instruction manual. Have defective
switches replaced by an authorised service centre.
Do not use tool if the switch does not turn it on and
off.
20.Warning!
The use of any other accessory or attachment other
than recommended in the operation instructions or
the catalogue may present a risk of personal injury.
21.Have your tool repaired by an expert
This electric appliance is manufactured in accordance
with the relevant safety standards. Repairing of elec-
trical appliances must be carried out only by experts
otherwise considerable danger for the user may
result.
22.Connect the dust extraction device
Whenever there are facilities for fitting a dust extrac-
tion system, make sure it is connected and used.
23.Keep batteries and chargers safe
When using and storing battery chargers for cordless
tools, ensure that they are always kept dry and away
from dampness otherwise a fire and/or explosion
may result.
24.For any queries relating to:
Safety matters concerning this tool, please refer to
Omega on Telephone [phone] (Monday-Fri-
day 8 a.m - 6 p.m Saturday 9 a.m - 1p.m)
SPECIAL SAFETY INSTRUCTIONS
Before using the machine the guidelines must be taken
into consideration. Every mechanical or electrical altera-
tion to the machine which does not meet the applicable
guidelines carries a considerable accident risk.
During use the following points must be taken
into consideration:
•Do not remove any mechanical or electrical protective
provisions.
•Check whether all the protective provisions are in place
andhavebeenattachedcorrectly.
•Wearsafetygogglesduringdrilling.
•Ifyouhavelonghair,besureto wear hair protection (hair
netor cap). Longhair can easilybe caught inmoving parts.
•Wearfittedclothing;tiebuttonsonsleeves.
•Do not hold any workpieces in your hands when drilling.
Alwaysuseamachineclamporanotherclampingtool.
•Protect workpieces and clamping tools on the bench to
prevent them from getting caught. Fasten them yourself
with screws or clamp them to a machine clamp fastened
tothetable.
•Checkwhetherthedrillholderistightenedproperly.
•Checkwhethercablelead-throughsareokay.
•To remove drill chips only use hand brushes, brushes,
rubberwipers,chiphooksorsimilaraids.
•Do not carry out any cleaning or greasing work while the
machineisinoperation.
•Always keep V-belts covered (so that your hands cannot
becomecaught).
•Onlytighten the toothed ring drill holder bymeansof the
wrench.
•Never leave the wrench of the drill holder in the drill hol-
der! Before switching on the machine, check whether
thewrenchreallyhasbeenremoved!
•Donotuseanydrillswhicharedamagedontheshank.
•Drillisnotsuitabletouseaspress!
•If the mains cable is damaged, it may only be replaced by a
mainscableofthesametype.
Immediately switch off the machine when:
•Interruption in the mains plug, mains lead or mains
lead damage.
•Defect switch.
•Smoke or stench of scorched isolation.
ELECTRICAL INSTALLATION
The machine is provided with an electrical installation,
which meets the standards. Repairs may only be carried
out by a recognised professional.
The machine is provided with a zero voltage switch.
After the tension drops the machine will not start to
run automatically for safety reasons. The machine must be
switched on again.
Electrical safety
Always check that the power supply corresponds to the
voltage on the rating plate.
Replacing cables or plugs
Immediately throw away old cables or plugs when they
have been replaced by new ones. It is dangerous to insert
the plug of a loose cable in the wall outlet.
Using extension cables
Only use an approved extension cable suitable for the
power input of the machine. The minimum conductor
size is 1.5 mm2. When using a cable reel always unwind
the reel completely.
4Ferm

8Ferm
ASSEMBLY
Fig.B
•Place the footplate (13) in the correct position.
•Fasten the column (11) with the bolts supplied (12) to
the footplate.
•Now slide the table holder (10) with the table over
the column (11). With the fastening handle (6) the
table is fastened into the desired position.
•Now you can assemble the machine casing (7) and
lock with the locking pins (8).
•Since the drill spindle is greased in the factory, it is
advisable to run in the machine for approximately 15
minutes at the lowest speed.
Before you push the chuck with pin into the drill
spindle, the inside of the chuck must be completely
grease-free!
SETTING UP THE BENCH DRILL
Before use the drill must be mounted on a fixed base. The
footplate (13) has therefore been provided with drilling
holes. By means of screws the footplate can be fixed to
the base in this place. If it is mounted on a wooden board,
sufficiently large washers must be used on the opposite
side, so that the bolts are not pushed into the wood and
the machine cannot become loose.
The fastening screws may be fastened so far that
the footplate is not under tension or deformed.
When the tension is too high there is a risk of breakage.
ADJUSTING THE NUMBER OF REVOLU-
TIONS OF THE DRILL SPINDLE
Fig.C
The different revolutions of the drill spindle can be adjus-
ted by shifting the V-belt into the belt drive. The machine
is protected by a safety switch so that the machine is
automaticly switched off when opening the casing.
The V-belt is shifted as follows:
•Open the V-belt cover (14) by loosen the screw on
the right side of the cover.
•Loosen the fastening button (18) and slide the engine
in the direction of the machine head, upon which the
V-belt is released.
•Shift the V-belt according to the table on the inside of
the V-belt cover.
•Tension the V-belt again by pushing the engine plate
(17) to the back. Then the tensioning device is faste-
ned with the fastening button (18).
•Close the V-belt cover and the machine is ready again
for use.
Keep the V-belt cover closed during use.
V-BELT TENSION
Fig.D
If you have shifted the V-belt, you must tighten it again by
means of the engine plate (17) with the fastening button
(18). The tension is correct when the V-belt can be pres-
sed in by approximately 1 cm.
The engine pulley must be aligned horizontally, so that
early wear and loosening of the V-belt can be prevented.
For this purpose the engine pulley on the engine can be
slid along the engine axle, after loosening the socket head
screw.
SPINDEL SPEEDS
Fig.E
Position V-belt Revolutions/min
A 2650
B 1650
C 1220
D 850
E 580
The number of revolutions of the drill spindle of the V-
belt combinations can be read from the illustration and
the table.
DRILL SPINDLE AND DRILL HEAD PIN
All the blank parts of the machine are provided with a
protective lacquer layer, which prevents rust formation.
This protective lacquer layer is easy to remove by means
of environmentally friendly solvents. Test the V-belt ten-
sion before you connect the machine to the electricity
mains.
The inside of the drill spindle must be degreased comple-
tely. For this purpose use environmentally friendly sol-
vents. Proceed in the same way with the drill head pin. A
correct transmission can only be achieved in this way.
Ferm 5

MAINTENANCE
Make sure that the machine is not live when car-
rying out maintenance work on the motor.
The Ferm machines have been designed to operate over
a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon pro-
per machine care and regular cleaning.
Cleaning
Keep the ventilation slots of the machine clean to pre-
vent overheating of the engine.
Regularly clean the machine housing with a soft cloth,
preferably after each use. Keep the ventilation slots free
from dust and dirt.
If the dirt does not come off use a soft cloth moistened
with soapy water. Never use solvents such as petrol,
alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Lubrication
The machine do not need to be greased. All bearings and
driving gears are maintenance-free and greased for life.
The drill must be cleaned with compressed air or a dry
cloth. It is advisable to clean the blank parts from time to
time with environmentally friendly solvents and to only
grease withacid-free oil or grease.
Faults
Should a fault occur, e.g. after wear of a part, please con-
tact your local Ferm dealer.
In the back of this manual you find an exploded view
showing the parts that can be ordered.
ENVIRONMENT
In order to prevent the machine from damage during
transport, it is delivered in a sturdy packaging. Most of
the packaging materials can be recycled. Take these
materials to the appropriate recycling locations.
Take your unwanted machines to your local Ferm-
dealer. Here they will be disposed of in an environmen-
tally safe way.
GUARANTEE
The guarantee conditions can be found on the separately
enclosed guarantee card.
We declare under our sole responsibility that this
product is in conformity with the following
standards or standardized documents
EN61029-1, EN55014-1, EN55014-2
EN61000-3-2, EN61000-3-3
in accordance with the regulations.
98/37/EEC
73/23/EEC
89/336/EEC
from 03-02-2000
GENEMUIDEN NL
G.M. Ensing
Quality department
CE
ı
DECLARATION OF CONFORMITY (UK)
Ferm 7
OPERATION, HINTS AND TIPS
DEPT STOP
Fig.F
The drill spindle is provided with a depth stop. It can be
adjusted using the nut. The drill depth can be read on the
scale division.
CLAMPING THE DRILL
Fig.G
In the drill head of the bench drill, drills and other tools
with a cylindrical shank can be clamped. The moment of
rotation is transferred to the drill by means of the ten-
sion of the three clamping jaws. To prevent the drill from
sliding away, it must be clamped using the toothed ring
wrench. If the drill slides away in the drill holder, a slight
burr occurs on the drill shank, which makes centric clam-
ping impossible. A burr which occurs in this way must in
any case be removed by grinding
CLAMPING THE WORKPIECE
Fig.H
The drill bench and the footplate of the bench drill are
provided with grooves for fastening clamping tools.
Always clamp the workpiece in the machine clamp or
other clamping tools. In this way you will prevent acci-
dents and even increase the drilling accuracy because the
workpiece is in a fixed position.
ADJUSTING THE BENCH
Fig.I
The drill bench is fastened to the drill column and can be
adjusted in height after loosening the fastening handle.
Adjust the bench in such a way that there is still enough
space between the top of the workpiece and the point of
the drill. You can also swivel the bench sideways, if you
wish to clamp a workpiece directly onto the footplate.
Fig.J
For slanted drilling and with a slanted supporting surface
of the workpiece the bench can be swivelled. For this
purpose loosen the hexagonal screw (20) on the hinge
point (21) of the bench and remove the centring. Swivel
the bench (19) to the desired position. Then screw down
the hexagonal screw (20) properly using a wrench.
NUMBER OF REVOLUTIONS, SPEED OF
ROTATION, SUPPLY
The supply - the feed motion of the drill - takes place by
hand on the 3-armed drill lever. The speed of rotation is
determined by the number of revolutions of the drill
spindle and by the diameter of the drill.
The correct choice of supply and the number of revolu-
tions of the drill spindle are the deciding factors for the
lifespan of the drill. The following applies as a basic rule:
with a larger diameter of the drill the number of revolu-
tions must be adjusted lower; the greater the firmness of
the workpiece, the greater the cutting pressure must
also be. In order not to overheat the drill in this case, the
supply and speed of rotation must be lowered at the
same time. In addition, the drill must be cooled with drill
oil.
For thin plates, quite large drillings must be carried out
carefully with little supply and little cutting pressure, so
as to get a precise result and so that the drilling remains
the correct size. For deep drilling (larger than 2 x the dia-
meter of the drill) the discharge of chips is more difficult
and the temperature of the drill is higher. Therefore
lower the supply and the number of revolutions and ens-
ure a better discharge of chips by regularly pulling back
the drill. For drilling with a greater diameter than 8 mm,
pre-drilling must take place, so that early wear of the drill
- main cutting edge can be avoided and so that the drilling
point is not too heavily loaded.
6Ferm
