Fermax AC-MAX User manual

Cod. 970078I-1 V12_19
P a g e 1 | 8
GUIDE-1 AC-MAX KITS INSTALLATION-WIRING
GUIDE
Note: This document refers to this AC-MAX installation example.
Introduction
This document indicates step by step how to start up a two/four door AC-MAX installation
using both Wiegand readers and ref. 5225 FPAC-MAX RS485 fingerprint readers.
For this we will use for the guide a kit of 2 doors and 3 readers. In door 1 we will use 2 readers
one entrance for another one exit, and in door 2 an entrance reader.
Using the following elements.
•Access controller AC-MAX-CU-KIT-2 (kit ref. 5223)
•2 x RS485 FINGERPRINT readers FPAC-MAX (Ref. 5225) (As input reader and output
reader for Door 1).
•1 x WIEGAND reader (Resistant keyboard 5293) (As door 2 input reader)
Door 1
Door 2

Cod. 970078I-1 V12_19
P a g e 2 | 8
Installation-wiring
The following wiring diagrams show how 2 or 4 door kits can be wired. We made the example
with a system of two doors with a door with reader of entry and another one with reader of
entry / exit.
Diagram Example: of an installation whose commissioning is set out in this guide.

Cod. 970078I-1 V12_19
P a g e 3 | 8
Internal prewiring kit
Connection of the power supply to the expander and the expander to the central unit. The use
of the battery is optional and would be connected to the expander in BAT +, BAT-.
Connection of the data bus from terminals A and B of the expander to terminals A1 B1 of the
control unit. As in Diagram 1.
Diagram 1. RS485 data wiring and power supply kit.
Step 1: Installation

Cod. 970078I-1 V12_19
P a g e 4 | 8
Installation steps-Wiring.
Step 1: Connect power to the different readers.
WIEGAND READERS: Hose ref. 5922 (6 wires x 0.5mm2) or UTP CAT5 (1 pair for D0, D1 and
another pair for negative, is recommended up to 100m. Use CAT6 for industrial installations.
READERS RS-485 FPAC-MAX: UTP CAT5 (1 pair for A, B and another pair for negative, up to
100mts, is recommended. Use CAT6 for industrial installations.
Maximum RS-485 distance, up to 1.200m between UC and further fingerprint reader.
Depending on the cable and the power supplies of the installation.
Warning: Do not install the cables near other high voltage or high current cables, especially
230V or more. Use the same pair for lines A, B or D0, D1.
Step2: Connection DATA, of the different readers.
a) WIEGAND READERS: Wire the data of the different wiegand Do and D1 readers
directly to the central unit.
Terminal 5 (First Wiegand reader 1)
D0, D1
IN1, IN2
Terminal 6 (Second Wiegand reader 2)
D0, D1
IN3, IN4
Terminal 7 (Third Wiegand reader 3)
D0, D1
IN5, IN6
Terminal 8 (Fourth Wiegand reader 4)
D0, D1
IN7, IN8

Cod. 970078I-1 V12_19
P a g e 5 | 8
Example of installation of 4 wiegand readers.
Depending on the type of reader selected the wiring is as follows:
Diagram 2. Readers or keypad Resistant Wiegand y proximidad Mifare Skyline, cityline.

Cod. 970078I-1 V12_19
P a g e 6 | 8
Diagram 3. Keypad City, Skyline y Marine Wiegand ref. 5190, 5191 and 5192.
a) RS-485 FINGERPRINT READER FPAC-MAX: If the readers are FPAC-MAX RS485
fingerprint readers, wire to the corresponding data bus depending on the door to be
connected.
Installation Fingerprint Reader FPAC-MAX RS485.

Cod. 970078I-1 V12_19
P a g e 7 | 8
Diagram 4. Example of the installation of 4 fingerprint readers in a 2-door kit. D1-Door 1 and
D2-Door 2. With input fingerprint reader and output fingerprint reader, per door.
Diagram 5. Example of the installation of 8 fingerprint readers in a 4-door kit. D1-Door 1, D2-
Door 2. With input fingerprint reader and output fingerprint reader, per door.

Cod. 970078I-1 V12_19
P a g e 8 | 8
Step3: Connect the accessories of each door.
b) Wire accessories to the expander. Door opener, door contact, exit button. Etc.
Diagram 6. Example of installation of accessories on door 1.
LCK Lock / Normal fuction.
BELL / Bell.
DC / Door contact
DR Door reléase / Push button
