Festo CP-FB13-E Owner's manual

Manual
Programming and
diagnosing
CP field bus
node13
Type CP−FB13−E
Field bus
connection
PROFIBUS−DP
asperEN50170
Manual
165 213
en 0802h
[730 623]
Compact Performance

Contentsand general instructions
I
FestoP.BE−CP−FB13−E−EN en 0802h
Original de. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editionen 0802h. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DesignationP.BE−CP−FB13−E−EN. . . . . . . . . . . . . . . . . . . . . .
Order no.165 213. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
E (FestoAG&Co. KG, D73726 Esslingen, Federal Republic
of Germany, 2008)
Internet: http://www.festo.com
E−Mail:[e-mail]
The copying, distribution and utilization of this document as
well as the communication of itscontentstootherswithout
expressed authorization is prohibited. Offenderswill beheld
liable for the payment of damages. All rightsarereserved, in
particular the right tocarry out patent, utility model or orna
mental design registration.

Contentsand general instructions
II FestoP.BE−CP−FB13−E−EN en 0802h

Contentsand general instructions
III
FestoP.BE−CP−FB13−E−EN en 0802h
Contents
Designated use IV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Target group V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Notes on the use of this manual V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important user instructionsVI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. Installation 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1General instructionson installation1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2Configuring the field busnode1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1Setting the field busnode1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3Connecting the field bus1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.1Field buscable 1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.2Field busbaud rateand field buslength1−11. . . . . . . . . . . . . . . . . . . . .
1.3.3Field businterface 1−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.4 Connectionpossibilities 1−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Bustermination withterminating resistors1−17. . . . . . . . . . . . . . . . . . . . . . . . . .
1.5Connecting the CP modules 1−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.6Connecting the power supply1−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. Commissioning 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1Preparing the CP system for commissioning 2−3. . . . . . . . . . . . . . . . . . . . . . . . .
2.1.1Saving the string assignment 2−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.2Information on commissioning 2−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2Device master file (GSD) and icon files 2−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3Configuration withaSiemensmaster2−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.1STEP 7 HW Config (up toV 5.2)2−14. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.2Examples of addressing 2−20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.3Commissioning the CP system on the PROFIBUS−DP2−24. . . . . . . . . . .
3. Diagnosis and error treatment 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1LEDdisplayson the busnode3−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1Normal operating status3−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contentsand general instructions
IVFestoP.BE−CP−FB13−E−EN en 0802h
3.1.2Fault display of the POWERLEDs 3−5. . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.3Fault messages of the LEDBUS ERROR 3−6. . . . . . . . . . . . . . . . . . . . . .
3.2Testing the valves 3−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Diagnosis via PROFIBUS−DP3−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.1 Diagnostic words3−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 Diagnostic steps3−10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.3Overview of diagnostic bytes 3−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.4 Details for standard diagnostic information3−12. . . . . . . . . . . . . . . . . .
3.4 Fault treatment 3−17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1SiemensSIMATIC S5/S73−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5Onlinediagnosis withSTEP 73−20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5.1 Read diagnostic buffer withSTEP 7(up toV 5.2)3−20. . . . . . . . . . . . . .
3.6Short circuit/overload3−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.1Output module 3−22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.2Input module 3−24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A. Technical appendix A−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1Technical specificationsField busnodeCP FB13−E A−3. . . . . . . . . . . . . . . . . . . .
A.2Commissioning withthe general DP masterA−5. . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.1Busstart A−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.2Send parametriziung dataA−6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.3 Check the configuration dataA−7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.4 Transferring input and output dataA−9. . . . . . . . . . . . . . . . . . . . . . . . .
A.2.5 Read diagnostic informationA−11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.6Implemented functionsand service access points(SAP) A−11. . . . . . . .
A.2.7Busparameters/reaction timesA−12. . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.2.8Transmission times on the PROFIBUS−DPA−12. . . . . . . . . . . . . . . . . . . .
B. Index B−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contentsand general instructions
V
FestoP.BE−CP−FB13−E−EN en 0802h
Designated use
The CP field busnodetypeCP−FB13−E described in this man
ual has been designed exclusively for use as aslaveon the
PROFIBUS−DP. CP modules from Festocan beconnected to
CPfield busnodeCP−FB13−E.
The CP nodemay only beused as follows:
as specified in industrial applications.
w
ithout any modificationsby the user Only the conver
sionsor modificationsdescribed in the documentation
supplied withthe product arepermitted.
in faultless technical condition.
The maximum values specified for pressures, temperatures,
electrical data, torques etc. must beobserved.
If additional commercially−available componentssuch as sen
sorsand actuatorsareconnected, the specifiedlimitsfor pres
sures, temperatures, electrical data, torques, etc. must not
beexceeded.
Please comply withnational and local safety lawsand regula
tions.

Contentsand general instructions
VIFestoP.BE−CP−FB13−E−EN en 0802h
Target group
This manual is intended exclusively for technicianstrained in
control and automation technology, who haveexperience in
installing, commissioning, programming and diagnosing
PROFIBUS−DPslaves.
Service
Please consult your local Festorepair service if you haveany
technical problems.
Notes on the use of this manual
This manual containsspecific information on installing, com
missioning, programming and diagnosingCP field busnode
FB13 for PROFIBUS−DP in accordance withEN 50170.
Information on further CP modules can befound in the
manual for the relevant module. An overview is provided in
Tab.0/1.
Information on pneumatics can befound in the Pneumatics
manual, P. BE−CPV−... ."
Further information on the PROFIBUS−DP can befound in:
the setting up guidelines for the PROFIBUS−DP
the manuals of the master manufacturer.

Contentsand general instructions
VII
FestoP.BE−CP−FB13−E−EN en 0802h
Important user instructions
Danger categories
This manual containsinstructionson the possible dangers
which may occur if the product is not used correctly. These
instructionsaremarked (Warning, Caution, etc.), printed on a
shaded background and marked additionally withapicto
gram. A distinction is madebetween the following danger
warnings:
Warning
This meansthat failuretoobservethis instruction may
result in seriouspersonal injury or damagetoproperty.
Caution
This meansthat failuretoobservethis instruction may
result in personal injury or damagetoproperty.
Please note
This meansthat failuretoobservethis instruction may
result in damagetoproperty.
The following pictogram markspassages in the text which
describeactivities withelectrostatically sensitivecompo
nents.
Electrostatically sensitivecomponentsmay bedamaged if
they arenot handled correctly.

Contentsand general instructions
VIII FestoP.BE−CP−FB13−E−EN en 0802h
Marking special information
The following pictogramsmark passages in the text contain
ing special information.
Pictograms
Information:
Recommendations, tipsand references toother sources of
information.
Accessories:
Information on necessary or sensible accessories for the
Festoproduct.
Environment:
Information on environment−friendly use of Festoproducts.
Text markings
·The bullet indicates activities which may becarried out in
any order.
1.Figures denoteactivities which must becarried out in the
numerical orderspecified.
 Hyphensindicategeneral activities.

Contentsand general instructions
IX
FestoP.BE−CP−FB13−E−EN en 0802h
Manuals on the CP system Peri−
pherals
Manual CP system, installation and commissioning"
typeP.BE−CPSYS−...
ContentsGeneral basic information on the method of operation, fitting, installation
and commissioning of CP systems
Manual CP field busnode,
programmingand
diagnosis"
typeP.BE−CP−FB...
or P.BE−VIFB...−10...
CPV valveterminal,
pneumatics" or
CPAvalveterminal,
pneumatics"
typeP.BE−CPV−...
or P.BE−CPA−...
CP modules,
electronics"
typeP.BE−CPEA−...
ContentsSpecial information
oncommissioning,
programmingand
diagnosing related
tothe nodeused
Information on fitting,
installingand
commissioningCPA or
CPV valveterminals
Information on fitting,
installingand
commissioning
CPI/Omodules
Ó
Ó
Ó
Ó
Ó
ÓÓ
Ó
Ó
Ó
Ó
Ó
Ó
Ó
Ó
Ó
Ó
Ô
Ô
Ô
Ô
Ô
Ô
Ô
Ô
Ô
Ô
ÔÔ
Tab.0/1:Manuals on the CP system

Contentsand general instructions
XFestoP.BE−CP−FB13−E−EN en 0802h
The following product−specific termsand abbreviationsare
used in this manual:
Term/abbreviation Meaning
Busy bit Enable bit, for analysing dataexchangewiththe CP system
CP cable Special cable for coupling the variousCP modules
CP connection Plug or socket on the CP modules which enables the modules tobe
connected withthe CP cable
CP modules Common term for variousmodules which can beincorporated in a
CPsystem
CP systemCompletesystem consisting of CP field busnodeand P modules
I Digital input
I/Omodules Common term for the CP modules which providedigital inputsand
outputs(CP input modules and CP output modules)
I/Os Digital inputsand outputs
Node CP field busnodewith/without field busconnection towhich the
I/Omodules areconnected
O Digital output
Octet Number of address bytes assigned by the CP system
PLC/IPCProgrammable logic controller/industrial PC
SAVE button Savethe current string assignment (connected I/Os); when the CP
system is restarted, the last saved string assignment will becompared
withthecurrent string assignment. Deviationswill beindicated by flash
ing LEDs.
String Total number of I/Omodules connected together on one CP connection
of the field busnode
String assignment Total number of all I/Omodules connected via stringstoaCP field bus
node(0...3)

Installation
1−1FestoP.BE−CP−FB13−E−EN en 0802h
Chapter 1

1. Installation
1−2FestoP.BE−CP−FB13−E−EN en 0802h
Contents
1. Installation 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1General instructionson installation1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2Configuring the field busnode1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1Setting the field busnode1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3Connecting the field bus1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.1Field buscable 1−9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.2Field busbaud rateand field buslength1−11. . . . . . . . . . . . . . . . . . . . .
1.3.3Field businterface 1−12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.4 Connectionpossibilities 1−13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Bustermination withterminating resistors1−17. . . . . . . . . . . . . . . . . . . . . . . . . .
1.5Connecting the CP modules 1−18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.6Connecting the power supply1−19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1. Installation
1−3
FestoP.BE−CP−FB13−E−EN en 0802h
1.1 General instructions on installation
Warning
Beforecarrying out installation and maintenance work,
switch off the following:
the compressed air supply,
the operating voltageon the field busnode
(pins1and 2),
the load voltagesupply tothe valves.
You can thereby avoid:
uncontrolled movementsof loose tubing.
unexpected movementsof the connected actuators.
non−defined switching states of the electronic compo
nents.
Caution
The nodeof the CP system containselectrostatically sensi
tivecomponents.
·Do not thereforetouch any contacts.
·Observethe regulationsfor handling electrostatically
sensitivecomponents.
You will then prevent the electronics in the nodefrom being
damaged.
General information on installing the CP modules can be
found in the manual Installing and commissioning
CPsystems."

1. Installation
1−4 FestoP.BE−CP−FB13−E−EN en 0802h
Electrical connecting and display elements
1Field businterface
2LEDBUS ERROR
3LEDs POWERand
POWERV
4CP connections
for 4 strings(0...3)
5String fault LEDs
6Identification
fields
7Rotary and DIL
switches
8Cover of the
rotary/DIL
switches
9SAVE button
aJ Connection for
power supply
0
1
3
2
SAVE
POWER
24VDC
POWERV
BUSERROR
ERROR
PROFIBUS−DP
6
5
2
78
9
0
1
3
4
6
5
2
789
0
1
3
4
1
2
3
456
7
8
9
aJ
Fig.1/1:Connecting and display elementsof the CP field busnode

1. Installation
1−5
FestoP.BE−CP−FB13−E−EN en 0802h
1.2 Configuring the field bus node
Rotary and DIL switches can befound under the cover on the
field busnode(see Fig.1/1).
Open and close the cover as follows:
·Opening: Removethe 2screwsin the cover. Lift up the
cover.
·Closing: Place the cover in position and tighten the screws
by hand.
Caution
Tighten the screwsof the switch cover only by hand.
1.2.1Setting the field busnode
Withthe rotary and DIL switches you can set the following
functions:
the station number
the voltagemonitoring
the field busprotocol PROFIBUS−DP:
Switch elements3...6arereserved and must beset tothe
positionsspecified below.

1. Installation
1−6FestoP.BE−CP−FB13−E−EN en 0802h
Setting the station number
You can set the station number withthe rotary switches and
element 1of the DIL−switch.
1Rotary switch for
the UNITS figure
2Rotary switch for
the TENS figure
3DIL switch for the
HUNDREDS figure
6
5
2
789
0
1
3
4
6
5
2
789
0
1
3
4
UNITS
TENS
1
2
3HUNDREDS
Examples of set station numbers:005 121
6
5
2
789
0
1
3
4
6
5
2
789
0
1
3
4
Fig.1/2:Setting the station number and examples
Proceed as follows:
1.Switch off the operating voltage.
2.Assign an unused PROFIBUS address tothe fieldbus
node.
3.Use ascrewdriver toset the arrow of the relevant rotary
switch or element 1of the DIL switch tothe units, tensor
hundredsfigureof the desired station number.

1. Installation
1−7
FestoP.BE−CP−FB13−E−EN en 0802h
The following station numbersarepermitted:
Protocol Address designation Permitted station
numbers
PROFIBUS−DP Station number1; ...; 125
Tab.1/1:Permitted station numbers
Please note
The station number (DP slaveaddress) of the valveter
minal cannot bemodified by the DP master. The valveter
minal can only beaddressed by the station number set on
the rotary/DIL switches.
Station numbersmay only beassigned once per field bus
module/PROFIBUS−DPinterface.
Observeany possible limitationsas regardsthe assign
ment of station addresses by your DP master.
Recommendation:
Assign the station numbersin ascending order. If necessary,
assign the station numberstosuit the machinestructureof
your system.

1. Installation
1−8FestoP.BE−CP−FB13−E−EN en 0802h
Setting the voltage monitoring
Withswitch element 2of the DIL switch, you can specify
whether or not the load voltageof the valves and the output
modules is tobemonitored (see chapter 3Diagnosis and
fault treatment").
DIL switch Voltage monitoring
active
Voltage monitoring
inactive
DIL 2: ONDIL 2: OFF
Tab.1/2:Setting the voltagemonitoring, DIL switch
element 2
Reserved DIL switch elements 3...6
Leaveswitch elements3...6set as follows:
DIL switch Setting reserved
DIL 3...5: ON
DIL 6: OFF
Tab.1/3:Reserved DIL switch elements3...6
