USE AND MAINTENANCE MANUAL
iMx 50B
iMx 50BT
iMx 50BB
ED. 05-2013 EN
ORIGINAL
INSTRUCTIONS
Doc. 10042009
Ver. AA

The descriptions contained in this document are not binding.
The company therefore reserves the right to make any modifications at any time to elements,
details, or accessory supply, as considered necessary for reasons of improvement or
manufacturing/commercial requirements.
The reproduction, even partial, of the text and drawings contained in this document is prohibited
by law.
The company reserves the right to make any technical and/or supply modifications. The images
are for reference purposes only, and are not binding in terms of design and supply.
Symbols used in the manual
Open book symbol with an "i"
Indicates the need to consult the instruction manual
Open book symbol
Used to tell the operator to read the manual before using the machine
Warning symbol
Carefully read the sections marked with this symbol and observe the
indications, for the safety of the operator and the machine
Warning symbol
Indicates danger of gas exhalation and leakage of corrosive liquids
Warning symbol
Indicates operator should take safety measures to avoid damage to
limbs.
Warning symbol
Indicates the danger of fire.
Do not go near with free flames
Warning symbol
Indicates that the packed product should be handled with suitable lifting
means that comply with the legal requirements
Disposal symbol
Carefully read the sections marked with this symbol for machine
disposal

3
CONTENTS
ON CONSIGNMENT OF THE MACHINE............................................................................................................................................................5
INTENDED USE..................................................................................................................................................................................................5
INTRODUCTORY COMMENT............................................................................................................................................................................5
SERIAL NUMBER PLATE..................................................................................................................................................................................5
TECHNICAL DESCRIPTION...............................................................................................................................................................................5
SYMBOLS USED ON THE MACHINE................................................................................................................................................................6
GENERAL SAFETY REGULATIONS.................................................................................................................................................................9
MACHINE PREPARATION...............................................................................................................................................................................10
1. HANDLING OF THE PACKED MACHINE.........................................................................................................................................................................10
2. HOW TO MOVE THE MACHINE.......................................................................................................................................................................................11
3. FRONT MACHINE COMPONENTS...................................................................................................................................................................................11
4. SIDE COMPONENTS OF THE MACHINE........................................................................................................................................................................11
5. REAR COMPONENTS OF THE MACHINE.......................................................................................................................................................................11
6. CONTROL PANEL COMPONENTS (VERSION B)...........................................................................................................................................................12
7. CONTROL PANEL COMPONENTS (VERSION BT).........................................................................................................................................................12
8. CONTROL PANEL COMPONENTS (VERSION BB).........................................................................................................................................................13
9. TYPE OF BATTERY...........................................................................................................................................................................................................13
10. BATTERY MAINTENANCE AND DISPOSAL..................................................................................................................................................................14
11. HANDLING - INSERTING BATTERIES...........................................................................................................................................................................14
12. CONNECTING THE BATTERIES AND BATTERY CONNECTOR..................................................................................................................................16
13. CONNECTING THE BATTERY CHARGER (VERSIONS WITHOUT BC) ......................................................................................................................16
14. CONNECTING THE BATTERY CHARGER (VERSIONS WITH BC)..............................................................................................................................18
15. BATTERY CHARGE LEVEL INDICATOR (B-BT VERSIONS)........................................................................................................................................19
16. HOUR METER (B-BT VERSIONS)..................................................................................................................................................................................19
17. BATTERY CHARGE LEVEL INDICATOR (BB VERSIONS) ...........................................................................................................................................19
18. FORWARD WORK SPEED (BT VERSIONS)..................................................................................................................................................................20
19. FORWARD WORK SPEED (B-BB VERSIONS)..............................................................................................................................................................20
20. FILLING THE SOLUTION TANK......................................................................................................................................................................................20
21. ASSEMBLING THE SQUEEGEE.....................................................................................................................................................................................21
22. ASSEMBLING THE BRUSH (B-BT VERSIONS).............................................................................................................................................................22
23. ASSEMBLING THE BRUSH (BB VERSIONS) ................................................................................................................................................................22
24. TRANSPORTATION MODE.............................................................................................................................................................................................22
WORK ...............................................................................................................................................................................................................23
25. PREPARING TO WORK (B-BT VERSIONS)...................................................................................................................................................................23
26. PREPARING TO WORK (BB VERSIONS).....................................................................................................................................................................25
27. REGULATING THE DETERGENT (B VERSION)............................................................................................................................................................26
28. REGULATING THE DETERGENT (BT VERSION).........................................................................................................................................................27
29. REGULATING THE DETERGENT (BB VERSION).........................................................................................................................................................27
30. ADJUSTING THE FORWARD WORKING SPEED (BT VERSIONS)..............................................................................................................................28
31. REVERSE FUNCTION (BT VERSIONS).........................................................................................................................................................................28
32. "ECO" DEVICE (B-BT VERSIONS)..................................................................................................................................................................................28
33. OVERFLOW DEVICE (B-BT VERSIONS).......................................................................................................................................................................29
34. OVERFLOW DEVICE (BB VERSIONS)...........................................................................................................................................................................30
35. EMPTYING THE RECOVERY TANK (B-BT VERSIONS)...............................................................................................................................................30
36. EMPTYING THE RECOVERY TANK (BB VERSIONS)...................................................................................................................................................30
AT THE END OF WORK...................................................................................................................................................................................31
37. AT THE END OF WORK (B-BT VERSIONS)...................................................................................................................................................................31
38. AT THE END OF WORK (BB VERSIONS)......................................................................................................................................................................33
DAILY MAINTENANCE ....................................................................................................................................................................................35
39. CLEANING THE SOLUTION TANK FILTER - CAP.........................................................................................................................................................35
40. CLEANING THE RECOVERY TANK FILTER..................................................................................................................................................................35
41. CLEANING THE BRUSH (B-BT VERSIONS)..................................................................................................................................................................36
42. CLEANING THE BRUSH (BB VERSIONS) .....................................................................................................................................................................37
43. CLEANING THE SQUEEGEE BODY..............................................................................................................................................................................37

4
WEEKLY MAINTENANCE................................................................................................................................................................................39
44. CLEANING THE VACUUM HOSE...................................................................................................................................................................................39
45. CLEANING THE RECOVERY TANK...............................................................................................................................................................................39
46. CLEANING THE SOLUTION TANK.................................................................................................................................................................................41
EMERGENCY MAINTENANCE........................................................................................................................................................................42
47. ADJUSTING THE PARKING BRAKE (ONLY FOR BT VERSIONS)...............................................................................................................................42
48. BRUSH REPLACEMENT (B-BT VERSIONS)..................................................................................................................................................................42
49. BRUSH REPLACEMENT (BB VERSIONS).....................................................................................................................................................................42
50. REGULATING MACHINE DIRECTION............................................................................................................................................................................43
51. REPLACING SQUEEGEE BODY RUBBERS..................................................................................................................................................................43
52. ADJUSTING THE SQUEEGEE INCLINATION................................................................................................................................................................44
53. ADJUSTING THE SQUEEGEE HEIGHT.........................................................................................................................................................................44
TROUBLESHOOTING......................................................................................................................................................................................45
54. THE MACHINE DOES NOT START................................................................................................................................................................................45
55. INSUFFICIENT WATER ON THE BRUSHES..................................................................................................................................................................45
56. THE SQUEEGEE DOES NOT DRY PERFECTLY ..........................................................................................................................................................45
57. THE MACHINE DOES NOT CLEAN WELL.....................................................................................................................................................................45
58. EXCESSIVE FOAM PRODUCTION ................................................................................................................................................................................45
59. THE VACUUM CLEANER DOES NOT FUNCTION........................................................................................................................................................45
60. THE BRUSH MOTOR DOES NOT WORK......................................................................................................................................................................45
DISPOSAL ........................................................................................................................................................................................................46
CHOOSING AND USING THE BRUSHES.......................................................................................................................................................47
EC DECLARATION OF CONFORMITY............................................................................................................................................................48

5
On consignment of the machine
When the machine is consigned to the customer, an immediate check
must be performed to ensure all the material mentioned in the shipping
documents has been received, and also to check the machine has not
suffered damage during transportation. If this is the case, the carrier must
ascertain the extent of the damage at once, informing our customer
service office. It is only by prompt action of this type that the missing
material can be obtained, and compensation for damage successfully
claimed.
Intended use
The floor scrubbing machine is designed exclusively for the professional
cleaning of surfaces and floors in industrial, commercial and public
environments. The machine is only suitable for use in closed - or at least
covered - locations.
The machine is not suitable for use in the rain, or under water jets. It is
FORBIDDEN to use the machine for picking up dangerous dusts or
inflammable liquids within places with a potentially explosive atmosphere.
In addition, it is not suitable as a means of transport for people or objects.
Introductory comment
The iMx is a floor scrubbing machine which, by means of the mechanical
action of the rotating brush and the chemical action of a water/detergent
solution, can clean any type of flooring. As it advances, it also collects
any removed dirt as well as the detergent solution not absorbed by the
floor.
The machine must only be used for this purpose. Even the best
machines will only work well if used correctly and kept in good working
order. We therefore suggest you read this instruction booklet carefully
and read it again whenever difficulties arise while using the machine. If
necessary, remember that our customer assistance service (organised in
collaboration with our dealers) is always available for advice or direct
intervention.
Serial number plate
TECHNICAL DESCRIPTION
UM
iMx 50B
iMx 50BT
iMx 50BB
Working width
mm
508
508
508
Squeegee width
mm
705
705
705
Working capacity, up to
m2/h
2032
2032
2032
Disc brush
No. / ∅Ø mm
1 / 508
1 / 508
1 / 508
Disc brush rotations
rpm
166
166
166
Brush motor
V/W
24 / 500
24 / 500
24 / 500
Maximum pressure on the brush
kg
25
25
25
Traction motor
V/W
-
24 / 150
-
Traction wheel (number / diameter / width)
No. / (∅mm / mm)
2 / (225 / 64)
2 / (225 / 64)
2 / (172.5 / 45)
Maximum forward speed in transport mode
km/h
-
4
-
Maximum forward speed in working mode
km/h
-
3.9
-
Maximum gradient with full load
%
2
2
2
Vacuum motor
No./(V/W)
1 / (24 / 310)
1 / (24 / 310)
1 / (24 / 310)
Suction vacuum
mmH2O
610
610
610
Rear wheel (number / diameter / width)
∅mm / mm
1 / 80 / 23
1 / 80 / 23
1 / 80 / 23
Solution tank
l
41
41
41
Recovery tank
l
37
37
37
Steering diameter
mm
850
850
850
Machine length
mm
1180
1180
1180
Machine length (with splash guard kit)
mm
1200
1200
1200
Machine height
mm
1030
1030
1030
Machine width (without squeegee)
mm
570
570
570
Machine width (without squeegee + optional splash guard kit)
mm
580
580
580
Battery compartment (l x w x h)
mm
353 / 333 / 250
353 / 333 / 250
353 / 333 / 250
Rated battery voltage
Nr / V / Ah
2 / 12 / 77
2 / 12 / 77
2 / 12 / 77
Battery weight (calculated with 12 V 77Ah battery)
kg
26.5
26.5
26.5
Machine weight (machine + brush + squeegee)
kg
69
76
69
Machine weight in transport (machine + batteries + brush + squeegee)
kg
122
129
122
Machine weight in running order (machine + batteries + water + brush + squeegee)
kg
163
170
163
Sound pressure level (ISO 11201) - L pA
dB (A)
52.9
63
52.9
Uncertainty KpA
dB (A)
1.5
1.5
1.5
Hand vibration level (ISO 5349)
m/s
2
0.663
0.612
0.663
Uncertainty of measurement of vibrations
6%
6%
6%

6
SYMBOLS USED ON THE MACHINE
Symbol for main switch or key switch (only for B-BT version).
Used on the control panel, to indicate the key switch for machine operation on (I) or off (0).
ECO mode symbol (only for B-BT version).
Used on the control panel to indicate the button that activates the ECO mode of the machine.
Vacuum motor symbol (only for B-BT version).
Used on the control panel to indicate the button that commands vacuum motor operation.
“Auto” work mode symbol (Only for B-BT version).
Used on the control panel to indicate the button that commands the brush motor function on the vacuum motor and the
proportional solenoid valve.
Reverse drive selector symbol (only for BT version).
Used on the control panel to indicate the button for engaging the reverse gear.
Proportional solenoid valve open/close symbol (only for BT version).
Used on the control panel to indicate the button that commands proportional solenoid valve delivery flow operation.
Symbol denoting proportional solenoid valve open (only for B version).
Used on the control panel to indicate the button that commands proportional solenoid valve delivery flow operation.
Proportional solenoid valve close symbol (only for B version).
Used on the control panel to indicate the button that commands proportional solenoid valve delivery flow operation.
Brush uncoupling symbol (only for B-BT version).
Used on the control panel to indicate the button for uncoupling the brush.

7
SYMBOLS USED ON THE MACHINE
Traction motor potentiometer symbol (only for BT version).
Used on the control panel to indicate the knob that commands the potentiometer that controls the traction motor.
Main switch position "ON- SOLENOID VALVE" symbol (Only for BB version).
Used on the control panel to indicate the button that commands the activation of the brush motor and the solenoid valve.
Main switch position "OFF" symbol (Only for BB version).
Used on the control panel to indicate the button that commands the deactivation of the brush motor and of the solenoid valve.
Main switch position "ON- NO SOLENOID VALVE" symbol (Only for BB version).
Used on the control panel to indicate the button that commands the activation of the brush motor but not of the solenoid valve.
Symbol for vacuum motor switch “ON - VACUUM” (only for BB version).
Used on the control panel to indicate the button that commands vacuum motor operation.
Symbol for vacuum motor switch “OFF - VACUUM” (only for BB version).
Used on the control panel to indicate the button that commands vacuum motor switch-off.
Brush uncoupling symbol (only for BB version).
Used on the instrument panel to indicate the button for automatic brush uncoupling
Work direction control symbol (Only for B-BB version).
Used on the brush head unit to indicate the knob which allows users to control the work direction of the machine in working
mode.
Symbol indicating the maximum temperature of the water used to fill the solution tank

8
SYMBOLS USED ON THE MACHINE
Symbol indicating the position of the solution tank drain cap.
Symbol indicating the position of the solution tank filter.
Symbol indicating the position of the recovery tank drainage tube
Detergent flow control symbol.
Used on the machine to indicate the position of the lever used to control the flow of the detergent solution present in the water
system.
Parking brake symbol (only for BT version).
Used on the machine to indicate the parking brake control lever
Indicates the maximum gradient

9
GENERAL SAFETY REGULATIONS
The regulations below must be carefully followed in order to avoid harm to the operator and damage to the machine.
WARNING:
•Read the labels on the machine carefully. Do not cover them for any reason and replace them immediately if they become damaged.
•The machine must be exclusively used by authorised, trained personnel.
•Do not use the machine on surfaces with an inclination greater than the one shown on the plate.
•The machine is not suitable for cleaning rough or uneven floors. Do not use the machine on slopes.
•If the power supply cable of the battery charger is damaged, contact an Authorised service centre immediately.
•n case of danger, disconnect the battery connector on the rear of the machine.
•For all maintenance interventions, switch off the machine and disconnect the battery connector and/or the power supply cable.
•Children must be supervised to ensure they do not play with the device.
•During the working of the machine, pay attention to other people and especially to children.
•Only use the brushes supplied with the machine, or those specified in the "CHOOSING AND USING THE BRUSHES" paragraph of the instruction
manual. The use of other brushes could compromise safety levels.
•The machine must only be powered with a voltage equal to the one shown on the serial number plate.
WARNING:
•The machine is not suitable for use by children and persons with reduced physical, mental and sensory capabilities, or people who lack experience and
knowledge.
•The machine must not be used or stored outdoors, in damp conditions or directly exposed to rain.
•The storage temperature must be between -25°C and +55°C; do not store outdoors in damp conditions.
•Conditions of use: room temperature between 0°°C and 40°°C with relative humidity between 30 and 95%.
•The socket for the machine's power cable (electric version) or for the battery charger power cable (battery version) must be correctly earthed.
•Adapt the speed to the adhesion conditions.
•Do not use the machine as a means of transport.
•The machine does not cause harmful vibrations.
•Do not use the machine in an explosive atmosphere.
•Do not vacuum inflammable liquids.
•Do not use the device to collect dangerous powders.
•Do not mix different types of detergent as this may produce harmful gases.
•The machine is not suitable for cleaning carpets.
•Do not place any liquid containers on the machine.
•Avoid working with the brushes when the machine is standing still, so as not to damage the floor.
•In the event of a fire, use a powder extinguisher. Do not use water.
•Do not knock against shelving or scaffolding, where there is a danger of falling objects. The operator must always be equipped with the appropriate
safety devices (gloves, shoes, helmet, goggles, etc.).
•The machine is designed to carry out the scrubbing and drying operations simultaneously. Different operations should only be carried out in areas
where the passage of unauthorised persons is prohibited. Signal the presence of damp floors with suitable signs.
•If the machine does not work properly, check this is not caused by failure to carry out routine maintenance. Otherwise, ask for intervention of the
authorised technical assistance centre.
•If you need to replace any components, request the ORIGINAL spare parts from an Authorised dealer and/or Retailer.
•Restore all electrical connections after any maintenance interventions.
•Before using the machine, check that all the hatches and covers are positioned as shown in this Use and Maintenance Manual.
•Do not remove the guards that can only be removed with the aid of tools, except for maintenance work (see the relevant paragraphs)
•Do not wash the machine with direct water jets or with pressurised water, nor with corrosive substances.
•To prevent scaling in the solution tank filter, do not fill the tank with detergent solution many hours before using the machine.
•Do not use acid or basic solutions that could damage the machine and/or harm people.
•Have the machine checked by an authorised technical assistance centre every year.
•When disposing of consumable materials, observe the laws and regulations in force.
•When your machine has reached the end of its long working life, dispose of the materials it contains (especially oils, batteries and electronic
components) in an appropriate manner, taking into account that the machine itself was constructed using 100% recyclable materials.
•The batteries must be removed from the machine before its disposal. The batteries must be disposed of in a safe manner, fully observing the laws and
regulations in force.

10
MACHINE PREPARATION
1. HANDLING OF THE PACKED MACHINE
The machine is contained in specific packaging with a pal
let for the handling with fork trucks. The
packages cannot be placed on top of each other.
Gross weight of machine with packaging:
iMx version B: 94 kg
iMx version BT: 101 kg
iMx version BB: 94 kg
The dimensions of the packaging are as follows:
A=
1170mm
B= 660mm
C= 1430mm
A
CB
1. Remove the outer package.
2. The machine is fixed to the pallet with wedges which block the wheels
3. Remove the wedges
4. Disconnect the parking brake (only for BT versions), rotate the lever (1) on the right side of the
machine anti-clockwise.
5. Use a chute to get the machine down from the pallet, pushing it backwards. Do not assemble the rear
squeegee before unloading the machine, and avoid violently jolting the brush head. To assemble the
squeegee, read the “ASSEMBLING THE SQUEEGEE” paragraph.
WARNING: During transport operations, the instrument panel may be activated but
the machine is still off.
6. Keep the pallet for any future transport needs.
WARNING: If the product is delivered in cardboard containers, handle the
packed product with suitable lifting means that comply with the legal
requirements
WARNING: During this operation, check there are no people or objects near
the machine

11
MACHINE PREPARATION
2. HOW TO MOVE THE MACHINE
1. Using a chute, mount the machine on the pallet. Carry out this operation with the rear squeegee and
the brush detached from the machine.
2. Check the solution tank and recovery tank are empty; if necessary, empty them
3. Check that the main machine switch is in position "0" (for B-BT versions) or "OFF" (for BB versions). If
this is not the case, place the switch in this position.
4. Disconnect the electric system connector from the battery connector
5. Secure the machine to the pallet using wooden wedges
6. Apply the parking brake (only for BT version).
3. FRONT MACHINE COMPONENTS
The front components of the machine are identified as follows:
1.
Direction control knob.
2.
Fast water filler cap.
3.
Water filler cap, detergent dispenser.
4.
Recovery tank lifting handle
4. SIDE COMPONENTS OF THE MACHINE
The components on the left
-hand side of the machine are identified as follows:
1.
Cap - solution tank filter.
2.
Solution tank filler level tube.
3.
Vacuum support cover – brush – squeegee body.
4.
Detergent solution flow control lever.
The components on the right-hand side of the machine are identified as follows:
5.
Parking brake lever (only for BT version).
5. REAR COMPONENTS OF THE MACHINE
The components at the rear of the machin
e are identified as follows:
1.
Main switch with key (B-BT versions).
2.
Squeegee body control lever.
3.
Electrical system connector
4.
Document compartment cover or battery charger power cable (CB version).

12
MACHINE PREPARATION
5. Squeegee vacuum hose
6.
Battery charger connector cable cap.
7.
Recovery tank drainage tube
8. Control handlebar, with dead man's lever beneath.
9.
Vacuum motor tube.
10.
Recovery tank lifting handle.
11.
Recovery tank cover
6. CONTROL PANEL COMPONENTS (VERSION B)
The control panel components are identified as follows:
1. Level indicator for battery/hour meter.
2. "ECO" function button
3. Vacuum motor control button.
4. “AUTO” function button.
5. Proportional solenoid valve control button, increases the detergent flow.
6. Proportional solenoid valve control button, decreases the detergent flow.
7. Brush uncoupling button.
7. CONTROL PANEL COMPONENTS (VERSION BT)
The control panel components are identified as follows:
1. Level indicator for battery/hour meter.
2. Speed regulation knob (only for BT version).

13
MACHINE PREPARATION
3. "ECO" function button.
4. Vacuum motor control button.
5. “AUTO” function button.
6. Reverse button
7. Proportional solenoid valve control button.
8. Brush coupling/uncoupling button.
8. CONTROL PANEL COMPONENTS (VERSION BB)
The control panel components are identified as follows:
1. Level indicator for battery/hour meter.
2. Main switch with three positions:.
Position “I”: Switch in “ON + SOLENOID VALVE ON” position activates the brush motor and the
solenoid valve
Position “0”: Switch in “OFF” position interrupts the power supply in the machine's electrical system.
Position “II”: Switch in “ON + SOLENOID VALVE OFF” position activates the brush motor but not the
solenoid valve
3. Vacuum motor control button.
Position-01: Switch in “ON - VACUUM” position activates the vacuum motor
Position-02: Switch in “OFF - VACUUM” position deactivates the vacuum motor
4. Brush uncoupling switch.
WARNING: From this point on in the document the positions of the main switch (02)
will be identified with “I or 0 or II”.
WARNING: from this point on in the document, the positions of the vacuum motor
control switch (03) will be identified with “Pos.-01" or "Pos.-02”.
9. TYPE OF BATTERY
Power to th
e machine must be supplied by two sealed traction batteries with gas recombination or gel
technology. The batteries must meet the requirements laid out in the norms: CEI EN 60254
-1:2005-12 (CEI
21
-5) + CEI EN 60254-2:2008-06 (CEI 21-7).
Foroptimum perform
ance,theuseoftwo12V77Ah/C5batteriesisrecommended(size:330mmx169mmxH233mm
each with a weight of 27 kg), or two 12V 75Ah/C5 batteries (size: 259 mm x 169 mm x H2227mm each with a
weight of 25 kg).
WARNING: If batteries with weights or dimensions differing from those advised above
are used, the machine performance could vary considerably.

14
MACHINE PREPARATION
10. BATTERY MAINTENANCE AND DISPOSAL
For maintenance and recharging, respect the instructions provided by the battery
manufacturer.
Particular attention must be paid when choosing the battery charger, if not supplied, since there are
different kinds according to the type and capacity of the battery.
When the battery reaches the end of its working life, it must be disconn
ected by expert, trained personnel
then removed from the battery compartment with the aid of suitable lifting devices. DEAD BATTERIES
ARE CLASSIFIED AS DANGEROUS WASTE AND MUST BE DELIVERED TO THE AUTHORISED
BODIES FOR CORRECT DISPOSAL.
11. HANDLING - INSERTING BATTERIES
The batteries must be housed in the special compartment beneath the recovery tank and should be handled using
lifting equipment that is suitable in terms of both weight and coupling system. They must also satisfy the require
ments
ofStandardCEI 21
-5.Thedimensionsof thebattery compartmentare: 353mm x333 mmx H250mm.
WARNING: Ensure that you comply with the accident prevention regulations in force
in the country where you work or with DIN EN 50272-3 and DIN EN 50110-1, before
any handling of the batteries.
WARNING: To prevent an accidental short circuit use insulated tools to connect the
batteries, and do not place or drop metal objects on the battery. Remove rings,
watches and any clothing with metal parts that may come into contact with the battery
terminals.
To insert the batteries into the compartment proceed as follows:
1. Check that the recovery tank is empty; if not, empty it using the tube provided for this purpose (01)
positioned at the rear of the machine.
2. Check that the main switch (02) is in the "0" position; if not turn the key a quarter turn to the left (for B-
BT version only), and remove the key from the instrument panel. Check that the machine's main switch
at the back of the machine is in the “0” position; if not, turn to “0” (for BB version only).
3. Make sure the electric system connector (03) is disconnected from the battery connector; if not,
disconnect it.
4. Rest the brush head on the floor.
5. Rest the squeegee on the floor, by moving the lever designed for this purpose, positioned on the rear
of the machine.
6. Secure the machine by applying the parking brake, move the lever (04) on the right side of the
machine (only for BT versions).
7. Remove the recovery tank drainage tube (01) and lay on the ground.
8. Remove the vacuum motor tube (05) from the connector present on the recovery tank.
9. Remove the squeegee vacuum hose (06) from the hole in the recovery tank.

15
MACHINE PREPARATION
10.Remove the vacuum cover and attach to the support designed for this purpose, positioned at the rear
of the machine.
11.Remove the recovery tank from the machine, taking care with the drainage hose, and rest on a raised
surface in order to avoid accidental damage.
WARNING: The shape of the recovery tanks means that it can be rested on the
ground with the rear part in contact with the floor, in order to avoid accidental damage
to the drainage joint.
12.Using the correct tool, attach the battery locking blades (07) to the flat base of the batteries.
In the image to the side, the position of the blades for 12V 77Ah batteries is shown (battery size: 259
mm x 168 mm x H208mm each with a weight of 27 kg).
In the image to the side, the position of the blades for 12V 75Ah batteries is shown (battery size: 259
mm x 168 mm x H208mm each with a weight of 25 kg).
WARNING: Before installing the battery, clean the battery compartment with a damp
cloth. Check that the connectors on the cables supplied are functioning correctly.
WARNING: Check that the characteristics of the battery that you are looking to use
are appropriate for the type of work to be performed. Check the battery charge and
the condition of the contacts on the battery.
WARNING: You are advised to only lift and move the batteries with lifting and
transportation means suitable for the specific weight and size
WARNING: The lifting hooks must not damage the blocks, connectors or cables.
13.Place the batteries in the correct compartments, positioning the “+” and “-“ poles opposite each other,
taking care not to table the vacuum motor tube (05).
In the image to the side, the position of the battery blades is shown for 12V 77Ah batteries.
WARNING: Before inserting the batteries into the machine, remember to cover the
terminals with a little grease to protect them against external corrosion.
In the image to the side, the position of 12V 75Ah batteries is shown. Place the batteries into the correct
compartment, positioning the "+" and "-" poles opposite each other as shown in the diagram, taking care
not to damage the vacuum motor tube (05).
WARNING: Before inserting the batteries into the machine, remember to cover the
terminals with a little grease to protect them against external corrosion.

16
MACHINE PREPARATION
12. CONNECTING THE BATTERIES AND BATTERY CONNECTOR
1. Connect the batteries in series to the "+" and "-" poles using the supplied jumper cable (03).
2. Connect the battery connector cable (02) to the “+” and “-“ poles to obtain a voltage of 24V on the
terminals.
3. Connect the electrical system connector to the battery connector
WARNING: All installation and maintenance operations must be carried out by expert
personnel, trained at the specialised assistance centre
4. Position the machine recovery tank on the machine, ensuring the drainage hose is positioned
correctly.
5. Fix the recovery tank drainage tube (01) at the rear of the machine.
6. Insert the vacuum motor tube (05) into the holder at the rear of the recovery tank.
7. Insert the squeegee vacuum hose (06) into the hole at the rear of the recovery tank.
13. CONNECTING THE BATTERY CHARGER (VERSIONS WITHOUT BC)
In order not to cause permanent damage to the batteries, it is essential to avoid their complete discharge:
arrange the recharge within a
few minutes of the switching on of the "discharged batteries" blinking light.
WARNING: Never leave the batteries completely discharged, even if the machine is
not being used. Check the battery charger is suitable for the batteries installed, in
terms of both capacity and type.
To connect the battery charger you must:
1.
Move the machine near to the battery charger
2.
Check that the recovery tank is empty; if not, empty it using the tube provided for this purpose (01)
positioned at the rear of the machine.
3.
Check that the main switch (02) is in the "0" position; if not turn the key a quarter turn to the left (for B-
BT version only), and remove the key from the instrument panel. Check that the machine's main switch
at the back of the machine is in the “0” position; if not, turn to “0” (for BB version only).
4. Make sure the electric system connector (03) is disconnected from the battery connector; if not,
disconnect it.
5.
Rest the brush head on the floor.
6.
Secure the machine by applying the parking brake, move the lever (04) on the right side of the
machine (only for BT versions).
WARNING: Park the machine in an enclosed place, on a flat and level surface; near
the machine there must be no objects that could either damage it, or be damaged
through contact with it.

17
MACHINE PREPARATION
7. Remove the recovery tank drainage tube (01) and lay on the ground.
8.
Remove the vacuum motor tube (05) from the connector present on the recovery tank.
9.
Remove the squeegee vacuum hose (06) from the hole in the recovery tank.
10. Remove the vacuum cover and attach to the support designed for this purpose, positioned at the rear
of the machine.
11.
Remove the recovery tank from the machine, taking care with the drainage hose, and rest on a raised
surface in order to avoid accidental damage.
WARNING: The shape of the recovery tanks means that it can be rested on the
ground with the rear part in contact with the floor, in order to avoid accidental damage
to the drainage joint.
12. Disconnect the electric system connector from the battery connector.
13.
Connect the battery charger cable to the battery connector.
14.
Connect the recently wired cable to the external battery charger
WARNING: Carefully read the use and maintenance instructions of the battery
charger that is used for charging.
WARNING: Keep the recovery tank open for the duration of the battery recharging
cycle to allow gas fumes to escape
WARNING: The room used to recharge the batteries must be adequately ventilated
to prevent the accumulation of gases that leak from batteries.
WARNING: Danger of gas exhalation and leakage of corrosive liquids.
WARNING: Danger of fire: Keep naked flames at a safe distance.
15.
When the recharge cycle is complete, disconnect the battery charger connector from the battery
connector.
16.
Connect the electrical system connector to the battery connector.
17. Position the recovery tank on the machine, ensuring the drainage tube is positioned correctly.
18.
Fix the recovery tank drainage tube (01) at the rear of the machine.
19.
Insert the vacuum motor tube (05) into the holder at the rear of the recovery tank.
20.
Insert the squeegee vacuum hose (06) into the hole at the rear of the recovery tank.

18
MACHINE PREPARATION
14. CONNECTING THE BATTERY CHARGER (VERSIONS WITH BC)
In order not to cause permanent damage to the batteries, it is essential to avoid their complete discharge:
arrange the recharge within a few minutes of the switching on of the "discharged batteries" blinking light.
WARNING: Never leave the batteries completely discharged, even if the machine is
not being used.
To connect the battery charger you must:
1.
Move the machine near to the battery charger
2.
Check that the recovery tank is empty; if not, empty it using the tube provided for this purpose (01)
positioned at the rear of the machine.
3.
Check that the main switch (02) is in the "0" position; if not turn the key a quarter turn to the left (for B-
BT version only), and remove the key from the instrument panel. Check that the machine's main switch
at the back of the machine is in the “0” position; if not, turn to “0” (for BB version only).
4. Make sure the electric system connector (03) is disconnected from the battery connector; if not,
disconnect it.
5.
Rest the brush head on the floor.
6.
Secure the machine by applying the parking brake, move the lever (04) on the right side of the
machine (only for BT versions).
WARNING: Park the machine in an enclosed place, on a flat and level surface; near the
machine there must be no objects that could either damage it, or be damaged through
contact with it.
7. Remove the recovery tank drainage tube (01) and lay on the ground.
8.
Remove the vacuum motor tube (05) from the connector present on the recovery tank.
9.
Remove the squeegee vacuum hose (06) from the hole in the recovery tank.
10. Remove the vacuum cover and attach to the support designed for this purpose, positioned at the rear
of the machine.
11.
Remove the recovery tank from the machine, taking care with the drainage hose, and rest on a raised
surface in order to avoid accidental damage.
WARNING: The shape of the recovery tanks means that it can be rested on the
ground with the rear part in contact with the floor, in order to avoid accidental damage
to the drainage joint.
12. Remove the cap (07) from the battery charger plug.
13.
Connect the battery charger cable to the socket on the charger itself
14.
Plug the battery charger cable into the mains socket.
WARNING: Keep the recovery tank open for the duration of the battery recharging
cycle to allow gas fumes to escape.
WARNING: The room used to recharge the batteries must be adequately ventilated to
prevent the accumulation of gases that leak from batteries.
The battery charger power cable is delivered inside the bag con
taining this instruction booklet.

19
MACHINE PREPARATION
WARNING: Carefully read the use and maintenance manual of the charger that is
delivered inside the bag containing this instruction booklet.
WARNING: Before inserting the charger power cable into the socket, verify that there
is no condensate or other forms of liquids.
WARNING: If the machine's electric system is accidentally powered, the command
display will show “BATTERY-CHARGER” and none of the steering wheel commands
will function (only for B-BT version).
15. When the recharge cycle is complete, disconnect the battery charger power supply cable from wall
plug.
16.
Disconnect the battery charger cable connector from the plug (08) on the battery charger itself, and
insert in the storage drawer (09).
17.
Replace the cap (07) on the battery charger plug.
15. BATTERY CHARGE LEVEL INDICATOR (B-BT VERSIONS)
On the instrument panel of the machine there is a monitor (1) indicating (amongst other things) the battery
charge status. If the lower line contains ten light indicators, the battery charge level is 100%. If
the battery
charge percentage is at 00% and flashing, this means the batteries are discharged.
WARNING: a few seconds after the battery charge level reaches 20%, the brush
motor switches off automatically. With the remaining charge it is possible to complete
the drying process before starting the recharge.
WARNING: a few seconds after the battery charge level reaches 10%, the vacuum
motor switches off automatically. With the remaining charge, it is still possible,
however, to move the machine to the location designated for its recharging (only for
BT versions).
16. HOUR METER (B-BT VERSIONS)
On the machine's instrument panel there is a display (1) indicating the total machine usage time.
The top line shows the hours and minutes of f
unctioning. The flashing “:” symbol Indicates that the hour
meter is counting the machine functioning time.
17. BATTERY CHARGE LEVEL INDICATOR (BB VERSIONS)
On the upper part of the display, you will see the total operating time. The line
visualised shows the operating
hours; the number consists of five figures, plus one figure after the point “.” to show the tenth of an hour.
The battery indicator uses LEDs and has 8 positions (7 yellow
- charged batteries, and 1 red - run down
batteries).
WARNING: A few seconds after the red indicator light comes on, the brush motor
switches off automatically. With the remaining charge it is possible to complete the
drying process before starting the recharge.

20
MACHINE PREPARATION
18. FORWARD WORK SPEED (BT VERSIONS)
This machine is equipped with electronic traction control. To move the machine, after turning the key to
position "I" simply push the dead man's lever, located under the grip of the handlebar.
WARNING! The machine will not start to move (either forward or backward) if the
potentiometer adjustment knob (01) is set to minimum.
19. FORWARD WORK SPEED (B-BB VERSIONS)
The traction of these machines is obtained by means of the brush which, working with the righ
t weight
distribution, is able to drag the machine forwards.
WARNING! If the machine shows signs of directional imbalance, refer to the section
"ADJUSTING THE DIRECTION.".
20. FILLING THE SOLUTION TANK
Before filling the solution tank, car
ry out the following steps:
1. The recovery tank must be completely empty each time the solution tank is filled.
2. Check that the brush head and squeegee are resting on the ground; if not, carry out this step.
3. Check that the main switch is in the "0" position; if not turn the key a quarter turn to the left (for B-BT
version only), and remove the key from the instrument panel. Check that the machine's main switch at
the back of the machine is in the “0” position; if not, turn to “0” (for BB version only).
4. Engage the parking brake by means of thelever on the right side of the machine (only for BTversions).
5. Check that the solution filter cap (02), located on the left side of the machine, is properly closed.
The solution tank can be filled in two different ways:
1. removing the inlet cap (01) and filling with the aid of a rubber tube
2. using the rubber cap (02); this supports the water hose on its own, but be sure to remove the filler cap
(01) to allow the proper vent of air.
Remove the filler cap (01) and fill with clean water at a temperature not superior to 50°C. The amount
inside the tank can be seen by means of the level pipe (03) on the left
-hand side at the rear of the machine.
Add the liquid detergent to the tank in the concentration and ma
nner indicated on the detergent
manufacturer's label. The formation of excess foam could damage the vacuum motor, so use only the
minimum amount of detergent that is necessary.
WARNING! The filler cap (01) can be used as dispenser for the detergent to added to
the solution tank; the cap features moulded notches identifying the percentage of
detergent, ranging from a minimum of 0.1% to a maximum of 0.5%.
