First Choice Mobility Komfy 4 EQ30FA User manual

!!!!Komfy!4
USER MANUAL
Model No: EQ30FA (UK)
Contents
1.INSTRUCTIONS FOR USE. ............................................. 3
2.INTRODUCTION...............................................................4
3.GENERAL SAFETY INFORMATION............................ 5
4.GETTING TO KNOW YOUR SCOOTER. ..............................19
5.PRODUCT SPECIFICATIONS. ................................................22
6.PUSHING AND TRANSPORTING THE SCOOTER. ........... 23
7.ADJUSTING THE SCOOTER.................................................. 25
7.1 ADJUSTING SEAT POSITION...................................................25
7.2 SWIVELING THE SEAT TO GET ONAND OFF ....................26
7.3 ADJUSTING THE BACKREST ANGLE. .................................26
7.4 ADJUSTING THE HEADREST HEIGHT ................................ 27
7.5 ADJUSTING THE TILLER ANGLE..........................................28
7.6 ADJUSTING THE SEAT BELT LENGTH AND FITTING
............................................................................................................28
7.7 TURNING THE SEAT.................................................................28
8.OPERATING THE SCOOTER..................................................29
8.1 POWERING ON/OFF.................................................................30
8.2 LED DISPLAY PANEL................................................................... 31
8.3 ADJUSTING THE SPEED. .................................................. 31-32
8.4 DRIVING FORWARDS AND BACKWARDS............................33
8.5 USING THE BRAKES. ..............................................................34
8.6 OVERLOAD PROTECTION. ....................................................34
8.7 SWITCHING ON THE HEADLIGHTS.....................................35
8.8 SWITCHING ON THE HORN...................................................35
8.9 SWITCHING ON THE HAZARD Lights. ................................ 35
8.10 SWITCHING ON THE TURN SIGNAL..................................36
8.11 POWERING OFF/PARKING THE SCOOTER...................... 36
8.12 12V POWER SOCKET ............................................................37
1

9.BATTERY AND CHARGING ........................................................ 38
9.1 BATTERY STATUS DISPLAY ....................................................... 39
9.2 CHARGING THE BATTERIES. ..............................................40-42
9.3 AFTER CHARGING................................................................... 43
9.4 ERROR CODE............................................................................ 43
BEFORE DRIVING
1.INSTRUCTIONS FOR USE
The KOMFY scooter is a motorised electric scooter for use primarily
outdoors on flat surfaces such as pavements, roads, parking lots and
driveways. It is intended to increase the mobility of persons who are
both physically and mentally capable of correctly assessing driving
situations and reacting correspondingly to them at any time.
Uses:
DO NOT operate this equipment without first reading and
understanding the user manual. If you are unable to understand the
warnings, cautions, and instructions, contact your service provider;
otherwise injury or damage may result. Procedures other than those
described in this manual MUST be performed by a qualified
technician!
We reserve the right to make changes and update this manual without
further notice.
Copyright © 2019 KYMCO UK Ltd.
This mobility scooter meets all of the requirements
of ISO 7176-9: 2009

WARNING! Please consult your healthcare professionals
routinely to ensure there are no health or physical
conditions that may limit or impair your ability to safely
operate your scooter.
2. INTRODUCTION
With your KOMFY you have now purchased a product that has
been manufactured in accordance with the newest technical
capabilities and based on the highest operating user comfort.
We have placed great value on the simplest possible operation and
long service life, in both construction and material selection.
A large variety of useful accessories rounds off our range in addition
to the scooter.
This Operating Manual assumes that the suitability of the user for
scooter usage has been discussed with a doctor, therapist and /or
an approved dealer before operation.
The operating manual will help you get to know the function of your
scooter and, in addition, describes
·Operation
·Care and maintenance
·Repair
The manual has been drawn up using information available at the
time of printing with regard to construction and operation of the
scooter.
We reserve the right to make changes due to technical improvements.
If you have any other questions about this scooter please contact
your retailer or supplier.
3. GENERAL SAFETY INFORMATION
WARNING! Before you operate your scooter, please read
and understand all information provided with your scooter
for your safety. As when operating any vehicle, only drive
with full alertness to ensure safety.
WARNING! Please observe the warnings below to avoid
any damage or injury resulting from improper use of your
scooter. The scooter user is responsible for taking proper
safety measures. We will not be held liable for personal
injury and/or product damage resulting from improper use
of the scooter. Obey all local pedestrian traffic rules. It
may be difficult for others to see you when you are seated
on your scooter. Wait until your path is clear of traffic, and
then proceed with extreme caution. Use of safety
equipment such as reflectors/reflective clothing & lights,
are very useful for ensuring your safety while driving.
WARNING! Do not operate your scooter while you are
under the influence of alcohol, as this
can impair your ability to safely operate your scooter.
WARNING! Every scooter is different. Take the time to
learn the feel of this scooter before you begin driving.
WARNING! BE AWARE that becoming a capable and
safe scooter operator will take time and practice.
WARNING! Consult your physician if you are taking
prescription or over-the-counter medication or if you
have any physical limitations. Some medications
and physical limitations may impair your ability to
safely operate your scooter.

WARNING! Inspect the seatbelt for loose parts or
damage before each use of the scooter. If damaged,
contact your approved service provider for maintenance
and repair immediately. Do not operate your scooter
with a faulty seatbelt.
WARNING! Do not remove the seat cushion provided
with the scooter. Do not place any cushion, padding, or
pillow on the seat. This could create an unstable seat
position, resulting in a fall from the scooter.
WARNING! Your scooter is designed for one passenger
only. Do not carry passengers on your scooter!
WARNING! Do not change your seating configuration.
Please contact your approved service provider for any
adjustments.
WARNING! We strongly recommend that you do not
smoke cigarettes while seated on your scooter. You must
adhere to the following safety guidelines if you decide to
smoke cigarettes while seated in your scooter: Do not
leave lit cigarettes unattended. Keep ashtrays a safe
distance from the seat cushions. Always make sure
cigarettes are completely extinguished before disposal.
WARNING! Do not modify your scooter in any way by
yourself. For any accessories, please contact your
approved service provider for installation by an
authorized service technician.
WARNING! The addition of accessories to your scooter
may change certain specifications such as overall weight,
size, and/or center of gravity of your scooter. Please
note how some of the changes may damage any objects
around you.
WARNING! Do not use any replacements on your
scooter, such as a different seating system. Only use the
seating system that has been tested for safety and
provided by the manufacturer.
WARNING! Anti-tippers substantially reduce your risk of
tipping over backwards, which can cause you
serious injury.
WARNING! Have someone to help you practice bending
and reaching on the scooter and transferring to and from
the scooter, until you learn how to do it safely.
WARNING! NEVER try a new manoeuvre on your own.
WARNING! Get to know the areas where you plan to
use your scooter. Look for hazards and learn how to
avoid them.
WARNING! Do not use the scooter other than for its
original purpose. Avoid any use, such as weight
training, sports and athletics, hauling, moving or towing
anything, that may lead to safety hazards and undue
stress on the scooter.
WARNING! Always use the seatbelt to safely operate
your scooter and make sure it is fastened securely. This
will reduce the possibility of a fall from the scooter and
will ensure that the seatbelt cannot get caught in the
tires while driving.

WARNING! Do not use your scooter in “freewheel”
mode without an attendant present.
WARNING! Keep yourself, your clothing, and all other
objects away from the tires while driving. Do not allow
any objects to drag behind the scooter when driving.
Loose-fitting clothing or other objects can get caught in
the tires and/or the running gear.
WARNING! Possible strangulation hazard! Be aware
that clothing, lanyards, necklaces, other jewelry, purses,
and other accessories worn or carried by you while you
are seated on or operating the scooter may get caught
around the armrests or throttle control lever.
WARNING! Do not connect any device to the scooter
electrical system or use the scooter batteries to power
anything else other than your scooter.
WARNING! Always grasp the connector itself when
disconnecting the harness to prevent wire damage.
Do not pull on electrical wires or harnesses directly.
WARNING! Please contact your service provider if there
is any abnormal tyre wear and/or abnormal issues.
WARNING! Keep all charger power cord connectors
clean, dry and away from sources of dampness at all
times to prevent damage to the electrical system and/or
personal injury. Check any actuators for loose, worn,
or damaged items and have any damaged wires
replaced immediately.
WARNING! Do not place the scooter in “freewheel”
mode while the unit is powered up. Always power off
the scooter and remove the key from the key switch
before engaging or disengaging “freewheel” mode. The
scooter should be turned off prior to entering or exiting
the scooter.
WARNING! The scooter may come to a sudden stop
at any time during operation. Do not to operate the
scooter if it is behaving abnormally or erratically.
Storage temperature is -15°~40°
WARNING! To prevent the scooter from rolling
uncontrollably on its own, never place the scooter in
“freewheel” mode on any incline or decline.
WARNING! Avoid using any accessories that may
interfere with the operation of the throttle control lever,
which may result in unintended or uncontrolled
movement of the scooter.
WARNING! If you anticipate being seated in a stationary
position for an extended period of time, turn off the
power to the scooter. This will prevent unexpected or
unintended scooter movement.

11
10
WARNING! Check electrical components frequently for
signs of corrosion and have them replaced as
necessary.
WARNING! Always secure the scooter and its batteries
when it is being transported. Batteries should be
secured in an upright position and protective caps
should be secured on the battery terminals. Do not
transport the scooter and/or batteries with any
flammable or combustible items.
WARNING! Do not handle batteries without
supervision by an authorized service technician.
Battery posts, terminals, and related accessories
contain lead and lead compounds and can be
hazardous. Scooter batteries are heavy. Anyone
lifting scooter batteries should use proper lifting
techniques and avoid lifting beyond his/her capacity.
WARNING! NEVER attempt to recharge the batteries
by attaching cables directly to the battery terminals or
clamps.
WARNING! DO NOT attempt to recharge the batteries
and operate the equipment at the same time.
WARNING! Always use two batteries of the exact
same type, chemistry, and amp-hour (Ah) capacity.
Follow the specifications provided in the user manual
for battery type and capacities.
WARNING! Do not mix old and new batteries. Always
replace both batteries at the same time.
WARNING! Only sealed batteries that meet DOT CFR
173.159 should be used in the scooter. Replacement
batteries should be obtained directly from an authorized
provider to ensure conformity, fit, and function.
WARNING! Always protect the batteries from freezing;
for those living in cold climates, make sure you store
the scooter properly. Never charge a frozen battery.
Charging a frozen battery may result in damage to the
battery.
WARNING! Do not remove overload trips or fuse links
from the battery harnesses. If the fuse links appear
damaged, contact your authorized provider for service.
WARNING! Do not operate the scooter with depleted
batteries; you could be stranded.
WARNING! Reduce your speed, do not make any
sharp turns and maintain a stable center of gravity
while turning/cornering. To prevent tipping, avoid
shifting your weight in the opposite direction of the turn.
WARNING! While driving up inclines or curbs, drive
your scooter straight on with the wheels perpendicular
to the incline and/or curb; both front wheels should
contact the incline/curb at the same time. To reduce
the possibility falling, do not drive at an angle; do not
get one wheel or side of the scooter on the incline/curb
first. Always exercise extreme caution when negotiating
an incline.

13
12
WARNING! Do not travel up or down potentially
hazardous surfaces and/or inclines, including but not
limited to areas covered with snow, ice, cut grass, or
wet leaves.
WARNING! When climbing an incline, try to keep the
scooter moving. If stopping is necessary, start up again
slowly and then accelerate with caution.
WARNING! To prevent tipping, do not attempt to
negotiate inclines / declines and / or obstacles with
your seat in a reclined position.
WARNING! To avoid overloading the scooters and
potential tipping, never carry anything or fill the basket
with contents weighing more than 15 lbs. (6.8 kg).
WARNING! Never try to pick up an object from the
floor by reaching down between your knees.
WARNING! Never reach or lean over the top of the
seat back. This may damage the backrest and
cause you to fall.
WARNING! Do not use the armrests for any weight
bearing purposes. Such use may cause the scooter
to tip, which may result in a fall from the scooter and
personal injury.
WARNING! Do not put all of your weight on one side
of the scooter deck. Such use may cause the
scooter to tip.
WARNING! Avoid any change of position or movement
that may change your center of gravity while sitting on
the scooter. This may cause your scooter to tip.
WARNING! A drop-off (as small as 2”/ 5cm) at the
bottom of a slope can stop a front wheel and cause the
scooter to tip forward.
WARNING! Never reach or lean if you must shift your
weight sideways or rise up off the seat.
WARNING! Never reach or lean if you must move
forward in your seat to do so. Always keep your
buttocks in contact with the backrest.
WARNING! When descending an incline, use the
slowest speed possible. If the descent is faster than
you desire, release the throttle control lever to stop the
scooter. Then press the throttle control lever slightly to
control the speed of your descent.
WARNING! The maximum recommended incline angles
(see specifications) are tested in a controlled
environment. Your scooter’s ability to climb up inclines
is affected by your weight, speed and the angle you
approach the incline, among other factors.
WARNING! Only drive backwards on a flat surface.
When driving backwards, operate your scooter at a
lower and even speed. Stop often and check to make
sure your path is clear of obstacles. To prevent tipping,
do not travel down an incline or ramp backwards.

15
14
WARNING! Even though your scooter may be
capable of handling greater obstacles, we
recommend that you do not attempt to negotiate a
curb that has a height greater than 2”/ 5 cm.
Doing so could cause instability in your scooter.
Riding over curbs or obstacles can cause tipping
and serious bodily harm. If you have any doubt that
you can safely cross any curb or obstacle, ALWAYS
ASK FOR HELP. Be aware of your riding skills and
personal limitations. You may need to remove or
cover threshold strips between rooms and install a
ramp at the entry or exit of doors.
WARNING! If you feel unsure about a driving surface,
avoid that surface.
WARNING! Do not expose your scooter to open
flames.
WARNING! Keep your scooter in a dry and clean
condition. Never take your scooter into a shower, tub,
pool, or sauna. Rain, snow, salt, mist/spray
conditions, and icy/slippery surfaces can damage the
scooter components or cause the scooter’s frame to
prematurely rust.
WARNING! Avoid prolonged exposure to heat or cold;
it may affect the temperature of upholstered and
non-upholstered components on the scooter.
Exercise caution when using your scooter in extremely
hot or cold conditions.
WARNING! Do not tow your scooter. Towing may
exceed the maximum speed threshold, resulting in
damage to critical components of the scooter.
WARNING! Use extreme caution when it is necessary
to move an unoccupied scooter up or down stairs.
Remove the seat, batteries, and any accessories
before attempting the transfer. Use proper lifting
equipment / techniques and use only solid, non-
removable frame components to lift the scooter with
multiple physically capable attendants. Do not lift or
move your scooter or seating system by grasping or
holding onto any of its removable parts, including the
armrest(s), seat cushions, seatback, or shrouds.
WARNING! Do not try to climb an obstacle when on
an incline.
WARNING! Do not drive over an obstacle with just
one wheel.
WARNING! Do not drive on uneven terrain and/or
soft surfaces.
WARNING! Do not drive near tall grass that can
entangle the running gear.
WARNING! Avoid driving on loosely packed gravel
and/or sandy surfaces.
WARNING! Do not use your scooter on or near
railroad tracks or crossings.
WARNING! Do not ride your scooter along the
edges of streams, lakes, or the ocean. Never
use your scooter to cross waterways.

17
16
WARNING! When your scooter is used with any type of
lift/elevation devices, always turn off the power of the
scooter; make sure the scooter is not in “freewheel”
mode and do NOT sit on your scooter. Failure to follow
this may result in unintended movement and personal
injury or product damage.
WARNING! Never use your scooter to negotiate stairs
or escalators.
WARNING! Never sit on the scooter while it is in a
moving vehicle.
WARNING! It is dangerous to transfer to and from your
scooter on your own. It requires good
balance and agility. Be aware that there is a point
during every transfer when the seat is not below you.
WARNING! To make a safe transfer: Always turn off
the power before you transfer to or from your scooter.
If you fail to do so you may touch the throttle control
lever and cause your scooter to move when you do not
expect it. Make sure the “freewheel”motor locks are
engaged; this keeps the scooter from moving when you
transfer. Work with your health care professional to
learn how to position your body and how to support
yourself during a transfer. Have someone help you
until you are sure you do a safe transfer on your own.
Move your scooter as close as you can to the seat you
are transferring to. Transfer as far back onto the seat
surface as you can. This will reduce the risk that you
will miss the seat or fall.
WARNING! Never transport the scooter in the front seat
of a vehicle. It may shift and interfere with the driver.
WARNING! Always secure the scooter so that it cannot
roll or shift.
WARNING! Refer to the tyre pressure recommended
in your user manual to ensure best
control. Only inflate the tyres using a regulated,
low - pressure air source with an available pressure
gauge. Do not underinflate or overinflate your tires.
Low pressures may result in loss of control, and high
pressures may result in the rupturing of tires. Check
your tyre pressure at least once a week!
WARNING! Should the fittings on your seating system
become loose, please call your approved service
provider.
WARNING! Replace worn or damaged upholstery
immediately to reduce the risk of fire hazard.
WARNING! Be aware that washing of upholstered
items may reduce the fabric’s resistance to
flammability.

19
18
4. GETTING TO KNOW YOUR SCOOTER
Seat assembly, with
Manual brake
Front turn signal
Control panel
Key
backrest, headrest
and handle
USB port
Charging port
LED light
Knob
Tail light /
Rear turn signal
seat adjustment lever
Important Information
1) 20 volts per meter (V/m) is a generally achievable
and useful immunity level against interference from
radio wave sources (as of May 1994) (the higher
the level, the greater the protection);
2) This product has an immunity level of 20 volts
per meter (V/m)
Front wheel Foot area
Rear wheel Anti-tipper
WARNING! Radio wave sources, such as radio stations,
TV stations, amateur radio (HAM) transmitters, two-way
radios, and cellular phones, can affect motorised
scooter control. Following the warnings listed below
should reduce the chance of unintended brake release
or motorised scooter movement, which could result in
serious injury.
1).Do not turn ON hand-held personal communication
devices, such as citizens band (CB) radios and
cellular phones, while the motorised scooter is
turned ON;
2).Be aware of nearby transmitters, such as radio or
TV stations, and try to avoid coming close to them;
3).If unintended movement or brake release occurs,
turn the scooter OFF as soon as it is safe;
4).Be aware that adding accessories or components,
or modifying the scooter, may make it more
susceptible to interference from radio wave sources
(Note: There is no easy way to evaluate their effect
on the overall immunity of the scooter
5.Report all incidents of unintended movement or
brake release to your approved service provider, and
note whether there is a radio wave source nearby.

21
12 digits LED energy meter
Turn signal
Hazard indicator
switch button
Front LED light
Horn button
Turn indicator Speed control dial
Throttle lever
38.5in
15.35in
45.7in
39.3in
18.1in
3.81in
50in
61.4in
61.4in
23.6in

5. PRODUCT SPECIFICATIONS
6. PUSHING AND TRANSPORTING
THE SCOOTER
·Please carefully read the safety information in section 3 related to
transportation first.
·Pushing the scooter:
In order to push the scooter, you must place the scooter in
“freewheel” mode, which disengages the drive motor. The lever (1)
is located at the bottom right-hand side of the scooter under the seat.
To push the scooter:
= Freewheel
Mode (A):
(Motor is disengaged.)
1.Power off the scooter
and remove the key.
2.Pull the lever (1)
upwards as far as the
stop (see diagram A).
3.Push the scooter to
your desired location.
4.Push the lever (1)
downwards as far as
the stop (see diagram).
WARNING!
When the lever is pulled up in freewheel mode:
·The scooter must be on a flat surface.
·Do not sit on the scooter.
A
B
Model Name
KOMFY 4 Model
Maximum weight capacity
25stone (160kg)
Overall height
38.5 in (980 mm)
Overall length
49.6 in (1280 mm)
Overall width
23.6 in (600 mm)
Drive System
Direct drive rear wheels
(with differential gear)
Battery
12 V ×45 Ah ×2 Pcs
Battery charger
Off-board
Input voltage: 100-240VAC
Output voltage: 24VDC
Output current: 5A
Front wheel
Pneumatic, 10” (254mm)
Rear wheel
Pneumatic, 10” (254mm)
Rear wheel drive system
Transaxle
Braking system
Motor electromagnetic brake+
manual auxiliary brake
Maximum incline angle
10 degree
Per-charge Run distance
Energy Consumption(Max Range)
16.1 miles (26km)
ISO 7176-4 (160kg)
Maximum Potential Range (127kg)
25 miles (40km)
Maximum speed
Forward
4 mph (6.4 kmh)
Backward
1.86 mph (3 kmh)
Turning radius
61.4 in (1560 mm)
Overall height of seat
23.7 in (602 mm) (from ground)
Overall width of seat
18.1 in (460 mm)
Overall depth of seat
17.5 in (445 mm)
Overall weight of seat
42 lbs. (19.5 kg)

= Driving Mode (B):(Motor is engaged.)
1.Always switch the scooter off to push it.
2.Do not push the scooter too fast. If a pre-set
speed is exceeded while you are pushing the scooter, the drive motor
will switch on automatically and brake the scooter.
After any adjustments, repair or service and before use, make sure all
hardware is tightened securely - otherwise injury or damage may
result.
7. ADJUSTING THE SCOOTER
The following describes how to set up and adjust your Scooter in
order to have a comfortable and safe drive.
7.1 ADJUSTING SEAT POSITION
1. Pull the seat
locking lever
(1) upwards
and move the
seat forwards
or backwards
to the desired
position or
distance.
2. Let go of the
locking lever
and engage
the locking
mechanism
by pushing the
seat slightly forwards and/or
backwards.
Accident hazard due to an improperly locked seat:
Ensure that the seat is properly locked after adjustment; if the seat is
properly locked, it will not move when you try pushing the seat
slightly forwards and backwards.

1. SWIVELING THE SEAT TO GET ON AND OFF
Lift the seat lever, rotate the seat to the side (left or right) to get on.
2.Sit on the seat and turn the seat back to the direction of travel. Lock
the seat in place by releasing the seat lever. Fasten your seat belt.
7.2ADJUSTING THE BACKREST ANGLE
The backrest angle can be adjusted to several locking stages.
1.Pull the locking lever up and move the backrest forwards or
Accident hazard if backrest is not properly locked!
Ensure that the backrest is properly locked after adjustment by seeing
that it doesn’t move when you try pushing it slightly forwards and
backwards.
7.3ADJUSTING THE HEADREST HEIGHT
Raising the headrest:
Pull the headrest upwards into the desired position until the lowering
protection locking mechanism engages.
Lowering the headrest:
Press the locking lever in and push the
headrest down to the desired position.
Release the locking lever, and
engage the lowering protection by
moving the headrest slightly.
7.4ADJUSTING THE TILLER ANGLE
Always adjust the locking knob on the
tiller so that you can reach the
dashboard and control your scooter
easily at anytime.
1.Loosen the locking knob.
2.Push the tiller forwards or backwards
to the desired position.
3. Tighten the locking lever knob.
4.Ensure that the tiller is engaged
backwards to the desired position.
2.Let go of the locking lever and engage the locking mechanism by correctly by trying to move it
forwards and backwards.
Push the locking lever –to lock
Pull the locking lever –to unlock
pushing the backrest slightly forwards and backwards. Accident hazard due to non-engaged tiller:
Ensure that the tiller is properly
locked after adjustment by seeing that it doesn’t move when you
try pushing it slightly forwards and backwards..
Ensure that the seat is properly engaged after adjustment by
seeing that the seat doesn’t move when you try rotating it to
either side
!
!

Accident hazard due to non-engaged tiller:
Ensure that the locking lever knob is properly locked after
adjustment by seeing that it doesn’t move when you try pushing
it slightly forwards and backwards.
7.5 TURNING THE SEAT
The seat can be turned to both sides, and firmly
engaged in 8 positions (at 45° intervals).
Pull the turning lock (1), turn the
seat in the required
direction or position (2) and engage.
When mounting the seat, place in the middle of the seat tube
assembly, the locking lever should be pulled up and do not release
it until the seat is firmly engaged. To turn the seat, pull up the
locking lever and the seat can be turned 180°.
OPERATING
8.OPERATING THE SCOOTER
Always carry out the safety information described in the “General
Safety Information” section:
Before starting to drive, adjust the seat and tiller to a comfortable
position.
Please observe the following tips for a safe journey:
1).Always match your speed to the driving situation in which you
find yourself.
2).Always reduce your speed when you are driving through:
-Unclear areas - narrow gaps
-Tight curves - inclines
-Ramps
3).Take a trial run with the scooter in an area with no pedestrians, or
in a closed-off area.
WARNING! Every scooter is different. Take the time
to learn the feel of your scooter before you begin
riding.
WARNING! BE AWARE that becoming a capable and
safe scooter operator will take time and practice.
WARNING! Anti-tippers substantially reduce your risk
of tipping over backwards, which can cause serious
injury.
Accident hazard due to incorrect seat position:
Always turn the seat to face forward and lock it before
driving. If the seat has been turned, the possibility of
tipping is increased. Before turning the seat, always
ensure that the scooter is on an even and solid surface.

31
4).Always steer the scooter with both hands on the handlebars.
5).Always keep your feet within the foot area while driving the
scooter.
6).Check before you switch on the scooter:
8.2 LED DISPLAY PANEL
LED panel “On”:
The scooter is switched on and ready for driving.
If the status indicator is blinking:
There may be a faulty situation.
Please switch off the
scooter and contact
your approved service
provider. Status
indicator
8.1POWERING ON/OFF
The switch is located near the right side of the dashboard. Insert
the key into the switch and turn it to the right to power on the
scooter. Turn it to the left to power off the scooter.
8.3 ADJUSTING THE SPEED
Use the speed adjustment dial
to adjust the speed to suit your
driving conditions. Always use
lower speeds if you are
uncertain about the driving
conditions.
Ensure your scooter is in
drive mode (not in “freewheel”
mode)
Check the “freewheel” mode
lever is in the pushed down
position
Seat is locked into the desirable
position
Move the seat forwards and
backwards to ensure it is
stationary.
Are the batteries charged?
Check the battery indicator to
verify the charging status of the
batteries
Are the brakes working?
Check by driving slowly and
stopping again
Are the tires and wheels
undamaged and is the air
pressure correct?
Visual check of tires and wheels

Speed Control Dial:
a. Located in the centre of the
dashboard. Turning to rabbit means
fast, to turtle means slow.
8.4 DRIVING FORWARDS AND
BACKWARDS
Hold the tiller handles
firmly with both hands.
Use your right index and
middle fingers to pull the
right side of the lever to
move forward.
= driving forwards
Release the lever and allow the
scooter to come to a complete stop.
forwards
Use your left index and middle fingers to pull the left side of the
lever to move backwards.
Anticipated Speed levels:
b.The speed levels are tested under controlled environments and your
driving speed may vary depending on the driving conditions and
loads.
= driving backwards
Do not pull both sides of the throttle control lever simultaneously.
backwards

8.5 USING THE BRAKES
1.Using the motor electromagnetic brake:
When the throttle control lever is released and returns to
the center position, the brake is engaged to stop the scooter.
Emergency braking = let
go of the drive lever:
The throttle control lever
automatically
returns to the central
position if you let go, the
scooter
automatically brakes.
2.Using the handbrake:
To use the handbrake,
pull the brake lever
slowly towards the
handlebar.
Tipping hazard
Pulling the brake lever too harshly can cause the scooter to tip over.
Pull the brake lever slowly to brake.
8.6 OVERLOAD PROTECTION
The overload protection switches the power off when the motor
becomes overloaded while trying to climb over too high an obstacle,
such as a curb or trying to climb too steep of an incline.
If the motor is overloaded, the following happens:
•The scooter becomes noticeably slower and then stops
•The control system shuts down the scooter. To rectify this:
Switch the scooter off and allow it to cool down for a few minutes.
Reset the trip (see below), switch the scooter on and reverse away
from the obstacle (such as a curb) and then avoid the obstacle.
During the driving, the overload protector
will automatically power off to protect when
the climbing or loading exceeds the
specification of the overload protector, and the
button of it will protrude, which needs to be
manually reset before it can be used normally.
8.7 SWITCHING ON THE HEADLIGHTS
Headlight button:
Switch on = press button once
Switch off = press button again
A switch indicator will light up to
show that the headlight is switched on.
If you drive with the headlights on, the
batteries will drain faster and the scooter
driving range will be slightly reduced.
8.8 SWITCHING ON THE HORN
Press the horn button.
It will sound for as long as you
hold the button down.
8.9 SWITCHING ON THE HAZARD
Lights Button switch:
Switch on = press button once
Switch off = press button again
The switch indicator will light
up to show that the hazard
lamps are switched on.
Leaving the scooter with the
hazard lamps on will drain the
battery.

8.10 SWITCHING ON THE TURN SIGNAL
Turn signal indicating a right hand turn = Press the right arrow switch.
Turn signal indicating a left hand turn = Press the left arrow switch.
When turning is completed, push the switch again to turn the
indicators off.
8.12 12V USB POWER SOCKET
The power socket provides 24V / 5A / 120W
Voltage - 24V
Ampere - 5A
Watt - 120W
Don’t exceed the applicable power rating when using.
8.11POWERING OFF/PARKING THE SCOOTER
Turn the key to the left to switch the scooter off.
Always turn the scooter off using the key if you:
-want to get on or off.
-intend to stop for long periods. Always remove the key if you:
-want to park the scooter and get off.
USB powersocket

9. BATTERY AND CHARGING 9.1 BATTERY STATUS DISPLAY
The battery status display
on the dashboard shows the
current level of
battery power.
If the scooter is at a
decrease driving range, charge batteries as soon as possible.
New batteries MUST be fully charged (approximately 24 hours) prior
to initial use of the equipment.
Always charge new batteries before initial use or battery life will be
reduced.
As a general rule, you should recharge your batteries as frequently as
possible to assure the longest possible life and to minimize required
charging time. Plan to recharge them when you do not anticipate
using the equipment.
The range per battery charge, using recommended batteries, should
be approximately 8 to 12 hours of typical operation. Extensive use on
inclines may substantially reduce per charge mileage.
standstill, it is often the case
that the battery status may
show fuller than it actually
is. The battery status display
may vary greatly while the
vehicle is travelling depending
on the load.
If the vehicle is under a heavier load, such as fast acceleration or
driving up inclines, the battery status display may move towards the
empty zone.
This may not indicate the actual status of the batteries.
After a journey, the battery status display may move towards the full
zone after the scooter has been turned off for a long period of time.
If the orange or red LED light of battery indicator is on at the end of
a journey, the battery must be charged immediately. Otherwise, it
can lead to battery damage.
When the battery indicator shows last 2 led, you can drive about
4.8 kilometers (approx. 3 miles on plane level road) ：
(When less than 5 LEDs battery status display is left, then the status
display flickers, indicating to charge).
max range
Corrosive chemicals contained in battery.
Explosive conditions exist!
Do not use batteries with different amp- hour (Ah)
capacities.
Keep tools and other metal objects away from the
battery terminals. Contact with tools can cause
electrical short circuit.
Flammable material contained in battery. Do not
expose to heat sources such as open flame or sparks.
Do not transport batteries with flammable or
combustible items.
Disposal and recycling - Contact your approved
service provider.
