for
Green White/BluePark / Auto
I/O Changes
ClutchPCU
Lights
CANInstallYearModelMake
FEATURE COVERAGE
PARKING LIGHTS
AUTOLIGHT CTRL
TACH OUTPUT E-BRAKE STATUS
BRAKE STATUS
HOOD STATUS TRUNK STATUS
DOOR STATUS
TRUNK/HATCH RELEASE
DISARM OEM ALARM ARM OEM ALARM
DOOR UNLOCK
DOOR LOCK
A/M CONTROL
IMMOBILIZER DATA
REQUIRED CONNECTION
E
REQUIRED CONNECTION
D
Manual Transmission Clutch Bypass: Vehicles equipped with a manual transmission require additional wiring in order to provide
the required clutch signal. The red/black negative starter output of the CM7/X series controller must be connected to the vehicle
clutch status wire (brown, in the 2-pin connector at the clutch switch (top of clutch pedal assembly).
CONNECTOR COLORS VARY
C
REQUIRED CONFIGURATION
B
REQUIRED CONNECTIONS (CONNECTOR MODIFICATION REQUIRED)
A
Firmware:
This installation requires BLADE-AL(DL)-HA6 firmware, flash module and update the controller firmware before installing.
Lights:
Type B parking light control interfaces with separate auto-light and park-light circuits at the headlight switch connector,
the included adapter provides these connections without having to cut any vehicle wiring, please ensure proper configuration.
The headlight switch cable included in the latest versions of the kit provides connections for parking light and auto-light control.
Use only the BLACK Type B connector. Caution: Using the WHITE Type A connector will damage the light switch.
When using the included adapter, the parking lights ( - ) and GWR connections in the CM I/O connector must be removed
and replaced with wires from the included headlight switch adapter, as illustrated.
PCU Connections:
The 28-pin connector at the Smart PCU can be either LIGHT BROWN or GRAY, and Smart PCU locations vary by model,
please consult the component locator on the following page for the proper location.
FTI-HDP6: Installation and Configuration Notes
FTI-HDP6: Vehicle Coverage and Preparation Notes
Accord PTS MT 2013-17 Type 1 PCU Type B LSC Brown N/A
DL-HA6
Honda

12
2
3
Clutch Switch
brown
E
D
NEG START
CLUTCH
3
FTI-HDP6 - DL-HA6 - Type 1
1
2
PWR
BLADE
Lt. Brown or Gray
Gray
Smart PCU
66 11
772121
2121 11
4242 3131
1141
82 51
1141
82 51
Headlight Switch
C
A
B A
B
2
1
LED Programming Error Codes
Module LED flashing RED during programming
1x - CAN error, check connectors
2x - Klon error, check connections, retry programming
if error persists, perform a clearing flash then retry
programming with all doors closed
3x - Immobilizer error, check connectors, confirm car starts
4x - VIN error, check connectors, re flash using vehicle entry
Takeover not supported: Vehicle engine will shut down when
doors are opened.
2013-17 Honda Accord PTS MT

Patent No. US 8,856,780 CA 2759622
INSTALL GUIDE
WWW.IDATALINK.COM Automotive Data Solutions Inc. © 2020
CARTRIDGE INSTALLATION
1Slide cartridge into unit. Notice
button under LED. 2Ready for Module Programming Procedure.
MODULE PROGRAMMING PROCEDURE
12 Module Programming
Procedure completed.
11 Press UNLOCK on the OEM
remote.
x1
2Turn ignition to ON position.
ENGINE
START
STOP
OFF ACC ON START
ON 8Turn ignition to ON position.
ENGINE
START
STOP
OFF ACC ON START
ON
4Turn ignition to OFF position.
OFF ACC ON STARTOFF
ENGINE
START
STOP
10 Turn ignition to OFF position.
OFF ACC ON STARTOFF
ENGINE
START
STOP
5WARNING:
Disconnect power last.
Disconnect RS from vehicle.

7WARNING: Do not press RS
programming button.
Connect power first.
Connect RS to vehicle.

6Connect RS to computer
and proceed with extended
programming.

3Wait, LED will flash BLUE
rapidly.
9Wait, LED will turn solid BLUE
for 2 seconds.
!If the vehicle is equipped with a power liftgate: Open and
close the power liftgate with the OEM keyfob.
1Close driver door.
Re-open driver door to wake up
data bus.
Page 40 of 41 COM-BLADE-AL(DL)-HA6-EN 20210503
Doc. No.: ##75672##
