CGI905DNGTB4, CGI905DLPTB4, CGI60DNGTB4, CGI60DLPTB4
COMBI: GAS + INDUCTION COOKTOP
INSTALLATION GUIDE
NZ AU

SAFETY AND WARNINGS
! WARNING!
If the information in this manual is not
followed exactly, a fire or explosion
may result causing property damage,
personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any otherappliance.
NEVER use this appliance as a
space heater to heat or warm the
room. Doing so may result in carbon
monoxide poisoning and overheating
of theappliance.
What to Do if you Smell Gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your
building.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas
supplier, call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.

SAFETY AND WARNINGS
!WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• Disconnect the appliance from the mains
electricity supply before carrying out any work
or maintenance.
• Connection to a good earth wiring system is
essential and mandatory.
• Alterations to the domestic wiring system must
only be made by a qualified electrician.
! WARNING!
Cut Hazard
Failure to use caution could result in injury.
• Take care: some edges are sharp.
READ AND SAVE THIS GUIDE
General Use
zSuitable only for indoor installation.
zDo not modify this appliance
zRead these instructions carefully before installing this product.
zSave these instructions for the local electrical inspector’s use.
zInstallation must comply with your local building and local electricity regulations.
zThis appliance is to be installed and serviced only by a Fisher & Paykel trained and
supported service technician or qualified person.
zThe manufacturer accepts no responsibility for the incorrect installation of appliances.
Incorrect installation may result in personal injury, damage to property and may
invalidate any warranty or liability claims.
zPacking elements (eg plastic bags, polystyrene foam, staples, packing straps etc) and
tools should not be left around during and after installation, especially if they are within
easy reach of children, as these may cause serious injuries.
zMake sure you recycle the packaging material.
zBefore disposing of any appliance, make sure that it can no longer be used and that all
hazardous parts are removed or made harmless, so that children playing with the old
appliance cannot harm themselves.
zOnly genuine replacement parts may be used for servicing the appliance. These are
available from your nearest Fisher & Paykel Service Centre.
zThese appliances are registered in: New Zealand at www.energysafety.govt.nz and
Australia with SAI Global at www.saiglobal.com.
zAppliances are factory set for natural gas but are convertible to ULPG. If in doubt, refer
to the local gas network operator or gas supplier to confirm gas type at installation site.
zDo not modify this appliance.
zDo not use or store flammable materials on or near this appliance.
zDo not spray aerosols in the vicinity of this appliance while it is in operation.
zThis cooktop must be connected to the mains power supply only by a suitably
qualified person.
zDo not use adapters, reducers, or branching devices when connecting the cooktop to
the mains power supply to prevent overheating and fire.
zThe power supply cable must not touch any hot parts and must be positioned so that
its temperature will not exceed 75°C at any point.
zThis cooktop requires adequate supply of cool air to fully function. The base of the
cooktop must have direct, unrestricted ventilation to the room where the cooktop
is installed. There must be a 4mm air gap at the front of the cooktop. (See ‘Venting
Clearances’ page)
3

Prior to installing your cooktop, ensure the following:
zThe local distribution conditions (nature of gas and pressure) and the adjustment of
the appliance are compatible. For adjustment conditions for this appliance see ‘Gas rate
summary’.
zA suitable disconnection switch is incorporated in the permanent wiring, mounted and
positioned to comply with the local wiring rules and regulations. A means of disconnection
with at least a 3mm air gap contact separation in all poles must be incorporated into the
fixed wiring in accordance with the wiring rules, unless the local wiring rules allow for
alternative means.
zThere is a power outlet within reach of the power supply cable. This must be accessible
after installation. The power supply cable should not touch any metal parts.
zIf the supply cord is damaged, it must be replaced by a special cord or assembly available
from authorised Fisher & Paykel Service Agents.
zThe supply connection point (gas shut-off valve) is accessible after installation.
zThe benchtop is made of a heat-resistant material.
zThe installation complies with all the requirements of Australian and New Zealand Gas
Installation Standards (AS/NZS 5601.1.2010), including that the product has to be installed
so that the surface temperature of any nearby combustible surface will not exceed 65 OC
above ambient. Refer to ‘Clearance Dimensions’.
zIf installed with an approved flexible hose, the hose should not come in contact with
the bottom of the appliance or any sharp edges. Flexible hose assemblies should be
AS/NZS 1869 Class B or Class D certified with a maximum length of 1.20m.
zThe cooktop will not be installed directly above a dishwasher, fridge, freezer, washing
machine or clothes dryer, as the humidity may damage the cooktop electronics.
zRemove all internal and external packaging and recycle it responsibly where possible.
During installation, please ensure the following:
zSeal the exposed bare edges of the cutout with an oil-based paint or moisture-proof
polyurethane to prevent possible moisture creeping between the cooktop trim and
the benchtop.
zTake extreme care not to chip, crack, or break the top glass surfaces during installation.
A heavy metal tool or part accidentally dropped on the glass could damage it.
zIf, after following the instructions given, correct performance cannot be achieved, please
contact your nearest Fisher & Paykel Service Centre, Customer Care, or contact us through
our local website listed at the end of this document.
WARNING!
The owner carries all risk for flush mounting the cooktop. The owner must ensure the
cooktop has been cut out from the countertop before servicing can be carried out.
Fisher & Paykel will not be liable for any costs associated with removing or replacing a flush-
mounted and/or sealed-in product, nor for repairing any damage that may be incurred by
doing this.
INITIAL CONSIDERATIONS
PRIOR TO INSTALLATION DURING INSTALLATION
4

COMPONENTS REQUIRED
Wrench
*LPG models only **NG models only
Hex key
Crosshead
screwdriver
Router
Silicone Cutter
Fibre washer Elbow 1/2” BSP
external thread
Clamping
brackets
ULPG test
point adapter*
NG regulator**
PARTS SUPPLIED TOOLS REQUIRED
Dual wok pan
support
Small pan
support
Wok stand
zKeep all packing materials until the unit has been inspected.
zInspect the product to ensure there is no shipping damage. If any damage is detected
contact the dealer or retailer you bought the product from to report the damage.
zFisher & Paykel is not responsible for shipping damage.
5

PRODUCT DIMENSIONS — CGI603D MODELS
Actual product dimensions may vary by ± 2 mm
PLAN ISOMETRIC
PROFILEFRONT
C
G
D
B
m
a
eFH
k
j
l
i
PRODUCT DIMENSIONS
CGI603D
MM
A Overall height of cooktop* 126
B Overall width of cooktop 599
C Overall depth of cooktop 530
D Height of chassis 60
E Width of chassis 556
F Depth of chassis 485
G Height of cooktop glass and flange 5
H Depth of front overhang of cooktop 12
I Depth of rear overhang of cooktop glass** 33
J Depth of left overhang of cooktop glass** 23
K Depth of right overhang of cooktop glass** 20
L Height of tallest trivet*** 61
M Distance from centre of burner to rear of
cooktop 218
Height from benchtop to centre of gas inlet**** 31
Depth from front of chassis to gas inlet**** 31
*Including tallest trivet
**Including flange
***From cooktop surface
****Located at the rear on the left hand side
6

PRODUCT DIMENSIONS — CGI905D MODELS
Actual product dimensions may vary by ± 2 mm
PLAN ISOMETRIC
PROFILEFRONT
C
G
D
B
m
a
e FH
k
j
l
i
PRODUCT DIMENSIONS
CGI905D
MM
A Overall height of cooktop* 126
B Overall width of cooktop 899
C Overall depth of cooktop 530
D Height of chassis 60
E Width of chassis 852
F Depth of chassis 485
G Height of cooktop glass and flange 5
H Depth of front overhang of cooktop 12
I Depth of rear overhang of cooktop glass** 33
J Depth of left overhang of cooktop glass** 23
K Depth of right overhang of cooktop glass** 24
L Height of tallest trivet*** 61
M Distance from centre of burner to rear of
cooktop 218
Height from benchtop to centre of gas inlet**** 31
Depth from front of chassis to gas inlet**** 31
*Including tallest trivet
**Including flange
***From cooktop surface
****Located at the rear on the left hand side
7

CUTOUT DIMENSIONS — CGI603D MODELS
CUTOUT DIMENSIONS
CGI603D
MM
A Overall width of cutout 560
B Overall depth of cutout 490
C Corner radius of cutout max 2
CUTOUT DIMENSIONS
CGI603D
MM
A Overall width of routered recess 605
B Overall depth of routered recess 535
C Offset overhang allowance 34
D Height of routered recess 5
E Width of cutout 560
F Depth of cutout 490
G Corner radius of routered recess max 2
H Corner radius of cutout max 10
FRONT
PLAN
B
A
C
FRONT
PLAN
fB
E
A
H
G
C
D
PROUD INSTALLATION FLUSH INSTALLATION
8

PROUD INSTALLATION FLUSH INSTALLATION
CUTOUT DIMENSIONS — CGI905D MODELS
FRONT
PLAN
B
A
C
FRONT
PLAN
fB
E
A
H
G
C
D
CUTOUT DIMENSIONS
CGI905D
MM
A Overall width of cutout 865
B Overall depth of cutout 490
C Corner radius of cutout max 2
CUTOUT DIMENSIONS
CGI905D
MM
A Overall width of routered recess 905
B Overall depth of routered recess 535
C Offset overhang allowance 34
D Height of routered recess 5
E Width of cutout 865
F Depth of cutout 490
G Corner radius of routered recess max 2
H Corner radius of cutout max 10
9

CLEARANCES — CGI603D MODELS
CLEARANCE DIMENSIONS
CGI603D
MM
A Minimum clearance from top of trivets to:
zRangehood 650
zOverhead exhaust fan 800
zDownward facing combustible surface* 650
zDownwards-facing tiled or fire resistant surface 500
B Minimum clearance below bench top to:
zCombustible surface 70
zFisher & Paykel oven or nearest non-combustible surface 65
C Minimum clearance from side of cutout to nearest adjacent combustible surface 115
D Minimum distance from right edge of cooktop to gas connection point on wall
(if using a flexible hose) 250
E Distance from floor to gas connection point on wall
(if using a flexible hose) 800-850
F Minimum clearance from countertop to overhead cabinet
(not directly above the cooktop) 450
G Maximum depth of overhead cabinetry 600
H Minimum distance between overhead cabinets
(centered above cooktop) 600
I Minimum clearance from rear edge of cutout to nearest:
zCombustible surface 85
zNon-combustible surface 45
A
H
f f
b
C
C
D
E
g
i
*Combustible surface definition
Any materials of a building structure or decorative structure made of wood, compressed paper,
plant fibres, vinyl/plastic or other materials that are capable of transferring heat or being
ignited and burned. Such material shall be considered combustible even though flame-proofed,
fire-retardant treated or surface-painted, or plastered.
Ensure there is an earthed power outlet within 900mm of the centre rear of the product. The gas
connector on the wall should be accessible with the product installed.
10

CLEARANCES — CGI905D MODELS
CLEARANCE DIMENSIONS
CGI905D
MM
A Minimum clearance from top of trivets to:
zRangehood 650
zOverhead exhaust fan 800
zDownward facing combustible surface* 650
zDownwards-facing tiled or fire resistant surface 500
B Minimum clearance below bench top to:
zCombustible surface 70
zFisher & Paykel oven or nearest non-combustible surface 65
C Minimum clearance from side of cutout to nearest adjacent combustible surface 115
D Minimum distance from right edge of cooktop to gas connection point on wall
(if using a flexible hose) 250
E Distance from floor to gas connection point on wall
(if using a flexible hose) 800-850
F Minimum clearance from countertop to overhead cabinet
(not directly above the cooktop) 450
G Maximum depth of overhead cabinetry 600
H Minimum distance between overhead cabinets
(centered above cooktop) 900
I Minimum clearance from rear edge of cutout to nearest:
zCombustible surface 85
zNon-combustible surface 45
A
H
f f
b
C
C
D
E
g
i
*Combustible surface definition
Any materials of a building structure or decorative structure made of wood, compressed paper,
plant fibres, vinyl/plastic or other materials that are capable of transferring heat or being
ignited and burned. Such material shall be considered combustible even though flame-proofed,
fire-retardant treated or surface-painted, or plastered.
Ensure there is an earthed power outlet within 900mm of the centre rear of the product. The gas
connector on the wall should be accessible with the product installed.
11

VENTING CLEARANCES
Oven* with cooling fanDrawer or other obstruction
This cooktop requires adequate supply of cool air to fully function. The base of the cooktop
must have direct unrestricted ventilation to the room where the cooktop is installed. There
must be a 4mm air gap at the front of the cooktop.
CLEARANCE DIMENSIONS MM
A Minimum ventiliation gap at the front of the cooktop 4
B Minimum clearance from cooktop to drawer or other obstruction 65
C Minimum ventiliation gap at the rear of the cooktop 20
D Minimum diameter of cooling air hole 50
CLEARANCE DIMENSIONS MM
A Minimum ventilation gap at the front of the cooktop 4
B Minimum ventilation gap at the rear of the cooktop 20
C Minimum diameter of cooling air hole 50
*Some ovens require installation in a sealed box. Please refer to your oven installation guide for more information.
A A
B
D C
C B
DRAWER OR OTHER OBSTRUCTION OVEN WITH COOLING FAN
12

GAS CONNECTION CONSIDERATIONS
The following are the available options for connecting the gas line to the cooktop to suit your installation:
NATURAL GAS MODELS LPG MODELS
GAS LINE TO GAS INLET GAS LINE TO ELBOW FACING LEFT GAS LINE TO ELBOW FACING DOWN
Ensure the supplied natural gas
test point adapter dimensions are
considered prior to the installation.
This can be fitted at any point along
the gas line.
Ensure the supplied LPG test point
adapter dimensions are considered prior
to the installation. This can be fitted at
any point along the gas line.
65mm
30mm34mm
85mm
50mm
64mm
FRONT FRONTPROFILE PROFILE
test point
location
test point
location
BASE
ISO ISO ISO
BASE BASE
13

GAS RATE SUMMARY
CGI603D MODELS CGI905D MODELS
BURNER GAS TYPE JET SIZE
(MM)
NOMINAL RATING
(MJ/H)
1 Dual wok
NG (1.00kPa)*
1.45
21.501.45
0.70
ULPG (2.75kPa)*
0.81
20.500.81
0.50
*Nominal pressure with burner on high
BURNER GAS TYPE JET SIZE
(MM)
NOMINAL RATING
(MJ/H)
1 Dual wok
NG (1.00kPa)*
1.45
21.501.45
0.70
ULPG (2.75kPa)*
0.81
20.500.81
0.50
*Nominal pressure with burner on high
11
14

2 5
1 4
PROUD INSTALLATION
*The number of brackets varies based on your cooktop model
Gently lower the cooktop into the
cutout ensuring you have access
below the countertop to fit and
secure the brackets.
Locate the side brackets* to the
appropriate slots on the cooktop
chassis. The correct slot height is
determined by the thickness of
your countertop.
3
Tighten all screws to secure the
cooktop to the countertop.
Ensure cooktop is level.
Apply adhesive foam seal around
the glass overhang, 5mm in from
the edge of the glass.
Ensure the adhesive side is facing
down to form a continuous seal
around the cooktop.
Trim any excess seal using a
sharp knife taking care not to
damage the cooktop or surface.
*(1/2” BSP external thread)
Fit the elbow and washer to the
floating nut. Turn the cooktop
over carefully and place onto a
protected surface ensuring the
ignitor won’t be damaged.
floating nutelbow* washer
15

2
7
5
1
6
Prepare the countertop for flush
installation. Use a router to cutout
the edges of the countertop to
specified depth (5mm).
Attach an adhesive tape along
the edges of the routered recess.
Mask off the area to be siliconed
ensuring both the cooktop and
countertop are protected.
Apply silicone in the gap between
countertop and cooktop.
Wipe off any excess silicone.
FLUSH INSTALLATION
*The number of brackets varies based on your cooktop model
Tighten all screws to secure the
cooktop to the countertop.
Ensure cooktop is level.
adhesive
3
Gently lower the cooktop into the
cutout ensuring you have access
below the countertop to fit and
secure the brackets.
Locate the side brackets* to the
appropriate slots on the cooktop
chassis. The correct slot height is
determined by the thickness of
your countertop.
4
Fit the elbow and washer to the
floating nut. Turn the cooktop
over carefully and place onto a
protected surface.
floating nutelbow* washer
16

GAS CONNECTION
NG Models
LPG Models
Adjust to obtain a test point pressure of 1kPa with
the burner operating at the highest setting.
zEnsure the connection point will be accessible with
the installed cooktop.
zUse an isolating valve close to the cooktop.
If connecting the gas with a flexible hose:
zEnsure the hose is long enough to allow for removal
of cooktop for servicing.
zEnsure the connection is located as shown in
‘Clearace dimensions’.
zThe hose assembly must be AS/NZ 1869 Class
B or D certified, with an Rp 1/2” (ISO7-1) female
thread connection.
zNote the replacement date on hose if applicable.
zThe hose assembly must not be longer than 1.2m
in length with minimum internal diameter of 10mm
and comply with relevant AS 5601/NZS 5261
requirements.
zEnsure the hose is not kinked, and not subjected to
abrasion or permanently deformed.
zEnsure the hose is not near or in contact with any
hot surfaces (eg base of metal hotplate, flue, or
chassis of underbench oven, etc).
Adjust to obtain a test point pressure of 2.75kPa
with the burner operating at the highest setting.
manual shut-off valve
‘open’ position
gas supply line
to cooktop
zEnsure all dials are set to OFF before connecting cooktop to gas supply.
zAfter final gas connection is made, turn gas supply on and test all connections in gas
supply piping for gas leaks with a soapy water solution.
zIn order to avoid property damage or serious personal injury, never use a match or open
flame. If a leak is present, tighten joint or unscrew, apply more joint compound, tighten
again and retest connection for leak.
ON
GAS
Leak test points
Manual shut-off valve
NATURAL GAS MODELS
LPG MODELS
ALL MODELS
LEAK TESTING
17

ELECTRICAL CONNECTION
Before connecting the cooktop to the mains power supply check that:
zThe domestic wiring system is suitable for the power drawn by the cooktop.
zThe voltage corresponds to the value given in the rating plate.
zThe power supply cable sections can withstand the load specified on the rating plate.
MODEL MAX. CURRENT DRAW MAX. LOAD VOLTAGE
CGI603D* 16A 3700W 220-240V 1N ~
CGI905D 30A 7000W 220-240/380-415V 2N ~
PE
1
2
3
4
5
PE
1
2
3
4
5
N
L
N
L1L2
PE
1
2
3
4
5
N
L1L3L2
PE
1
2
3
4
5
N
L
220-240V~
PE
1
2
3
4
5
PE
1
2
3
4
5
N
L
N
L 1 L 2
PE
1
2
3
4
5
N
L
1 L 3 L 2
PE
1
2
3
4
5
N
L
380-415V~
CGI905D SINGLE PHASE CONNECTION
CONNECTION LOCATIONS CGI905D TWO-PHASE CONNECTION
CABLE CONNECTION
Connect the cooktop to the power
supply and attach the duplicate data
label to an accessible location.
*The CGI603D comes supplied with a cable. This must be wired into a suitably rated plug, permanent
connection outlet or power isolator
CG905D models
CGI905 models must be both plugged
in and hard-wired to allow use of the
induction and gas cooking surfaces.
CG603D models
Both supplied cables must be plugged
in to allow use of the induction and gas
cooking surfaces.
induction cable gas cable junction box gas cable
BASE BASE
18

COOKTOP BURNERS
Securely locate all pan supports ensuring
they are the installed in the correct
orientation and do not rock.
ATTACH PAN SUPPORTS
zTo check that the ignition system operates correctly, light the burner.
zCheck for a well-defined blue flame without any yellow tipping.
zIf any abnormality is evident, check that the components of the burner assembly are
located properly.
zNo air shutter adjustment is possible on the cooktop. Correct operation is achieved with
factory installed settings for the correct gas type.
zWhen installing the burner spreader, align the two location features in the bottom of the
spreader with the locating notch in the top side of the burner base and make sure these
are properly engaged.
zIncorrect installation may produce a potentially dangerous flame and result in poor
burner performance.
zIf proper operation cannot be obtained, contact Customer Care or your nearest
Fisher&Paykel Authorised Service Centre.
zThe cooktop must not be used until proper operation has been achieved.
lifting off stable blue flameyellow tip
TEST BURNERS
19

INSTALLER CHECKLIST
TO BE COMPLETED BY THE INSTALLER
GENERAL
Read safety and warnings in the user guide before operating the cooktop.
Specified clearance maintained.
Unit is level–front to back and side to side.
All packaging materials have been removed.
Dials turn correctly and freely.
Touch controls and displays are functioning.
Burner lights satisfactorily.
Cooking zones are functioning correctly. Turn on all of them to a high setting and leave
them on for at least one minute.
There is a constant flow of cool air from the cabinetry to the base of the cooktop.
Cooktop is securely clamped.
Basic operation has been demonstrated to the customer.
GAS
Manual gas shut-off valve installed in an accessible location.
Unit tested and free of gas leaks.
ELECTRICAL
Receptacle with correctly rated over-current protection is provided for service
cordconnection.
Adequate ground connection.
Power supply cable is not touching the cooktop and accessible.
Complete and keep for safe reference:
Model
Serial No.
Purchase Date
Purchaser
Dealer Address
Installer’s Name
Installer’s Signature
Installation Company
Installation Date
20
