INSTALLATION GUIDE
NZ AU
COMBINATION STEAM OVEN
MINIMAL
OS60SMTDB1, OS60SMTDG1
CONTEMPORARY
OS60SDTDX2

2
!WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electric shock or death.
• Before carrying out any work on the
electrical section of the appliance, it must
be disconnected from the mains electricity
supply.
• Connection to a good earth wiring system is
absolutely essential and mandatory.
• Alterations to the domestic wiring system
must only be made by a qualified electrician.
!WARNING!
Fire Hazard
Failure to follow this advice may result in
overheating, burning, and injury.
• Do not use adapters, reducers, or branching
devices to connect this appliance to the
mains power supply.
!WARNING!
Cut Hazard
Failure to use caution could result in injury.
• Take care: some edges are sharp.
READ AND SAVE THIS GUIDE
WARNING!
To avoid hazard, follow these instructions carefully before installing or using this appliance.
zPlease make this information available to the person installing the appliance—doing so
could reduce your installation costs.
zThis appliance must be installed and connected to the mains power supply only by a
suitably qualified person according to these installation instructions and in compliance
with any applicable local building and electricity regulations. Failure to install the
appliance correctly could invalidate any warranty or liability claims.
zIf the power supply cable is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person in order to avoid a hazard.
zIsolating switch: make sure this oven is connected to a circuit which incorporates an
isolating switch providing full disconnection from the power supply in accordance with the
wiring rules.
zThe oven must be earthed.
zDo not use adaptors, reducers or branching devices to connect the oven to the mains
electricity supply, as they can cause overheating and burning.
zThe appliance must not be installed behind a decorative door in order to avoid
overheating.
zPlease take extra care not to damage the lower trim of the oven during installation. The
trim is important for correct air circulation and allows the door to open and close without
obstruction. The manufacturer does not accept any responsibility for damage resulting
from incorrect installation.
SAFETY AND WARNINGS

3
Ensure that:
zthe oven cavity is square and level based on the required dimensions
zthe installation will comply with all clearance requirements and applicable standards and
regulations
zthe isolating switch will be easily accessible to the customer with the oven installed
zthe electrician provides sufficient free length of power supply cable to reach from the
bottom rear of the cavity to at least 1.5m in front of the bottom edge of the opening
zthe cable may enter the cavity from the side, top or bottom, but top entry must be at the
rear of the cavity
zthe oven connection socket is outside the cavity if the oven is flush to the rear wall
zthe oven will rest on a surface that can support its weight
zthe height from the floor suits the customer
zyou consult local building authorities and by-laws if in doubt regarding installation
IMPORTANT!
Some environmental factors and cooking habits can cause condensation in and around
the oven during use. To protect surrounding cabinetry from possible damage caused by
frequent or excessive condensation, we recommend moisture-proofing the oven cavity.
Ensure that:
zthe oven door can open fully without obstruction
zthe oven is not sealed into the cabinetry with silicone or glue. This makes future servicing
difficult. Fisher & Paykel will not cover the costs of removing the oven, or of damage
caused by this removal
zthe power supply cable does not touch any hot metal parts
zthe isolating switch is easily accessible to the customer with the oven installed
zyou complete the ‘Installer checklist’ at the end of the installation
zthere is enough clearance for opening and closing operation of the moving control panel.
If, after following the guidance given, correct performance cannot be achieved, please
contact your nearest Fisher & Paykel trained and supported service technician, Customer
Care, or contact us through our website fisherpaykel.com
INSTALLATION CONSIDERATIONS
BEFORE INSTALLATION AFTER INSTALLATION

4
COMPONENTS
STANDARD ACCESSORY KIT INSTALLATION KIT
Part No. 580836
Supplied with all models.
Part No. 580720
Supplied with all models.
Supplied with all models.
Large solid dish Large perforated dishSmall perforated dish Tray
Screws (2) Cabinetry trim (1)
STEAM ACCESSORY KIT
Roast dish Grid Grill rack
Full extension sliding shelf
Food probe
Step down wire shelf

5
PRODUCT DIMENSIONS
OS60SDT
MM
A Overall height of oven 598
B Overall width of oven 596
C Overall depth of oven (excluding handle and dials) 566
D Height of chassis 575
E Width of chassis 556
F Depth of chassis 545
G Depth of oven frame and control panel (between front of chassis and front of oven door) 21
H Depth of oven door when fully open (measured from front of control panel) 460
PRODUCT DIMENSIONS
a
c
f
g
d
e
B
h
FRONT
PLAN
PROFILE

6
CABINETRY DIMENSIONS
OS60SDT
MM
A Minimum inside width of cavity 560
B Overall width of cabinetry 600
C Minimum inside height of cavity 580
D Overall height of cabinetry 600
E Minimum inside depth of cavity 550
If installing a cooktop above the oven, ensure adequate clearance is provided as per the cooktop manufacturer’s instructions.
CABINETRY DIMENSIONS
PROUD INSTALL
FLUSH INSTALL
16-20mm
16-20mm
2mm
PROFILE PLAN
e
b
a
D C
Ensure a 5mm minimum clearance is maintained between the top of the oven chassis and the cabinetry. Ensure the oven is not bearing
any weight from cabinetry or products installed above.

7
Remove the packaging from the side
and accessories box from the top of
the oven, and set aside.
Recycle responsibly
DISCARD PACKAGING RESPONSIBLY

8
zThis oven must be connected to the mains power supply only by a suitably
qualified person.
zThis oven must be earthed.
Before connecting the oven to the mains power supply, check that:
the domestic wiring system is suitable for the power drawn by the oven (as specified on
the rating plate).
the voltage corresponds to the value given on the rating plate.
CONNECT THE OVEN TO THE MAINS SUPPLY
L1N(L2) E
L1N(L2) E
MODEL CODE MAX POWER (W) HZ VOLTAGE (V) AMPS (A)
OS60SDT 2800 - 3300 50 - 60 220 - 240 V~ 12.8 - 13.8 Brown (Live)
Blue (Neutral)
Green & Yellow (Earth)
Ensure cable
clamp is
tightened
Unclip
and lift

9
SECURE THE OVEN TO THE CABINETRY
zDo not lift the oven by the door handle.
zDo not over-tighten the screws.
zDo not seal the oven into the cabinetry
with silicone or glue. This makes future
servicing difficult. Fisher & Paykel will
not cover the costs of removing the
oven, or of damage caused by this
removal.
1
2
3
cavity
Use the supplied screws to secure the oven to the
cabinetry.
Open the oven door fully.
Mark and pre-drill the screw holes to the sides of the
cabinetry.
For dark cabinetry, the supplied trim can be used to
enhance clashing finish. To install, remove the trim
adhesive and press to secure to cavity.
Position the oven in the prepared cavity.

10
Complete and keep for safe reference:
Model
Serial No.
Purchase Date
Purchaser
Dealer Address
Installer’s Name
Installer’s Signature
Installation Company
Installation Date
INSTALLER CHECKLIST
TO BE COMPLETED BY THE INSTALLER
F Ensure the oven is level and securely fitted to the cabinetry.
F Open the oven door slowly until it is fully open and check there is adequate
clearance between the bottom of the door and the lower trim.
This is to ensure correct air circulation. Should the lower trim become damaged,
straighten the trim and ensure the oven door opens fully without obstruction.
F Ensure all internal packaging (including the circular yellow packing retainers
holding the accessory box in place) is removed.
F Ensure all oven vents and openings are clear and free of any obstruction or
damage.
Failure to make sure all oven vents are clear may result in poor product
performance.
F Ensure the isolating switch is accessible by the customer.
TEST OPERATION:
F Turn on the oven. The display should light up.
F Set the clock following the instructions in the ‘User guide’.
F Turn on the moving control panel. Remove protective wrap from control panel
arms. Check clearance during opening and closing operation.
F Set the oven to BAKE at 50oC. The cavity light should turn on inside the oven
cavity and air should blow out from the vent at the top of the oven. After five
minutes, open the oven door. The air inside should feel warm. Turn the oven off.
F Demonstrate the basic operation to the customer.
