Fisher-Price B2108 User manual

w
w
w.
fi
s
he
r
-p
r
i
c
e
.
c
o
m
Model Number: B2108, B3469, G5175
PLEASE KEEP FOR FUTURE REFERENCE.
Please read these instructions before assembly and use of this product, as they contain important information.
Adult assembly is required.
Tool needed for assembly: Phillips Screwdriver (not included).
Requires four “D” (LR20) alkaline batteries for operation.
Maximum Weight Limit: 24 lbs. (10.9 kg).
IMPORTANT! The maximum weight limit for this product is 24 lbs. If your child weighs
less than 24 lbs., but is really active and appears to be able to climb
out of the swing, immediately discontinue its use.
Product features and decorations may vary from picture above.
Accessories sold separately.
Smart Response™Swing

Consumer InformationWarnings and Caution
2
Occasionally a consumer may experience a problem with
one of our products. If this should happen, please call us
toll-free, rather than return this product to the store. Usually,
we can solve the problem over the telephone or send you
replacement parts. Please call Fisher-Price® Consumer
Relations, toll-free at 1-800-432-5437,8AM - 6 PM EST
Monday through Friday. Hearing-impaired consumers using
TTY/TDD equipment, please call 1-800-382-7470.
Or, write to:
Fisher-Price®
Consumer Relations
636 Girard Avenue
East Aurora, New York 14052
•To prevent serious injury or death
from falls and being strangled in
the restraint system:
- Always use the restraint sys-
tem. Never rely on the tray to
restrain child.
- Never use with an active child
who may be able to climb out of
the seat.
•Never leave child unattended.
WARNING
This product contains small parts
in its unassembled state.
Adult assembly is required.
CAUTION

Parts
3
Front Base Rear Base
Seat with Restraint
2 Seat Tubes
Seat Wire
2 Seat Wire
Caps
2 Accessory Bins
Pad
Toy Bar
(Toys may be different)
Tray
2 Front Legs
(Longer)
2 Rear Legs
(Shorter)
Bracket
(with M4 Lock Nuts)
Housing
Motor Housing
M4 Screw - 4
Shown Actual Size
Note: Tighten or loosen all screws with a Phillips screwdriver. Do not over-tighten the screws.
#8 x 13/8" Screw - 6
Shown Actual Size
#6 x 5/8" Screw - 8
Shown Actual Size

•Place the front base on a flat surface.
•Position a front leg (longer) so that the tapered end is
downward, as shown.
•While pressing the button on one of the front legs, insert it
into the front base. Push down on the front leg until the
button “snaps” into the hole in the front base.
•Repeat this procedure to assemble the other front leg to
the front base.
Front Base
Tapered End
Tapered End
Front Legs
(Longer)
IMPORTANT! Before assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use
if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts.
Assembly
•While standing on the front base, pull the front legs up.
The front legs should remain secured to the front base.
If you can remove the front legs, you have not assembled
them correctly to the front base. Reread and repeat
assembly step 1.
4
Press
Button
Press
Button
Front Legs Pull Up
Pull Up
Front Base
1
2
•Position the housing so that the hub is inward.
•While pressing the button on the top of front leg, insert it
into the housing slot, as shown. Push the front leg until the
button “snaps” into the hole in the housing.
•Repeat this procedure to assemble the motor housing to
the other front leg.
•Pull the front legs down to be sure they are secure in the
housings. If you can remove them, you have not assembled
them correctly. Please re-read and repeat this assembly step.
Hub
Housing
Slot Motor
Housing
Front
Legs
Press
Buttons
3
•Position a rear leg so that the tapered end is upright.
•While pressing the button on the top of the rear leg, insert it
into the housing short tube, as shown. Push the rear leg
until the button “snaps” into the hole in the short tube.
•Repeat this procedure to assemble the other rear leg to the
motor housing short tube.
•Pull the rear legs down to be sure they are secure in the
housings. If you can remove them, you have not assembled
them correctly. Please re-read and repeat this assembly step.
Button
Rear Legs
4
Motor Housing
Short Tube
Tapered
End

Assembly
5
•Place the rear base on a flat surface so that the buttons
face the front base.
•While pressing the buttons on each side of the rear base,
fit the rear legs onto the rear base. Push the rear legs
down until the buttons on the rear base “snap” into the
holes in each rear leg.
Rear Base
Front
Base
Rear
Legs
•Position the seat face down, with the top of the seat
facing you.
•Position a seat tube so that the long end is upright and
toward you and the curved end is toward the outside edge
of the seat.
•Insert the curved end of the seat tube through the holes in
the ridges on the seat back.
•Repeat this procedure to assemble the other seat tube to
the seat.
Press
Button
Press
Button
6
•While standing on the rear base, pull the rear legs up.
They should remain secured to the rear base. If you can
remove the rear legs, you have not assembled them cor-
rectly to the rear base. Reread and repeat assembly step 6.
•Set the frame assembly aside for Assembly step 17.
Rear Legs
Pull Up
Pull Up
Rear Base
7
8
Top of Seat
Seat Tube
Long Ends
Ridges
•Pull both rear legs out until they “snap” into place.
Pull
Rear
Leg Pull
Rear
Leg
5
Curved
End

Assembly
6
•Insert four M4 screws into the seat tubes and tighten.
•Rotate the seat tubes down.
Seat
Tubes
10
Bracket
Seat Tubes
11
•Position the bracket so that the tall end is toward the
bottom edge of the seat.
Hint: The M4 lock nuts have been assembled to the bracket at
the factory. During shipment of this product, they may have
fallen out. Check to be sure there is a lock nut in each hexagonal
opening on the bracket. If one (or more) has fallen out, fit the lock
nut into a hexagonal opening in the bracket. Make sure the
rounded side of the lock nut is facing up.
•Fit the grooves on the bracket to the seat tubes, as shown.
Seat
Tubes
Bracket
Grooves
Tall
End
Bottom
Edge of
Seat
9
M4 Screw - 4
Shown Actual Size
Lock Nut
Hexagonal
Opening
Shown Actual Size
M4 Lock Nut
Rounded Side
•Fit the seat wire through the slot in the bracket as shown.
Bracket
Slot
Seat Wire
12

Assembly
7
•While holding the seat wire in place, carefully turn the
seat around so that the front faces you.
•Position the seat wire cap so that the rounded edge
is upright.
•Fit each end of the seat wire through the hole in each
seat wire cap.
Ends of
Seat Wire
•Turn the seat face down.
•Fit an accessory bin into the groove on each side of the
seat, as shown.
•Insert two #8 x 13/8" screws into each accessory bin
and tighten.
Seat Wire Cap
Seat Wire
Cap
Grooves
Seat
Accessory Bin
Accessory Bin
14
16
•Lift the seat tubes slightly.
•With the seat wire hanging down, insert the ends of the seat
wire through the slots in the seat, as shown.
Slots
Seat Wire
13
#8 x 1
3/8
”Screw - 4
Shown Actual Size
Seat Wire
Cap Hole
Rounded Edge Up
15
•Press the seat wire caps
into place.
•Insert two #6 x
5/8"
screws
through each seat wire cap
and tighten.
Seat Wire
Caps
Seat Wire is
Through Hole in
Seat Wire Cap
Press in Place
#6 x 5/8" Screw - 4
Shown Actual Size
Hint: The seat wire caps are designed to fit into the seat only one
way. If the screw holes in the seat wire caps do not align with the
holes in the seat, try switching the seat wire caps onto the
opposite ends of the seat wire.

Assembly
8
•Fit the pocket on the back of the pad onto the seat back.
•Fit the waist belts through the smaller slots in the pad.
Crotch Belt
Waist Belts
Pad
19
•Lift the bottom of the pad.
•Insert the pad elastic loops through the holes in the
seat bottom.
•Insert the crotch belt through the slot in the pad.
•From under the seat, fit the elastic loops onto the tabs on
the seat bottom.
20
•Insert a #8 x 13/8" screw into each frame hub and tighten.
•Again, push down on the seat to be sure the seat is secured
to both frame hubs.
Frame
Hubs
18
Pad
Elastic
Loops
Holes
Crotch
Belt
Seat Bottom
#8 x 1
3/8
”Screw - 2
Shown Actual Size
•Position the seat assembly so that the front of the seat is
toward the curved front base.
•While pressing the buttons on the swing tubes, insert them
into the frame hubs. Push the swing tubes up until the but-
tons “snap” into the hole in the frame hubs.
•Push down on the seat to be sure the seat is secured in both
frame hubs.
Swing
Tube
Front
of Seat
Curved
Front
Base
Push
Button
Frame Hub
17

9
Assembly Battery Installation
Installation
•Locate the battery compartment door on the swing frame.
•Insert a coin into the battery compartment door and pry the
battery compartment door off of the swing frame.
•Insert four “D” (LR20) alkaline batteries.
•Replace the battery compartment door.
Battery
Compartment
Door
Hint: When swinging, sound or power L.E.D. slows/dims/stops,
it’s time to replace the batteries! We recommend using alkaline
batteries for longer battery life.
Battery Safety Information
Batteries may leak fluids that can cause a chemical burn
injury or ruin your product. To avoid battery leakage:
•Do not mix old and new batteries or batteries of different
types: alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium).
•Insert batteries as indicated inside the battery compartment.
•Remove batteries during long periods of non-use. Always
remove exhausted batteries from the product. Dispose of
batteries safely. Do not dispose of batteries in a fire.
The batteries may explode or leak.
•Never short-circuit the battery terminals.
•Use only batteries of the same or equivalent type,
as recommended.
•Do not charge non-rechargeable batteries.
•Remove rechargeable batteries from the product
before charging.
•If removable, rechargeable batteries are used, they are
only to be charged under adult supervision.
1.5V x 4
“D” (LR20)
SHOWN ACTUAL SIZE
•Fit the toy bar plugs into the sockets on the swing tubes.
Hint: If the toy bar plugs do not fit into the sockets, turn the
toy bar around.Now, fit the plugs into the sockets.
•Insert two #6 x 5/8" screws into each plug and tighten.
22
Plug
Toy Bar
(Toys may
be different) Plug
Socket
Plug
Hub
#6 x
5/8
”Screw - 4
Shown Actual Size
•Fit the bottom edge of the pad around the bottom edge
of the seat.
•Hook the elastic loops on each side of the pad to the peg on
the back of the accessory bins.
21
Elastic
Loop
Elastic
Loop

IMPORTANT! Before each use, inspect this product for
damaged hardware, loose joints, missing parts or sharp
edges. DO NOT use if any parts are missing or broken. Contact
Fisher-Price® for replacement parts and instructions if
needed. Never substitute parts.
Securing Your Child
•Place your child in the seat. Position the crotch belt between
your child’s legs.
•Fasten both waist belts to each side of the crotch belt. Make
sure you hear a “click” on both sides.
•Check to be sure the restraint system is securely attached by
pulling it away from your child. The restraint system should
remain attached.
10
Crotch
Belt
Waist
Belt
Waist
Belt
1
•To prevent serious injury or death
from falls and being strangled in the
restraint system:
- Always use the restraint sys-
tem. Never rely on the tray to
restrain child.
- Never use with an active child
who may be able to climb out of
the seat.
•Never leave child unattended.
WARNING
B
2
Tighten
B
Loosen
To tighten the restraint:
•Feed the anchored end of the waist belt up through the
buckle to form a loop . Pull the free end of the waist
belt .
To loosen the restraint:
•Feed the free end of the waist belt up through the buckle to
form a loop . Enlarge the loop by pulling on the end of
the loop toward the buckle. Pull the anchored end of the
waist belt to shorten the free end of the waist belt .
Note: After adjusting the restraint to fit your child, make sure
you pull on it to be sure it is securely fastened.
B
B
