Fisher-Price Laugh Smile & Learn L3480 Assembly Instructions

1
Please keep this guide for future
reference, as it contains
important information.
Adult assembly is required.
Tool required for assembly:
Slotted screwdriver
(not included).
www.fisher-price.com
Computer Learning
System
Parent’s Guide
L3480

2
3 Grow-With-Me Levels of Learning! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Message to Parents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Your Computer Learning System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tips for Setup and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Installing/Uninstalling Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Assembling the keytopper to Your Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Removing the keytopper from Your Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Let’s Learn Together. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Level 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Level 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Level 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table of Contents

3
Our specially-developed, infant-appropriate software offers three levels of play for growing baby.
Tapping on the keytopper brings the screen to life with exciting animation, music, sing-along
songs, sounds, and lots of learning activities. What a great way for you and baby to play and
learn — together!
9M+ Level 1
Baby bats keys for fun sounds, and surprise animations!
18M+ Level 2
Older babies discover letters, shapes, counting and peek-a-boo fun!
24M+ Level 3
Toddlers learn and explore by touching specific keys for more advanced interaction.
3 Grow-With-Me Levels of Learning!

4
CAUTION
Laugh, Smile & Learn™Computer Learning System is designed to be a supervised activity. Under
proper supervision, the keytopper and software will provide a safe and enjoyable shared experience
for you and your child. Do not leave your infant or toddler unattended in a chair with access to the
cords and accessories that are associated with a computer.
Message to Parents
To prevent strangulation, keep computer
cables away from children.

5
Keytopper
2 Brackets CD
#4 x ½” Screws - 2
Shown Actual Size
This product contains small parts in its
unassembled state. Adult assembly is required.
Your Computer Learning System
CAUTION

6
• Operating System: Windows 2000, Windows XP and Windows Vista™
• Processor: 750MHz
• Memory: 256MB RAM
• Hard Drive space: 250MB available
• Internet connection - optional for automatic software updates
Note: This software is only compatible with English keyboards.
Minimum System Requirements

7
1. Make sure your computer keyboard is completely
flat before attaching the keytopper. Lower the
tabs on the back of your keyboard if necessary.
2. Do not use the keytopper with your computer
keyboard while it is in a tray or drawer.
Be sure to place your computer keyboard
on a large, flat surface before assembling
the keytopper.
3. Make sure the "Caps Lock" button on your
computer keyboard is off.
4. Install the software before assembling
the keytopper.
5. The keytopper fits over most standard
computer keyboards (but may not fit some
unique styles or ergonomic designs).
Tips for Setup and Use

8
In order to run the program, you will first need to run the installer to setup the necessary program
files on your hard drive.
1. Insert the CD-ROM disc into the CD-ROM drive in your computer.
2. Click the OK button.
3. Follow the installation instructions.
Installing Software
Uninstalling Software
1. Click the Start button and select Programs.
2. Navigate to Fisher-Price®then to the Laugh, Smile & Learn™program.
3. Choose "Uninstall."

9
Bracket Long Legs
Keytopper
Tab
Slot
Long Leg Short Leg
Peg
• Pull the peg out on each bracket and extend the bracket to its widest position.
• Position the brackets so that the long leg on each is toward the top of the keytopper and the peg
on each is facing out.
• Position one of the brackets at a 45
o
angle to the keytopper. Insert and “snap” the bracket tab into
the slot on the side of the keytopper.
• Repeat this procedure to assemble the other bracket to the keytopper.
Note the long leg and short
leg on each bracket.
Assembling the Keytopper to Your Keyboard

10
Bracket
Bracket
• While holding the brackets in place, carefully turn the keytopper over.
• Insert the screws through the slot in each bracket and into the keytopper. Loosely tighten the
screws with a slotted head screwdriver. Do not fully tighten the screws.
• Note the locations of the positioning ribs on the underside of the keytopper.
Assembling the Keytopper to Your Keyboard
Positioning RibPositioning Rib

11
Alpha-Numeric Portion
• Locate the alpha-numeric portion of your computer keyboard.
• Locate the keys highlighted in the illustration above. The keytopper positioning ribs will fit
between these keys.
Note: For proper function, be sure the "Caps Lock" button on your computer keyboard is off.
Assembling the Keytopper to Your Keyboard

12
Positioning Rib Positioning Rib
• With the keytopper face up, position the keytopper over the alpha-numeric portion of your
computer keyboard.
• Fit the positioning tabs between the keys shown in the illustration above.
Hint: If you have properly positioned the keytopper over your computer keyboard, the keytopper
cannot be moved from side or up or down.
Assembling the Keytopper to Your Keyboard

13
Computer Keyboard Lower Edge
Left Bracket
Lower Leg
• Position the right bracket lower leg to the lower edge of your computer keyboard.
Hint: If you have properly positioned the keytopper over your computer keyboard, the left bracket
lower leg will not contact the computer keyboard bottom edge.
• Position the left bracket lower leg so that it aligns with the right bracket lower leg.
Right Bracket
Lower Leg
Assembling the Keytopper to Your Keyboard

14
Fully Tighten Screws
• While keeping the brackets in position, carefully remove the keytopper from your
computer keyboard.
• Turn the keytopper over and fully tighten the screws in the brackets with a slotted screwdriver.
Do not over-tighten.
Assembling the Keytopper to Your Keyboard

15
Positioning Rib Positioning Rib
Assembling the Keytopper to Your Keyboard
• Replace the keytopper over the computer keyboard, Make sure the positioning tabs fit between the
keys shown in the illustration above.
Hint: If you have properly positioned the keytopper over your computer keyboard, the keytopper
cannot be moved from side or up or down.

16
• Pull the peg out on each bracket and slide the top legs until they contact the upper edge of
your computer keyboard.
Peg
Bracket Bracket
Peg
Assembling the Keytopper to Your Keyboard

17
Assembling the Keytopper to Your Keyboard
• Check to be sure you have properly positioned
the keytopper over your computer keyboard.
• Make sure your computer is on. Using your
computer keyboard mouse, click the Laugh,
Smile & Learn™software icon.
• At the home page, click "Level 2" and then
click Start.
• Next, you will press three buttons on the
keytopper to be sure you see correct responses.
- Press the number 6 button (you should see
a 6 on your computer screen).
- Press the phone (you should see a phone on
your computer screen).
- Press a shape button (you should see a shape
on your computer screen).
• If you see and hear correct responses,
you have correctly positioned the
keytopper over your computer keyboard
(go to page 20). If not, please go to the
next page for additional instructions.

18
Foot
Foot
Leg
• If the keytopper isn't properly positioned, you may need to: raise or lower the keytopper (see
instructions on this page); or reattach the keytopper over the keyboard (see instructions beginning
on page 9).
• To adjust the height of the keytopper over the keyboard, turn the feet on each bracket to raise or
lower the keytopper.
Hint: Make sure each foot is contacting the flat surface.
• Check again for correct responses on your computer screen when pressing keytopper buttons.
Refer to page 17.
Assembling the Keytopper to Your Keyboard

19
• Pull the peg out and slide it to enlarge the bracket to its widest position.
• Remove the keytopper from your computer keyboard.
IMPORTANT!
When placing the keytopper over your computer keyboard, remember to re-adjust the keytopper top
legs. The keytopper top legs should contact the upper edge of your computer keyboard.
Peg
Bracket Bracket
Peg
Removing the Keytopper from Your Keyboard

20
Hint: Use your computer mouse to make selections from the Home screen. Selections on the Home
screen cannot be made using the keytopper.
Let’s Learn Together
