Flashforge Guider IIs User manual

SZ11S-ZN/EN-A02
P11

9. Leveling Nut

3. The bottom PE foam should contain: a spool of
PLA filament, a spool holder, a solid glue, a USB
cable, a filament guide tube and a accessories
bag.

9. Tap [Tools].
Build
Power Switch
12. Remove both bottom foam pieces. Tear off
the stretch wrap.
7. Tear off tape and the stretch wrap of front door.
Squeeze top lid slightly from both sides to the
middle so as to take top lid successfully.
Remove the stretch wrap of top lid.
Tear off the
stretch wrap

5. After filament goes through guide tube, press
spring presser on the left side of extruder, and
insert filament vertically into filament intake.
1. Locate the spool holder. Install the spool holder
into the left quadrangular opening on the back.
6. After inserting into filament intake, insert guide
tube into extruder filament intake to fix.
Press here Filament intake

How to use the leveling nuts
Rotate the nut clockwise
Rotate the nut Anticlockwise
Build Plate
Build Plate
Leveling Build Plate

Screw the three nuts under the platform
counterclockwise until they are tight,
then tap the [OK] button.
3. Please wait while the extruder and platform finish initial movements. Screw three nuts under the
platform anticlockwise, then tap [OK] button.
Attention: three nuts may be tightened up before going out, please skip this step if you find
three nuts have been tightened up, and continue to following steps
1. Tap [Tools]-[Level] on touch screen. 2. Tap [Tools]-[Level] on touch screen.
4. After tapping [OK] button, the extruder will move towards the first point and the plate will move
up and down to verify the distance between nozzle and plate.
5.
Build

6. If the distance still not appropriate, please follow the prompts to adjust again till you see [OK]
button. The extruder will move towards the next point, repeat steps according to the prompts on
the touch screen to level the second and third points. Then tap [Finish] to exit.
Loading Filament

1. Please insert the USB stick into USB stick
input on the right side of the printer. Tap [Build].
2. Tap [USB Stick].
4. Tap [Test Files].
6. Tap [Build]. 7. The printer starts to heat and it prints
automatically after heating completed.
5. Tap [Test Files].
3. Turn to next page.
4. Do not leave the Guider IIs unattended during
operation.
Happy3D Software Installation Package 软
件安装包
Quick Start Guide快启
flashprint切片软件
User Guide说明书
PLA
PLA

Press here Filament intake
Done
Extruder
Extruder
Load Unload
Unload started, press down on the
spring lever and withdraw filament
1. Tap [Tools].
3. Tap [Unload], extruder starts to heat. When heating to target temperature, press spring presser
and withdraw filament vertically after compressing filament for 3 seconds.
Please follow steps below if you need to unload filament in
daily use.
2. Tap [Filament].
Unloading Filament
10

6. 触摸屏 7. 触摸屏开关 9. 调平螺母

3. 在纸箱底部的泡沫块中包含有一卷耗材、
丝盘轴、固体胶、USB线、耗材导丝管和
工具包。
2. 将打印机从纸箱中提出。
5. 移除打印机顶部泡沫块，上面附带有电源线、
《快速启动指南》和《售后服务卡》。撕除
固定前门的无痕胶带。

7. 撕保护前门的无痕胶带和缠绕膜。轻轻从两
侧向中间挤压顶罩，以便顺利取出顶罩。
8. 取出电源线，插入打印机背部的电源接口，
按下图中箭头所示的电源开关，接通电源。
9. 开机后在液晶屏上点击[Tools]。
12. 取出下方的两块泡沫块，撕除固定打印
平台的缠绕膜。
Build
电源开关
撕除此处
的缠绕膜

2. 丝盘轴插入丝盘轴插口后，让丝盘轴底部向下
贴住打印机背部。
5. 耗材穿过导丝管后，按下喷头左侧的压板，
然后将耗材垂直插入喷头进丝孔中。
6. 耗材插入进丝孔后，再将导丝管插入喷头进丝
孔固定。
按下压板
进丝孔

调平
打 印 平 台
打 印 平 台

确认
1. 在触摸屏上点击[工具]。
3. 待初始化运动完成后逆时针拧紧底板下的三颗螺母，点击[确认]。
请注意：在出厂前的测试中，三颗螺母可能已经被拧紧，如发现螺母已处于拧紧状态，请跳过
拧紧螺母这一步骤，继续进行后续操作。
4.
5. 根据触摸屏提示，顺时针调节平台下的三颗螺母一致的圈数，直到听到持续稳定的提示声，之后
点击[验证]进行确认。
2. 点击[调平]。
换 丝
打 印
调 平 回 零
设 置 状 态 关 于
手动调节

6.
3. 点击[进丝]后，喷头开始加热。当喷头加热到预定的温度后会自动开始进丝。看到喷嘴开始出丝
时请勿立即停止进丝，直到耗材均匀出丝为止。
1. 在触摸屏上点击[工具]。 2. 点击[换丝]。
填装耗材
