Flexispot H2S User manual

Item No. H2S
Installation Guide
01
Warning
·The packaging materials of this product could be dangerous to young children. Please keep all
plastic bags, screws, tools and other small or potentially hazardous materials away from young
children as they may present a choking risk.
·This Flexispot desk should not be used by children. To avoid potential danger, keep children and
people with cognitive impairments away from this height-adjustable desk, its control unit.
The manufacturer is not responsible for unintended use of this equipment.
·Before using this product, please read the instructions carefully and make sure you fully
understand all the product's functions and settings. If you have any questions, please contact us.
08
Website: www.flexispot.com
Tel: [phone]

Specifications
Accessory Package
Parts Included
Step 1
02 03
Pitch Quantity 2
Max. Weight Capacity
Adjustable Height
Wide expand 43.3" - 70.9" (1100 - 1800mm)
A B C D E
x2
M5 x 8 mm
F
x1
5x5 Square
gasket
x6 x8
Figures shown are for reference only. Please contact customer service if there are any accessories or
tools missing.
Diagram of Components
NO. Parts Qty
Step 2
176 Ibs (80 kg)
28.3"-48.4"(720 - 1230mm)
G H
x1
4x4
x1
3x3 M8 x 16 mm
Bolt
x8 x24
St4.2 x 16 mm
Screw
M8 x 35 mm
Bolt
Screw
NO. Parts Qty
1 2
3 4
5 6
7 8
910
2
1
1
1
11
11
11
Turn the legs (2,3) upside down. Attach the feet (1) to the bottom of the legs using 8pcs M8x16mm
bolts (F) and tighten with 5x5 hex key (A).
43.3" - 70.9"
(1100 - 1800mm)
3
3
2
1FA
A
F
A
G
Attach the legs (2, 3) to the cross bar (4) using 4pcs of the M8x35mm bolts (G). Use the 5x5 hex key
to lock bolts firmly in place. Then, using the 4x4 hex key (B), adjust the 8 screws on the bottom of the
cross bar (4) so that they will accommodate the actual size of your work surface.
2Note:
Tighten those screws in case of the
cross bar sagged.

Step 3
04
Step 4
05
Step 5
Insert the crank shaft (8) into the right leg which has a shaft hole, using 2pcs bolts (D) and lock firmly
with hex key (C).
Then insert crank handle (9) into crank shaft (8).
9
8
DC
6
7
A
G
7
Using the hex key (A), connect both the left and right side brackets (6, 7) to the bottom legs
using 4 bolts (G).
Please note:
Do not misplace the two brackets (6, 7).
Slightly loosen the adjustable nuts to adjust the length of the drive shaft (5). Insert the assembled
drive shaft into the slots that located at the top of each leg.
Loosen the adjustable nut
Insert to the slots
Tighten the nut
Adjust the length of drive shaft
5

06 07
Step 6 Step 7
10
H
H
6
7
E
Evenly place the work surface onto the legs then attach it to the side brackets (6, 7) using
screws (H). Tighten screws firmly with a drill or screwdriver.
Attach the crank handle holder (10) to the underside of the table top using 2 screws (H). Ensure
that the crank handle will properly settle onto the holder when pushed in before screwing crank
handle holder (10) to surface.
Place the crank here after you use.
Use the gaskets (E) while screw the cross bar (4),
using gasket (E) quantity depends on the length
of your desktop.
