FLIR IM75-2 User manual

USER MANUAL
FLIR MODEL IM75-2
Insulation Tester / Digital MultiMeter

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
2
Table of Contents
1. DISCLAIMERS 4
1.1 Copyright 4
1.2 Quality Assurance 4
1.3 Documentation 4
1.4 Disposal of Electronic Waste 4
2. SAFETY 5
2.1 FCC Compliance 6
2.2 Industry Canada Compliance 7
3. INTRODUCTION 8
3.1 Key Features 8
4. METER DESCRIPTION 9
4.1 Meter Sections 9
4.2 Function Switch Positions 10
4.3 Function Buttons, Selector Pad, and Rotary Switch 10
4.3.1 Selector Pad 11
4.3.2 Rotary Switch 11
4.4 Display Description 12
4.5 Display Icons and Indicators 13
5. OPERATION 14
5.1 Powering the Meter 14
5.1.1 Auto Power Off 14
5.2 Manual AC/DC Selection 14
5.3 Auto Range 14
5.4 ‘Smart’ Out-of-Range Warnings 14
5.5 Data Hold and Auto-Hold Modes 14
5.5.1 Data Hold Mode 14
5.5.2 Auto-Hold mode 14
5.6 Voltage Measurements 15
5.7 Insulation Resistance Measurements 15
5.7.1 PI/DAR Test 15
5.8 Earth Bond Resistance Measurements (ZERO Ω) 16

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
3
5.9 Continuity Test 16
5.10 Diode Test 16
5.11 Capacitance Measurements 17
5.12 Extended Functionality 17
5.12.1 Selecting Modes 17
5.12.2 VFD Mode (ACV only) 18
5.12.3 Frequency Mode (ACV only) 18
5.12.4 Pass/Fail Mode (COMPARE) 18
5.12.5 Setup Utility 18
5.12.6 Silent Mode 19
5.12.7 Data Recording Mode (99-point) 19
5.13 Keypad Lockout 19
5.14 Streaming Measurement Data using METERLiNK 20
5.14.1 General 20
5.14.2 Procedure 20
6. MAINTENANCE 21
6.1 Cleaning and Storage 21
6.2 Battery Replacement 21
6.3 Fuse Replacement 21
6.4 Disposal of Electronic Waste 21
7. SPECIFICATIONS 22
7.1 General specifications 22
7.2 Electrical Range Specifications 23
7.3 Input Specifications 25
8. CUSTOMER SUPPORT 26
9. WARRANTY 27
9.1 FLIR Limited Lifetime Warranty 27

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
4
1. Disclaimers
1.1 Copyright
© 2023, FLIR Systems, Inc. All rights reserved worldwide. No parts of the software including source
code may be reproduced, transmitted, transcribed, or translated into any language or computer
language in any form or by any means, electronic, magnetic, optical, manual, or otherwise, without
the prior written permission of FLIR Systems.
The documentation must not, in whole or part, be copied, photocopied, reproduced, translated, or
transmitted to any electronic medium or machine-readable form without prior consent, in writing,
from FLIR Systems.
Names and marks appearing on the products herein are either registered trademarks or
trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names or company
names referenced herein are used for identification only and are the property of their respective
owners.
1.2 Quality Assurance
The Quality Management System under which these products are developed and manufactured
has been certified in accordance with the ISO 9001 standard.
FLIR Systems is committed to a policy of continuous development; therefore, we reserve the right
to make changes and improvements on any of the products without prior notice.
1.3 Documentation
To access the latest manuals and notifications, go to the Download tab at: https://support.flir.com.
It only takes a few minutes to register online. In the download area you will also find the latest
releases of manuals for our other products, as well as manuals for our historical and obsolete
products.
1.4 Disposal of Electronic Waste
As with most electronic products, this equipment must be disposed of in an
environmentally friendly way, and in accordance with existing regulations for
electronic waste.
Please contact your FLIR Systems representative for more details.

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
5
2. Safety
Safety Notes
•Before operating the device, you must read, understand, and follow all instructions, dangers,
warnings, cautions, and notes.
•FLIR Systems reserves the right to discontinue models, parts or accessories, and other items, or to
change specifications at any time without prior notice.
•Remove the batteries if the device is not used for an extended period.
Warning Statements
•Do not operate the device if you do not have the correct knowledge. Formal qualifications and/or
national legislation for the electrical inspections can apply. Incorrect operation of the device can
cause damage, shock, injury or death to persons.
•Do not start the measuring procedure before you have set the function switch to the correct
position. This can cause damage to the instrument and can cause injury to persons.
•Do not change to resistance when you measure the voltage. This can cause damage to the
instrument and can cause injury to persons.
•You must disconnect the test leads from the circuit that you did a test on before you change the
range. If you do not do this, damage to the instrument and injury to persons can occur.
•Do not replace the batteries before you remove the test leads. This can cause damage to the
instrument and can cause injury to persons.
•Do not use the device if the test leads and/or the device show signs of damage. Injury to persons
can occur.
•Be careful when you do the measurements if the voltages are more than 25 VAC rms or 35 VDC.
There is a risk of shock from these voltages. Injury to persons can occur.
•Do not do diode, resistance, or continuity tests before you have removed the power from
capacitors and other devices under test during a measurement. Injury to persons can occur.
•Do not use the device as a tool to identify live terminals. You must use the correct tools. Injury to
persons can occur if you do not use the correct tools.
•Make sure that children cannot touch the device. The device contains dangerous objects and small
parts that children can swallow. If a child swallows an object or a part, speak with a physician
immediately. Injury to persons can occur.
•Do not let children play with the batteries and/or the packing material. These can be dangerous
for children if they use them as toys.
•Do not touch expired or damaged batteries without gloves. Injury to persons can occur.
•Do not cause a short-circuit of the batteries. This can cause damage to the instrument and can
cause injury to persons.
•Do not put the batteries into a fire. Injury to persons can occur.

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
6
Cautions
Do not use the device for a procedure that it is not made for. This can cause damage to the
protection.
This symbol, adjacent to another symbol or terminal, indicates that the user
must refer to the manual for further information.
This symbol, adjacent to a terminal, indicates that, under normal use,
hazardous voltages may be present.
Double insulation.
UL listing is not an indication or a verification of the accuracy of the meter
2.1 FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in an installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
7
WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
2.2 Industry Canada Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
8
3. Introduction
Thank you for selecting the FLIR IM75-2 Insulation Test / Digital MultiMeter. This device is shipped
fully tested and calibrated and, with proper use, will provide years of reliable service.
3.1 Key Features
•4000 count extra-large digital dual display with backlighting
•Auto Range with smart over-range indication
•Auto Hold and Standard Data Hold features
•On-screen menu selection and navigator key drive
•Variable-frequency drive mode (low-pass filter)
•Front panel insulation resistance test voltage selector
•COMPARE feature with front panel color coded PASS/FAIL LED indication
•0.1% DCV accuracy
•99-record data record/recall memory
•High power built-in work lights
•METERLiNK® app compatibility
•Safety Category Rating: CAT IV-600V, CAT III-1000V

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
9
4. Meter Description
4.1 Meter Sections
1. Courtesy Work lights
2. LCD Display
3. Pass-Fail (green/red) LED
4. Rotary Function Switch
5. Function Buttons (detailed below)
6. Positive (+) probe input jack for Voltage,
Capacitance, Diode, & Continuity
7. COM (negative -) probe input jack
8. Positive (+) probe input jack for insulation
resistance and earth bond resistance
1. Courtesy Work Lights
2. Test Probe Holders
3. Tilt Stand
4. Battery and Fuse Access
Fig 4-1 Front View
Fig 4-2 Rear View

FLIR IM75-2 USER MANUAL IM75-2-UM_en-US Rev AA
10
4.2 Function Switch Positions
OFF
The meter is switched OFF and in full power-saving mode.
The meter can measure voltage (V) through the probe inputs.
The meter can measure capacitance, diode polarity or continuity through
the probe inputs. The type of measurement is chosen by the MODE button.
ZERO Ω
Earth Bond Resistance testing mode.
50V, 100V, 250V, 500V, 1KV: Insulation resistance test voltage selections
4.3 Function Buttons, Selector Pad, and Rotary Switch
MODE
•Use this button to change the operating mode of the meter (ex: AC vs. DC)
•Also selects Insulation Resistance values to compare for PASS/FAIL testing
HOLD
Press to HOLD readings on the display during normal DMM measuring modes
(see Section 5.5 Data Hold and Auto-Hold Modes). Press and hold for Keypad
lockout mode (see Section 5.13 Keypad Lockout).
In INSULATION TESTING MODE this button will serve to enable the test lock
function for continuous insulation resistance testing. See Section 5.7 Insulation
Resistance Measurements for further information.
Use this Selector Pad to start/stop Insulation Resistance Tests, to enable
extended functionality modes, and to navigate mode menu options. Further
details provided in Section 4.3.1 Selector Pad
The Rotary Switch is used to select a measurement function. Details are
provided in Section 4.3.2 Rotary Switch
Press this button to exit an extended functionality mode.
•Press this button to enable/disable the display backlight.
•Press and hold the button for 2 seconds to enable/disable the work light.
Press to enable/disable METERLiNK communication, see section 5.14
Streaming measurement data using METERLiNK.
