FLIR IM75-2 User manual

Quick Start
Insulation Tester &
Multifunction Digital
Multimeter
MODEL IM75–2

Quick Start (en)
Note: Please refer to the User Manual for complete safety and op-
erational instructions: https://support.flir.com.
Additional language translations are available at the link above.
SAFETY STATEMENTS
WARNING
• Do not operate this device if you do not have the correct knowledge. Incor-
rect operation can cause damage, shock, injury or death to persons.
• Do not start a measurement before setting the function switch to the cor-
rect position. Failure to follow this warning can cause damage to the instru-
ment and injury to persons.
• Do not change to the resistance function when measuring voltage.
• Do not use the device if the test leads or the device show signs of damage.
• Use extreme care when measuring voltages > 25 VAC RMS or 35 VDC.
• Do not perform diode, capacitance, or continuity tests before removing
power from the circuit or device under test.
• Allow time for large capacitors to fully discharge before taking capacitance
measurements.
This symbol, adjacent to another symbol or terminal, indicates that
the user must refer to the manual for further information.
This symbol, adjacent to a terminal, indicates that, under normal use,
hazardous voltages may be present.
Double insulation.
• This device complies with part 15 of the FCC Rules. See the
User Manual for the full FCC Compliance text. This applies also
to Industry Canada Compliance.
• Safety Category Rating: CAT IV 600 V, CAT III 1000 V
#NAS100160; r. AB/92768/92769; en-US 1

PRODUCT DESCRIPTION
1. Work Lights
2. LCD Display
3. MODE button
4. PASS/FAIL indicator (green/red) for Compare (COMP) and PI/
DAR tests
5. Backlight button
6. Function switch
7. Positive (+) input terminal for Insulation/Earth Bond Resistance
tests
8. COM negative (-) input terminal
9. Positive (+) input terminal for Voltage, Diode, Continuity, and
Capacitance tests
10. Bluetooth button
11. HOLD and Lock button
12. Back (Return) button
13. Arrow keys and TEST OK button
Battery/fuse compartment, test lead holders, and tilt stand are lo-
cated on back of meter.
#NAS100160; r. AB/92768/92769; en-US 2

FUNCTION SWITCH
OFF Meter is powered down
VMeasure Voltage
Test capacitance (use MODE button to select)
Measure diode (use MODE button to select)
Test continuity (use MODE button to select)
ZERO Ω Earth Bond Resistance / ZERO (offset) function
50 V ~ 1K V Insulation Resistance test voltages
FUNCTION BUTTONS
Change the operating mode (AC or DC, for example).
Select Insulation Resistance values to compare for PASS/
FAIL testing.
Short press to freeze/release displayed readings.
In Insulation or Earth Bond resistance modes, long press for
test-lock (continuous test) mode.
In normal mode, long press to lock out the keypad.
Arrows for navigation; TEST-OK button for making selec-
tions, starting Insulation Resistance tests, and enabling ex-
tended function modes.
Exit a mode or return (back) from a menu.
Short press to enable/disable the display backlight.
Long press to enable/disable the work light.
Enable/disable Bluetooth communication.
#NAS100160; r. AB/92768/92769; en-US 3

DISPLAY DESCRIPTION
1. Main display digits
2. Secondary (smaller) display digits
3. Bar graph reading
4. Extended function icons
5. Units of measure
6. Alerts and Status icons
VOLTAGE MEASUREMENTS
1. Set the function switch to the Vposition.
2. Insert the black probe into the COM terminal and red probe into
the Vterminal.
3. Use the MODE button to select AC or DC.
4. Connect the probes in parallel to the part under test.
5. Read the voltage value on the display.
INSULATION RESISTANCE TESTS
1. Use the rotary switch to select the insulation test voltage.
2. Insert the black probe into the COM terminal and red probe into
the Insulation terminal.
3. Select the INSUL icon (bottom row of LCD) to enable the Insu-
lation Resistance function. These ‘extended function’ icons are
explained later in this guide.
4. Connect the probes to the device under test.
5. During the Test, the insulation voltage will appear in the upper
reading area. The resistance will be shown in the main reading
area.
6. Press TEST OK to start test.
7. To lock the test for continuous testing, long press the HOLD /
Lock button to engage, and then press TEST OK to test
continuously.
8. The TEST icon will appear while voltage is present.
9. Press TEST OK to stop the test.
#NAS100160; r. AB/92768/92769; en-US 4

PI / DAR INSULATION TESTS
1. Reference the instructions for Insulation Resistance tests above.
2. Select PI (Polarization Index) or DAR (Dielectric Absorption Ra-
tio) from the extended function icons on bottom row of LCD.
These icons are explained later in this guide.
3. Press TEST OK to test.
4. Press MODE to show the test time. The clock icon and the
elapsed timer will appear. PI is a ten-minute test and DAR is a
one-minute test.
5. The test stops automatically and the result (ratio) appears. The
PASS/FAIL LED will indicate in green for PASS or red for FAIL.
EARTH BOND RESISTANCE TESTS
1. Select the Earth Bond resistance switch position (ZERO Ω).
2. Insert the black probe into the COM terminal and red probe into
the ZERO/Ω terminal.
3. Enable the Earth Bond resistance extended function icon (bot-
tom row of LCD, third from left). These icons are discussed later
in this guide.
4. Short the ends of the probes and press the MODE button to
zero the display.
5. Connect the probes to the device under test.
6. Press TEST OK to test.
7. To lock the test ON, long press the HOLD / Lock button and
then press TEST OK to start.
8. Press TEST OK to stop the test.
CONTINUITY TESTS
1. Set the function switch to the Continuity symbol position.
2. Insert the black probe into the COM terminal and red probe into
the Continuity terminal.
3. Press MODE to select continuity.
4. Touch the tips of the probes across the circuit under test.
5. If the resistance is 30 ± 5 Ω, or lower, the meter will beep.
DIODE TESTS
1. Set the function switch to the Diode symbol position.
2. Press MODE to select the Diode function.
3. Insert the black probe into the COM terminal and the red probe
into the Diode terminal.
4. Touch the tips of the probes across the device under test.
5. Reverse the polarity of the probes, by interchanging the probe
test locations.
#NAS100160; r. AB/92768/92769; en-US 5

6. Touch the tips of the probe across the device.
7. If one reading displays a value between (+) 0.400 and 0.900 V
and the other reading displays a value between ( - ) 0.400 and
0.900 V, then the component is normal.
8. If both readings display OL, the component is either open or
shorted.
CAPACITANCE MEASUREMENTS
1. Set function switch to Capacitance symbol position.
2. Press MODE to select Capacitance mode.
3. Insert the black probe into the COM terminal and the red probe
into the Capacitance terminal.
4. Touch the tips of the probes across the part under test.
5. Read the capacitance value on the display.
EXTENDED FUNCTION ICONS
A variety of modes are available that provide extended functionality.
Mode icons, related to the selected function, are displayed at the
bottom of the LCD.
1. Use the left/right arrows to navigate to an icon. The currently se-
lected icon will flash.
2. Press TEST OK to enable the selected (flashing) icon. The icon
will appear framed.
3. Use the up/down arrows to step through the additional mode
options (if any).
4. For icons 1 through 4 (diagram below), press TEST OK to dis-
able the selected icon. For icons 5 through 10, use the Return
(back) button.
5. Refer to the User Manual for complete details on these modes:
1VFD (low pass filter)
2 Frequency measurements
3 Earth Bond Resistance
4 Insulation Resistance
5Resistance Compare mode (Pass/Fail LED)
6PI mode (Pass/Fail LED)
#NAS100160; r. AB/92768/92769; en-US 6

7DAR mode (Pass/Fail LED)
8Data Recording (99 memory locations)
9Setup utility for APO, Backlight timer, Auto-Hold, Continuity thresh-
old, and Factory default
10 Silent mode (beeper)
METERLiNK DATA TRANSFER
Stream measurement data from the meter to iOS and Android devi-
ces using the METERLiNK® mobile app. Download the app from
the Apple Store® or Google Play™ and follow the application on-
screen prompts. See the User Manual for complete details.
LIMITED LIFETIME WARRANTY
This product is protected by FLIR’s Limited Lifetime Warranty. Visit
www.flir.com/testwarranty to read the Limited Lifetime Warranty
document. Register your product at the website.
CUSTOMER SUPPORT
Customer Support Telephone List:
https://support.flir.com/contact
Repair, Technical Support, Registration, & Document downloads:
https://support.flir.com
#NAS100160; r. AB/92768/92769; en-US 7
