SEE AT NIGHT; STAY SAFE
FLIR’s H-Series handheld thermal imaging cameras let law
enforcement officers see clearly in total darkness, giving
them the undeniable tactical advantages they need to
stay safe and operate effectively at night.
With true night vision finally available to every agency,
officers will have the information they need to make
quick decisions, enhancing mission effectiveness,
maximizing operational capabilities, and improving
officer safety.
H-SERIES CAMERAS LE T OFFICERS:
•See suspects in total darkness. H-Series provides a 320 × 240 resolution VOx microbolometer for half the cost
of comparable cameras, giving officers excellent, high-fidelity thermal imagery that provides the detail necessary
for cutting edge performance and improved detection and recognition ranges in total darkness, as well as through
smoke, dust, and light fog.
• Seebetterthroughcamouflageandfoliageinanylightingconditions.BecauseH-Seriescamerasseeheat,notlight,
they’re not fooled by suspects wearing dark clothes and hiding in bushes. Crooks can’t hide their heat, so they
can’t hide from the H-Series.
• Seemore–andseefarther–thanwithothernightvisiontechnologies.BecauseH-Seriesthermalcamerassee
clearly without any light whatsoever, they can see farther at night than technologies that need ambient light to
work and they can see heat sources that these other cameras could never find.
• Deploy withthe latest technology at their fingertips.With a varietyof lens options,on-board imageandvideo
capture capability, and optional wireless transmission all built in to the camera, H-Series is the most potent
imaging package available today. And now it’s affordable enough for almost every agency.
H-SERIES
Compact Tactical Thermal Night Vision Camera
Image Intensified (I2) Thermal

SYSTEM Patrol and Command Models
Start up from stand-by <1.5 seconds
Thermal Sensitivity, Waveband <50 mK @ f/1.0, 7.5 - 13.5 µm
DetectorType 320 × 240 VOx Microbolometer
Image Processing FLIRProprietaryDigitalDetailEnhancement
Focus, Zoom Manual,2XEZoom
Video Output NTSC or PAL composite video; RCA jack
POWER
BatteryType 4AABatteries;NiMH,Li-Ion,orAlkaline
BatteryLifeOperating(Stand-By) >6 Hours on NiMH batteries, (120 hours on NiMH batteries)
ENVIRONMENTAL
Ratings IP-67, Submersible, 1 m drop
Operational Temp. -4°F–140°F(-20°C–60°C)
PHYSICAL
Weight (incl. lens) 1.45 lb (653 g) with batteries; add 0.7 lb (315 g) for 2× extender
Size (L × W × H) 10.42” × 3.33” × 2.62” (256 × 84.5 × 66.5 mm)
LENS CHOICE HS-324 HS-307
FOV 24° × 18° 7° × 5°
FOV(w/Optional2×Extender) 12° × 9° N/A
PATROL MODEL H-Series Handheld Thermal Camera (with choice of lens), Hot
Shoe Charging & Video Output Attachment, 4 Rechargeable
AA Batteries, AC Power Adapter/Charger, Car Adapter/Charger,
NeckLanyard,Manual,USBCable,VideoOutputCable
COMMAND MODEL EverythinginPatrolModel,plusTacticalCarryingPouch,imagesave
function, video save function with real-time stamp, USB2
port enabled
ADDITIONAL FEATURES IN COMMAND MODEL ONLY
Still Image Storage, Format SDCard,JPEG;320×240resolution
Video Storage, Format Approx.8seconds/MbonSDCard,320×240MPEG-4
Wireless RF Transmission
Frequency, Format, Range
2.4GHz,320×240MPEG-4,Approx33’
RANGE DETECTION HS-324 HS-307
DetectMan(1.8m×0.5m) 1,445’ (440 m)/2,890’ (880 m) 4,330’ (1,320 m)
Recognize Man 360’ (110 m)/720’ (220 m) 1,115’ (340 m)
DetectVehicle(2.3m×2.3m) 4,070’ (1240 m)/8,140’ (2480 m) 11,810’ (3,600 m)
Recognize Vehicle 1,050’ (320 m)/2,100’ (640 m) 3,180’ (970 m)
Actual range may vary depending on camera set-up, environmental conditions, user experience, and type of display used.
EquipmentdescribedhereinmayrequireUSGovernmentauthorizationforexportpurposes.DiversioncontrarytoUSlawisprohibited.
